Verilux CleanWave VH01WW4 User manual

VH01WW4
SAVE THESE INSTRUCTIONS
CleanWave®deodorizes and
eliminates up to 99.9% of
viruses (including H1N1),
bacteria (including MRSA),
allergens*, dust mite and
flea eggs from household
surfaces.†
† Kills up to 99.9% of germs, viruses and other micro-organisms
on solid, non-porous, surfaces.
* Effective on allergens such as mold & dust mite eggs.

2
Dear Customer,
Thank you for purchasing the Verilux CleanWave®Sanitizing
Wand. You have received an innovative and quality
manufactured product, backed by a one-year limited warranty.
Many other healthy lighting products are available through our
catalog and online. Visit us on the web at www.verilux.com
to request a free catalog and learn more about all our quality
Verilux products, or call our toll-free number 1-800-454-4408.
As a Verilux customer, your satisfaction means everything to us.
We look forward to serving you now and in the future.
Have a bright day!
Nicholas Harmon
President, Verilux, Inc.

3
Contents
Warnings and Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
What’s Included. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Sanitizing Wand Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Sanitizing Wand Initial Set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Charging the Wand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Sanitizing Wand Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Sanitizing Wand Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Sanitizing Wand Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4
Warnings and Precautions
• To prevent fire or shock hazard, do not expose this product to rain or
excessive moisture.
• Do not leave product unattended while on.
• No serviceable parts. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus is damaged in any way, for
example the power supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally or has been dropped.
• The CleanWave®Sanitizing Wand should not be exposed to dripping or
splashing and objects filled with liquids, such as vases, should not be
placed on or near the apparatus.
• This unit should not be handled or used by children due to the danger of
accidental direct exposure to UV-C rays.
• Always direct the UV-C rays AWAY from the eyes and skin.
• Never use this device on pets.
• Care should be taken to prevent bulb breakage.
• Allow bulb to cool before replacing.
• Not intended for use on food.
WARNING: Direct exposure of eyes or skin to this lamp can cause
serious skin burn and eye inflammation from short wave ultraviolet
radiation. Radiation from these lamps is harmful to the eyes and skin.
WARNING: Mercury Hazard. Be careful to not break the bulb during
replacement. UV-C bulbs contain a small amount of mercury, which can
cause injury if inhaled or ingested. For more information on clean-up
and disposal, see www.lampsrecycle.org.
WARNING: Leakage of battery may cause damage to the wand. If the
battery is found to be leaking do not use the device. Avoid direct skin
or eye contact with the material leaking from the battery. Dispose of
batteries per local regulations.
WARNING: Only the wand adapter provided with the device should be
used.
CAUTION: Over time, UV-C light may degrade, discolor and/or bleach
plastic and rubber.
CAUTION: With prolonged or overexposure, UV-C light may degrade,
discolor and/or bleach fabrics and colors. Do not hold device static
over any surface for more than 1 minute.

5
Warnings and Precautions — continued
FCC INFORMATION
The Sanitizing Wand complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device complies with Part 18 of the FCC Rules. This product may
cause interference to radio communications and should not be installed near
maritime safety communications equipment or other critical navigation or
communication equipment operating between 0.45 - 30 MHz.
WARNING: Changes or modifications to these units not expressly
approved by the party responsible for compliance could void the user’s
authority to operate equipment.
1. Sanitizing Wand
2. Sanitizing Wand Adapter
3. Sanitizing Wand Battery Pack
What’s Included
1.
2.
3.
Ultraviolet (UV-C) Radiation Hazard
Overexposure will cause significant eye
damage and may cause skin damage.
Do not look into UV-C light source.
SAVE THESE INSTRUCTIONS

6
Introduction
Your new Verilux®CleanWave®Sanitizing Wand eliminates up to 99.9% of
viruses (including H1N1), bacteria (including MRSA), germs, mold, dust mite
eggs and flea eggs on surfaces.
We hope you enjoy this product and use it frequently. Your results will
be cumulative – your “kill rate” may be 90% during your first use on a
surface, then “90% of the remaining 10%” on your next use.
About Light and UV-C Light
Visible light is electromagnetic radiation in wavelengths visible to the human
eye. The wavelength of visible light, in nanometers, is about 400nm to 750nm.
A nanometer is one billionth of a standard metric meter.
Ultraviolet or UV light is the part of the electromagnetic spectrum – from
about 10nm to 400nm – that contains frequencies just higher than visible light.
Above ultraviolet rays are X-rays. And above X-rays are gamma rays – the
highest – and highest energy – waves yet found.
Ultraviolet light was discovered by German physicist Johann Ritter. In 1801,
Ritter was experimenting with silver chloride, a chemical known to break
down when exposed to sunlight. He found that light at the blue end of the
spectrum increased the reaction.
Experimenting further, he discovered that the reaction was even more efficient
when exposed to radiation beyond blue – radiation that was invisible. He
called this new type of radiation ultraviolet, meaning “beyond the violet” (ultra
comes from the Latin for “beyond”).
UV light is invisible to humans, but birds and some species of insects, snakes,
turtles and fish can see ultraviolet light.
UV light can be divided into various wavelength bands with differing
characteristics.
The Sun emits ultraviolet radiation in UV-A, UV-B and UV-C bands, but
because of absorption in the ozone layer, 99% of the ultraviolet radiation that
reaches Earth is “long wave” UV-A.
UV-A, also known as “black light,” creates fluorescent effects at your local
disco and “midnight bowling” sessions as UV light (which cannot be seen) is
absorbed by materials and re-emitted in the visible range.
UV-B “medium wave” rays both help and hurt. Too much UV-B exposure
causes sunburn and can damage human tissue. Too little UV-B exposure
leads to a lack of Vitamin D absorption in animals.
The higher energy “short wave” UV-C band rays (100 to 280 nanometers)
are highly lethal to micro–organisms. This range is known as the Germicidal
Spectrum.

7
Introduction — continued
UV-C light sanitizes micro-organisms and biological pollutants, including
viruses, bacteria, germs, mold, dust mite and flea eggs by penetrating their
cell membranes and attacking and deactivating their cellular DNA, stopping
their reproductive capabilities and killing them.
The scientific community has long known that UV-C light acts as a
natural sanitization system. Hospitals, food processing facilities, scientific
laboratories, water treatment plants and air handling systems use UV-C light
to eliminate up to 99.9% of contaminants and germs.
The Verilux®CleanWave®Sanitizing Wand provides that same UV-C ultraviolet
technology for use in your home and on the road.
Benefits of Using UV-C Light
• No Chemicals. Your home may contain more deadly chemicals than
laboratories did 50 years ago. With Verilux’s CleanWave Technology, you
can sanitize surfaces effectively and safely without chemicals and chemical
residues. CleanWave eliminates up to 99.9% of viruses, bacteria, germs,
allergens* and mold with no chemical residue.
• Sanitizing with UV-C light means you don’t need harsh chemicals that
pollute our water and add unnecessary product packaging to our landfills.
Reduced production of household cleansers means fewer chemicals in our
environment and reduced fuel expenditures for transporting them to the
marketplace.
• Deodorizes upholstery, fabrics and carpets. Bedding and couches will
smell and feel fresh with consistent use of the Sanitizing Wand. Because
CleanWave eliminates biological material that causes odors, musty smells
and pet odors are virtually eliminated.
* Effective on allergens such as mold & dust mite eggs.

8
Your new Verilux®CleanWave®Sanitizing Wand eliminates up to 99.9% of
viruses, bacteria, germs and mold on surfaces throughout your home. Use
regularly on surfaces to help keep your home sanitized without the risk of
chemical contamination.
This Wand features:
• A powerful Ultraviolet (UV-C) illumination system that eliminates up to
99.9% of viruses, bacteria, germs, mold, dust mite eggs and flea eggs on
surfaces.
• This unit deodorizes and helps remove allergens*.
• Perfect for use on bedding, in closets, as well as sofas and chairs.
• Portable, hand-held design is easy to operate.
• Built-in count up timer displays the total time the Wand is used during each
session.
• Status Indicator informs the user when the Wand is charging and when it is
on.
• The 6-inch UV-C light bulb allows wide coverage and makes sanitizing
large areas quick and easy.
* Effective on allergens such as mold & dust mite eggs.
Safety Feature
An internal safety switch will automatically turn the unit off if the light source is
turned upward in order to protect eyes from exposure.
NOTE: The safety mechanism includes a switch that will make a rattling
sound — this is a normal function.
Sanitizing Wand Features

9
Sanitizing Wand Initial Set-up
The battery pack is shipped separately from the Sanitizing Wand. Before
using the Sanitizing Wand, install the battery pack and fully charge the Wand.
Installing the Battery
NOTE: Be sure the charger is unplugged before installing a new battery pack.
1. Remove the gray handle faceplate on the
underside of the Wand using a screwdriver.
2. Attach the battery cable to the battery pack.
3. Place the battery pack in the battery
compartment.
4. Replace the faceplate. Tighten the screws.
NOTE: Used batteries should be disposed of
properly and never incinerated.
NOTE: The Sanitizing Wand contains a
rechargeable 4.8V Nickel Metal Hydride (NiMH)
battery pack made only by Verilux. Do not
attempt to replace with other brands. To order
a new battery, call Verilux customer service at
1-800-786-6850.

10
Sanitizing Wand Initial Set-up — continued
Charging the Wand
It takes approximately 14 hours to fully charge the
battery for the first time.
• Connect the power adapter to the Wand.
• Plug the power adapter into a 110V grounded
electrical outlet.
• The status LED light is RED when the Wand is
charging.
• The status LED light is GREEN when the Wand is fully
charged or in use.
• After the first full charge, typical charging time is 8
hours under normal use. The Wand can be used for
11/2hours when fully charged. You will not overcharge
the battery or otherwise harm the device by keeping it
connected to the charger between uses.
Low Battery Indication
When the battery is low and requires charging, the Wand will beep 10 times
and the red LED will flash 10 times.
LED Indicator Status
• Flashing Red – the Wand needs to be recharged.
• Red – the Wand is charging.
• Green – the Wand is fully charged or the Wand is on.
Sanitizing Wand Operation
Timer
During operation, a count-up timer shows total sanitizing
time. The display increments each second to 59, then
briefly displays the minutes elapsed before starting
another 59-second count-up. The next minute reached
is then shown briefly and the count-up begins again.
This cycle repeats for 99 minutes or until the Wand
requires charging.
To see the current minute of sanitizing time, quickly
press and release the blue button.
T
i
m
e
r
P
r
e
s
s
B
u
t
t
o
n
f
o
r
M
i
n
s
To Start,
Press Until
Beep

11
12"
10 Seconds
Sanitizing Wand Operation — continued
For example, if you’ve been using the Wand for 3 minutes and 20 seconds,
the Wand will show “20.” Press the button and the display will briefly show
“03” before continuing the by-the-second count-up to minute “04.”
Step by step:
1. To turn the Wand on, press the blue button until the Wand beeps – about
two seconds.
2. Lift your finger off the button. The Wand will turn on. The fluorescent bulb
may take another second or two to light.
3. The display window will show the count-up timer.
4. Begin sanitizing by holding the Wand as close as possible and no more
than one-half inch above the surface and moving Wand slowly side to
side in a 12" (1 foot) area. The energy required to kill micro-organisms is a
product of the light’s intensity and exposure time. The closer the Wand is to
an object, the more intense the energy* (see illustration below).
*Calculation based on eliminating 99.9% of Influenza A on standardized size items.

12
Even with regular use, it is unlikely that you’ll ever need to replace the long-life
Verilux®bulb. If you do need to replace a bulb, use only Verilux bulbs. Use of
a non-Verilux bulb can result in damage to the Wand or the bulb.
To order a replacement bulb, use the Component Re-order form included
with this product. Or call Verilux Customer Service at 1-800-786-6850 or visit
www.verilux.com.
Sanitizing Wand Bulb Replacement
Sanitizing Wand Operation — continued
5. Move the Wand to next 12" (1 foot) area and continue sanitizing.
6. Repeat until you have completely sanitized your desired surface area.
7. When you have finished, press the blue button for three seconds. The
Wand will turn off.
NOTE: Be sure the Wand is facing downward, directly over your desired
sanitizing area. A safety switch will automatically turn off the UV-C light if the
Wand is tilted upward from the horizontal position (the counter will not stop
during this temporary bulb safety shut-off).
When the battery charge is low, the Wand will begin to beep and the red
indicator light will flash, indicating that the battery needs to be charged.
Using the Wand in Charging Mode
The Wand can be used in charging mode simply by connecting the power
adapter to the Wand and following the Operation Instructions.

13
Sanitizing Wand Troubleshooting
The Wand Will Not Turn On
1. Try turning on the Wand while it is connected to the AC adapter and
plugged in. If it works, the battery may not be charged or connected
properly.
2. Open battery compartment, disconnect battery clips for two seconds.
Re-connect clips; re-insert battery and cover. Try again.
No Blue Light Underneath
• Bulb may be loose from shipping.
• Bulb may be broken or otherwise need replacing.
• Be sure the Wand is facing downward directly over the surface being
sanitized. If the Wand is not operated in this manner, the internal safety
switch will prevent the Wand from operating. This feature is to help prevent
direct exposure to UV-C Light. Use caution when operating the Wand and
do not attempt to override this product feature.
WARNING: This unit should never be handled by children. Always
direct the UV-C rays AWAY from the eyes and skin.

14
Technical Specifications
Environment
Operating Temperature: 15°C to 35°C (59°F to 95°F)
Storage Temperature: 0°C to 40°C (32°F to 104°F)
Relative Humidity: 5% to 95% non-condensing
UV-C Bulb
Replacement bulb: 4 Watt UV-C bulb (replace with Verilux® brand only)
Battery
4.8V, 1500mAh NiMH battery pack
Power Supply
Input Power: 100-240 VAC, 50/60 Hz, 0.5 A
Output Power: DC 6.5V 1.5A
Class II
Conforms to IEC Class II safety requirements and the CEC Class IV efficiency
classification.
This Class II digital apparatus complies with Canadian ICES-003.

15
One Year Limited Warranty
ATTENTION! ONCE OPENED, PLEASE DO NOT RETURN THIS PRODUCT TO THE
STORE WHERE IT WAS PURCHASED FOR REPAIR OR REPLACEMENT!
Many questions may be answered by visiting www.verilux.com, or you may call our
Customer Service Department at 800-786-6850 during normal business hours.
This limited warranty is provided by: Verilux, Inc., 340 Mad River Park, Waitsfield, VT 05673
Verilux warrants this product to be free from defects in material and workmanship for a
period of one year from the date of the original retail purchase from Verilux or an authorized
Verilux distributor. Proof of purchase is required for all warranty claims. During the
limited warranty period, Verilux, Inc. will, at its option, repair or replace defective parts of
this product, at no charge to the customer, subject to the following limitations: This limited
warranty does not include any postage, freight, handling, insurance or delivery fees. This
warranty does not cover damage, defect or failure caused by or resulting from accident,
external destruction, alteration, modification, abuse, misuse or misapplication of this
product.
This warranty does not cover damage to the product resulting from return shipping or
handling. The use of shipping insurance is recommended to help protect your product.
Return Authorization is required for all returns. To obtain a Return Authorization, please
contact the Verilux Customer Service Department at 800-786-6850.
If, during the first year of ownership, this product fails to operate properly, it should be
returned as specified at www.verilux.com/warrantyreplacement or as instructed by a Verilux
customer service representative at 800-786-6850.
Note: Verilux recommends using a quality surge suppressor on all electronics equipment.
Voltage variations and spikes can damage electronic components in any system. A quality
suppressor can eliminate the vast majority of failures attributed to surges and may be
purchased at electronics stores.
Due to ongoing improvements, actual product may have slight variations from the product described in this manual.
Please visit our web site at: www.verilux.com or call
1-800-786-6850
Representatives are available Monday — Friday, 9am — 5pm EST
340 Mad River Park, Waitsfield, VT 05673

VH01-MAN-Rev14
Made in China
Printed in China for Verilux, Inc.
© Copyright 2010 Verilux, Inc. All rights reserved.
