Verilux CleanWave User manual

VH07

2
Dear Customer,
Thank you for purchasing the Verilux CleanWave®UV-C Sanitizing
Furniture & Bed Vac.You have received an innovative and quality
manufactured product, backed by a one-year limited warranty.
Many other healthy lighting products are available through our catalog
and online. Visit us on the web at www.Verilux.com to request a free
catalog and learn more about all our quality Verilux products, or call our
toll-free number 1-800-786-6850.
As a Verilux customer, your satisfaction means everything to us. We
look forward to serving you now and in the future.
Have a bright day!
Nicholas Harmon
President, Verilux, Inc.

3
Table of Contents
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FCC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
What’s Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CleanWave®UV-C Sanitizing Furniture & Bed Vac Features . . . . . . . . . . . . . . . . 7
Description of Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Initial Set-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Vacuuming with UV-C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Using the Hand Vacuum Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Mattress / Bedding Cleaning Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning the UV-C Bulb. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Replacing the UV-C Bulb. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Safety Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4
Important Safety Instructions
READ ALL INSTRUCTIONS BEFORE USING YOUR CLEANWAVE®UV-C SANITIZING
FURNITURE & BED VAC
When using an electrical appliance, the following basic safety precautions should always be
observed.
WARNING: To reduce the risk of fire, electric shock or injury:
• Do not leave appliance when plugged in. Unplug from outlet when not in use and before
servicing.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close attention is needed when used by or near
children.
• Use only as described in this manual. Use only with manufacturer’s recommended
attachments.
• Do not use with damaged cord or plug. Do not use vacuum if it has been dropped,
damaged, left outdoors or dropped in water.
• Do not pull or carry cord, use cord as a handle, close a door on cord or pull cord around
sharp edges or corners.
• Do not run vacuum over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any openings blocked; keep free of
dust, lint, hair and anything that may reduce air flow.
• Keep hair, loose clothing, fingers and all body parts away from openings and moving
parts.
• Do not vacuum anything that is burning or smoking, such as cigarettes, matches or hot
ashes.
• Turn off vacuum before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to vacuum flammable or combustible liquids such as gasoline or use in areas
where they may be present.
• Follow all labels and instructions.
• Keep all openings away from your face and body.
• Do not use the vacuum cleaner without dust filter in place.
• Store the vacuum cleaner indoors. Put the vacuum cleaner away after use to prevent
tripping accidentally.
• Using improper voltage may result in damage to the motor and possible injury to the user.
The correct voltage is listed on the rating-label.
• Use on dry, indoor surfaces.
• Do not use for any purpose other than described in this manual.
• This appliance is provided with double insulation. Use only with identical replacement
parts.
• With the exception of the replacement of the UV-C bulb, this appliance contains no user
serviceable parts.
• All repairs must be carried out by a qualified service technician.
• There are a number of safety switches on the underside of the unit. These switches prevent

5
Important Safety Instructions continued
FCC Compliance
the UV-C bulb from activating when the product is removed from the cleaning surface. The
UV-C bulb will re-activate when placed back on a cleaning surface.
• For your safety, DO NOT attempt to manually over-ride the safety switch.
• DO NOT point the vacuum cleaner directly at your or anyone’s face.
• Do not touch the UV-C bulb during or directly after use; it will be hot and may burn.
• UV-C bulbs contain mercury, which is considered a hazardous waste and is subjected to
Federal and/or State hazardous waste regulations.
• Do not leave product unattended while on.
• No serviceable parts. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus is damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally or has been
dropped.
• Never use this device on pets.
• Always direct the UV-C rays AWAY from the eyes and skin.
• Allow bulb to cool before replacing.
• Care should be taken to prevent bulb breakage.
• No one individual should use this product more than one hour per day without ear
protection.
• Always turn off this appliance before connecting or disconnecting the base.
WARNING: This product contains a chemical known to the state of California to cause birth
defects or other reproductive harm.
CAUTION: UV-C light may degrade plastic and rubber over time.
WARNING: These bulbs can cause serious skin burn and eye inflammation from short wave
ultraviolet radiation. Radiation from these bulbs is harmful to the eyes and skin.
WARNING: Mercury Hazard. Be careful to not break the bulb during replacement. UV-C
bulbs contain a small amount of mercury, which can cause injury if inhaled or ingested.
Ultraviolet (UV-C) Radiation Hazard
Over exposure will cause significant eye
damage and may cause skin damage.
Do not look into UV-C light source.
This device complies with Part 18 of the FCC Rules. This product may cause interference
to radio communications and should not be installed near maritime safety communications
equipment or other critical navigation or communication equipment operating between 0.45-
30 MHz.
This device complies with the appliance efficiency regulations laid down by the California
Energy Commission.
SAVE THESE INSTRUCTIONS

6
Introduction
What’s Included
Your new Verilux®CleanWave®UV-C Sanitizing Furniture & Bed Vac is both a
convenient and powerful hand-held vacuum and an easy-to-use bed vacuum. The
hand-held design makes it a fast and effective anytime, anywhere vacuum.
As a bed vacuum, the combination of powerful suction and UV-C light quickly
removes dust and dirt while eliminating up to 99.9% of viruses, bacteria, dust mite
eggs and dust mite waste – a common cause of colds, allergic* reactions
and asthma.
*Allergens due to mold and dust mites
• Instruction manual
• Handheld vacuum cleaner with dirt container and dual filters
• Base unit with UV-C bulb
• Nozzle attachment
• Brush attachment

7
Your new Verilux®CleanWave UV-C Sanitizing Furniture & Bed Vac features:
• A powerful ultraviolet (UV-C) illumination system that eliminates up to 99.9%
of viruses (including the H1N1 “swine flu” virus), bacteria, fungus and mold
spores.
• Vacuum cleaner removes dead skin cells, fleas and flea eggs, dust mites, dust
mite feces and other allergens*.
• Handheld convenience – use as a UV-C vacuum/sanitizing unit or as a
handheld vacuum cleaner.
• Easy to empty dirt container. No messy bags.
• Dual filters: Micro-fiber filter captures large particles; HEPA filter traps pollen
and microscopic allergens* as small as 0.3 microns with 99.97% efficiency.
Only clean air is expelled back into the room.
• Removes odors and dangerous allergens* including those that can cause
pneumonia, asthma and other conditions.
*Allergens due to mold and dust mites
CleanWave®UV-C Sanitizing Furniture & Bed Vac Features
Description of Functions
ON/OFF Switch
Vacuum Cleaner
Lock
Vacuum Base Unit
UV-C
Confirmation
Windows
Bulb Protection Cover & UV-C Bulb
Under Unit
Handheld Vacuum
Cleaner

8
Initial Set-up
Vacuuming with UV-C
1. Attach the vacuum cleaner to
the base unit. Insert it into the
base unit and then press the
rear down firmly. Press lever
down when docking vacuum.
Then pull up until lever clicks
to lock. (See Figure 1)
2. Turn on the cleaner using the
on/off switch.
The UV-C bulb will turn on when
the UV-C safety switch is in
contact with the surface to be
cleaned. You can confirm that the
UV-C light is on by checking the
confirmation windows on the top of the unit.
Avoid vacuuming fine dust, such as cement and plaster, as this will block the
filters. If fine dust is picked up, the filters, dust container and tools must be
thoroughly cleaned immediately after use.
CAUTION: Direct exposure to UV-C light can cause serious skin burn and eye
inflammation from short wave ultraviolet radiation. Radiation from this bulb is
harmful to the eyes and skin.
CAUTION: Do not override the safety switches manually.
CAUTION: Do not attempt to pick up large or sharp objects as these may cause
damage to the vacuum cleaner.
Using the Hand Vacuum Only
1. Turn the cleaner off using the on/
off switch.
2. To remove the cleaner from the
base, press the lever at the rear of
the vacuum base. (See Figure 1)
3. Lift the hand vacuum from the
base.
Certain tasks may require the use
of the nozzle or brush attachments.
These tools are stored in the base
unit. (See Figure 2)
Figure 1
Figure 2

9
Mattress / Bedding Cleaning Guidelines
In order for the UV-C light to be fully effective against bacteria and other
pathogens, the area to be cleaned must be exposed for a sufficient time.
We suggest the following guidelines:
• Start in one corner of the bed.
• Keep the vacuum flat against the mattress.
• Move the vacuum in a smooth and steady motion.
• To make sure that every part of the mattress is exposed, follow a
predetermined pattern.
• With double (or larger) beds, clean one side of the bed at a time.
• If possible, clean both sides of the mattress.
• With a used mattress, clean on a daily basis for seven days, then as much as
once a week, at the least once a month. With a new mattress, once a month
cleaning is usually sufficient.
• If cleaning carpets using the UV-C head, follow a similar method.

10
Cleaning the Inlet
If the inlet is blocked by dust, completely remove the foreign materials – after first
turning the vacuum OFF.
A blocked inlet may result in weakened suction and noise. If the inlet is blocked,
there is also a risk of damage or malfunction caused by overheating.
Care and Maintenance
Figure 3
Figure 4
Emptying Dust Container and
Cleaning Filters
1. Disconnect the cleaner from the base
section by pressing the release lever
at the rear of the cleaner and lifting
up.
2. Press the dust container lock button
to release the dust container from the
vacuum. (See Figure 3)
3. Carefully pull the filter assembly
outward and remove.
4. Empty the container. (See Figure 4)
5. Unlock the outer filter by twisting it
slightly to the right (clockwise).
6. Remove the outer filter by pulling it
away from the main casing.
7. Pull the inner filter out to remove.
8. The filters should be cleaned every
time the dust container is emptied by
tapping them on the side of the bin to
release trapped dust.
9. Wash both filters in lukewarm water
on a regular basis.
10. Make sure the filters are completely
dry before reassembly.
11. Reassemble in the reverse order.

11
Care and Maintenance continued
Avoiding Exposure to Dust
When emptying any vacuum cleaner, it is difficult to avoid exposure to dust. If you
are an allergy sufferer or sensitive to dust, you can minimize this risk.
1. Place the dust container in a large bag, and close the bag as tightly as
possible around the container before emptying it.
2. Remove the container, close the bag tightly and dispose of immediately.
You might also consider wearing disposable gloves and a facemask while
emptying the dust container. Or ask a non-allergy sufferer to empty the container,
when required.
It is important to empty the dust container and clean the filters regularly. If this is
not done, the cleaner will lose its effectiveness.
We recommend that you empty and clean the vacuum after each use.
Cleaning the UV-C Bulb
During use, dust may collect on the protective cover and the UV-C bulb, which will
reduce the effectiveness of the UV-C light. For maximum UV-C exposure, clean the
bulb periodically.
1. Detach the protective grill on the bottom of the base unit by gently pulling up
on the two tabs at the back of the covering. Set the cover aside. (See figure 5)
2. Using a soft lint-free cloth, carefully remove any dust from the protective cover
and the UV-C bulb.
3. Replace the protective cover by aligning it, pressing on the rear tabs to snap
them into position and finally pressing down the front of the cover, which will
click into place.
Figure 5

12
Replacing the UV-C Bulb
Before replacing the bulb, make sure the vacuum cleaner is switched off and
unplugged from the power outlet.
The life span of the UV-C bulb, under normal use, is 2 to 3 years.
Caution: Use only Verilux®bulbs. Use of an incorrect bulb can result in damage.
To order a replacement bulb, use the Component Re-order form included with this
product, or call Verilux Customer Service at 1-800-786-6850 or visit www.Verilux.com.
1. Detach the protective grill on the
bottom of the base unit by pulling
up the two tabs at the back of the
covering. Set the cover aside. (See
Figure 5)
2. Remove the two plastic pieces that
cover the ends of the UV-C bulb.
3. Unscrew the screws surrounding
the protective housing.
4. Using a small pair of pliers at one
end of the bulb, rotate the bulb 90
degrees and remove. (See Figure 6)
Note: UV-C bulb is housed in a glass sleeve
to protect it from accidental damage.
Remove old bulb from this sleeve before
disposal.
5. Insert the new bulb into protective
sleeve and place back into unit. Rotate
bulb by 90 degrees to secure.
6. Relocate the protective housing and
tighten all screws.
7. Relocate the protective grill and snap
back into place.
Figure 6
Figure 5

13
Troubleshooting
Poor Suction
The filter may be blocked.
• Remove and clean the filter.
The dust container may be full.
• Empty dust container.
UV-C Light is not Illuminated
Vacuum cleaner may not be fitted to base unit correctly.
• Ensure the cleaner is securely locked into position.
Safety switch may not be depressed or sensors not covered.
• Sensor switches only operate when the base is level and in contact with the
surface being cleaned.
Safety Switches
The UV-C light will only turn on when the vacuum cleaner is facing downward and
in contact with the surface being cleaned.
On the bottom of the base unit, there is pressure sensitive wheel. The wheel is
activated when it contacts a cleaning surface.
Three additional sensors must also be covered for the UV-C bulb to work.
Do not manually override the pressure sensitive wheel or cover the sensors.

14
Technical Specifications
Environment
Operating Temperature: 10°C (50°F) to 40°C (104°F)
Storage Temperature: 0°C (32°F) to 60°C (140°F)
Relative Humidity: 10% to 90% non-condensing
UV-C Bulb
8 Watt UV-C bulb (replace with Verilux Model Number VH07RB1 only)
UV-C Peak Wavelength
254 nanometers
Power
Input Power: AC 120V, 60Hz 400 Watts
Weight
4.98 pounds
Warning: This product contains a chemical known to the state of California to
cause birth defects or other reproductive harm.
This device complies with the appliance efficiency regulations laid down by the
California Energy Commission.

VH07-MAN-Rev8
Please visit our web site at: www.Verilux.com
340 Mad River Park, Waitsfield, VT 05673
Printed in China for Verilux, Inc.
© Copyright 2009 Verilux, Inc. All rights reserved.
