Verint Nextiva S1100 User manual

S1100 User Manual

S1100
Firmware Release 3.30
User Manual
Verint Video Solutions

© 2004 Verint Systems Inc. All rights reserved.
By providing this document, Verint Systems Inc. is not
making any representations regarding the correctness or
completeness of its contents and reserves the right to alter
this document at any time without notice.
Verint, Actionable Intelligence, BehaviorTrack, Dellis,
HealthCheck, Lanex, Loronix, Loronix Video Manager,
MotionTrack, microDVR, nDVR, netDVR, Powering Actionable
Intelligence, SmartSight, and Video Manager are trademarks
of Verint Systems Inc., its subsidiaries or affiliates. All other
registered trademarks, trademarks, and any associated logos
are the properties of their respective owners.
Published by:
Verint Video Solutions
1800 Berlier Street
Laval (Quebec)
Canada
H7L 4S4
www.verint.com/smartsight
Publication date: February 10, 2005

Verint Video Solutions iii
Warning: If you connect multiple S1100 units on the same
24V AC power source, always wire them the same
way: The red power wires (VIN) of all units must be
on the same terminal or lead of the AC power source.
This is because the black power wire (VIN_RETURN)
of the S1100 is internally connected to the S1100
chassis (earth). Swapping the power connection
scheme from unit to unit will short out the AC power
source.
Warning: If you connect third-party equipment with an
earth-referenced power input, it is important to plug
the earth-referenced terminal of that device to the
same AC power source terminal as the S1100 black
wire. Failing to do so will short out the AC power
source.
Red Black Black Red
St a t
us
T
M
St a t
us
T
M
St a t
us
T
M
Red
Black
Third-party
equipment
Isolated 24V AC
AC main

iv Verint Video Solutions

Verint Video Solutions v
Contents
Preface ........................................................................ ix
Who Should Read this Manual ......................................x
How to Use this Manual ...............................................x
Contents ..............................................................x
Conventions ........................................................xi
Related Documentation ........................................ xii
Related Verint Video Solutions Products ................. xii
About Us ................................................................. xii
Warranty ................................................................ xiv
Chapter 1 Overview ................................................... 1
About the S1100 ....................................................... 2
Security .............................................................. 2
Video ................................................................. 2
Shipment ................................................................. 3
Casing Description ..................................................... 4
Chapter 2 System and RF Planning ............................ 5
Frequency Bands and Channels ................................... 6
2.4 GHz Band ...................................................... 6
5 GHz Band ......................................................... 6
Wireless Cells ........................................................... 7
TPC ......................................................................... 9
DFS ......................................................................... 9
Colocated Systems ...................................................11
Distance Limitations ............................................12
2.4 GHz Band .....................................................12
5 GHz Band in North America ...............................14
5 GHz Band in Europe ..........................................15
RF Planning .............................................................17
Location Evaluation .............................................18
Antenna Requirements ........................................20
Interference .......................................................21
RF Exposure Considerations .................................21
Chapter 3 Configuring and Installing the Unit .......... 23
Cable for Power, Video, and Serial Data .......................24
Computer Requirements ............................................25
Configuring a Point-to-Point System ............................25

Contents
vi Verint Video Solutions
Configuring a Point-to-Point Repeater ..........................27
Installing the Equipment ...........................................28
Installing the S1100 Units ....................................29
Performing the RS-422/485 Serial Connection ........31
Adding an Antenna ..............................................33
Configuring the I/Os .................................................34
Audio ................................................................34
Alarms ..............................................................36
Performing a Hardware Reset .....................................37
Status LED ..............................................................37
Chapter 4 Using the Configuration Assistant ............ 39
Getting Started ........................................................40
Performing a Basic Configuration ................................42
Performing an Advanced Configuration ........................43
General .............................................................44
Wireless ............................................................44
Video ................................................................46
Audio ................................................................47
Serial Port ..........................................................47
Checking the Connection Statuses ..............................48
Wireless ............................................................48
Video ................................................................49
Audio ................................................................49
Serial Port ..........................................................50
Repeater Consideration .............................................50
Accessing the CLI of the Unit .....................................54
Chapter 5 Understanding the On-Screen Display ...... 57
Quadrant 2: SmartSight Logo ....................................58
Quadrant 3: Receiver Settings ...................................59
Quadrant 4: Transmitter Settings ...............................59
Chapter 6 Updating the Firmware ............................ 61
Appendix A Factory Default Configuration ................ 65
Appendix B Cable Descriptions.................................. 67
CAB9P ....................................................................68
CAB8P ....................................................................70
Appendix C DTE and DCE Connections....................... 71
Appendix D Surge Protection .................................... 75
Appendix E RF Contact between Masters .................. 77
Appendix F Separation Between Units Using Adjacent
Channels ................................................ 81

S1100 User Manual
Verint Video Solutions vii
Appendix G Technical Specifications ......................... 87
Glossary ..................................................................... 91
Index .......................................................................... 97
Compliance ............................................................... 103

viii Verint Video Solutions

Verint Video Solutions ix
Preface
The S1100 User Manual presents the information and
procedures for installing, configuring, and using the
SmartSight®S1100 wireless video systems.

Preface
x Verint Video Solutions
Who Should Read this
Manual
This manual is intended for managers, engineers, and
technicians who will use the S1100 units. It provides conceptual
information on how to configure, install, and operate the units.
This manual assumes that you are familiar with:
Installation and manipulation of electronic equipment
General use of computers
Microsoft Windows operating systems
Pan-tilt-zoom (PTZ) platforms (cameras and keyboards)
Radio frequency (RF) regulations
How to Use this Manual
The S1100 User Manual contains all the information needed to
install, configure, and use an S1100 unit.
Contents
This manual is divided into the following chapters:
1. Overview—Provides a brief description of the features of
the S1100 unit and an illustration of its casing.
2. System and RF Planning—Lists the available frequency
bands and describes planning operations relative to system
setup and radio frequency (RF).
3. Configuring and Installing the Unit—Presents the
configuration and installation procedures for the S1100
unit.
4. Using the Configuration Assistant—Explains how to
program the S1100 unit using the SmartSight Configuration
Assistant.
5. Understanding the On-Screen Display—Presents the
four quadrants on the video monitor connected to the
S1100 receiver unit.

S1100 User Manual
Verint Video Solutions xi
6. Updating the Firmware—Describes how to upgrade the
firmware of the S1100 unit.
The manual also includes the following appendixes:
A. Factory Default Configuration—Lists the default
parameter values of the S1100 unit.
B. Cable Descriptions—Describes the 8-pin and 9-pin
cables supplied with the unit.
C. DTE and DCE Connections—Presents diagrams
explaining how to differentiate and connect data
terminal equipment (DTE) and data communication
equipment (DCE).
D. Surge Protection—Describes how to protect the S1100
unit from voltage and current surges.
E. RF Contact between Masters—Explains how to ensure
that two master units “see” each other.
F. Separation Between Units Using Adjacent
Channels—Lists the minimum distances between units
using adjacent frequency channels.
G. Technical Specifications—Lists the complete technical
specifications of the S1100 units.
A glossary, an index, and compliance information complete the
manual.
Conventions
The following typographic conventions are used throughout this
manual:
Visual cue Meaning
Connect The name of an interface element you have to act
on. A key to press. The value of an interface
element.
Advanced > VSIP Any sequence of steps (in the menu structure of
a graphical application, in the navigation
structure of a web site, and so on).
connection_name Text that must be replaced by a user-supplied
value. Text representing variable content.
S1100.xh The name of a command, file, or directory. Text
that appears on the screen. Examples of
user-supplied values.

Preface
xii Verint Video Solutions
Related Documentation
In addition to this manual, the following documentation is also
available:
S1100 Installation Guide—Contains the configuration
steps and the installation procedure for the S1100 unit.
SConfigurator User Manual—Presents the instructions on
how to use a proprietary Verint Video Solutions software to
perform advanced configuration tasks.
Release Notes—Contain information about S1100 upgrades
and known issues still under investigation, as well as a
description of features not covered in this version of the
documentation.
All these documents are contained on the SmartSight Utilities
CD shipped with the unit. Furthermore, a paper copy of the
installation guide is included with your order.
Related Verint Video Solutions
Products
You can use the S1100 units with the S3100 outdoor wireless
bridge. For more details about this product, visit our web site.
For pricing information, call your dealer.
About Us
Verint Systems (NASDAQ: VRNT) is a leading global provider of
video security, surveillance and business intelligence solutions.
Verint Video Solutions transform digital video into actionable
intelligence: timely, mission-critical insights for faster, more
effective decisions.
Today, more than 1000 companies in 50 countries use Verint
Systems solutions to enhance security, boost operational
efficiency, and fuel profitability.

S1100 User Manual
Verint Video Solutions xiii
Web Site
For information about the SmartSight line of products, visit
www.verint.com/smartsight. To download the product
specifications, application notes, and user documentation, as
well as to request the latest versions of firmware and software,
use the following links:
Support
If you encounter any type of problem after reading this manual,
contact your local distributor or Verint Video Solutions
representative. You can also use the following sections on our
web site to find the answers to your questions:
Verint Video Solutions technical support personnel is available
to help you use your SmartSight units and the related software:
On the web: www.verint.com/smartsight/request
By phone: [phone] (North America) or
[phone] Monday to Friday, from 8:30 to
17:30 EST
By fax: [phone]
To access Visit
Complete selection of what is
available:
www.verint.com/smartsight/support
User documentation: www.verint.com/smartsight/manuals
Various tools and demos: www.verint.com/smartsight/tools
Firmware upgrade requests: www.verint.com/smartsight/firmware_
upgrade
To access Visit
Technical support request form: www.verint.com/smartsight/request
Solution database (FAQ): www.verint.com/smartsight/faq
Login to our customer service
system:
www.verint.com/smartsight/account

Preface
xiv Verint Video Solutions
Warranty
Each product manufactured by Verint Systems is warranted to
meet all published specifications and to be free from defects in
material and workmanship for a period of two (2) years from
date of delivery as evidenced by the Verint Systems packing
slip or other transportation receipt. Products showing damage
by misuse or abnormal conditions of operation, or which have
been modified by Buyer or repaired or altered outside Verint
Systems factory without a specific authorization from Verint
Systems shall be excluded from this warranty. Verint Systems
shall in no event be responsible for incidental or consequential
damages including without limitation, personal injury or
property damage.
The warranty becomes void if the product is altered in any way.
Verint Systems responsibility under this warranty shall be to
repair or replace, at its option, defective work or returned parts
with transportation charges to Verint Systems factory paid by
Buyer and return paid by Verint Systems. If Verint Systems
determines that the Product is not defective within the terms of
the warranty, Buyer shall pay all handling and transportation
costs. Verint Systems may, at its option, elect to correct any
warranty defects by sending its supervisory or technical
representative, at its expense, to customer’s plant or location.
Since Verint Systems has no control over conditions of use, no
warranty is made or implied as to suitability for customer’s
intended use. There are no warranties, expressed or implied,
except as stated herein. This limitation on warranties shall not
be modified by verbal representations.
Equipment shipped ex works Verint Systems factory shall
become the property of Buyer, upon transfer to the common
carrier. Buyer shall communicate directly with the carrier by
immediately requesting carrier’s inspection upon evidence of
damage in shipment.
Buyer must obtain a return materials authorization (RMA)
number and shipping instructions from Verint Systems prior to
returning any product under warranty. Do not return any Verint
Systems product to the factory until RMA and shipping
instructions are received.

Verint Video Solutions 1
Overview
The S1100 is a professional video transmission product
designed for the CCTV (closed circuit television) market. It
allows digital video transmission over multiple license-free
bands. It delivers high-quality MPEG-4-based video at
30 frames per second in NTSC (25 in PAL). This wireless system
is built on open standards to provide long-term investment
protection.
Note: The S1100 units require professional installation.

1: Overview
2 Verint Video Solutions
About the S1100
Each S1100 system consists of a video transmitter (-T) and a
video receiver (-R) unit. Unless otherwise specified, the word
S1100 refers to any of these units.
Each unit is configured to operate, right out of the box, with the
most popular camera data port configuration (4800 baud,
8 data bits, no parity, 1 stop bit).
The S1100 covers the 2.4 GHz and 5 GHz frequency bands in
North America and Europe.
You can buy 12V DC and 24V AC units. A unit pair does not
need to have the same input voltage.
Security
Every S1100 unit includes the SDCF (SmartSight distributed
coordinated function) security feature. This proprietary MAC
(media access control) protocol uses AES encryption with key
rotation over the wireless link to secure the audio and video
communication between the units.
Video
The S1100-R unit has one video output. The S1100-T has one
video input with two encoders; by default, only one encoder is
available.
The video frame rate of the units can be:
NTSC—1 to 7, 10, 15, or 30 frames per second (fps)
PAL—1 to 6, 8, 12, or 25 fps

S1100 User Manual
Verint Video Solutions 3
The S1100 units can have the following video resolutions and
maximum frame rates (in frames per second):
* Without noise, I/Os, and other factors affecting quality, the
unit can achieve the highest frame rate.
Shipment
Your S1100 shipment contains the following items:
The requested transmitter and receiver, each coming with
an integrated patch antenna (with a gain of 8.5 dBi in the
2.4 GHz band or 13 dBi in the 5 GHz band)
Two wall mount bracket sets, already installed on the units
Two pole mount bracket sets
Two cable assemblies for video, power, and serial port
(CAB9P)
The SmartSight Utilities CD containing the documentation
and release notes for the unit
The S1100 Installation Guide
This user manual
Resolution Number of
columns
Number of lines Maximum frame
rate
NTSC/PAL NTSC PAL NTSC PAL
QCIF 176 128 144 30 25
CIF 352 240 288 30 25
2CIF 352 384 448 30 25
2CIFH 704 240 288 30 25
4CIF 704 480 576 15 12
All lines 352 480 576 30 25
2/3 D1 480 480 576 15/30 * 12/25 *
VGA 640 480 576 15/30 * 12/25 *

1: Overview
4 Verint Video Solutions
The shipment may also contain the following options:
One or two high-gain antennas
Warning: When choosing antennas, you must ensure that
the combined transmission power of the unit and
antenna does not exceed the maximum power
established by your country’s regulations. For
more information, see page 20.
One or two junction boxes (JBOX)
One or two alarm/audio cable assemblies (CAB8P)
One or two power supplies
Note: If you are using power supplies other than those
supplied by Verint Video Solutions, you need to
ensure that they have a minimum capacity of 1A
(12V DC) or 30 VA (24V AC).
Casing Description
The S1100 electronics are enclosed in a weather-tight cast
aluminum module. All cable entries are mounted on the
underside of the module to maintain its weatherproof
properties. The front panel integrates one bicolor visual
indicator that illustrates the unit’s operational state.
Status
Main connector (video, power, serial
port)
Auxiliary connector (alarm, audio)
Status indicator
Integrated antenna
Antenna port
