Nextiva S2600e Series Installation Guide
www.verint.com/videosolutions October 18, 2006
Covering the S2600e, S2600e-AS, S2610e, and S2610e-AS.
Casing
Front:
Back:
Installation
Note: The S2600e-AS and S2610e-AS may heat more than a device
without analytics capabilities (S2600e and S2610e).
1. Remove the cap in front of the camera.
2. Check that the locking screw is fastened.
3. For a C-mount lens, install a C-to-CS adaptor (not supplied by Verint
Video Intelligence Solutions) on the front of the camera.
4. Screw the lens on the back focus ring in the front of the camera. The
lens and the back focus ring should turn as one unit when the locking
screw is loosened.
5. If you are using an auto iris lens, insert the auto iris plug into the
adaptor on the back of the camera.
6. Connect the camera to the network and power it.
7. View video, then adjust the focus on the lens. To view video, either
plug an analog monitor into the video output connector on the back of
the camera, or use a laptop computer to access the web interface.
8. If you were able to do the focus with the adjustment on the lens, go to
step 14. Otherwise, execute step 9 to step 13.
9. For an auto-iris lens, reduce the ambient lighting until the lens is
opened to its maximum.
10. For a manual iris lens, open it to its maximum. If the monitor is too
bright, reduce the ambient lighting.
11. If the location does not allow the reduction of ambient light, hold a
neutral density filter against the front of the lens.
12. If the camera has a fixed focal length lens:
a. Set the physical focus of the lens to the middle of its range.
b. Aim the camera at an object in the area of interest.
c. Unfasten the locking screw.
d. Adjust the back focus to get the best possible picture.
e. Fasten the locking screw.
f. Fine tune the focus with the adjustment of the lens.
13. If the camera has a zoom lens:
a. Set the lens to full telephoto view.
b. Set the physical focus of the lens to infinity.
c. Aim the camera at an object in the area of interest.
d. Unfasten the locking screw.
e. Adjust the back focus to get the best possible picture.
Locking screw
Back focus ring
RJ-45 Ethernet
S
ystemstatus
Reset
Video output
Input/output and 12V DC
Auto iris lens adaptor
SD card slot (on the S2600e-AS and S2610e-AS)

Nextiva S2600e Series Installation Guide
For more information, refer to the Nextiva S2600e Series User Guide, which is available on the Utilities CD included in this package.
© 2006 Verint Systems Inc. All rights reserved.
www.verint.com/videosolutions M222-2003-001
f. Set the lens to full wide angle, then focus again at the object. If
necessary, re-adjust the back focus to get optimum clarity.
g. Fasten the locking screw.
You should be able to adjust the focus on the object, no matter the
zoom adjustment.
14. If the camera is installed upside down, ensure that the Video Rotation
parameter is set to Automatic or On in the web interface.
Configuration
c
1. Power the camera and establish its Ethernet connection.
2. Start SConfigurator.
The SConfigurator window appears.
3. In the General tab, click Program Options.
The Program Options window appears.
4. Check Detect All Units on LAN.
5. Ensure that the VSIP Port is 5510; otherwise, click Default.
6. Ensure that the Discovery IP Address is 255.255.255.255;
otherwise, click Reset to Broadcast.
7. Click OK.
8. Select the Units tab, then click Discover.
A device of type “Unknown” with a 169.254.X.YIP address appears in
the list; it corresponds to your new device.
9. Select the unknown device, then click Configure. In the Reconfigure
unit? confirmation window, click Yes.
The New Network Configuration window appears.
10. To use DHCP, check Use DHCP. Otherwise, enter the IP address,
subnet mask, and gateway of the device, as provided by your network
administrator.
11. Click OK.
The device reboots with its new network configuration; it may take up
to 20 seconds. You can perform further configuration with the Verint
Video Intelligence Solutions SConfigurator or Nextiva™ software.
