Verint RP 400 Series Service manual

Mounting and Operating Instructions of
RP406K and RP406K-IC
for mobile video surveillance
12 / 2005

Foreword
Dear customer,
By selecting a product from Verint Video Solutions GmbH you have purchased a professional device that
ensures highest quality and reliability. Thank you for your confidence in our product. We would like to ask you
to read through the following information carefully before you begin operating the device. This way you can
completely enjoy all the benefits this product provides.
In presenting this document, Verint Systems does not make any guarantee regarding the correctness or
completeness of its contents, and reserves the right to alter this document at any time without notice.
This document may not be duplicated, photocopied, reproduced, translated, transferred to an electronic
medium or converted into machine-readable form without the previous written approval of Verint Video
Solutions GmbH.
© 2005 Verint Systems Inc.
2

Contents
General Information.....................................................................................................................................4
Product overview......................................................................................................................................................... 4
Security information ................................................................................................................................................... 4
EPlace of installation.................................................................................................................................................. 5
Scope of delivery ......................................................................................................................................................... 5
Accessories / additional devices............................................................................................................................. 5
Warranty ......................................................................................................................................................................... 5
Installation .....................................................................................................................................................6
System overview.......................................................................................................................................................... 6
Detailed view................................................................................................................................................................ 6
Monunting ..................................................................................................................................................................... 7
Connecting diagram ................................................................................................................................................... 8
Appendix ......................................................................................................................................................10
Technical Specifications ..........................................................................................................................................10
Claening and maintenance / Servicing information ......................................................................................11
Error search .................................................................................................................................................................11
Technical support......................................................................................................................................................12
Notice............................................................................................................................................................13
Version Date
Ver 1.0 08.12.2005
3

General Information
Product overview
The Verint® RP 400 Series mini dome camera housings provide a reliable solution for mobile vehicles such as
buses, trams or trains.
The RP 400 Series has a vandal-resistant mini dome housing that can be either wall or ceiling mounted. The RP
400 Series provides high-resolution pictures for day or night operation, and is available in a color or black and
white model.
The lightly smaller housing has rounded edges to minimize the risk of injury to passengers. The cameras are
designed to operate in very bright but also in dark places and under extreme weather conditions. The RP 400
Series meets common mobile transportation standards for Europe.
When combined with our wide range of recorders and monitors, the RP 400 Series provides a comprehensive
networked digital video surveillance solution to help transit personnel protect people and property, refute false
claims, and reduce frivolous lawsuits.
Safety information
•Read these instructions carefully before operating the device. This will help prevent possible damages
from improper use.
•The device should only be installed by qualified professionals according to existing VDE (Association
for Electrical, Electronic & Information Technologies) regulations.
•Operate the cameras exclusively using the normal service voltage indicated.
•Observe any warnings on the device.
•The camera should only be used in a dry, dust-free and non-hazardous environment.
•Never use the device for purposes others than those for which it was intended.
•The device should be repaired only by qualified professionals.
•Should liquids or hard objects enter the housing, disconnect the power supply immediately. Have the
device checked by a qualified professional before you use it again (risk of electric shock).
•Operate the device only indoors.
•To avoid internal heat build-up in the device:
- the device should not be subjected to direct sunlight
- should have adequate distance from direct heat sources
•For cleaning and maintaining the camera, follow the directions given in these instructions.
4

General Information
Place of installation
The camera is specially designed for video surveillance in busses and trains and fulfils the required European
standards for public transport.
Scope of delivery
•High resolution vandalism-proof dome camera with fixed lens
•connection cable
•Mounting materials
•Mounting instructions
Accessories / Additional Equipment
•Video cable 75 Ohm (e.g. RG-59)
•BNC connector
Warranty
The warranty is valid for 24 months and begins on the date of delivery. Any defects must be reported within 10
working days following delivery of the product. Hidden defects must be reported immediately when they are
discovered.
The warranty does not include damages to the products caused by accidents, unsuitable or improper usage,
non-authorized or incorrect mounting or startup, incorrect or improper handling, damages during transport or
improper maintenance. The warranty does not include costs you incur from installation or initial operation as
part of a warranty claim.
In response to a warranty claim we can choose to provide a replacement or repairs within an appropriate
period of time. If the defect is not successfully remedied we have the option of rescission or reduction, in case
of a negligible defect of reduction only.
5

Installation
System overview
12 V DC (recorder connection)
Video signal (recorder connection)
The RP 406K (-IC) dome camera needs a stabilized power supply of 12 V DC and has a power consumption of
max. 2.0 W.
Cable connections
It is possible to lay separate cables for all connections.
Video = coaxial cable 75 Ω, (F)BAS, 1 Vss/75 Ω
Power supply = Operating Voltage: 12 V DC / GND
Detailed view
All specifications in mm!
6

Installation
Mounting
Information on camera mounting location
•Keep an adequate distance to direct heat sources.
•Do not point the camera towards artificial lighting, the sun, the sky or in the direction of a window. The
best image quality will be achieved if both camera and lighting point to the area you want to record.
•Reduce the picture section to the essential area and install the camera as close to the object as
possible.
•Avoid head lights as back light in the video picture (also caused by reflections, e.g. on window panes).
Mounting the camera on a wall or ceiling
Always proceed in the following order to mount the camera:
7

Installation
RP 406K
•Fix the camera mounting plate on an adequate surface with the mounting materials that come in the
shipment. The camera can be installed on a ceiling or wall. (Dimensions – see detailed view on page
6)
•Loosen the inside camera ball fixture ring and set the required viewing angle. Ensure that the lens is
not touched by fingers. Then fix the camera position by locking the ball fixture ring. When mounting
the camera on a wall, the ball fixture ring may be exchanged for the flat ring included with the
shipment, if necessary. This has a low adjustment range in the vertical axis, but it does not have a
clamp over the camera unit. This way the lens is not covered when mounted on a wall.
•Screw on the housing once the correct viewing angle has been set and ensure the housing seal fits
correctly.
•Protect the housing from unauthorized opening by using the fixing screw with the hexagonal socket
screw key included in the shipment.
RP 406K - IC
•Make a suitable fitting – mounting aperture (diameter 60mm, fitting depth approx. 35mm) for the
fitted camera and fasten the camera with the mounting material included in the shipment. The camera
can be installed on a ceiling or wall. (Dimensions – see detailed view on page 6)
•Loosen the inside camera ball fixture ring and set the required viewing angle. Ensure that the lens is
not touched by fingers. Then fix the camera position by locking the ball fixture ring.
•Screw on the housing once the correct viewing angle has been set with the mounting ring and ensure
the housing seal fits correctly.
•Protect the housing from unauthorized opening by using the fixing screw with the hexagonal socket
screw key included in the shipment. The fixing screw is screwed into the mounting ring.
8

Installation
Connecting diagram
cable length approx. 100cm PIN 1 GND
PIN 2 +12 VD
C
PIN 3 Shield
female:
ar
female
•Connect the video output signal of the camera (BNC jack) using a suitable video cable (insulated
coaxial cable, 75 Ohm) to the designated video input of the recorder. Make sure that the BNC
connector fits correctly and cleanly.
•The recorder provides service voltage to the attached cameras (12 V DC). Use a suitable cable for
connecting the power supply and make sure the connector fits correctly and cleanly and has the
correct polarity. Operate the camera exclusively using the normal service voltage indicated. The mating
component of the system voltage plug (Wago male) is included in the scope of delivery.
Initial operation
Check to see that the camera provides an acceptable video signal and that the picture section was chosen
correctly.
The camera switches on automatically to a black and white signal at dusk. This ensures a higher level of detail
recognition under poor lighting conditions.
Please never open the dome camera itself. There are no further setting options on the inside of the camera
module.
9

Appendix
Technical Data RP 406K (–IC)
CCD Sensor 1/3“ Sony Exview Interline CCD
Max. pixels (h x v) 768 x 576
Horizontal resolution 470 TV lines
Sensitivity 0.015 lux on sensor / 0.3 lux with F2.0
TV standard PAL, 625 lines
Enhancer Yes
Gamma correction 0,45
Electronic shutter Automatic, 1/50 -1/100,000 sec.
Signal-to-noise ratio 50 dB (AGC off)
AGC 30 dB
Synchronization Internal
Backlight Automatic
Spectral response 380 -660 nm
Smear effect 0,005%
Video output signal FBAS 1Vss / 75 Ohm, BNC
Operating voltage 12V/DC (DC 8,0 -15.0 V)
Performance Max. 2 W
Operating temperature -10° to +50°C
Extended temperature area according to
EN501155-T1
-25° to +70°C
Humidity 90 % (not condensed)
Protective system according to associatio
n
German electrotechnicians (VDE)
IP41, class III
MTBF 80,000 hours
Housing shape Mini dome camera (black)
Connections Connecting cables with open cable ends (12VDC) / BNC
plugs (video)
Weight Approx. 300 g
Installation RP 406K: Wall/ceiling mounting
RP 406K-IC: Wall/ceiling installation
Lens RP 406K: 2.9mm; 3.6mm; 4.3mm, 6mm; 8mm
RP 406K-IC: 4.3mm
Dimensions (diameter / height) RP 406K: 79 mm / 56.5 mm
RP 406K – IC: 79 mm / 62 mm
Extended product standards EN 50155
"e" mark
EN 50121-3-2
DIN 5510
10

Appendix
Cleaning and maintenance / Servicing information
Before cleaning or servicing the camera, disconnect it from the power supply.
Clean the camera housing with a dry or slightly moist cloth (add a few drops of dishwashing liquid). Never use
organic solutions such as thinners, alcohols, petroleum products etc. for cleaning.
The interior of the device should only be cleaned by customer service or by qualified professionals. To
safeguard the electrical components, the interior of the device should never be cleaned with water or other
liquids or be immersed in water.
The instructions should be included if giving the device to a third party.
Error search
Error description Cause
Camera station does not send a video
signal.
♦Check the connection of the service voltage (12 V
DC).
♦Check the connection of the video cable at the
camera.
♦Check to see that your power supply is functioning
(12 V DC).
♦Check the connections to the camera (video /
voltage).
The video picture is too dark ♦There is insufficient lighting.
The video picture is out of focus ♦The focus is not adjusted properly.
Video picture has double images (ghosts) ♦Incorrect 75 Ωterminating resistance.
♦Video cable shielding is broken.
If there is still no change after following the help measures described above, please contact Technical Support
with an exact description of the error.
11

Appendix
Technical support
Should difficulties arise while installing or operating the device, we offer you technical support at +49 (0)
4321 269 81 36 or at [email protected].
