Vertex Aletheia dac-1 User manual

Aletheia dac-1
A superlative quality 16-bit non-oversampling
D to A converter
Manufactured in Wales by Vertex AQ Limited

Background
Aletheia is a new brand of electronics produced by
the design team at Vertex AQ. The dac-1 is a high-
end, 16 bit, non-oversampling (NOS) DAC of
superlative performance.
To understand the dac-1 we need to look first at the
development of Vertex AQ, a company that
produces a range of accessories covering mains,
cables and supports. Their USP is based on the
reduction of systematic interaction faults caused by
RFI/EMI1and microphony. When Vertex products
are applied to a hi-fi system, significant gains are
achieved. But the design process employed for the
Vertex products always started at the electronics
inside the box. So the next logical step was to take
the 'systematic thinking' inside the box and through
every internal process, in just the same manner as
at a system level.
Over the past 3 years, the level of development in
digital and analogue processing has increased
within the company, driven by the desire to apply
the proven techniques of the Vertex approach, and
the skills and knowledge acquired through our
more general research work. This has led us to the
dac-1.
Key Design Criterion
The dac-1 employs 16 bit D to A conversion with no
oversampling in order to reduce processing
complexity. No software or hardware noise
shaping, or filtering is used to avoid break-down of
signal integrity, phase shifting and filter ringing. So
lets be clear here, the dac-1 is deliberately a very
basic DAC in processing terms, with the majority of
the design effort focussed on reducing systematic
interactions right down to a component level. But
the essence of the dac-1 development pivots
around the desire to prevent systematic
interactions around the player, down to a
component-by-component level.
There is extensive RFI suppression throughout the
design - all internal wiring is fitted with EMI
absorptive tubing, and all wiring downstream of the
mains transformer is solid-core silver. The major
components in the design (mains transformer, pre-
regulator, DAC board) are housed in separate
modules, each with EM absorptive linings and
acoustic absorption. Within these modules is
extensive acoustic absorption right down to
individual components. The mains transformer and
pre-regulator are housed in separate, compliant
mounted modules, with extensive EM absorption.
The mains input has a built-in 'HiRez Jaya' shunt
filter, and input/output signal lines each have an
internal RFI/acoustic absorption module fitted, and
signal sockets are mounted on isolated sub-panels.
An ultra high-speed, dual-stage power supply
topology is used. A pre-regulator feeds 4 discrete
component second-stage regulators to separately
feed each processor supply. Each analogue output
is taken straight out of the DAC chip and converted
to a voltage signal passively, across a high quality
resistor (passive I/V) to avoid any additional active
output stages. Output capacitors are the
outstanding Mundorf Supreme (silver/gold in oil).
The balance of engineering decisions for the dac-1
is based more around time domain thinking, not
frequency domain thinking. The core processing is
simple 16 bit non oversampling with no filtering. In
our view the problems that filtering brings are
worse, in sound quality terms, than any residual
aliasing or sampling noise. The filter ringing
problem and phase shifting seems to directly affect
the musical performance quite significantly,
whereas without filters, any residual high frequency
sampling noise does not seem to do any damage
to the listening experience, much the same way
that vinyl surface noise is quickly ignored.
Our experience has shown us that the systematic
faults are far more crippling to performance than
most people imagine. The biggest issue is these
effects are closely linked to the musical
programme, breaking down the structure of the
music. We have seen these effects in the
measurement alliance2, and in essence these
systematic faults prevent the system from correctly
tracking the desired output in the time domain. In
our view the musical envelope is broken down and
re-mixed into a lower level of reality by too much
processing. So, by avoiding as much processing as
possible, and minimizing systematic faults at every
possible point within the dac-1 design, we believe
we have a DAC that outputs very closely the
intended waveform - in the time domain.
Aletheia dac-1
1
1RFI = Radio Frequency Interference - high frequency signals carried within and around conductors
EMI = Electro Magnetic Interference - high frequency radio waves transmitted/received through the air between conductors
2Research project between Vertex AQ, Nordost and Acuity Products. See www.vertexaq.com and click on Projects > Knowledge
Alliance.

Sound Quality
Most digital replay gets blurred and confused when
playing complex material, mixing and
intermodulating the musical programme in a very
obvious way. With the dac-1, the complex threads
and intertwining harmonic 'fibers' of dense
passages remain clearly separated and accurate.
As the intensity of the music increases, you hear a
dazzling display of performance and emotion deep
into the mix thats incredibly easy to follow. This
ability regularly reveals things you never previously
heard in your recordings.
Another clear indication of the lack of systematic
distortion is the way music from the dac-1 images,
and remains detached from the speakers. To
explain a bit more, if you play a string quartet piece,
well recorded in a nice ambient environment, the
image should be spread well around behind the
plane of the speakers. When the dac-1 plays the
piece, the sound is clearly in the soundstage, and
remains there. With lesser sources, parts of the
music (particularly with lots of treble content like
strings) collapse back onto the face of the
speakers.
The next huge advantage with the dac-1 is the
vibrancy and richness of the midband, and a total
lack of harshness to leading edges. You get a
completely realistic sense of the body of
instruments - nothing sounds washed-out. And
sounds clearly stop and start in a totally incisive,
yet completely smooth manner.
And finally there is a significant improvement in the
way the dac-1 conveys the energy envelope. Most
D to A processing seems to accentuate quieter
passages, making them seem artificially spotlit,
then as the music builds, it gets to a certain level
then wont go any further without quite an obvious
increase in distortion levels. With the dac-1 the
music scales up and down over a huge range, and
remains stable and listenable over its whole output.
Overall, due to the ability of the dac-1 to track
accurately, there are huge benefits when playing
complex, dense material. Most digital replay gets
blurred and confused with such material, mixing
and intermodulating the musical programme in a
very obvious way. Conversely with the dac-1 the
complex threads and intertwining harmonic 'fibers'
of dense passages remain clearly separated and
accurate. The listening experience is hugely
improved with a dazzling display of musical
interplay that remains easy to follow. In these
situations other equipment clearly loses the plot.
More about tracking.
In our work in the knowledge alliance one of the
main drivers was the measurement of the huge
improvements brought about by the vertex AQ
accessory equipment. As we progressed with this
work we were indeed able to see significant
amounts of time related errors and that these errors
were, predominantly, related to the musical
program being played. Looking in the time domain
we can see the actual analogue output deviating
from the source data quite significantly and that this
deviation is proportional to the level and complexity
of the signal. In other words, whilst a conventional
player might supposedly output it's signal with an
error below it's specified noise limits of say +/- 1/2
of the least significant bit (LSB) (ie quantisation
noise) when playing a tiny sine wave, there are
much more significant processes driving its output
well off target when playing complex music (and
nobody ever tests with complex music).
The 'Vertex' Point of View
Another way of looking at the dac-1, and perhaps
better understand the balance of investment within
the product, is to consider it in it's 'Vertex
component' guise. There are 2 main elements to
this approach:
1.!Protecting the DAC process from the
outside world.
Although not in the normal heavy aluminum boxes
found on the Vertex cables, there are many Vertex
modules inside the dac-1. The internal mains feed
is fitted with a HiRez Roraima and HiRez Jaya. The
S/PDIF input wiring is fitted with a HiRez illimani,
and the analogue output wiring is fitted with a pair
of HiRez Solfonn modules. Furthermore, the signal
input and output sockets are physically decoupled
from the back panel to reduce ingress of chassis
vibration into these delicate circuits.
2.!Isolating the different elements of the DAC
processes from each other.
Once we get into the core of the dac-1, the thinking
is then applied to the mains transformer, and all the
way through the pre-regulation and second-stage
regulation - every step of the power supply is
vibration and RFI treated with HiRez techniques.
Every element of the core digital processing and
the analogue output stages equally has extensive
HiRez acoustic treatment and RFI absorption
techniques applied.
Aletheia dac-1
2

Positioning
The dac-1 should ideally be positioned on a good
hi-fi shelf or rack. If a specialist hi-fi rack is not
available, a high-quality shelf unit should be used.
Even more performance can be achieved if the
dac-1 is placed on a Vertex AQ Kinabalu support
system.
Users should avoid degrading the performance of
the dac-1 by placing it on top of other electronics
boxes such as transports or amplifiers. Also, care
should be taken with positioning to ensure that
cables lead away from the unit without being
pinched, trapped or bent in tight radiuses. Avoid
cables having high-load contact with rack uprights,
or walls to the rear or sides of the hi-fi.
Connectivity
Mains is fed to the unit via a high-quality IEC inlet
socket on the right of the rear panel. Use a high-
quality mains lead. The mains power on/off switch
is situated above.
Digital input is via the decoupled sub-chassis panel
in the centre of the rear panel. S/pdif can be input
via BNC or RCA sockets. Toslink can be input via
the optical socket.
Analogue output is via the decoupled sub-chassis
panel to the left of the rear panel. RCA analogue
outputs and XLR analogue outputs are provided.
Configuration
The left hand decoupled sub-chassis panel is also
fitted with 3 switches.
•The top switch toggles between optical input or
the s/pdif electrical coaxial input (BNC or RCA).
Set to required input.
•The middle switch disables or enables the
analogue XLR circuitry. Set to on if using the XLR
outputs, set to off if using the RCA outputs.
•The lower switch gives the option to defeat the
front-panel LED lamps.
Use
The front panel 'power' indicator is lit when the unit
is receiving power. The front panel 'error' indicator
is illuminated when the unit is not receiving data.
When the unit receives a digital data stream (16 bit,
up to 96KHz), the lamp will extinguish.
The unit is internally fused. If it ceases to operate,
inform your dealer.
Cleaning. Use only a soft dry cotton duster to clean
the case. The perspex top may be polished with a
specialist perspex cleaner. We recommend socket
contacts are cleaned occasionally with Caig Deoxit.
Aletheia dac-1
3
power on/off
switch
mains IEC
socket
s/pdif digital inputs. upper
socket BNC, lower RCA
toslink optical
input
XLR analogue
outputs
RCA analogue
outputs
front LED
defeat switch
XLR output
select switch
digital input
select switch

Features Summary
Inputs/Outputs
•S/PDIF (75 Ohm) and toslink optical
•16 bit, 44.1 to 96KHz
•SPDIF RCA input WBT silver nextgen
socket.
•Analogue single-ended RCA outputs. WBT
silver nextgen sockets.
•Analogue balanced XLR outputs. Gold-plated
Neutrik XLR sockets.
Rear panel
•Analogue and digital input and output
sockets mounted on isolated sub-chassis
panels.
Internal digital input topology
•SPDIF
•Silver-plated copper co-ax feed.
•HiRez acoustic absorption module with
full RFI/EMI absorption.
D to A engine
•Digital interface DIR 9001.
•DAC TDA 1543 (current output).
•Non-oversampled.
•No digital noise shaping.
•No output filtering.
•Passive output current-to-voltage conversion
(I to V) across Vishay non-inductive thick film
resistors (matched pair).
•TDA 1543 reference voltage set by Vishay
non-inductive thick film resistor.
•Decoupling capacitors are Sanyo Os-Con.
•All significant components fitted with direct
coupled acoustic absorption.
•Housed in poly box with EMI/RFI absorptive
lining.
Analogue output topology
•Output wiring is solid-core silver with
unbleached cotton insulation.
•Output capacitors are 4.7uF Mundorf MCap
Supreme metallised polypropylene silver/
gold/oil (99% silver/1% gold), with dual
induction-free windings.
•Dual acoustic absorption modules on output
lines with full RFI/EMI absorption. Output
capacitors and XLR circuitry within. All
mounted directly on acoustic absorption
labyrinth.
Mains
•Furutech rhodium plated IEC inlet.
•hi-fi tuning mains fuse. 500mA slow-blow,
internally mounted.
•Internal mains wiring fitted with acoustic and
EMI/RFI absorption module.
•Input mains shunt filtered with high
performance passive filter (HiRez Jaya).
•100VA toroid transformer module.
•Transformer housed in compliantly
mounted poly box with EMI/RFI
absorptive lining.
•Power consumption - less than 20W.
Power supplies
•Input mains wiring is silver-plated OFC.
•All ac and dc wiring downstream of
transformer is solid-core silver with EMI
absorptive tubing.
•Pre-regulation.
•Input 15Vac, output regulated 13Vdc
•Housed in compliant mounted poly box
with EMI/RFI absorptive lining.
•Ultra high-speed discreet component
regulator with extensive surface-mount
components and Panasonic FC and
Sanyo Os-Con capacitors.
•All components fitted with direct-coupled
acoustic absorption.
•Second-stage regulation.
•Ultra high-speed discreet voltage
regulators with extensive surface-mount
components, Panasonic FC and Sanyo
Os-Con capacitors.
•Three shunt regulators for digital
sections
•One series regulator for analogue
section.
•All components fitted with direct-coupled
acoustic absorption and EMI treatment.
•Pre-regulator and second stage
regulators are all Paul Hynes Design
modules, heavily modified by Vertex AQ.
Aletheia dac-1
4

The diagram below is a simplified schematic of the
dac-1, showing the main modular components that
are incorporated within the unit.
Aletheia dac-1
5
mains
transformer
pre-regulator
2nd stage regulators x 4 DAC board
precision shunt
mains filter
Acoustic/RFI
absorption
L/R analogue output acoustic/
RFI absorption modules (inc
output caps & XLR circuits)
S/PDIF input
acoustic/RFI
absorption module
Optical interface
L/R analogue out Optical in S/PDIF in Mains IEC in
If you have any further queries about the dac-1 then
please do not hesitate to contact us. Please use the
feedback form on the website or use the details below.
Vertex AQ Limited, Unit 6, Old Town Hall Workshops,
Temple Street, Llandrindod Wells, Powys, Wales,
LD1 5DU, UK
Tel: [phone]
Web: www.vertexaq.com
Even in ecology it's the
foundations that count -
Vertex AQ supports
Buglife.
Visit www.buglife.org.uk
