Vestfrost CNF186Z W User manual

EN NO FROST
COMBI REFRIGERATOR
Freezer - Fridge
User manual
CNF186Z W
CNF186Z B
CNF186Z X
UA КОМБІ-ХОЛОДИЛЬНИК
NO FROST
Інструкція користувача

EN
2
Index
BEFORE USING THE APPLIANCE ................................. 4
General warnings...................................................................... 4
Old and out-of-order fridges...................................................... 6
Safety warnings ........................................................................ 6
Installing and operating your fridge........................................... 7
Before Using your Fridge.......................................................... 8
Information about New Generation Cooling Technology .......... 9
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS .......................................................... 10
THE VARIOUS FUNCTION AND POSSIBILITIES ......... 12
Display and control panel ........................................................ 12
Operating your fridge............................................................... 12
Cooler temperature settings ............................................... 12
Super cool mode ................................................................. 13
Economy mode ................................................................... 13
Warnings about Temperature Adjustments.............................. 13
Accessories ............................................................................. 14
Freezer box.......................................................................... 14
Chiller Shelf ......................................................................... 15
Humidity Controler ............................................................... 15
Adjustable Door Shelf .......................................................... 16
Adjustable Glass Shelf......................................................... 16
Natural Ion Tech / Ionisier .................................................... 17
CLEANING AND MAINTENANCE .................................. 18
Defrosting ................................................................................ 19
ARRANGING FOOD IN THE APPLIANCE ..................... 20
Refrigerator compartment........................................................ 20
Freezer compartment .............................................................. 21
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION ........................................................................26
Repositioning the door............................................................. 26

EN
3
BEFORE CALLING YOUR AFTER SALES SERVICE ... 27
TIPS FOR SAVING ENERGY ..........................................30

EN
4BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: In order to avoid any hazards resulting from
the instability of the appliance, it must be xed in accor-
dance with the following instructions:
• If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for
a few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
- sta󰀨 kitchen areas in shops, o󰀩ces and other work-
ing environments.

EN
5
BEFORE USING THE APPLIANCE
- farm houses and by clients in hotels, motels and oth-
er residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be
used with a specially grounded socket of 16 amperes.
If there is no such socket in your house, please have
one installed by an authorised electrician.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.

EN
6BEFORE USING THE APPLIANCE
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock
before discarding it, because children may get trapped
inside it and may cause an accident.
• Old fridges and freezers may contain isolation material
and refrigerant with CFC or HFC. Therefore, take care not
to harm environment when you are discarding your old
fridges..
Please ask your municipal authority about the disposal of the
WEEE reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before
installing and using your appliance. We are not
responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction
manual, and keep this manual in a safe place to resolve
the problems that may occur in the future.
• This appliance is produced to be used in homes and it
can only be used in domestic environments and for the
specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the
appliance to be cancelled and our company will not be
responsible for losses incurred.
• This appliance is produced to be used in houses and it is
only suitable for cooling / storing food. It is not suitable for
commercial or common use and/or for storing substances
except for food. Our company is not responsible for losses
to be incurred in the contrary case.
Safety warnings
• Do not connect your Fridge Freezer to the mains
electricity supply using an extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.

EN
7
BEFORE USING THE APPLIANCE
• This appliance is designed for use by adults, do not allow
children to play with the appliance or let them hang o󰀨 the
door.
• Never touch the power cord/plug with wet hands as this
could cause a short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-
making compartment as they can burst as the contents
freeze.
• Do not place explosive or ammable material in your
fridge. Place drinks with high alcohol content vertically in
the fridge compartment and make sure that their tops are
tightly closed.
• When removing ice from the ice-making compartment, do
not touch it. Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-
cream or ice cubes immediately after you have taken them
out of the ice-making compartment.
• Do not re-freeze frozen goods after they have melted. This
may cause health issues such as food poisoning.
• Do not cover the body or top of fridge with lace. This a󰀨ects
the performance of your fridge.
• Secure any accessories in the fridge during transportation
to prevent damage to the accessories.
Installing and operating your fridge
Before using your fridge, you should pay attention to the
following points:
• The operating voltage for your fridge is 220-240 V at 50Hz.
• We do not accept responsibility for any damages that
occur due to ungrounded usage.
• Place your fridge where it will not be exposed to direct
sunlight.
• Your appliance should be at least 50 cm away from stoves,
gas ovens and heater cores, and at least 5 cm away from
electrical ovens.
• Your fridge should never be used outdoors or exposed to
rain.
• When your fridge is placed next to a deep freezer, there

EN
8BEFORE USING THE APPLIANCE
should be at least 2 cm between them to prevent humidity
forming on the outer surface.
• Do not place anything on your fridge, and install your fridge
in a suitable place so that at least 15 cm of free space is
available above it.
• Use the adjustable front legs to make sure your appliance
is level and stable. You can adjust the legs by turning them
in either direction. This should be done before placing food
in the fridge.
• Before using your fridge, wipe all parts with a solution of
warm water and a teaspoon of sodium bicarbonate, then
rinse with clean water and dry. Place all parts in the fridge
after cleaning.
• Install the plastic distance guide (the part with black vanes
at the rear) by turning it 90° (as shown in the gure) to
prevent the condenser from touching the wall.
• The refrigerator should be placed against a wall with a free
space not exceeding 75 mm.
Before Using your Fridge
• When using your fridge for the rst time, or after
transportation, keep it in an upright position for at least 3
hours before plugging into the mains. This allows e󰀩cient
operation and prevents damage to the compressor.
• Your fridge may have a smell when it is operated for the
rst time. This is normal and the smell will fade away when
your fridge starts to cool.

EN
9
BEFORE USING THE APPLIANCE
Information about New Generation Cooling
Technology
Fridges with new generation cooling technology have a
di󰀨erent working system than static fridges. In normal fridges,
humid air that enters into fridge and the water vapor that comes
out from the foods, accumulates frost formation in freezer
compartment. In order to melt this frost, in other words defrost,
the fridge has to be stopped. During the stopping period, to
keep the foods cold, user has to extract the food to outside of
fridge and user has to clear the ice during this period.
In the fridges with new generation cooling technology, situation
in the freezer compartment is completely di󰀨erent. With the
aid of fan, cold and dry air is blown out through many points
into the freezer compartment. As a result of the homogenously
blown cold air, even in the spaces between shelves, foods are
frozen equally and correctly. On the other hand there will be
no frost formation.
In the refrigerator compartment, there will be nearly same
conguration with freezer compartment. Air, that is emitted
with the fan, located at the top of refrigerator compartment,
is cooled while passing through the gap behind the air duct.
At the same time, air is blown out through the holes on the air
duct so that cooling process is successfully completed in the
refrigerator compartment. Holes on the air duct are designed
such that the air distribution becomes homogenous in this
compartment.
As there is no air passage between freezer and refrigerator
compartment, there will be no odor mixing.
As a result of these, your fridge with new generation cooling
technology, gives you, ease of use beside the huge volume
and esthetic appearance.

EN
10
1
2
5
6
7
8
9
10
11
4
3
12
B
13
14
15
16
17
A
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS

EN
11
A) Fridge compartment
B) Freezer compartment
1) Fridge shelves
2) Wine rack *
3) Interior display / In room control
4) Ionisier *
5) Chiller *
6) Crisper cover
7) Crisper
8) Freezer top basket
9) Freezer middle basket
10) Freezer bottom basket
11) Leveling feet
12) Ice trays
13) Freezer glass shelves *
14) Bottle shelf
15) Adjustable door shelf * / Door shelf
16) Door shelf
17) Egg holder
* In some models
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS

EN
12 THE VARIOUS FUNCTION AND POSSIBILITIES
Display and control panel
Operating your fridge
Cooler temperature settings
• Initial temperature value for Cooler Setting Indicator is 6 oC.
• Press set button once, the set value will start to blink.
• If you keep pressing set button, lower temperatures will be selected.
(8, 6, 5, 4, 2, super and eco)
• If no button is pressed for 1 second, your choice will be set, it will blink
3 times. Buzzer will sound beep beep.
• The temperature value selected before Super Cool Mode or Economy
Mode is activated will remain the same when the mode is over or
cancelled. The appliance continues to operate with this temperature
value.
C
o
8 6 5 4 2
It is Economy mode
indicator.
It is Super cool mode
indicator.
Set button
Thermostat set level
indicator
Button LED

EN
13
THE VARIOUS FUNCTION AND POSSIBILITIES
Super cool mode
How would it be used?
Press set button until super cool symbol will be seen on the screen.
Buzzer will sound beep beep. Mode will be set.
During this mode:
• Economy mode can not be selected.
• Super cool mode can be cancelled by the same operation of
selecting.
Economy mode
How would it be used?
Press set button until eco symbol will be seen on the screen. Buzzer
will sound beep beep. Mode will be set.
During this mode:
• Super cool can be selected. Economy mode is automatically
cancelled and the selected mode is activated.
• Eco mode can be cancelled by the same operation of selecting.
Warnings about Temperature Adjustments
• Temperature adjustments should be made according to the frequency
of door openings and the quantity of food kept inside the fridge.
• Do not pass to another adjustment before completing an adjustment.
• Your fridge should be operated up to 24 hours according to the
ambient temperature without interruption after being plugged in to be
completely cooled. Do not open doors of your fridge frequently and do
not place much food inside it in this period.
• A 5 minute delaying function is applied to prevent damage to the
compressor of your fridge, when you take the plug o󰀨 and then plug
it on again to operate it or when an energy breakdown occurs. Your
fridge will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals
stated in the standards, according to the climate class stated in the
information label. We do not recommend operating your fridge out
of stated temperatures value limits in terms of cooling e󰀨ectiveness.

EN
14 THE VARIOUS FUNCTION AND POSSIBILITIES
• This appliance is designed
for use at an ambient
temperature within the
10°C - 43°C range.
Accessories
Freezer box
The freezer box allows foods are maintained more regularly.
Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
! Make the inverse of the same operation for the resetting the sliding
compartment.
Note: Always Keep the handle of box while removing the box.
Climate Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Freezer boxes
Ice tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely turned into ice, you can twist the tray
as shown below to remove the ice cubes.

EN
15
THE VARIOUS FUNCTION AND POSSIBILITIES
Chiller Shelf
Keeping food in the Chiller compartment instead
of the freezer or refrigerator compartment allows
food retain freshness and avour longer, while
preserving its fresh appearance. When chiller tray
becomes dirty, remove it and wash it with water.
(Water freezes at 0°C, but foods containing salt or
sugar freeze at temperature lower than that)
Normally people use the chiller compartment for
raw sh, lightly pickled, rice, etc...
Do not put foods you want to freeze or ice trays in order to make ice.
Removing the Chiller shelf
• Pull the chiller shelf out toward you by sliding on rails.
• Pull the chiller shelf up from rail to remove.
Humidity Controler
When the humidity controler in the closed position, it allows fresh fruit and
vegetables to be stored longer.
In case of the crisper is totally full, the fresh
dial is located in front of crisper, should
be opened. By means of this the air in the
crisper and humidity rate will be controlled
and endurance life will be increased.
If you see any condensation on glass shelf,
humidity control should be taken into the
open positions.
(In some models)
(In some models)

EN
16 THE VARIOUS FUNCTION AND POSSIBILITIES
Adjustable Door Shelf
Six di󰀨erent height adjustments can be made to provide
storage areas that you need by adjustable door shelf.
To change the position of adjustable door shelf ;
Hold the bottom of the shelf and pull the buttons on the side of
the door shelf direction of arrow (Fig.1).
Position door shelf the height you need by moving up and
down. After you get the position that you want the door shelf,
release the buttons on the side of the door shelf (Fig.2) Before
releasing the door shelf, move up down and make sure the
door shelf is xed.
Note: Before moving door shelf is loaded, you must hold the
shelf by supporting the bottom. Otherwise, door shelf could fall
o󰀨 the rails due to the weight. So damage may occur on the
door shelf or rails.
Adjustable Glass Shelf
Adjustable glass shelf mechanism provides higher storage
spaces with a simple movement. To cover the glass shelf,
push it.
You can load your food as you want in the resulting extra
space. To bring the shelf in its original position, pull it toward
you.
(In some models)
(In some models)
Figure -1
Figure -2
Figure -1
Figure -2

EN
17
THE VARIOUS FUNCTION AND POSSIBILITIES
Natural Ion Tech / Ionisier
Natural Ion Tech spreads negative ions which neutralize particles of
unpleasant smell and dust in the air.
By removing these particles from the air in the refrigerator, Natural Ion
Tech improves air quality and eliminates odours.
• This feature is optional. It may not exist on your product.
• The location of your ioniser device may vary from product to product.
Ionisier
(In some models)
Visual and text descriptions on the accessories section may
vary according to the model of your appliance.

EN
18 CLEANING AND MAINTENANCE
• Disconnect the unit from the power supply before
cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp housing and
other electrical components.
• The refrigerator should be cleaned periodically using a
solution of bicarbonate of soda and lukewarm water.
• Clean the accessories separately with
soap and water Do not clean them in the
dishwasher.
• Do not use abrasive products, detergents or soaps. After
washing, rinse with clean water and dry carefully. When
you have nished cleaning, reconnect the plugto the mains
supply with dry hands.
• Clean the condenser with a broom at least twice a year.
This will help you to save on energy costs and increase
productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.

EN
19
CLEANING AND MAINTENANCE
Defrosting
Your refrigerator has fully automatic defrosting. The water
formed as a result of defrosting passes through the water
collection spout, ows into the vaporisation container below
the condenser and evaporates there.
• Make sure you have disconnected the plug of your
refrigerator before cleaning the vaporization container.
• Remove the vaporization container from its position by
unscrewing the screws as indicated. Clean it with soapy
water at specic time intervals. Thus, the odor formation
will have been prevented.
Replacing LED Lighting
If your refrigerator has LED lighting contact the help desk as
this should be changed by authorized personnel only.
Evaporating
tray
