Vestfrost FN371E W User manual

UA Морозильна камера
Інструкція користувача
FREEZER
User manual
EN
FN371E W
FN371E X
FN 371E B
FN371E D/X

EN - 1 -
Index
BEFORE USING YOUR FREEZER.....................................................2
General warnings........................................................................................2
Old and out-of-order fridges or freezer........................................................4
Safety warnings...........................................................................................4
Installing and operating your freezer...........................................................5
Before using your freezer............................................................................6
Information on No-Frost Technology ...........................................................6
USAGE INFORMATION.......................................................................7
Display and control panel............................................................................7
Freezer Set Button...............................................................................................7
Sr Alarm................................................................................................................7
Operating the Freezer.................................................................................8
Super Freeze Mode ...................................................................................8
Economy mode ....................................................................................................8
Freezer temperature settings......................................................................8
Door Open Alarm Function...................................................................................8
Warnings about temperature adjustments...................................................9
Accessories................................................................................................10
Making Ice Cubes................................................................................................10
Ice tray.................................................................................................................10
PLACING THE FOOD.........................................................................10
CLEANING AND MAINTENANCE .....................................................14
Defrosting...................................................................................................14
Replacing LED lighting...............................................................................14
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION
15Repositioning the door ...............................................................................15
BEFORE CALLING SERVICE............................................................15
Tips for saving energy................................................................................17
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS....18

EN - 2 -
BEFORE USING YOUR FREEZER
General warnings
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the
appliance, it must be xed in accordance with the instructions.
• IfyourapplianceusesR600aasarefrigerant(thisinformation
willbeprovidedonthelabelofthecooler)youshouldtakecare
during transportation and installation to prevent the cooler
elements from being damaged. R600a is an environmentally
friendly and natural gas, but it is explosive. In the event of a
leak due to damage of the cooler elements, move your fridge
away from open ames or heat sources and ventilate the
room where the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.
• This appliance is intended to be used in household and
domestic applications such as:
- staff kitchen areas in shops, ofces and other working
environments.
- farm houses and by clients in hotels, motels and other
residential type environments.
- bed and breakfast type environments;

EN - 3 -
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, a service agent or similarly
qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with
a specially grounded socket of 16 amperes. If there is no
such socket in your house, please have one installed by an
authorised electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
useoftheapplianceinasafewayandunderstandthehazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorised service agent or similar qualied
persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.

EN - 4 -
Old and out-of-order fridges or freezer
• Ifyour oldfridge hasa lock,break orremove thelock beforediscarding it,
because children may get trapped inside it and may cause an accident.
• Old fridges and freezers may contain isolation material and refrigerant
with CFC or HFC. Therefore, take care not to harm environment when
you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE
reuse, recycle and recovery purposes.
Notes:
• •Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for the damage occurred due to misuse.
• •Follow all instructions on your appliance and instruction manual, and keep this manual
in a safe place to resolve the problems that may occur in the future.
• •This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled and
our company will not be responsible for losses incurred.
• •This appliance is produced to be used in houses and it is only suitable for cooling
/ storing food. It is not suitable for commercial or common use and/or for storing
substances except for food. Our company is not responsible for losses to be incurred in
the contrary case.
Safety warnings
• Do not connect your to the mains electricity supply using an extension
lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
•
• This appliance is designed for use by adults, do not allow children to play
with the appliance or let them hang off the door.
• Never touch the power cord/plug with wet hands as this could cause a
short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.
• Do not place explosive or ammable material in your freezer. Place
drinks with high alcohol content vertically in the freezer and make sure that their tops
are tightly closed.

EN - 5 -
• When removing ice from the ice-making compartment, do not touch it.
Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice
cubes immediately after you have taken them out of the ice-making
compartment.
• Do not re-freeze frozen goods after they have melted. This may cause
health issues such as food poisoning.
• Donotcoverthebodyortopoffreezerwithlace.Thisaffectstheperformance
of your freezer.
• Secure any accessories in the freezer during transportation to prevent damage to the
accessories.
• Whenthedoor ofthefreezer isclosed,a vacuumseal
will form. Wait for about 1 minute before reopening it.
• This application is optional for easy opening of the
door. With this application, a little condensation may
occur around this area and you may remove it.
Installing and operating your freezer
Before starting to use your freezer, you should pay attention to the following points:
• The operating voltage for your freezer is 220-240 V at 50Hz.
• We do not accept responsibility for any damages that occur due to ungrounded usage.
• Place your freezer where it will not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores,
and at least 5 cm away from electrical ovens.
• Your freezer should never be used outdoors or exposed to rain.
• When your freezer is placed next to a deep freezer, there should be at least
2 cm between them to prevent humidity forming on the outer surface.
• Do not place heavy items on the appliance.
• Do not place anything on your freezer, and install your freezer in a suitable
place so that at least 15 cm of free space is available above it.
• Use the adjustable front legs to make sure your appliance is level and stable. You can
adjust the legs by turning them in either direction. This should be done before placing
food in the freezer.
• Before using your freezer, wipe all parts with a solution of warm water and
a teaspoon of sodium bicarbonate, then rinse with clean water and dry.
Place all parts in the freezer after cleaning.
• Install the plastic distance guide (the part with black vanes at the rear)
by turning it 90° (as shown in the gure) to prevent the condenser from
touching the wall.
• The freezer should be placed against a wall with a free space not
exceeding 75 mm.
• This appliance is designed to work in difcult climate conditions (up to 43 °C or 110°
F) and is powered with ‘Freezer Shield’ technology which ensures that the frozen food
in the freezer will not defrost even if the ambient temperature falls as low as -15 °C. So

EN - 6 -
Before using your freezer
• When using your freezer for the rst time, or after transportation, keep it
in an upright position for at least 3 hours before plugging into the mains.
This allows efcient operation and prevents damage to the compressor.
• Your freezer may have a smell when it is operated for the rst time. This
is normal and the smell will fade away when your freezer starts to cool.
Information on No-Frost Technology
No-frost freezers differ from other static freezers in their operating
principle.
In normal freezers, the humidity entering the freezer due to opening the
door and the humidity inherent in the food causes freezing in the freezer
compartment. To defrost the frost and ice in the freezer compartment, you
are periodically required to turn off the freezer, place the food that needs
to be kept frozen in a separately cooled container and remove the ice
gathered in the freezer compartment.
The situation is completely different in no-frost freezers. Dry and cold air
is blown into the freezer compartment homogeneously and evenly from
several points via a blower fan. Cold air dispersed homogeneously and
evenly between the shelves cools all of your food equally and uniformly,
thus preventing humidity and freezing.
Therefore your no-frost freezer allows you ease of use, in addition to its
huge capacity and stylish appearance.
you may then install your appliance in an unheated room without having to worry about
frozen food in the freezer being spoilt. When the ambient temperature returns to normal,
you may continue using the appliance as usual.

EN - 7 -
Display and control panel
USAGE INFORMATION
Freezer Set Button
The freezer set button allows changes to be made to the temperature of the freezer
compartment. Super freeze and economy mode can also be activated using this button.
Sr Alarm
Sr alarm will change to red and an alarm will sound if any problems occur.
Sr Alarm Indicator
Freezer Set Button

EN - 8 -
Operating the Freezer
Super Freeze Mode
Activating Super Freeze Mode
• Push the freezer set button until the super freeze symbol illuminates. The buzzer will
sound twice and the mode will be set.
During Super Freeze Mode
• Super freeze mode can be cancelled in the same way it is selected.
Note: Super freeze mode will automatically cancel after 54 hours, depending on the
environmental temperature or when the freezer sensor reaches a sufciently low temperature.
Economy mode
Activating Economy Mode
• Press the freezer set button until the economy symbol illumintes.
• If no button is pressed for 1 second the mode will be set and the buzzer will sound twice
as conrmaiton.
• To cancel, press the freezer set button.
Freezer temperature settings
• The initial temperature value for the freezer setting indicator is "Eco".
• Press the freezer set button once
• When you rst press the button, the previous value will appear on the setting indicator
of the freezer.
• Whenever you press this button, a lower temperature will be set (-24°C, -22°C, -20°C,
Economy, -16°C, Super freeze)
• If you press the freezer set button until the super freeze symbol appears on the freezer
setting indicator, and do not press any buttons for 1 second, super freeze will ash
• If you continue to press the same button, it will restart from -16°C.
Door Open Alarm Function
If freezer door is opened more than 2 minutes, appliance sounds ‘beep beep’.

EN - 9 -
Warnings about temperature adjustments
• It is not recommended that you operate your fridge in environments colder than 10°C in
terms of its efciency.
• Temperature adjustments should be made according to the frequency of door openings
and the quantity of food kept inside the fridge.
• Do not pass to another adjustment before completing an adjustment.
• Your fridge should be operated up to 24 hours according to the ambient temperature
without interruption after being plugged in to be completely cooled. Do not open doors
of your fridge frequently and do not place much food inside it in this period.
• A 5 minute delaying function is applied to prevent damage to the compressor of your
fridge, when you take the plug off and then plug it on again to operate it or when an
energy breakdown occurs. Your fridge will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals stated in the
standards, according to the climate class stated in the information label. We do not
recommend operating your fridge out of stated temperatures value limits in terms of
cooling effectiveness.
• This appliance is designed for use
at an ambient temperature within the
10°C - 43°C range.
Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
T/SN Between 10 and 43 (°C)

EN - 10 -
PLACING THE FOOD
• The freezer compartment is used for freezing fresh food, for storing frozen foods for the
period of time indicated on packaging and for making ice cubes..
• Do not put fresh and warm food next to frozen food as it can thaw the frozen food.
• While freezing fresh foods (i.e. meat, sh and mincemeat) divide them in portions you
will use in a single serving.
• For storing frozen foods, the instructions shown on frozen food packages should always
be followed carefully. If no information is provided, food should not be stored for more
than 3 months from the purchased date.
• Maximum load: if you want to store large quantities of food and use the maximum net
capacity of the freezer, you can remove all the sliding drawers but you should keep
the upper shelf aps. Thanks to this, it is possible to store bulky items directly on the
shelves.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.
• Frozen food should be transported in appropriate containers to maintain the quality of
the food and should be returned to the freezing surfaces of the unit in the shortest
possible time.
Accessories
Making Ice Cubes
• Pull the lever towards you and remove the ice maker
tray
• Fill with water to the level of line
• Hold the left end of the lever and set the ice-tray on
the icebox
• When ice cubes are formed, twist the lever to drop ice
cubes into the ice box.
Do not fill the icebox with water in order to make ice.
It can break.
(In some models)
Ice tray
• Fill the ice tray with water and place in freezer compartment.
• After the water completely turned into ice, you can twist the tray as shown below to get
the ice cube.
(In some models)

EN - 11 -
Dairy Products Preparation Maximum Storing
time (months) Storing Conditions
Packet
(Homogenize) Milk In its own packet 2 - 3 Pure Milk – In its own packet
Cheese-excluding
white cheese In slices 6 - 8
Original package may
be used for short storing
period. It should be
wrapped in foil for longer
periods.
Butter, margarine In its package 6
A+ models
If there is a power cut or malfunction, do not open the door. This will help maintain the
temperature inside the freezer, ensuring that foods are conserved for about 15 hours at
25°C. Do not re-freeze food that is defrosting or that has already been defrosted. These
foods must be cooked and eaten.
• If a package of frozen food shows signs of humidity and abnormal swelling it is probable
that it has been previously stored at an unsuitable temperature and that the contents
have deteriorated..
• The storage life of frozen foods depends on the room temperature, thermostat setting,
how often the door is opened, the type of food and the length of time required to transport
the product from the shop to your home. Always follow the instructions printed on the
packaging and never exceed the maximum storage life indicated.
If you would use maximum freezing capacity of your freezer:
• While freezing fresh foods, the maximum amount of fresh food (in kg) that can be
frozen in 24 hours is indicated on the appliance label. (your refrigerator has the
capacity to freeze 25 kg at 25°C ambient)
• For optimum appliance performance to reach maximum freezing capacity, activate
Super Freeze (SF) mode 24 hours before placing fresh food into the freezer.
• After placing fresh food into the freezer, 24 hours is generally sufcient for freezing.
”Super Freeze” mode will be deactivated automatically in 2-3 days to save energy.
If you would freeze a small amount (up to 3 kg) in your freezer:
• Place your food without touching already frozen food and activate “Fast Freezing”
mode. You can put your food next to other frozen food after it is completely frozen (after
minimum 24 hours).
• Do not re-freeze frozen food after it has thawed. This may cause health issues, such as
food poisoning.
• Allow hot food to completely cool down before placing it in the freezer.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.

EN - 12 -
Meatandsh Preparation Maximum
Storing time
(month)
Steak Wrapping in a foil 6 - 8
Lamb meat Wrapping in a foil 6 - 8
Veal roast Wrapping in a foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packages without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be packaged even if it has
membrane
Chicken and turkey Wrapping in a foil 4 - 6
Goose and Duck Wrapping in a foil 4 - 6
Deer, Rabbit, Wild Boar In 2.5 kg portions and as llets 6 - 8
Fresshwatershes(Salmon,
Carp, Crane, Siluroidea) After cleaning the bowels and
scales of the sh, wash and dry
it; and if necessary, cut off the tail
and head.
2
Leansh;bass,turbot,
ounder 4
Fattyshes(Tunny,Mackarel,
bluesh,anchovy) 2 - 4
Shellsh Cleaned and in bags 4 - 6
Caviar In its package, aluminium or
plastic container 2 - 3
Snails In salty water, aluminum or plastic
container 3
Note: Frozen meat should be cooked as fresh meat after being thawed. If the meat
is not cooked after being thawed, it must not be re-frozen.
Maximum Storing
time (months)
Thawing time in
room temperature
(hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)

EN - 13 -
Vegetables and Fruits Preparation Maximum Storing time
(months)
String beans and beans Wash and cut into small pieces and boil in
water 10 - 13
Beans Hull and wash and boil in water 12
Cabbage Cleaned and boil in water 6 - 8
Carrot Clean and cut to slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove
the core and boil in water 8 - 10
Spinach Washed and boil in water 6 - 9
Cauliower Take the leaves apart, cut the heart into pieces, and leave it in water with a little
lemon juice for a while 10 - 12
Eggplant Cut to pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet
corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12
Cooked fruits Adding 10 % of sugar in the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12

EN - 14 -
CLEANING AND MAINTENANCE
evaporating container
• Disconnect the unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp housing and other electrical
components.
• The freezer should be cleaned periodically using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately with soap and water Do not
clean them in the dishwasher.
• Do not use abrasive products, detergents or soaps. After washing, rinse
with clean water and dry carefully. When you have nished cleaning,
reconnect the plugto the mains supply with dry hands.
• Clean the condenser with a broom at least twice a year. This will help
you to save on energy costs and increase productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
Defrosting
Your freezer has fully automatic defrosting. The water
formed as a result of defrosting passes through the
water collection spout, ows into the vaporisation
container below the condenser and evaporates there.
Replacing LED lighting
If your refrigerator has LED lighting, contact the help desk as this should be changed by
authorized personel only.

EN - 15 -
BEFORE CALLING SERVICE
Repositioning the door
• It is not possible to change the opening direction of your freezer door, if the door handle
on your freezer are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any handle.
• If the door opening direction of your freezer may be changed, you should contact the
nearest authorised service to have the opening direction changed.
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION
• The original packages and foamed polystyrene (PS) can be retained if required.
• During transportation, the appliance should be secured with a wide string or a strong
rope. The instructions written on the corrugated box must be followed while transporting.
• Before transporting or changing the installation
position, all the moving objects (ie, drawer, Ice trays,
…) should be taken out or xed with bands in order
to prevent them from getting damaged.
Carry your freezer in the upright position.
CheckWarnings;
Your fridge warns you if the temperatures for freezer are in improper levels or when a
problem occurs in the appliance.
ERROR TYPE ERROR TYPE WHY WHAT TO DO
SR "Failure
Warning"
There is/are some
part(s) Out of order
or there is a failure in
cooling process
Call Service for
assistance as soon as
possible.
If your freezer is not operating:
• Are there any electrical faults?
• Is the plug fully in the socket?
• Is the plug fuse or the mains fuse blown?
• Is there any fault in the socket? Examine this by plugging your freezer into a socket
which you are sure that is working.
Ariseinthetemperaturemaybecausedby;
• Frequent door opening for long periods of time
• Loading with large quantities of warm foods
• High ambient temperature
• An error with the appliances.
Check Warnings:
Warning codes are displayed in the freezer indicators if an incorrect temperature is detected
in the freezer or when a problem occurs in the appliance.

EN - 16 -
Also a warning sound is heard.
The problem code and audible alarm will continue until you press the SET or MODE button.
When you press one of these buttons, the audible alarm will stop immediately and the “LF”
warning will disappear in 15 minutes. You don’t have to call your service. This condition may
occur due to the reasons given above. You can keep storing your foods in your freezer. If
the “LF” warning does not disappear an hour after pressing the button, call your service and
do not re-freeze any thawed food. Thawed food must be eaten quickly.
If your freezer is operating too loudly:
Normal Noises
Cracking (Ice cracking) Noise:
• During automatic defrosting.
• When the appliance is cooled or warmed (due to expansion of appliance material).
Short cracking: Heard when the thermostat switches the compressor on/off.
Compressor noise (Normal motor noise): This noise means that the compressor is
operating normally. The compressor may cause more noise for a short time when it is rst
activated.
Bubbling noise and splash: This noise is caused by the ow of the refrigerant in the
tubes of the system.
Waterownoise: Normal ow noise of water owing to the evaporation container during
defrosting. This noise can be heard during defrosting.
Air Blow Noise: Normal fan noise. This noise can be heard in No-Frost freezer during
normal operation of the system due to the circulation of air.
If the edges of freezer cabinet that the door joint contact are warm:
Especially in summer (hot weather), the surfaces that the joint contact may get warmer
during the operation of the compressor, this is normal.
Ifhumiditybuildsupinsidethefreezer;
• Is all food packed properly?Are the containers dried before placing them in the freezer?
• Is the freezer door being opened frequently? Humidity of the room gets in the freezer
when the doors are opened. Humidity build up will be faster when you open the doors
more frequently, especially if the humidity of the room is high.
• Building up of water drops on the rear wall after automatic defrosting is normal (in Static
Models).
Ifthedoorisnotopenedandclosedproperly;
• Do the food packages prevent closing of the door?
• Are door joints broken or torn?
• Is your freezer on a level surface?
IMPORTANT NOTES:
• In the event of a power cut, to prevent any damage to the compressor we recommend
that you unplug the freezer. Your appliance will start after 5 minutes, there is nothing to
worry about.
• If the appliance is not used for long time (for example during holidays) unplug it. Clean
your freezer according to Chapter 4 and leave the door open to prevent humidity and
smell.

EN - 17 -
Tips for saving energy
1.Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near
a heat source (radiator, cooker.. etc). Otherwise use an insulating plate.
2.Allow warm food and drinks to cool down outside the appliance.
3.Cover drinks or other liquids when placing them in the appliance Otherwise humidity
increases in the appliance. Therefore, the working time gets longer. Also covering drinks
and other liquids helps to preserve smell and taste.
4.Try to avoid keeping the doors open for long periods or opening the doors too frequently
as warm air will enter the cabinet and cause the compressor to switch on unnecessarily
often.
5.Keep the covers of the different temperature compartments (crisper, chiller ...etc ) closed
6.Door gasket must be clean and pliable. Replace gaskets if worn.
• If the problem persists after you have followed all the instructions above, please consult
to the nearest Authorised service.
• The lifetime of your appliance stated and declared by the Department of the Industry
is 10 years (the period for retaining parts required for the proper functioning of the
appliance).

EN - 18 -
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
1
3
2
4
5
6
1. ICE TRAY / ICE MATIC *
2. FREEZER FLAPS
3. FREEZER BIG DRAWER
4. FREEZER DRAWERS
5. FREEZER BOTTOM DRAWER
6. LEVELLING FEET
In some models there is a shelf
with icematic in the top basket.
* In some models

UA - 19 -
Зміст
ПЕРЕД ВИКОРИСТАННЯМ МОРОЗИЛЬНОЇ КАМЕРИ ...................... 20
Загальні попередження .................................................................................20
Старі та несправні холодильники і морозильні камери ..............................22
Попередження щодо безпечного використання ..........................................23
Установка та експлуатація морозильної камери .........................................24
Перед використанням морозильної камери ................................................25
Інформація щодо технології сухого заморожування «No-Frost» ................25
ІНФОРМАЦІЯ ЩОДО ВИКОРИСТАННЯ ............................................. 26
Дисплей та панель управління .....................................................................26
Кнопка налаштування параметрів морозильної камери......................................26
Аварійний сигнал (Sr) .............................................................................................26
Експлуатація морозильної камери ...............................................................27
Режим швидкого заморожування ...............................................................27
Економічний режим ................................................................................................27
Налаштування температури морозильної камери ......................................27
Функція сигналізації відкривання дверцят ............................................................27
Попередження щодо регулювання температури.........................................27
Аксесуари .......................................................................................................28
Виготовлення кубиків льоду...................................................................................28
Піднос для льоду ....................................................................................................29
РОЗМІЩЕННЯ ПРОДУКТІВ .................................................................. 29
ЧИЩЕННЯ ТА ОБСЛУГОВУВАННЯ .................................................... 33
Розморожування ............................................................................................33
Заміна LED-освітлення...........................................................................................33
ТРАНСПОРТУВАННЯ ТА ПОВТОРНА УСТАНОВКА ......................... 34
Переустановлення дверей............................................................................34
ПЕРЕД ЗВЕРНЕННЯМ ДО ЦЕНТРУ ОБСЛУГОВУВАННЯ ................ 35
Поради щодо енергозбереження..................................................................37
КОМПОНЕНТИ ХОЛОДИЛЬНИКА ТА ЙОГО ВІДДІЛЕННЯ ............... 38
