Vestfrost VWF15FFE01W User manual

ELECTRONIC FREEZER
User manual
МОРОЗИЛЬНИК С
СИСТЕМОЙ ОХЛАЖДЕНИЯ NO FROST
VWF15FFE01W

EN - 2 -
Index
BEFORE USING YOUR FREEZER .....................................................3
SAFETY INSTRUCTIONS ...................................................................3
General Safety Warnings ............................................................................3
During Usage .............................................................................................. 7
Installation warnings....................................................................................8
Before using your freezer ............................................................................ 9
Information on No-Frost technology ............................................................ 9
USAGE INFORMATION ......................................................................10
Display and Control Panel..........................................................................10
Operating your Freezer ..............................................................................10
Alarm light ...........................................................................................................10
Freezer Temperature Set Button .........................................................................10
Super Freezer Mode ...........................................................................................10
Freezer Temperature Settings.............................................................................10
Warnings about temperature adjustments.................................................. 11
Accessories ................................................................................................12
Making Ice Cubes................................................................................................12
Ice tray.................................................................................................................12
PLACING THE FOOD .........................................................................12
CLEANING AND MAINTENANCE .....................................................16
Defrosting ...................................................................................................16
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION
17
Repositioning the door ............................................................................... 17
BEFORE CALLING AFTER-SALES SERVICE ..................................17
Warning: Risk of re / ammable materials

EN - 3 -
BEFORE USING YOUR FREEZER
SAFETY INSTRUCTIONS
General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
WARNING: In order to avoid any hazards resulting from the
instability of the appliance, it must be xed in accordance with
the instructions.
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler) you
should take care during transportation and installation to
prevent the cooler elements from being damaged. R600a is an
environmentally friendly and natural gas, but it is explosive. In
the event of a leak due to damage of the cooler elements,
move your fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a few
minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.

EN - 4 -
• Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.
• This appliance is intended to be used in household and
domestic applications such as:
- sta󰀨 kitchen areas in shops, o󰀩ces and other working
environments.
- farm houses and by clients in hotels, motels and other
residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, a service agent or similarly
qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with
a specially grounded socket of 16 amperes. If there is no
such socket in your house, please have one installed by an
authorised electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances. Children are not expected
to perform cleaning or user maintenance of the appliance,
very young children (0-3 years old) are not expected to use
appliances, young children (3-8 years old) are not expected to
use appliances safely unless continuous supervision is given,
older children (8-14 years old) and vulnerable people can

EN - 5 -
use appliances safely after they have been given appropriate
supervision or instruction concerning use of the appliance.
Very vulnerable people are not expected to use appliances
safely unless continuous supervision is given.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorised service agent or similar qualied
persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.
To avoid contamination of food, please respect the following
instructions:
• Opening the door for long periods can cause a signicant
increase of the temperature in the compartments of the
appliance.
• Clean regularly surfaces that can come in contact with food
and accessible drainage systems
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto other
food.
• Two-star frozen-food compartments are suitable for storing
pre-frozen food, storing or making ice cream and making ice
cubes.
• One-, two- and three-star compartments are not suitable for
the freezing of fresh food.
• If the refrigerating appliance is left empty for long periods,
switch o󰀨, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.

EN - 6 -
Old and Out-of-order Fridges
• If your old fridge or freezer has a lock, break or remove the lock before discarding it,
because children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm environment when you are discarding your old fridges.
CE Declaration of conformity
We declare that our products meet the applicable European Directives, Decisions and
Regulations and the requirements listed in the standards referenced.
Disposal of your old appliance
The symbol on the product or on its packaging indicates that this product may
not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city o󰀩ce, your
household waste disposal service or the shop where you purchased the product.
Packaging and the Environment
Packaging materials protect your machine from damage that may occur during
transportation. The packaging materials are environmentally friendly as they are
recyclable. The use of recycled material reduces raw material consumption and
therefore decreases waste production.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual
in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled and
our company will not be responsible for any losses incurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing
foods. It is not suitable for commercial or common use and/or for storing substances
except for food. Our company is not responsible for any losses incurred by inappropriate
usage of the appliance.

EN - 7 -
During Usage
• Do not connect your freezer to the mains electricity supply using an
extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by adults. Do not allow children to play
with the appliance or hang o󰀨 the door.
• Never touch the power cord/plug with wet hands. This may cause a short
circuit or electric shock.
• Do not place glass bottles or cans in your freezer as they will burst when
the contents freeze.
• Do not place explosive or ammable material in your freezer.
• When removing ice from the ice-making compartment, do not touch it.
Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or
ice cubes immediately after they are removed from the ice-making
compartment.
• Do not re-freeze thawed frozen food. This may cause health issues such as
food poisoning.
When the door of the freezer is closed, a vacuum seal will form. Wait for 1
minute before reopening it.
This application is optional for easy opening of the door. With this application, a little
condensation may occur around this area and you may remove it.

EN - 8 -
Installation warnings
Before using your freezer for the rst time, please pay attention to the following points:
• The operating voltage for your freezer is 220-240 V at 50Hz.
• The plug must be accessible after installation.
• Your freezer may have an odour when it is operated for the rst time. This is normal and
the odour will fade when your freezer starts to cool.
• Before connecting your freezer, ensure that the information on the data plate (voltage
and connected load) matches that of the mains electricity supply. If in doubt, consult a
qualied electrician.
• Insert the plug into a socket with an e󰀩cient ground connection. If the socket has no
ground contact or the plug does not match, we recommend you consult a qualied
electrician for assistance.
• The appliance must be connected with a properly installed fused socket. The power
supply (AC) and voltage at the operating point must match with the details on the name
plate of the appliance (the name plate is located on the inside left of the appliance).
• We do not accept responsibility for any damages that occur due to
ungrounded usage.
• Place your freezer where it will not be exposed to direct sunlight.
• Your freezer must never be used outdoors or exposed to rain.
• Your appliance must be at least 50 cm away from stoves, gas ovens and
heater cores, and at least 5 cm away from electrical ovens.
• If your freezer is placed next to a deep freezer, there must be at least 2 cm between
them to prevent humidity forming on the outer surface.
• Do not cover the body or top of freezer with lace. This will a󰀨ect the performance of your
freezer.
• Clearance of at least 150 mm is required at the top of your appliance. Do not place
anything on top of your appliance.
• Do not place heavy items on the appliance.
• Clean the appliance thoroughly before use (see Cleaning and Maintenance).
• Before using your freezer, wipe all parts with a solution of warm water and a teaspoon of
sodium bicarbonate. Then, rinse with clean water and dry. Return all parts to the freezer
after cleaning.
• Use the adjustable front legs to make sure your appliance is level and stable. You can
adjust the legs by turning them in either direction. This must be done before placing food
in the appliance.
• Install the two plastic distance guides (the parts on the black vanes -condenser- at the
rear) by turning it 90° (as shown in the gure) to prevent the condenser
from touching the wall.
• The distance between the appliance and back wall must be a maximum
of 75 mm.

EN - 9 -
Before using your freezer
• When using your freezer for the rst time, or after transportation, keep it
in an upright position for at least 3 hours before plugging into the mains.
This allows e󰀩cient operation and prevents damage to the compressor.
• Your freezer may have a smell when it is operated for the rst time. This
is normal and the smell will fade away when your freezer starts to cool.
Information on No-Frost technology
No-frost freezers di󰀨er from other static freezers in their operating
principle.
In normal freezers, the humidity entering the freezer due to opening
the door and the humidity inherent in the food causes freezing in
the freezer compartment. To defrost the frost and ice in the freezer
compartment, you are periodically required to turn o󰀨 the freezer,
place the food that needs to be kept frozen in a separately cooled
container and remove the ice gathered in the freezer compartment.
The situation is completely di󰀨erent in no-frost freezers. Dry and
cold air is blown into the freezer compartment homogeneously
and evenly from several points via a blower fan. Cold air dispersed
homogeneously and evenly between the shelves cools all of your food
equally and uniformly, thus preventing humidity and freezing.
Therefore your no-frost freezer allows you ease of use, in addition to
its huge capacity and stylish appearance.

EN - 10 -
USAGE INFORMATION
Display and Control Panel
1 2 3 4
Using the Control Panel
1. Freezer temperature set button
2. Super freeze symbol (Super freeze LED)
3. Alarm symbol (Alarm LED)
4. Freezer adjusted temperature indicator
Operating your Freezer
Alarm light
In case of a problem within the freezer, the alarm led will release red light.
Freezer Temperature Set Button
This button allows setting temperature of the freezer. In order to set values for freezer
partition, press this button. Use this button also to activate super freeze mode.
Super Freezer Mode
When Would It Be Used?
• To freeze huge quantities of food.
• To freeze fast food.
• To freeze food quickly.
• To store seasonal food for a long time.
How To Use?
• Press temperature set button until super freezing light comes on.
• Super freezing led will light during this mode.
• Maximum amount of fresh food (in kilograms) to be frozen within 24 hours is shown on
the appliance label.
• For optimal appliance performance in maximum freezer capacity, set the appliance to
active super freeze mode 24 hours before you put the fresh food into the freezer.
During This Mode:
If you press temperature set button, the mode will be cancelled and the setting will be
restored from -16.
Freezer Temperature Settings
• The initial temperature of the setting display is -18 °C.
• Press freezer setting button once.

EN - 11 -
• Every time you press the button, the setting temperature will decrease. (-16 °C, -18 °C,
-20 °C,.. super freezing)
• If you press freezer setting button until super freezer symbol is displayed on freezer.
• Settings display and you do not press any button within the following 3 seconds, super
freezing will blink.
• If you keep on pressing, it will restart from last value.
Recommended Temperature Values for Freezer
When to adjust Inner Temperature
For minimum freezing capacity -16 oC, -18 oC
In normal usage -18 oC, -20 oC, -22 oC
For maximum freezing capacity -24 oC
Warnings about temperature adjustments
• It is not recommended that you operate your fridge in environments colder than 10°C in
terms of its e󰀩ciency.
• Temperature adjustments should be made according to the frequency of door openings
and the quantity of food kept inside the fridge.
• Do not pass to another adjustment before completing an adjustment.
• Your fridge should be operated up to 24 hours according to the ambient temperature
without interruption after being plugged in to be completely cooled. Do not open doors
of your fridge frequently and do not place much food inside it in this period.
• A 5 minute delaying function is applied to prevent damage to the compressor of your
fridge, when you take the plug o󰀨 and then plug it on again to operate it or when an
energy breakdown occurs. Your fridge will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals stated in the
standards, according to the climate class stated in the information label. We do not
recommend operating your fridge out of stated temperatures value limits in terms of
cooling e󰀨ectiveness.
• This appliance is designed for use
at an ambient temperature within the
10°C - 43°C range.
Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
T/SN Between 10 and 43 (°C)
Important installation instructions
This appliance is designed to work in di󰀩cult climate conditions (up to 43 degrees C or 110
degrees F) and is powered with ‘Freezer Shield’ technology which ensures that the frozen
food in the freezer will not defrost even if the ambient temperature falls as low as -15 °C.
So you may then install your appliance in an unheated room without having to worry about
frozen food in the freezer being spoilt. When the ambient temperature returns to normal,
you may continue using the appliance as usual.

EN - 12 -
PLACING THE FOOD
• The freezer compartment is used for freezing fresh food, for storing frozen foods for the
period of time indicated on packaging and for making ice cubes..
• Do not put fresh and warm food next to frozen food as it can thaw the frozen food.
• While freezing fresh foods (i.e. meat, sh and mincemeat) divide them in portions you
will use in a single serving.
• For storing frozen foods, the instructions shown on frozen food packages should always
be followed carefully. If no information is provided, food should not be stored for more
than 3 months from the purchased date.
• Maximum load: if you want to store large quantities of food and use the maximum net
capacity of the freezer, you can remove all the sliding drawers but you should keep
the upper shelf aps. Thanks to this, it is possible to store bulky items directly on the
shelves.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.
• Frozen food should be transported in appropriate containers to maintain the quality of
the food and should be returned to the freezing surfaces of the unit in the shortest
Accessories
Making Ice Cubes
• Pull the lever towards you and remove the ice maker
tray
• Fill with water to the level of line
• Hold the left end of the lever and set the ice-tray on
the icebox
• When ice cubes are formed, twist the lever to drop ice
cubes into the ice box.
Do not ll the icebox with water in order to make ice.
It can break.
(In some models)
Ice tray
• Fill the ice tray with water and place in freezer compartment.
• After the water completely turned into ice, you can twist the tray as shown below to get
the ice cube.
(In some models)

EN - 13 -
Dairy Products Preparation Maximum Storing
time (months) Storing Conditions
Packet
(Homogenize) Milk In its own packet 2 - 3 Pure Milk – In its own packet
Cheese-excluding
white cheese In slices 6 - 8
Original package may
be used for short storing
period. It should be
wrapped in foil for longer
periods.
Butter, margarine In its package 6
A+ models
If there is a power cut or malfunction, do not open the door. This will help maintain the
temperature inside the freezer, ensuring that foods are conserved for about 15 hours at
25°C. Do not re-freeze food that is defrosting or that has already been defrosted. These
foods must be cooked and eaten.
possible time.
• If a package of frozen food shows signs of humidity and abnormal swelling it is probable
that it has been previously stored at an unsuitable temperature and that the contents
have deteriorated..
• The storage life of frozen foods depends on the room temperature, thermostat setting,
how often the door is opened, the type of food and the length of time required to transport
the product from the shop to your home. Always follow the instructions printed on the
packaging and never exceed the maximum storage life indicated.
If you would use maximum freezing capacity of your freezer:
• While freezing fresh foods, the maximum amount of fresh food (in kg) that can be
frozen in 24 hours is indicated on the appliance label. (your refrigerator has the
capacity to freeze 25 kg at 25°C ambient)
• For optimum appliance performance to reach maximum freezing capacity, activate
Super Freeze (SF) mode 24 hours before placing fresh food into the freezer.
• After placing fresh food into the freezer, 24 hours is generally su󰀩cient for freezing.
”Super Freeze” mode will be deactivated automatically in 2-3 days to save energy.
If you would freeze a small amount (up to 3 kg) in your freezer:
• Place your food without touching already frozen food and activate “Fast Freezing”
mode. You can put your food next to other frozen food after it is completely frozen (after
minimum 24 hours).
• Do not re-freeze frozen food after it has thawed. This may cause health issues, such as
food poisoning.
• Allow hot food to completely cool down before placing it in the freezer.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.

EN - 14 -
Meat and sh Preparation
Maximum
Storing time
(month)
Steak Wrapping in a foil 6 - 8
Lamb meat Wrapping in a foil 6 - 8
Veal roast Wrapping in a foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packages without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be packaged even if it has
membrane
Chicken and turkey Wrapping in a foil 4 - 6
Goose and Duck Wrapping in a foil 4 - 6
Deer, Rabbit, Wild Boar In 2.5 kg portions and as llets 6 - 8
Fresshwater shes (Salmon,
Carp, Crane, Siluroidea) After cleaning the bowels and
scales of the sh, wash and dry
it; and if necessary, cut o󰀨 the tail
and head.
2
Lean sh; bass, turbot,
ounder 4
Fatty shes (Tunny, Mackarel,
bluesh, anchovy) 2 - 4
Shellsh Cleaned and in bags 4 - 6
Caviar In its package, aluminium or
plastic container 2 - 3
Snails In salty water, aluminum or plastic
container 3
Note: Frozen meat should be cooked as fresh meat after being thawed. If the meat
is not cooked after being thawed, it must not be re-frozen.
Maximum Storing
time (months)
Thawing time in
room temperature
(hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)

EN - 15 -
Vegetables and Fruits Preparation
Maximum
Storing time
(months)
String beans and beans Wash and cut into small pieces and boil in
water 10 - 13
Beans Hull and wash and boil in water 12
Cabbage Cleaned and boil in water 6 - 8
Carrot Clean and cut to slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove
the core and boil in water 8 - 10
Spinach Washed and boil in water 6 - 9
Cauliower
Take the leaves apart, cut the heart into
pieces, and leave it in water with a little
lemon juice for a while
10 - 12
Eggplant Cut to pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet
corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12
Cooked fruits Adding 10 % of sugar in the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12

EN - 16 -
CLEANING AND MAINTENANCE
evaporating container
• Disconnect the unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp housing and other electrical
components.
• The freezer should be cleaned periodically using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately with soap and water Do not
clean them in the dishwasher.
• Do not use abrasive products, detergents or soaps. After washing, rinse
with clean water and dry carefully. When you have nished cleaning,
reconnect the plugto the mains supply with dry hands.
• Clean the condenser with a broom at least twice a year. This will help
you to save on energy costs and increase productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
Defrosting
Your freezer has fully automatic defrosting. The water
formed as a result of defrosting passes through the
water collection spout, ows into the vaporisation
container below the condenser and evaporates there.
Replacing LED Lighting
Depending on the model, one LED strip in the freezer
is used to illuminate the interior of your appliance.
To replace any of the LEDs, please contact the
nearest Authorised Service Centre.
Some versions may not include freezer
illumination.
LED strip

EN - 17 -
Repositioning the door
• It is not possible to change the opening direction of your freezer door, if the door handle
on your freezer are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any handle.
• If the door opening direction of your freezer may be changed, you should contact the
nearest authorised service to have the opening direction changed.
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION
• The original packages and foamed polystyrene (PS) can be retained if required.
• During transportation, the appliance should be secured with a wide string or a strong
rope. The instructions written on the corrugated box must be followed while transporting.
• Before transporting or changing the installation
position, all the moving objects (ie, drawer, Ice trays,
…) should be taken out or xed with bands in order
to prevent them from getting damaged.
Carry your freezer in the upright position.
BEFORE CALLING AFTER-SALES SERVICE
Errors
Your freezer will warn you if the temperatures for the freezer is at improper levels or if a
problem occurs with the appliance. In case of a problem within the freezer, the alarm led
will release red light.
Alarm
indicator LED
is turning on
MEANING WHY WHAT TO DO
"Failure" Warning
There is/are some
part(s) out of order or
there is a failure in the
cooling process.
The product is plugged
for the rst time or
a long-time power
interruption for 1 hour.
Check the door is open or not and check
if the product working 1 hour. If the door
is not open and the product had worked
1 hour, call service for assistance as
soon as possible.
If you are experiencing a problem with your freezer, please check the following before
contacting the after-sales service.
Your freezer is not operating
Check if:
• There is power
• The plug is correctly placed in the socket
• The plug fuse or the mains fuse has blown
• The socket is faulty. Examine this by plugging your freezer into a working socket.
What to do if your appliance performs poorly;
Check that;
• You have not overloaded the appliance,
• The freezer temperature set to -16,

EN - 18 -
• The doors are closed perfectly,
• There is no dust on the condenser,
• There is enough place at the rear and side walls.
Your freezer is operating noisily
Normal noises
Cracking (ice cracking) noise occurs:
• During automatic defrosting
• When the appliance is cooled or warmed (due to expansion of appliance material).
Short cracking noise occurs: When the thermostat switches the compressor on/o󰀨.
Motor noise: Indicates the compressor is operating normally. The compressor may
cause more noise for a short time when it is rst activated.
Bubbling noise and splash occurs: Due to the ow of the refrigerant in the tubes of
the system.
Water owing noise occurs: Due to water owing to the evaporation container. This
noise is normal during defrosting.
Air blowing noise occurs: In No-Frost freezers during normal operation of the system
due to the circulation of air.
The edges of the freezer in contact with the door joint are warm
Especially during summer (warm seasons), the surfaces in contact with the door joint may
become warmer during the operation of the compressor, this is normal.
The door does not open or close properly
Check if:
• There is food or packaging preventing the door from closing
• The door joints are broken or torn
• Your freezer is on a level surface.
Important Notes:
• In the case of a power failure, or if the appliance is unplugged and plugged in again,
the gas in the cooling system of your freezer will destabilise, causing the compressor
protective thermal element to open. Your freezer will start to operate normally after 5
minutes.
• If the appliance will not be used for a long period of time (such as during holidays),
disconnect the plug. Defrost and clean the freezer, leaving the door open to prevent the
formation of mildew and odour.
• If the problem persists after you have followed all the instructions above, please consult
the nearest Authorised Service Centre.
• This appliance is designed for domestic use and for the stated purposes only. It is not
suitable for commercial or common use. If the consumer uses the appliance in a way
that does not comply with these instructions, we emphasise that the manufacturer and
the dealer will not be responsible for any repair or failure within the guarantee period.

EN - 19 -
1 TIPS FOR SAVING ENERGY
1. Install the appliance in a cool, well-ventilated room, but not in direct sunlight and not
near a heat source (such as a radiator or oven) otherwise an insulating plate should be
used.
2. Allow warm food and drinks to cool before placing them inside the appliance.
3. Drinks or other liquids should be covered when inside the appliance. If left uncovered,
the humidity inside the appliance will increase, therefore the appliance uses more
energy. Keeping drinks and other liquids covered helps preserve their smell and taste.
4. Avoid keeping the doors open for long periods and opening the doors too frequently as
warm air will enter the appliance and cause the compressor to switch on unnecessarily
often.
5. The door gasket must be clean and pliable. In case of wear, if your gasket is detachable,
replace the gasket. If not detachable, you have to replace the door.

EN - 20 -
2 DESCRIPTION OF THE APPLIANCE
1
2
3
4
5
This presentation is only for information about the parts of the appliance. Parts may
vary according to the appliance model.
1. Control panel
2. Freezer aps
3. Freezer drawers
4. Levelling feet
5. Ice tray (In some models)
In some models there is a shelf with icematic in the top basket
