VETERAN 20V Max V20L3AP0K1 User manual

1
CORDLESSAIRPUMPModel:V20L3AP0K1
Pleasereadthecompleteusermanualbeforeuse.
GENERALSAFETYWARNINGSFORTHETOOL
WARNINGReadallsafetywarningsandinstructions.Failure to follow all warnings and instructions
may result in electric shock, fire and/or serious injury.
SAVETHESEINSTRUCTIONSFORFUTUREREFERENCE.
DANGER:Do not allow any liquid to come into contact with the charger. If the battery pack is cracked or damaged in
any other way, do not insert it in the charging base. There is a danger of electric shock or electrocution.
The term “power tool” in this manual refers to the V20L3AP0K1Cordless Air Pump, associated Battery and Charger.

2
GENERALPOWERTOOLSAFETY,USEANDCARE
Workareasafety
oVisibility is key -- keep work area clean and well lit. Cluttered and dark areas invite accidents.
oProper protective gear (safety goggles/glasses, etc.) is required when using this tool.
oDo not operate in the presence of flammable liquids, gasses, or dust. The operation of power tools creates
sparks which may ignite the dust or fumes, creating a potentially explosive atmosphere.
oAvoid distractions by working at a safe distance from any bystanders, children or pets.
Electricalsafety
oPower tool and battery charger plugs must match the outlet to reduce the risk of electric shock. Never modify
the plug in any way. Unmodified plugs and matching outlets will reduce risk of electric shock.
oAvoid bodily contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
oDo not expose power tools, batteries or charger to rain or wet conditions. Water can irreparably damage the
tool, battery and charger and increases the risk of electric shock.
oDo not abuse the cord. Never use the cord for carrying or pulling/unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
oIf the use of a charger in a damp indoor location is unavoidable, use a ground fault circuit
interrupter/residual current device (GFCI/RCD) protected supply. The use of an GFCI /RCD reduces the risk
ofelectric shock.
Personalsafety
oUse care and caution when operating any power tool. Do not use a power tool while you are under the
influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in
serious personal injury.
oAlways wear eye protection. The use of personal protective equipment such as a dust mask, non-skid safety
shoes, hard hat, or hearing protection used will reduce the risk of personal injuries.
oDress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair can be caught in moving parts.
oPrevent unintentional starting. Your finger should remain clear of the operating switch whenever you are not
intentionally using the tool. Ensure the switch is in the off position before connecting to the battery pack,
picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power
tools that have the switch on invites accidents.
oKeep proper footing and balance at all times. This enables better control of the power tool in unexpected
situations. Do not overreach.
oIf devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can reduce dust related hazards.

3
GeneralPowertooluseandcare
oDo not force the power tool. Use the correct power for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
oDo not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
oDisconnect the plug from the power source and/or the battery pack from the power tool before making any
adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
oStore power tools out of the reach of children and do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
oMaintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other
condition that may affect the power tools operation. If damaged, have the power tool repaired before use
oKeep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely
to bind and are easier to control.
oUse the power tool, accessories, and tool bits etc. in accordance with these instructions,taking into account
the working conditions and the work to be performed. Use of the power tool for operations different from
intended could result in a hazardous situation.
oEnsure the switch is in the “off” position before inserting battery pack. Inserting the battery pack into power tools
that have the switch in the “on” position can result in an unplanned activation and cause serious injury.
oRecharge only with the charger specified by the manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with another battery pack.
oUse power tools only with specifically designated battery packs. Use of any other battery packs may create a
risk of injury and fire.
oWhen battery packs are not in use, keep them away from other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can make a connection from one terminal to another. Shorting
the battery terminals together may cause burns or a fire.
oUnder abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
oDo not store or charge batteries in a location subject to extreme temperatures. Recommended temperature
range for charging is 32 to 113 degrees Fahrenheit. Recommended temperature range for discharge/use is -4
to 140 degrees Fahrenheit.
Service
oHave your power tool serviced by qualified repair person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained

4
SPECIALSAFETYINSTRUCTIONSforLithium‐IonBatteryPacks
oAlways charge the battery when the temperature is between 18-24°C (32°F to 113°F). Do not charge the
battery pack when the temperature is below 0°C (32°F), or above 40°C (113°F) This is important. Failure to
observe this safety rule could cause serious damage to the battery pack.
oThe battery is to be disposed of safely. Do not dispose of the battery pack by incinerating the battery pack .
The battery pack can explode in a fire.
oNever attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks
open or cracks, immediately discontinue its use and do not recharge it.
oDo not store or carry a spare battery pack in a pocket or toolbox or any other place where it may come into
contact with metal objects. The battery pack may be short circuited causing damage to the battery pack,
burns or a fire. If storing or disposing the battery pack, cover the terminals with a heavy insulation tape to
ensure short circuit cannot occur.
oBatteries, when stored for a long period of time, will discharge. If the battery pack has been stored for a long
time, you should charge the battery pack first before using it.
oAllow the battery pack to cool down after charging. Do not place it in a hot environment such as near a fire,
in a metal shed or open trailer left in the sun, etc. The best storage place is one that is cool and dry away
from direct sunlight and excess heat or cold.
oOnly charge the battery with the charger supplied.
oDo not splash or immerse in water or other liquids. This may cause premature cell failure.
oA small leakage of liquid from the battery pack may occur under extreme usage or temperature. This does
not necessarily indicate a failure of the battery pack. However, extra care should be taken during cleanup,
including wearing chemical-resistant rubber gloves, eye protection and other protective garb. The fluid can
damage clothing or skin upon contact. After donning appropriate safety wear, wipe battery with a
disposable dry rag to fully remove fluid and then dispose of rag appropriately.
Iftheoutersealisbrokenandthisleakagecomesintocontactwithyourskin:
Wash the affected area quickly with soap and water.
Neutralise the liquid with a mild acid such as lemon juice or vinegar.
Iftheleakagegetsinyoureyes:
Flush your eyes with clean water for a minimum of 10 minutes and seek immediate medical
attention. Inform the medical staff that the liquid is a 25-35% solution of potassium hydroxide.
IFIRRITATIONPERSISTSORFLUIDISINGESTED,SEEKIMMEDIATEMEDICALATTENTION!

5
EXTRASAFETYREGULATIONSCONCERNINGBATTERYCHARGER
oBefore using the charger, read all the instructions and cautionary markings on the charger and battery pack
as well as the instructions on the battery pack.
oThis model V20L0CH2B1 charger and VETERAN TOOL battery models V20L0BP2B1, V20L0BP4B1 and
V20L0BP5B1 are specifically designed to work together. Do not attempt to charge the battery pack with any
other charger than the one supplied or attempt to use this charger to charge other batteries.
oIf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
oOnly charge your battery pack indoors as the charger is designed for indoor use only..
oDo not place any object on top of the charger as it could cause overheating. Do not place the charger near any
heat source.
oPull on the plug end of the charger power cord to disconnect it from the outlet. Do not pull on the cord.
oMake sure that the charger cord is positioned where it will not be stepped on, tripped over or otherwise
subjected to damage or stress.
oDo not use an extension cord unless absolutely necessary. The use of an improper extension cord could cause
the risk of fire, electric shock or electrocution.
oDo not use the charger if it has been subjected to a heavy impact, dropped or otherwise damaged in any way.
Take the charger to an authorized service centre for a check or repair.
oDo not disassemble the charger. Take it to an authorized service centre when service or repair is required.
Incorrect re-assembly may result in the risk of fire, electric shock or electrocution.
oTo reduce the risk of an electric shock, unplug the charger from the power supply before attempting to clean
it. Removing the battery pack alone does not reduce the risk.
oThe charger is designed for use from a standard household electrical supply. Do not attempt to connect the
charger to a supply with a different voltage.
oThe charger is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the charger by a person responsible for their safety.
oChildren should be supervised to ensure that they do not play with the charger.
oDo not expose charger to rain or snow.
oDo not mount charger on wall or permanently affix charger to any surface. The charger is intended to use on
a flat, stable surface (i.e. table top, bench top)
oNever attempt to connect two chargers together.
oNever insert any objects into the charger’s air vents. Electric shock or damage to the battery charger may
result.
oDisconnect the charger from the outlet before attempting any cleaning. This will reduce the risk of electric
shock. Removing the battery pack will not reduce this risk.
oNever recharge a fully charged battery cartridge. Remove battery once fully charged.
oDo not attempt to charge non-rechargeable batteries.

6
SPECIALSAFETYINSTRUCTIONSforV20L3AP0K1PortableInflator
oInspect the Inflator before each use and do not use if any of the components are wet or damaged.
oEnsure that the inflator nozzle is fully engaged and in the locked position before starting the tool. An
unsecured air nozzle could result in personal injury or damage to property.
oTake care to review the maximum recommended air pressure of the object being inflated, and do not
exceed the recommended air pressure. Overinflation can result in catastrophic failure of the object being
inflated and could result in serious injury or death.
oDo not use the tire inflator on high pressure tires such as those used on commercial vehicles, agricultural or
specialist vehicles.
oDo not kink or block the air hose while the tire inflator is working.
oDo not use the tire inflator when the vehicle is moving.
oThe tire inflator is not designed for continuous use. Operation over an extended period of time will
overheat and damage the tire inflator. It should not be used continuously for more than 30 minutes. After
10 minutes, turn it off and let it cool for 15 minutes before resuming operation.
oIf the tire inflator is making an abnormal sound, or the temperature of the unit is too high, turn the power
off immediately and let it cool for at least 30 minutes before resuming operation.
oDo not leave the tire inflator unattended when operating and keep out of the reach of children.
oWhen not in use store the tire inflator in a cool, dry and dust free environment in the box.
oDo not place the tire inflator on or near sources of direct heat or in locations where it will be exposed to
direct sunlight for prolonged periods of me.
oDo not operate the tire inflator in or around flammable environments.
oOnly use the adapters supplied with the tire inflator.
oThe Tire inflator is not waterproof.
oEnsure cables and hoses connected to the Tire inflator do not interfere in the safe opera on of your vehicle.
oNever put the connector and adaptors into your mouth, ear or eye, they are not toys.
oThe inflator contains no user serviceable parts – Do not open.
oFor your own safety be sure to follow the instructions carefully when using the Tire inflator. Misuse of the
inflator could lead to injury.
oNo alterations should be made to the Tire inflator, attachments or adaptors supplied by the manufacturer.
oImproper use of the inflator can cause damage to property and possibly harm the user. When using the
Digital Tire inflator ensure the vehicle is parked in a safe location where your personal safety is not at risk.
oBefore inflating a tire mounted to a car, truck or other vehicle, ensure that the vehicle is incapable of
movement. The use of the parking brake and wheel chock blocks is highly recommended.
oAvoid using solvents when cleaning plastic parts. Most plastic parts are susceptible to damage from various
types of commercial solvents and may be damaged by their use. Use clean clothes to remove dirt, carbon
dust, etc. Ensure the Tire inflator is clear of any dust or other debris before connection.

7
USEANDMAINTENANCEOFV20L3AP0K1CORDLESS
AIRPUMPWITHINTEGRATEDPRESSUREGAUGE
LISTANDLOCATIONOFMAINPARTS
1 Trigger 2 Storage clips
3 Gauge 4 Schrader inflator
5 Ball attachment 6 Inflatable attachment
7 Schrader to Presta convertor 8 Charger
9 Battery pack
TechnicalSpecifications
Cordless Inflator with Pressure Gauge V20L3AP0K1
Measurement Range Max: 160Psi/11 Bar/1100 KPa
Measurement Accuracy +1 Psi, 25°C
Air Hose Length 15.75”
Battery V20L0BP2B1 Li-ion 2000mAh
Rated voltage of battery 20V MAX
Charger V20L0CH2B1 Input :100-240V ~ 50/60Hz 60W
Output : 20VDC, 2.0A
Charging time 1h
Ambient condition limits From 5°C to 40°C

8
BEFOREUSINGTHEEQUIPMENT
Remove any packing material and loose parts from unit.
Check the accessories before use. They should fit with the machine and your purpose.
If the battery is new it should be fully charged before use. Batteries are shipped with only a partial charge.
NOTE:Extendedperiodsofstoragewithoutcharge/dischargecycleswillreducethebatterycapacity.
A new battery or one which has not been used for an extended period achieves full performance only after charging
and discharging cycles. A substantial drop in operating period per charge indicates that the battery is worn out and
must be replaced.
USEOFBATTERYCHARGER
The lithium-ion battery can be charged at any time and will not develop a “memory” when charged after only a
partial discharge. It is not necessary to run down the battery pack charge before recharging. Remove the battery pack
from the tool when convenient for you and your job. You can “top-off” your battery pack’s charge before starting a big
job or long period of use.
1. Chargingthebattery
This lithium-ion battery pack is shipped partially charged. Before using it the first time, fully charge the battery pack.
A fully discharged battery pack with a temperature between 0℃and 40℃will charge in about 1 hour.
Plug the charger adapter into power source. The green light on the charger
stand will illuminate, indicating the charger is powered.
Slide the battery all the way into the charger until it locks in place with a
click. The red light on the charger will illuminate, indicating that the battery
is charging.
When charging is complete the red light will be replaced by a green light.
NOTE:Batteriesmaybecomewarmwhilecharging.Thisisnormal.Ifitishotaftercontinuoususeinthetool,
allowittocooldowntoroomtemperaturebeforecharging.Thiswillextendthelifeofyourbatteries.
WARNING: Always disconnect the battery pack from the tool before any adjustments or changing accessories.
2. Insertingandremovingrechargeablebattery
Hold the tool with one hand and the battery pack with the other.
To install: push and slide battery pack into battery port, make
sure the release latch on the rear side of the battery snaps into
place and battery is secure before beginning operation.
To remove: Press the battery release latch and pull the battery
pack out at the same time.

9
USEOFAIRPUMPANDPRESSUREGAUGE
PictureoftheCompressor’sPanel
BLUEmarkingsindicate
pressuremeasuredinBar
BLACKmarkingsindicate
pressuremeasuredinPSI

1. TireChecks
Note:Incorrect inflation shortens the life and performance of your tires, increasing fuel consumption and
jeopardizing safety. For best results, check tire pressure on at least a monthly basis and prior to any long trips.
To check tire pressure, attach air pump head to valve stem and pivot the locking lever to seat the head.
2. VehicleTireInflation
Note:Only inflate tires to the manufacturer’s specifications. Vehicle Tire pressures can generally be found in the
handbook, on the door pillar or on the inside of the fuel filler cap.
Uncoil the hose on the side of the air pump and insert the battery.
Remove the dust cap from the Tire valve and store in a safe place.
Plug the air hose’s valve tip directly onto the ’s air valve, then press
the lever down to lock it tightly.
Press to select pressure gauge measurement from Bar, kPa and Psi
and inflate to the desired pressure. When done, unhook air pump
and replace dust cap.
3. UsewithInflatableRecreationalItems
Note:Onlyinflateproductstothemanufacture’sspecifications.
When not in use, the adaptors for sports balls and the adaptor for inflatables like air mattresses, water toys, etc. can be
clipped to the back of the inflator for organized storage.
Select the appropriate adapter and screw into the valve connector then insert the connector adapter into the appropriate
inlet of the inflatable and inflate to the proper level.
When proper level is reached, remove valve connector and adaptor from the inlet, close the inlet and return the adaptor
to the storage mount on the inflator.

10
DESCRIPTIONOFSYMBOLSUSEDONTHE
TOOL,BATTERY,CHARGERANDMANUAL
Onthetool:
Read instructions carefully before any use.
Complies with relevant European regulations.
The crossed-out wheeled bin symbol indicates that the item should be disposed of
separately from household waste and handed in for recycling in accordance with local
environmental regulations for waste disposal.
Onthebattery:
Do not expose the battery to water
Do not expose the battery to fire or incinerate.
Do not expose the battery to high temperatures (above 40°C)
Onthecharger:
Class II machine – Double insulation – grounded plug not needed.
Use this device indoors only.
Fuse
