36" CIRCULATING LOUVERED FIREBOX
OWNER’S INSTALLATION MANUAL
C36EMW-RC with Brushed
Brass Finish Bi-fold Doors
C36EMW-RBC with Black
Finish Bi-fold Doors
C36EMW-RPLC with Platinum
Finish Bi-fold Doors
Includes Manual
Control Fan System
and Combustion
Air Kit
O-TL REPORT # 114-F-20-4

www.desatech.com 124558-01A2
TABLE OF CONTENTS
Safety .................................................................. 2
Specications ...................................................... 3
Fireplace Installation............................................ 3
Venting Installation .............................................. 6
Optional Gas Line Installation............................ 13
Finishing Fireplace ............................................ 15
Operation and Maintenance Guidelines ............ 15
Replacement Parts............................................ 17
Technical Service............................................... 17
Accessories ....................................................... 18
SAFETY
CAUTION: The structural
integrity of the mobile home
oor and ceiling/roof must be
maintained.
WARNING: Do not install a
replace insert in this box unless
the manufacturer's instructions
with the insert specically state
this replace has been tested for
use with the insert.
FOR YOUR SAFETY
• Do not store or use gasoline
or any other ammable vapors
or liquids in the vicinity of this
or any other appliance.
• Due to high temperatures, the
appliance should be located
out of trafc and away from
furniture and draperies.
• Do not place clothing or other
ammable materials on or near
the appliance.
• Never leave children unat-
tended when a re is burning
in the replace.
This replace is not intended to
be used as a substitute for a fur-
nace to heat an entire home. Use
for supplemental heat only.
This wood burning fireplace
complies with the UL 127 stan-
dard as a FACTORY BUILT FIRE-
PLACE and is listed and tested
by OMNI Test Laboratories.
WARNING: Improper instal-
lation, adjustment, alteration,
service or maintenance can
cause injury, propertydamageor
loss of life. Refer to this manual
for assistance or additional in-
formation. Consult a qualied
installer or local distributor.
IMPORTANT: Check HUD re-
quirements before installing this
replace.
The C36EMW Series is specically designed
for use in manufactured mobile homes. These
replaces include a manual control fan sys-
tem, combustion air kit and bi-fold doors.
Before beginning the installation of the
fireplace, read these instructions through
completely.
• This Style Crest replace and its compo-
nents are safe when installed according
to this installation manual. Unless you use
Style Crest approved components, which
have been designed and tested for the
replace system, you may cause a re
hazard.
• The Style Crest warranty will be voided by
and Style Crest disclaims any responsibil-
ity for the following actions.
a. Modication of the replace, compo-
nents, doors, blower, fans, air inlet
system and damper control.
b. Use of any component part not manu-
factured or approved by Style Crest
in combination with a Style Crest
replace system.
Proper installation is the most important step
in ensuring safe and continuous operation of
the replace. Consult the local building codes
as to the particular requirements concerned
with the installation of all factory built replac-
es. Although grounding may not be required
by code, the manufacturer recommends it.

www.desatech.com
124558-01A 3
SPECIFICATIONS
42"
361/4"331/4"
221/8"
63/4"
73/4"
93/8"
3"
36"
41"
1"
J-Box
Access
RH SIDE VIEW
LH SIDE VIEW
Gas Line Conduit
Sleeve (Both Sides)
1/2" Air Space
Back and Sides
0" To To p
Spacer
Round To p Te rmination
Storm Collar
Flashing
Firestop
1" Airspace
To Combustible
Materials
Combustible
Wall Board
No Combustible
Material On Face
Not Less Than 14"
To Perpendicular
Sidewall
Hearth Extension
52" x 16"
0" To
Bottom
8" Each
Side
221/16"
5/8"
13"
Rear View
of Fireplace Opening for
Outside Air
Firestop
Thimble
91/2"
14"
14"
FIREPLACE INSTALLATION
SELECTING LOCATION
To determine the safest and most efcient
location for the replace, you must take into
consideration the following guidelines:
1. The location must allow for proper clear-
ances (see Figures 1 and 2, page 4).
2. Consider a location where the heat output
will not be affected by drafts, air condition-
ing ducts, windows or doors.
3. A location that avoids the cutting of
joists or roof rafters will make installation
easier.
4. An outside air kit is available with this
replace (see Outside Air Kit on page 6).
WARNING: Do not install this
appliance in a bedroom.

www.desatech.com 124558-01A4
MINIMUM CLEARANCE TO
COMBUSTIBLES
Back and sides of replace 1/2" minimum*
Floor** 0" minimum
Wall to front of replace 36" minimum
Perpendicular wall to opening 14" minimum
Top spacers 0" minimum
Mantel clearances see Mantels,
page 15
Chimney outer pipe surfaces 1" minimum
* Not required at nailing anges
** See step 2 of Framing, page 5
WARNING: Do not pack re-
quired air spaces with insulation
or other materials.
Minimum/Maximum Chimney Height
Minimum height ofthe chimney, measured
from base of replace to ue gas outlet of
termination, is 14 feet* for straight ue or a
ue with one elbow set. Maximum distance
between elbows is 2 feet.
13" Min.
Maintain 1/2" Air Space
Between Framing
and Fireplace 43 5/8"
Min.
41 3/4" Min.
61 11 /16"Min.
Figure 2 - Corner Installation
FIREPLACE INSTALLATION
Continued
Maximum height of any system is 40 feet.*
This measurement includes replace, chim-
ney sections and height of termination assem-
bly at level of ue gas outlet (see Figure 3).
*For manufactured home application, minimum
height is 11' for straight ue or ue with one elbow
set. Maximum height of any system is 20'.
Figure 3 - Standard and Alternate
Venting Installation
Effective Height of
Te rmination Cap
Effective Height of
Termination Cap
Effective Height of
Te rmination Cap
RT-8DM RT-8DM
RT-8DM
14' Min.
Height
Standard Installation Alternate Installation
2' Max
Pipe Length 30E-8DM
11 ' for
Manufactured
Home
Application
14' Min.
Height
11 ' for
Manufactured
Home
Application
40' Max.
Height
20' for
Manufactured
Home
Application
Effective Height of
Te rmination Cap
Effective Height of
Termination Cap
Effective Height of
Te rmination Cap
RT-8DM RT-8DM
RT-8DM
14' Min.
Height
Standard Installation Alternate Installation
2' Max
Pipe Length 30E-8DM
11 ' for
Manufactured
Home
Application
14' Min.
Height
11 ' for
Manufactured
Home
Application
40' Max.
Height
20' for
Manufactured
Home
Application
Standard
Installation
Alternate
Installation
Alternate
Installation
42 1/4"
41 3/4"
22 5/8"
10"
Figure 1 - Framing Dimensions

www.desatech.com
124558-01A 5
Figure 4 - Nailing Flanges
Screw
or Nail
Nailing
Flange
FIREPLACE INSTALLATION
Continued
Figure 5 - Hearth Extension
Seal Gap
Fireplace
Front
Ember
Protector
Ember
Protector
Seal Gap Hearth
Extension
FRAMING
1. Frame opening for replace using dimen-
sions shown in Figures 1 and 2.
2. If replace is to be installed directly on
carpeting, tile (other than ceramic) or any
combustible material other than wood
ooring, replace must be installed on a
metal or wood panel extending full width
and depth of replace. (It is acceptable to
cover two outside ends or columns of top
louver panel leaving four center columns
open).
3. Set replace directly in front of this open-
ing and slide unit back until nailing anges
touch side framing.
4. Check level of replace and shim with
sheet metal if necessary.
5. Before securing replace to prepared fram-
ing, metal ember protector (provided) must
be placed between hearth extension (not
supplied) and under bottom front edge of
replace to protect against glowing embers
falling through. If replace is to be installed
on a raised platform, a Z-type ember pro-
tector (not supplied) must be fabricated to
t your required platform height. Ember
protector should extend under replace
a minimum of 1 1/2". The ember protector
should be made of metal material.
6. Using screws or nails, secure replace to
framing through anges located on sides
of replace (see Figure 4).
HEARTH EXTENSION
A hearth extension projecting a minimum of
16" in front of and a minimum of 8" beyond
each side of the replace opening is required
to protect combustible oor construction in
front of the replace. Use an equal material
which meets the following specications: a
layer of noncombustible, inorganic material
having a thermal conductivity of K=0.84 BTU
IN/FT, HR. F (or less) at 1" thick. For example,
if the material selected has a K factor of 0.25,
such as glass ber, the following formula
would apply:
0.25 x 1.0" = 0.30" thickness required
0.84
Thermal conductivity "K" of materials can be
obtained from the manufacturer or supplier of
the noncombustible material. If the hearth ex-
tension is to be covered, use noncombustible
material such as tile, slate, brick, concrete,
metal, glass, marble, stone, etc. Provide
a means to prevent hearth extension from
shifting and seal gap between replace frame
and hearth extension with a noncombustible
material (see Figure 5).
WARNING: Hearth extension
is to be installed only as shown
in Figure 5.
Fireplace Front
Elevated
Raised
Hearth
DO NOT Block Louvers
NO

www.desatech.com 124558-01A6
Figure 7 - Fan Kit Wiring Diagram
OF FIREPLACE
OUTER WRAPPER
TO
POWER SOURCE
ELECTRICAL
COVER PLATE
AND STRAIN RELIEF
POWER SOURCE WIRING (NOT SUPPLIED)
FIREPLACE
(NOT SUPPLIED)
WIRE NUT (3x)
HOUSING
ELECTRICAL
PRE-WIRED
RECEPTACLE
AND GROUND
CHASSIS GROUND
FIREPLACE INSTALLATION
Continued
Electrical
Cover Plate
Rocker
Switch
Strain
Relief
Figure 6 - Fan Kit BK2 Electrical Cover
FAN KIT ASSEMBLY (BK2)
A fan kit assembly is preinstalled in this
replace. Use of blowers or fans other than
model BK2 voids warranty. Fan is operated by
pressing rocker switch located at lower right
hand corner of replace face. Fan kit electri-
cal connections are made through electrical
cover plate located on side of replace as
shown in Figure 6.
Screws
Fan Kit Wiring Instructions
1. Loosen strain relief by turning plastic screw
counterclockwise.
2. Remove electrical cover plate (with strain
relief) from replace by removing two sheet
metal screws .
3. Slide power source wiring through strain
relief opening and electrical cover plate
and make all necessary connections
4. Place all wiring connections into electric
housing as shown in Figure 7.
5. Secure electrical cover plate with screws
previously removed.
6. Tighten strain relief plastic screw
Note: Electrical housing and cover plate have
sharp edges. Wear protective gloves.
VENTING INSTALLATION
OUTSIDE AIR KIT
Installation of an outside air kit should be
completed during the rough framing of
replace due to nature of its location. The
supplied ex duct measures approximately
10" compressed and up to approximately 36"
extended. Outside combustion air is accessed
through mobile home oor using air kit model
AK6E or a side wall using air kit model AK6-
WE (see Accessories on page 18).
Installer may choose either left or right side
mounting to allow for proper wall/rafter
clearances.
For AK6-WE Only: Construct a 4.5" x 4.5"
framing or opening on exterior wall (see
Figure 8, page 7).
For AK6E Only: The outside air vent is in-
stalled through a ventilated crawl space (see
Figure 9, page 7).

www.desatech.com
124558-01A 7
Figure 8 - Outside Air Kit AK6-WE Installation
Figure 9 - Outside Air Kit AK6E
Installation
Floor
Flex Duct
Extends
Up to 36"
Outside
Air Vent
Termination
Insulation
Insulation
Air Vent Location
Must Allow
for Bushes,
Snow and
Other Possible
Obstructions
Secure to Collar with
Metal Tape, Screws or
Tie Straps
Secure to Collar with
Metal Tape, Screws or
Tie Straps
Left Side
Mounting
Shown
Left Side
Mounting
Shown
Insert Inner Tab of
Inlet Tube into Slot
on Outer Surround
Insert Inner Tab of
Inlet Tube into Slot
on Outer Surround
VENTING INSTALLATION
Continued
1. Locate and remove air inlet cover plate on
replace‘s outer surround. Save screws.
2. Cut out any visible insulation that may
obstruct airow.
3. Extend ex duct to attach air inlet tube.
4. Insert inner tab of inlet tube into mating
slot next to opening.
5. Place outer tab of inlet tube over mating
hole next to opening and secure with
screws removed from cover plate in
step 1.
6. Install outside air vent termination in a
location that will not be obstructed by
bushes, snow, etc. Locate vent near the
replace to make ex duct installation
easier.
CHIMNEY PIPE
The chimney system approved for this
replace consists of 12", 18", 24", 36" and
48" snap-lock, double-wall pipe segments,
planned for maximum adaptability to individual
site requirements. Actual lengths gained after
tting overlaps must be taken into consider-
ation (lineal gain) and are given in the lineal
gain chart (see Figure 10). Lineal Gain is the
actual measurable length of a part after two
or more parts are connected.
Figure 10 - Lineal Gain
Hemmed
End
8"
Stainless
Inner Pipe
12 3/8"
Galvanized
Outer Pipe
LINEAL GAIN
PART NO. DESCRIPTION GAIN
C36EMW-R Fireplace 42 "
12-8DM Pipe Section 10 5/8 "
18-8DM Pipe Section 16 5/8 "
24-8DM Pipe Section 23 5/8 "
36-8DM Pipe Section 34 5/8 "
48-8DM Pipe Section 46 5/8 "
RTL-8DM Round Termination 7 3/4 "
*
* The lineal gain for the terminations is mea-
sured to the ue gas outlet height.

www.desatech.com 124558-01A8
There are two vent kits available which have
been specially designed for common installa-
tions in manufactured (mobile) homes: MW8K
(8' vent kit) and MW9K (9' vent kit). Contents
of these kits are listed under Accessories on
page 18. IMPORTANT: If height of chimney
assembly exceeds requirements for transpor-
tation of home, chimney installation may be
completed after home is sited.
Note: Termination must always be installed
after the home is sited.
ASSEMBLY AND INSTALLATION OF
DOUBLE WALL CHIMNEY SYSTEM
Each double wall chimney section consists of
a galvanized outer pipe, a stainless steel inner
ue pipe and a wire spacer. Pipe sections must
be assembled independently as chimney is
installed. When connecting chimney directly
to replace, inner ue pipe section must be
installed rst with lanced side up. Outer pipe
section can then be installed over ue pipe
section with hemmed end up. Press down
on each pipe section until lances securely
engage hem on replace starter. Wire will as-
sure proper spacing between inner and outer
pipe sections.
WARNING: The opening in the
collar around the chimney at the
top of the replace must not be
obstructed.Neveruseblowninsula-
tion to ll the chimney enclosure.
Continue to assemble chimney sections as
outlined above, making sure that both inner
and outer pipe sections are locked together.
When installing double wall snap-lock chimney
together, it is important to assure joint between
chimney sections is locked. Check by pulling
chimney upward after locking. Chimney will not
come apart if properly locked. It is not neces-
sary to add screws to keep chimney together
(exception, see Figure 16, page 11).
ADJUSTABLE FIRESTOP THIMBLE
(FST-A)
Adjustable Firestop Thimble Assembly (FST-
A) is used to provide necessary air space and
clearance between chimney pipe and insula-
tion in attic space of a manufactured home.
To install thimble assembly, determine dis-
tance between ceiling joist and roof framing.
Attach adjustable thimble to restop spacer
so that assembly will cover distance. Adjust-
able thimble should be even with or above
rooine. Sheet metal screws or staples may
be used to attach thimble to restop spacer.
An opening large enough to allow insertion
of restop thimble assembly will be required
in ceiling. Attach restop/thimble assembly to
ceiling/ceiling joist using screws or staples as
shown in Figure 11. A minimum of 8 screws
or staples should be used.
Firestop thimble assembly should also be
used where there is a cathedral ceiling, in-
sulation barrier and roof, all in one assembly
in a manufactured home (see Figure 11).
The FST-A thimble can be used in any one
of three common ceiling pitches; at, 12"/96"
and 30"/144".
An opening big enough to allow insertion of
restop thimble assembly will be required.
This opening depends on the pitch of your
ceiling. If your ceiling is a at or 12"/96" pitch,
you must use adapter plate provided to seal
unwanted openings. For 30"/144" pitch, dis-
card adaptor.
Thimble Extension
(If Needed)
Roof Line
Adjustable Thimble
Existing
Ceiling Frame
Firestop Spacer
Screws or Staples
(Min. of 8)
Figure 11 - Attaching Firestop/Thimble
Assembly to Ceiling
VENTING INSTALLATION
Continued

www.desatech.com
124558-01A 9
VENTING INSTALLATION
Continued
If adapter is needed, secure it onto restop
using holes provided (see Figure 12). The
row of holes on sides of thimble is provided
to allow for pitch variances. Position restop
(top and bottom side) and thimble to desired
angle and secure with screws provided. Insert
thimble and restop into prepared opening
and secure to ceiling by nailing through re-
stop anges. Thimble should be even with
or above rooine. Thimble extensions are
available (as an option) when required. See
Accessories on page 18. Firestop thimble is
not required for modular home application.
Note: If there is a second story in the home,
restop spacer 3600FS-8DM will be required.
See Firestop Spacers, page 11.
PENETRATING ROOF
To maintain a 1" clearance to pipe on a roof
with a pitch, a rectangular opening must be
cut.
1. Determine center point through which pipe
will penetrate the roof.
2. Determine center point of the roof. Pitch
is the distance the roof drops over a given
span, usually 12". A 6/12 pitch means that
the roof drops 6" for each 12" measured
horizontally down from roof rafters.
3. Use roof opening chart (Figure 13) to
determine correct opening length and
ashing required.
4. Remove shingles around opening mea-
sured. Cut out this section.
5. Add next sections of pipe until end pen-
etrates roof line. Check to see that proper
clearances are maintained. Extend chim-
ney by adding sections of double wall
pipe until pipe is minimum of 30" above
highest point of roof cutout. Termination
and chimney must extend a minimum of
36" above highest point where it passes
through roof.
Thimble (Open End)
12"
Min.
Thimble
(Closed End)
Firestop
Adapter Plate (If Needed)
Insulation
Barrier
Screw Holes
Provided
for Thimble
Firestop
Figure 12 - Use a Firestop Thimble
Assembly for Cathedral Ceiling,
Insulation Barrier and Roof
12"/96" Pitch
30"/144" Pitch
7.13"
11 .77"
144"
96"
12"
30"
Thimble
Adapter Plate
(For Flat and
12"/96" Pitch
Ceilings Only)
Firestop
Use for 12"/96"
Pitch Ceiling
Use for Flat
Pitch Ceiling
14
3
/
8
"
(36.5 cm)
30"
(76.2 cm)
1"
(2.5
cm)
1"
(2.5
cm)
Minimum Measurements
1"
(2.5 cm)
Opening "A"
PITCH SLOPE
OPENING
"A" MAX
FLASHING
MODE NO.
Flat 0° 15" 6F-8
0-6/12 26.6° 16 1/8 " 6F-8
6/12 -
12/12 45° 20 3/8"12F-8
Figure 13 - Determine Roof Opening

www.desatech.com 124558-01A10
VENTING INSTALLATION
Continued
OFFSET RISE CHIMNEY LENGTH
A B 12" 18" 24" 36" 48"
4 3/8"16 3/8" ELBOW SET ONLY
9 3/4"25 1/2"1
12 3/4"30 3/4"1
15" 34 3/4"1
18" 40" 1 1
21 1/4"46 1/4"1
23 3/4" 49 1/4"1 1
27 3/4"56 3/4"1
30" 60 3/4"1 1
33" 66" 1 1
36" 71" 1 1
38 1/4" 75" 2
41 1/4"80 1/4"1 1 1
45" 86 3/4"2
46 3/4" 89 1/2"1 1 1
51" 97" 1 1
53 1/4" 101" 1 2
56 1/4"106 1/4"2
59 1/4"111 1/2"1 1 1
61 3/4"115 1/2"1 2
64 3/4"120 3/4"1 2
68 1/4" 127" 2 1
70" 130" 1 1 2
74 1/4"137 1/2"1 2 1
76 3/4"141 1/2"1 2 1
79 3/4"146 3/4"4
USING ELBOW OFFSETS (30E-8DM)
1. To achieve desired offset, you may install
combinations of 12", 18", 24", 36" and 48"
length of double wall pipe (see offset chart
and Figure 14).
OFFSET CHART (22-50 FT. SYSTEM HEIGHT)
Figure 15 - Ceiling Support Pipe
12S-8DM
Straps
Straps
Straps
Straps
Detail A
Return Elbow
Detail B
Angle Firestop
See
Detail A
See Detail B
Figure 14 - Elbow Offset
B
A
Screws
2. Chimney weight above offset rests on
return elbow. Straps must be securely
nailed to rafters or joists (see Figure 15,
details A and B).
3. Maximum length of pipe between supports
(return elbow or 12S-8DM) is 6' of angle
run. Maximum of two 6' angle run sections
per chimney system (see Figure 14).
4. All pipe connections between offset and
return must be secured with two screws
on outer pipe only (see Figure 16). Do not
penetrate inner stainless.

www.desatech.com
124558-01A 11
Figure 16 - Typical Offset Terminations (For Systems with 2 Elbow Sets, Maximum
Height is 20')
Return
Elbow
Offset
Elbow
Return
Elbow
Offset
Elbow
6' Max.
6' Max.
6' Max.
6' Max.
6' Max.
6' Max.
Return
Elbow
Offset
Elbow
Offset
Elbow
Return
Elbow
A B C
Offset
Elbow
Ceiling
Support Pipe
12S-8DM
Return
Elbow
VENTING INSTALLATION
Continued
FIRESTOP SPACERS (3600FS-8DM)
Firestop spacers are required at each point
where the chimney penetrates a oor space.
Their purpose is to establish and maintain
the required clearance between the chimney
and the combustible materials. When the pipe
passes through a framed opening into a living
space above, the restop must be placed onto
the ceiling from below as shown in Figure 17.
Figure 17 - Firestop Spacer with Living
Space Above Ceiling
Existing
Ceiling
Frame
Firestop
Spacer
Screws or
Staples
(Min. of 8)
FLASHING INSTALLATION (V6F-8DM
OR V12F-8DM)
Determine the ashing to be used with the roof
opening chart. Slide ashing over pipe until
base is at against roof. Replace as many
shingles as needed to cover exposed area
and ashing base. Secure in position by nail-
ing through shingles (see Figure 18). DO NOT
NAIL THROUGH FLASHING CONE.
Nail Only
Outer
Perimeter
of Flashing
Storm Collar
Flashing
Cone
Underlap Shingles
at Bottom
Overlap
Shingles Top
and Sides Only
Figure 18 - Flashing Installation
Installing Flashing on a Metal Roof
When installing ashing on a metal roof, it
is required that putty tape be used between
ashing and roof. Flashing must be secured
to roof using #8 x 3/4" screws and then sealed
with roof coating to prevent leakage through
screw holes. A roof coating must also be
applied around the perimeter of ashing to
provide a proper seal.

www.desatech.com 124558-01A12
VENTING INSTALLATION
Continued
Storm Collar Installation (SC1)
Place storm collar over pipe and slide down
until it is snug against the open edge of ash-
ing (see Figure 19). Use SC1 for all round
terminations.
Note: Storm collar is required but can be
installed after the home is sited.
Terminations/Spark Arrestor
Overlap
Shingles Top
and Sides
RTL-8DM
Level of
Flue Gas
Outlet
Attach
Bracket Tabs
to Outer Pipe
(3 Places)
Secure with
Screws
Caulk
Storm
Collar
Flashing
Underlap Shingles
Bottom Only
Figure 20 - Termination
CHASE INSTALLATIONS
Instructions for chase installations are includ-
ed with chase style termination chosen. In a
multiple chase installation, be sure to provide
adequate distance between terminations to
prevent smoke spillage from one termination
to another. We suggest that terminations be
separated at least 24", center to center and
stacked at a vertical height difference of 18"
(see Figure 21).
24" Min.
24" Min.
18"
Min.
Typ.
Figure 21 - Multiple Chase Installation
Figure 19 - Storm Collar
Chimney
Pipe
Waterproof
Caulk
Storm
Collar Flashing
Fireplace system must be terminated with
listed round top termination. In any case, refer
to installation instructions supplied with termi-
nation. Terminations approved for this replace
are RT-8DM and RTL-8DM. Figure 20 shows
an RTL-8DM round top termination.
IMPORTANT: Terminations are required but
can be installed once the manufactured house
is sited.
CAUTION: Do not seal open-
ings on the rooftop ashing. Fol-
low the installation instructions
provided with the termination
being used.
Terminations with 16" slip pipe sections are
available. The RTT-8DM and RTTL-8DM
are approved for ashing installations. When
needed, these adjustable terminations may be
used in combination with the pipe assembly to
achieve correct chimney height.
Note: In the rare instance there is a problem
with side driven rain or wind, or the chimney is
not drafting properly, an ADS-8DM Anti Draft
Shield can be used with round terminations.

www.desatech.com
124558-01A 13
VENTING INSTALLATION
Continued
10 FOOT RULE
All ue gas outlet chimney terminations must
extend a minimum of 3 feet in height above the
highest point where it passes through the roof
and must be at least 2 feet above the high-
est point of the roof that is within a horizontal
distance of 10 feet (see Figure 22).
10'
2' Min.
10'
3' Min.
2' Min. 3' Min.
Level of
Flue Gas
Outlet
Figure 22 - 10 Foot Rule
CHIMNEY SUPPORT BRACKET KIT:
CSK-8DM
If exposed portion of chimney is greater than
ve feet above rooine, support wires are
recommended to keep chimney secured.
Support wires must be attached to chimney
support brackets. Chimney support brackets
must be attached to outer pipe of chimney
with self-drilling screws provided in kit (screws Figure 23 - Support Wires
OPTIONAL GAS LINE INSTALLATION
Chimney
Support
Bracket
Support
Wire
Cable
Ferrule
Eye
Bolt
Angle of Support
Wire Should Not
Be More Than 45°
From Horizontal
120°
120°
120° Top
View of
Chimney
Self Drilling
Screws
18"
Permanently Located (Sited) Homes Only
Gas line hook up should be done by your
supplier or a qualied service person.
Note: Before you proceed, make sure your
gas supply is turned off.
A gas line may be installed for the purpose
of installing a vented or vent free appliance
available through your local distributor. Use
only a 1/2" black iron pipe and appropriate
ttings. When installing a gas line, a shutoff
valve designed for installation outside appli-
ance is recommended.
1. Remove knockout indentation on refrac-
tory or rebrick wall located above the re-
fractory hearth oor. Knockout indentation
must be rmly tapped with any solid object
such as a 1/2" dowel until it is released.
Remove fragmented portions of refractory
(see Figure 24).
2. Remove gas line cover plate located on
either side of replace and pull out insu-
lation from gas line conduit sleeve. Save
insulation for reuse. Replace screws.
Figure 24 - Gas Line Knockout
Side
Firebrick
Finished
Side
Refractory
Knockout
Plug
Outside of
Fireplace
Gas Line
Conduit
Insulation
Gas
Conduit
Cover
1/2" Dowel
Knockout
must not penetrate inner ue pipe). The angle
of support wires should not be more than 45°
from horizontal when fastened to roof. Place
chimney support brackets approximately 18"
below replace termination and space brack-
ets approximately 120° apart (see Figure 23)
Follow instructions included in kit.

www.desatech.com 124558-01A14
VENTING INSTALLATION
Continued
Seal
Opening
with
Refractory
Cement
Outside of
Fireplace
Gas
Line
Conduit
Repack
Insulation
Incoming
1/2" Black
Iron Pipe
Side
Firebrick
Finished
Side
Provide Enough Threaded
End for Fitting Connection
Figure 25 - Gas Line Installation
3. Run a 1/2" black iron gas line into replace
through rear at gas line conduit sleeve
(if using a raised platform, add height).
Provide sufcient gas line into replace
chamber for tting connection (see Figure
25, page 14).
Note: Secure incoming gas line to wood
framing to provide rigidity for threaded end.
4. Repack insulation around gas line and into
sleeve opening. Seal any gaps between
gas line and refractory knockout hole with
refractory cement or commercial furnace
cement, Install gas appliance or cap off
gas line if desired.
CAUTION: All gas piping
and connections must be tested
for leaks after the installation
is completed. After ensuring
that the gas valve is on, apply
soap and water solution to all
connections and joints. Bubbles
forming show a leak. Correct
all leaks at once. DO NOT USE
AN OPEN FLAME FOR LEAK
TESTING AND DO NOT OPER-
ATE ANY APPLIANCE IF A LEAK
IS DETECTED. LEAK TESTING
SHOULD BE DONE BYA QUALI-
FIED SERVICE PERSON.
Note: Secure incoming gas line to wood fram-
ing to provide rigidity for threaded end.
If you wish to install an unvented (vent-
free) gas log set, ONLY UNVENTED GAS
LOG SETS WHICH HAVE BEEN FOUND
TO COMPLY WITH THE STANDARD FOR
UNVENTED ROOM HEATERS, ANSI
Z21.11.2, ARE TO BE INSTALLED IN THIS
FIREPLACE.
A vent-free log may be installed in an aftermar-
ket,* permanently located, manufactured (mo-
bile) home, where not prohibited by locator.
*Aftermarket: Completion of sale, not for pur-
pose of resale, from the manufacturer.
Note: A hood must be installed when using
an vent-free gas log set (see Accessories,
page 18).
WARNING: Do not oper-
ate an unvented gas log set in
this replace with the chimney
removed.
If you install a decorative gas appliance
(vented gas log), the decorative gas appliance
must comply with the Standard for Decorative
Gas Appliance for Installation in Solid Fuel
Burning Fireplaces, ANS Z21.60, Z21.84 or
RG 2-72 and shall also be installed in accor-
dance with the National Fuel Gas Code, ANSI
7223NFPA 54 latest edition.
WARNING: If the replace
has been used for wood burning,
the rebox and chimney must be
cleaned of soot, creosote and
ashes be a qualied chimney
cleaner. Creosote will ignite if
heavily heated.
WARNING: When using a
decorative vented gas log, the
damper must be removed or
permanently locked in the fully
open position and the glass
doors must be in the fully open
position.

www.desatech.com
124558-01A 15
FINISHING FIREPLACE
12 1/4" Ref.
6"
Ref.
12"
Min.
9" Min.
11/2" Max.
3" Nom.
33°
Combustible
Material
Safe
Zone for
Projection of
Combustible
Materials
Fireplace
Opening
Upper
Section of
Fireplace
Figure 26 - Mantel Clearances to
Combustible Material
OPERATION AND MAINTENANCE GUIDELINES
Figure 27 - Bi-Fold Glass Doors
Doors Fully Closed
Fireplace Front
Doors
Fully Opened
Fireplace Front
Combustible materials, such as wallboard,
gypsum board, sheet rock, drywall, plywood,
etc. may make direct contact with sides and
top around the replace face. It is important that
combustible materials do not overlap the face
itself. Brick, glass, tile or other noncombustible
materials may overlap the front face provided
they do not obstruct essential openings like lou-
vered slots or any other opening. When overlap-
ping with a noncombustible facing material, use
only noncombustible mortar or adhesive.
MANTELS
A mantel may be installed if desired (see
Figure 26). Woodwork such as wood trims,
mantels or any other combustible material
projecting from the front face must not be
placed within 9" of the replace opening.
Combustible materials above 9" and project-
ing more than 1 1/2" from the replace must
not be placed less than 12" from the top
opening of the replace (NFPA STD 211,
Sec. 7-3.3.3).
GLASS DOORS
Glass doors are standard with fireplace.
When replace is in operation, doors must
be FULLY OPENED or FULLY CLOSED
position only or a re hazard may be created
(see Figure 27).
A replace equipped glass doors operates
much differently than a replace with an open
front. A replace with glass doors has a limited
amount of air for combustion. Excessive heat
within replace can result if too large a re is
built or if combustion air gate is not completely
open. The following tips should be followed
to assure that both replace and glass door
retain their beauty and function properly.
Both ue damper and glass doors must be
fully opened before starting the re. This will
provide sufcient combustion air and maintain
safe temperatures in rebox.
IMPORTANT: Glass must be allowed to
warm slowly and evenly. Tempered glass will
withstand a gradual temperature rise to 550°
Fahrenheit, which is more than a normal re
will generate.
Such materials as pitch/wax laden logs, very
dry mill end lumber, and large amounts of pa-
per or cardboard boxes can create an exces-
sively hot re and should not be burned in this
replace. Always keep re back from doors
and never allow ames to contact glass.
WARNING: Fireplaces
equipped with glass doors
should be operated only with
doors fully opened or fully
closed. Doors, if left partly open,
may draw gas and ame out of
the replace opening creating
risks of both re and smoke.
Note: HUD requirements may supersede
these minimum dimensions.

www.desatech.com 124558-01A16
Door Removal
1. Fold doors (fully open) and press up on
upper door spring clip until top pin is free
of the spring clip (see Figure 28). Tip door
toward middle of replace opening and lift
door out of the lower pivot hole.
2. Repeat step 1 for remaining door.
OPERATION AND MAINTENANCE GUIDELINES
Continued
Figure 28 - Removing/Installing Bi-Fold
Doors
Spring
Clip
Insert Pin
into Spring
Clip
Pivot
Hole
Insert
Bottom
Pivot Pin
into Hole
Fold Door
and Slide
Top Pins
Into Track
Installing Glass Doors
1. With bi-fold doors completely folded, insert
bottom pivot pin into pivot hole located
near bottom corner of front face opening
and swing door to vertical position making
sure top pins slide into door track. Door is
installed when top door pin snaps into spring
clip (see Figure 28).
2. Repeat step 1 for remaining door.
If you nd the doors do not close properly or
do not appear level or straight, proceed with
section on door adjustment.
Door Adjustment
Remove doors and slightly loosen lower pivot
clips and upper spring clips. Replace doors
and fully close them. Use 1/8" shims (any
material) to level doors. Once proper setting
is achieved, carefully open doors enough so
that you can access spring clips with a phillips
screwdriver. Tighten screws. See Figure 29.
Figure 29 - Adjusting Bi-Fold Doors
CLEANING GLASS
Clean the glass with any commercial glass
cleaner or soap and water. Do not use any
abrasive material to clean glass. Do not clean
glass with any cool water if glass is still hot
from re and smoke.
DAMPER OPERATION
The damper handle, which opens and closes
damper blade, is located inside rebox at cen-
ter towards back wall. Pushing handle back
in keyway slot will free damper blade to au-
tomatically open. To close, reach in and push
handle back into keyhole slot then pull down
and forward to lock it in place (see Figure 30).
Damper is not designed to be airtight. A small
gap around damper blade is normal.
Figure 30 - Damper Operation
Damper
Weight
Damper
Handle
Open Damper
Closed Damper
GRATE
WARNING: Risk of re! Always
replace grate with a model num-
ber 11116 grate only. This grate
has been designed to keep the
operation of your replace safe
and efcient.

www.desatech.com
124558-01A 17
BI-FOLD GLASS DOORS
VDG36E - Brushed Finish
DP36E - Platinum Finish
VDBP36E - Black Finish
DUAL FAN KIT - BK2
EMBER PROTECTOR - 20093
GRATE - 11116
BRICK LINER
Rear - PN 20029
Left Side - PN 20030
Right Side - PN 20030
Front Bottom - PN 21242
Rear Bottom - PN 21241
OPTIONAL OUTSIDE AIR KIT FOR
FLOOR INSTALLATION
90154 - Model AK6E
REPLACEMENT PARTS
TECHNICAL SERVICE
You may have further questions about instal-
lation, operation, or troubleshooting. If so,
contact Style Crest at 1-800-231-4822 or
write to: Style Crest Service, P. O. Box 19110,
Wichita, KS. 67204. When calling or writing,
please have your model and serial numbers
of your heater ready.

www.desatech.com 124558-01A18
STORM COLLAR - SC1-1
ACCESSORIES
DOUBLE WALL PIPE - 12-8DM,
18-8DM, 24-8DM, 36-8DM and 48-8DM
ROOF FLASHING
V6F-8DM - 0 to 6/12 Pitch
V12F-8DM - 6/12 to 12/12 Pitch
ANTI-DRAFT SHIELD
(ROUND TOP TERMINATION ONLY)
ADS-8DM
CHIMNEY SUPPORT BRACKET KIT
CSK-8DM
Support Bracket
Self Drilling Screws
Cable Ferrule
Eye Bolt Screw
Strand Wire (50 ft)
30° OFFSET AND RETURN - 30E-8DM
ADJUSTABLE HOOD
GA6053 - Antique Brass Finish
GA6052 - Polished Brass Finish
GA6050 - Black Painted Finish
This hood is required when installing a vent-
free gas log heater in this rebox.
FIRESTOP SPACER - V3600FS-8DM
ADJUSTABLE FIRESTOP THIMBLE
FST-A
Includes:
Thimble - PN 22383
Adapter Plate - PN 22398 (For Flat or
12/96 Pitch Ceilings Only)
Firestop - PN 22377
ROUND TOP TERMINATION - RTL-8DM
12"/96" Pitch
30"/144" Pitch
7.13"
11 .77"
144"
96"
12"
30"

www.desatech.com
124558-01A 19
SQUARE CHASE-TOP
TERMINATION - ETL-8DM
ACCESSORIES
Continued
OPTIONAL OUTSIDE AIR KIT FOR
SIDE WALL INSTALLATION - AK-6WE
HEARTH EXTENSION - 90192
THIMBLE EXTENSIONS
TXL-8DM - 43" - PN 20745
TX-8DM - 26" - PN 20746
VENT KIT* DESCRIPTION
MW8K
(8' Vent Kit)
MW9K
(9' Vent Kit)
36-8DM 36" Double Wall Pipe 2 2
24-8DM 24" Double Wall Pipe 1 0
18-8DM 18" Double Wall Pipe 0 2
FST-A Adjustable Firestop Thimble 1 1
V6F-8DM Roof Flashing 1 1
SC1-1 Storm Collar 1 1
RTL-8DM Round Cap Termination 1 1
*Use for Most Common Manufactured (Mobile) Home Installations
FACE EXTENSION - FE-36R
Front face extension would add 6” to the width
and 6” to the height of the replace face.
FLEX DUCT 6" X 25" (3 PACK) - MP6-75
AIR INLET HOOD - AK6-WI
AIR INLET HOOD (6 PACK) - MK6-WI

DESA Heating, LLC
2701 Industrial Drive
Bowling Green, KY 42101
www.desatech.com
NOT A UPC
124558-01
Rev. A
10/08
124558 01
This replace is manufactured for Stylecrest
Inc. under the VEXAR brand name by
