VIA Technologies Eclipse 646 Guide

VIA SEATING USER GUIDES . VIASEATING.COM . 1-800-433-6614
Seating Series Adjustment Guide
Eclipse
Control Mechanisms:
• Task Chair #646
• Task Stool #11DR/#11XDR
. 09/05/23

Left
VIA SEATING USER GUIDES . VIASEATING.COM . 1-800-433-6614
Chair Adjustment Guide: Control Mechanism
< Watch our Eclipse Control
Online User Guide
Right
Eclipse Light Task Chair #646
Seat Height
Type: Pull paddle
Adjust the seat height by lifting
your weight out of the chair and
pulling up on the paddle. Proper
seat height is realized when the
top of your legs are somewhat
parallel to the oor.

Left
Foot Ring #11DR & #11XDR
Type: Footrest
Press down on the plastic inner hub and
lift the foot ring up to unlock. Adjust to
desired position. To lock, press down on
the outer foot rest until hub is in locked
positon.
VIA SEATING USER GUIDES . VIASEATING.COM . 1-800-433-6614
Chair/Stool Adjustment Guide: Control Mechanism
< Watch this Control
Online User Guide
Right
Light Task Stool #11DR
Seat Height
Type: Pull paddle
Adjust the seat height by lifting
your weight out of the chair and
pulling up on the paddle. Proper
seat height is realized when the
top of your legs are somewhat
parallel to the oor.
Watch our Foot Ring >
Online User Guide
