January 16, 2007 Version 1.01
Operating Guide
EPIA EX-Series Mini-ITX Mainboard

EPIA EX-Series Operating Guide
January 16, 2007 - i - Version 1.01
Table of Contents
Table of Contents............................................................................................................................................................................. i
VIA EPIA EX-Series Overview ..................................................................................................................................................... 1
VIA EPIA EX-Series Layout ......................................................................................................................................................... 2
VIA EPIA EX-Series Specifications .............................................................................................................................................. 3
VIA EPIA EX Processor SKUs...................................................................................................................................................... 4
VIA CX700M2 All-in-One System Processor Overview.............................................................................................................. 5
VIA EPIA EX-Series I/O Back Panel Layout............................................................................................................................... 6
VIA EPIA EX-Series Board Dimensions ...................................................................................................................................... 7
VIA EPIA EX-Series Height Distribution .................................................................................................................................... 8
Power Consumption ....................................................................................................................................................................... 9
VIA EPIA EX 1.0 GHZ................................................................................................................................................................ 9
VIA EPIA EX 1.5 GHZ.............................................................................................................................................................. 11
Power Specifications ..................................................................................................................................................................... 13
VIA EPIA EX-Series Microsoft and Linux Driver Support...................................................................................................... 14
MICROSOFT DRIVER SUPPORT...................................................................................................................................................... 14
LINUX DRIVER SUPPORT .............................................................................................................................................................. 14
Contact........................................................................................................................................................................................... 15

EPIA EX-Series Operating Guide
January 16, 2007 - 1 - Version 1.01
VIA EPIA EX-Series Overview
The VIA EPIA EX-Series Mini-ITX Mainboard is an ultra compact native x86 platform
optimized for today's demanding embedded and productivity applications. The mainboard is
based on the VIA CX700M2 advanced all-in-one system processor featuring an embedded
hardware MPEG-2, MPEG-4 and WMV9 video decoding accelerator. Its integrated VIA
UniChrome™ Pro II 2D/3D graphics provide rich digital media performance. With the
sizable memory bandwidth of DDR2 533MHz SDRAM DIMM and the high data transfer
speeds of ATA-133 and further enhanced by support of 8-Channel High Definition Audio
Codec for Smart 7.1 surround sound and SPDIF, the VIA EPIA EX-Series delivers the
increased performance levels required by today’s embedded digital media applications.
The latest in high-bandwidth connectivity features two USB 2.0 ports (and the ability to
support up to 2 more USB ports using the available onboard pin headers), a 1394 onboard
pin header and a 10/100 Fast Ethernet port for extended broadband connectivity. The VIA
EPIA EX-Series also has one PCI slot for expandability options. The VIA EPIA EX-Series is
compatible with a full range of Mini-ITX chassis as well as FlexATX and MicroATX enclosures
and power supplies.
The VIA EPIA EX-Series is fully compatible with Microsoft® and Linux operating systems and
is available in a variety of configurations.

EPIA EX-Series Operating Guide
January 16, 2007 - 2 - Version 1.01
VIA EPIA EX-Series Layout

EPIA EX-Series Operating Guide
January 16, 2007 - 3 - Version 1.01
VIA EPIA EX-Series Specifications
Model Name - EPIA EX15000 - EPIA EX10000E
Processor - VIA C7 1.5GHz NanoBGA2
processor
- VIA C7 1.0GHz NanoBGA2
processor
Chipset - VIA CX700M2 advanced all-in-one system processor
System Memory - 1 DDR2 533 DIMM socket
- Up to 1GB memory size
VGA - Integrated VIA UniChromeTM Pro II 3D/2D AGP graphics with
MPEG-2/4 and WMV9 video decoding acceleration
Expansion Slots - 1 PCI
Onboard IDE - 1 UltraDMA 133/100/66/33 connector
Onboard LAN - 1 VIA VT6107 10/100 Mbps Fast Ethernet Controller
Or 1 VIA VT6122 Gigabit Ethernet Controller (Optional)
Onboard Audio - VIA VT1708A High Definition Audio Codec
Onboard TV Out - VIA VT1625M HDTV Encoder
Onboard 1394 - VIA VT6307S IEEE 1394 Firewire
Onboard I/O
Connectors
- 1 USB pin connector for 4 additional USB 2.0 ports
- 1 1394 pin connector for 1 1394 port
- 1 Front-panel audio header for HP-out and MIC-in
- 1 Audio Line-in header
- 1 LPC header
- 1 LVDS connector to support 1-CH LVDS panel
- 1 TV out header for SCART and D-terminal
- 1 Video pin connector for VGA output, CCIR656/601 video input and
SMBUS
- 1 PS2 mouse/keyboard header
- 2 SATA connectors
- 2 Fan pin connectors for CPU and System fans
- 1 ATX power connector
Back Panel I/O - 1 DVI connector
- 1 RJ45 with USB stack 2.0 connector
- 1 miniDIN for S-Video output
- 1 Triple RCA jack for composite video and stereo audio outputs
- 1 Triple RCA jack for component video output
- 1 S/PDIF coaxial connector
- 1 S/PDIF optical connector
BIOS - Award BIOS
- LPC 4/8Mbit flash memory
Operating System Windows 2000/XP, Linux, Win CE, XPe
System Monitoring &
Management
- Wake-on-LAN, Keyboard-Power-on, Timer-Power-on
- System power management, AC power failure recovery
Operating Temperature 0 ~ 50 °C
Operating Humidity 0% ~ 95% (relative humidity; non-condensing)
Form Factor - Mini-ITX (6-layer)
- 17 cm x 17 cm
* The specification is subject to change without prior notice.

EPIA EX-Series Operating Guide
January 16, 2007 - 4 - Version 1.01
VIA EPIA EX Processor SKUs
The VIA EPIA EX-Series is available in two speed grades as follows:
• 1.0 GHz VIA C7 NanoBGA2 Processor
• 1.5 GHz VIA C7 NanoBGA2 Processor

EPIA EX-Series Operating Guide
January 16, 2007 - 5 - Version 1.01
VIA CX700M2 All-in-One System Processor Overview
The VIA CX700M2 All-in-One System Processor is designed to enable high quality digital
video streaming and DVD playback in a new generation of fanless, small form factor PCs
and IA devices. The CX700M2 features the embedded VIA UniChrome™ Pro II 2D/3D
MPEG-2, MPEG-4 and WMV9 video decoding acceleration, DDR2 533MHz support, motion
compensation and dual-display support to ensure a rich overall entertainment experience.
Outstanding connectivity features include USB 2.0, 10/100 LAN and ATA/133.

EPIA EX-Series Operating Guide
January 16, 2007 - 6 - Version 1.01
VIA EPIA EX-Series I/O Back Panel Layout
The EPIA EX’s ultra compact 17cm x 17cm, integrated design supports connectivity options
including one DVI port, one RJ45 port, two USB 2.0 ports, one S-Video port, one optical
SPDIF port, one coaxial SPDIF port, one set of composite audio/video outputs and one set of
component video outputs.
In addition to the ports available on the back panel, the EPIA EX also supports a host of
connectivity options through PS2 mouse/keyboard pin header, 1394 pin header, LPC pin
header, USB 2.0 pin headers, video pin header (for VGA, CCIR656/601 and SMBus), TV-out
pin header, LVDS connector, S-ATA connectors, and front audio jacks.
158.75
44.45
0.00
3.81
10.31
10.59
8.81
0.00 2.44
11.66 24.61 52.43 80.14 97.59
116.10 130.10 144.10
10.31
10.31
24.31
14.00
7.00
7.00
Coaxial
SPDIF
Optical
SPDIF DVI S-Video
LAN
USB Composite
Video Output
Composite
Audio Output
Component
Video Output

EPIA EX-Series Operating Guide
January 16, 2007 - 7 - Version 1.01
VIA EPIA EX-Series Board Dimensions
14
12
1
+
+ +
+
CPU
CX-700
170.00
7.92
39.37
10.16
6.17
6.35
165.10 170.00
33.02

EPIA EX-Series Operating Guide
January 16, 2007 - 8 - Version 1.01
VIA EPIA EX-Series Height Distribution
+
++ +
21
14
Height:34.5mm
Height:33mm
13.04
21.84
66.44
24.34
Height:29.2mm
DIMM (34.6mm)
Else height: under 21mm
83.25
1

EPIA EX-Series Operating Guide
January 16, 2007 - 9 - Version 1.01
Power Consumption
Power consumption tests were carried out comparing the VIA EPIA EX running with VIA C7
1.0 GHz NanoBGA2 and VIA C7 1.5 GHz NanoBGA2 processors. The following tables are a
comprehensive breakdown of the EPIA platform’s voltage, amp and wattage values while
running common system applications.
VIA EPIA EX 1.0 GHz
A. Playing DVD – Power DVD 5.0
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.255 1.585 5.159
Main Board +5V 5.061 1.350 6.832
Main Board 5VSB 4.960 0.101 0.501
Main Board +12V 12.033 0.180 2.166
Main Board Power Consumption 14.658
B. Playing MP3 – Media Player
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.261 1.563 5.097
Main Board +5V 5.065 1.333 6.752
Main Board 5VSB 4.963 0.101 0.501
Main Board +12V 12.031 0.181 2.178
Main Board Power Consumption 14.527
C. Running Network Application – Files Copy
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.260 1.555 5.069
Main Board +5V 5.077 0.974 4.945
Main Board 5VSB 4.964 0.101 0.501
Main Board +12V 12.020 0.180 2.164
Main Board Power Consumption 12.679
D. Idle
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.267 1.556 5.083
Main Board +5V 5.080 0.907 4.608
Main Board 5VSB 4.968 0.102 0.507
Main Board +12V 12.018 0.184 2.211
Main Board Power Consumption 12.409

EPIA EX-Series Operating Guide
January 16, 2007 - 10 - Version 1.01
E. Run C.C. Winstone 2004
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.260 1.555 5.069
Main Board +5V 5.077 0.974 4.945
Main Board 5VSB 4.964 0.101 0.501
Main Board +12V 12.020 0.180 2.164
Main Board Power Consumption 12.679
F. S3 Mode
Measured Voltage Measured Amp. Watts
Main Board +3.3V 0.000 0.000 0.000
Main Board +5V 0.000 0.000 0.000
Main Board 5VSB 4.980 0.124 0.618
Main Board +12V 0.000 0.000 0.000
Main Board Power Consumption 0.618

EPIA EX-Series Operating Guide
January 16, 2007 - 11 - Version 1.01
VIA EPIA EX 1.5 GHz
A. Playing DVD – Power DVD 5.0
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.280 1.589 5.212
Main Board +5V 5.064 1.419 7.186
Main Board 5VSB 4.955 0.100 0.496
Main Board +12V 12.030 0.204 2.454
Main Board Power Consumption 15.347
B. Playing MP3 – Media Player
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.283 0.556 1.825
Main Board +5V 5.068 1.425 7.222
Main Board 5VSB 4.958 0.100 0.496
Main Board +12V 12.029 0.204 2.454
Main Board Power Consumption 11.997
C. Running Network Application – Files Copy
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.284 1.560 5.123
Main Board +5V 5.076 1.076 5.462
Main Board 5VSB 4.957 0.100 0.496
Main Board +12V 12.013 0.204 2.451
Main Board Power Consumption 13.531
D. Idle
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.287 1.553 5.105
Main Board +5V 5.081 0.928 4.715
Main Board 5VSB 4.962 0.100 0.496
Main Board +12V 12.017 0.205 2.463
Main Board Power Consumption 12.780
E. Run C.C. Winstone 2004
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.285 1.555 5.108
Main Board +5V 5.078 1.006 5.108
Main Board 5VSB 4.960 0.100 0.496
Main Board +12V 12.021 0.204 2.452
Main Board Power Consumption 13.165

EPIA EX-Series Operating Guide
January 16, 2007 - 12 - Version 1.01
F. S3 Mode
Measured Voltage Measured Amp. Watts
Main Board +3.3V 0.000 0.000 0.000
Main Board +5V 0.000 0.000 0.000
Main Board 5VSB 4.980 0.125 0.623
Main Board +12V 0.000 0.000 0.000
Main Board Power Consumption 0.623

EPIA EX-Series Operating Guide
January 16, 2007 - 13 - Version 1.01
Power Specifications
The EPIA EX utilizes an industry standard 20-pin ATX main connector to the power supply.
Due to the EPIA EX platform’s ultra low power requirements a 90 – 120 Watt ATX power
supply is ample for even the heaviest of multimedia system applications.
1 +3V 11 +3V
2 +3V 12 -12V
3 Gnd 13 Gnd
4 +5V 14 PWR_ON-
5 Gnd 15 Gnd
6 +5V 16 Gnd
7 Gnd 17 Gnd
8 PWR_GD 18 NC
9 5V_SB 19 +5V
10 +12V 20 +5V
Note: NC = no connection
1
2
3
4
5
6
7
8
9
11
12
13
14
17
18
19
2010

EPIA EX-Series Operating Guide
January 16, 2007 - 14 - Version 1.01
VIA EPIA EX-Series Microsoft and Linux Driver Support
Microsoft Driver Support
VIA EPIA EX series offers full support for the complete range of Microsoft operating systems.
For standard operating systems, Windows 2000/XP latest drivers downloads can be found in
the VEPD website at www.viaembedded.com.
For embedded operating systems, Windows CE.NET and XP Embedded related driver
supports can be found in the VIA Arena website at www.viaarena.com.
Linux Driver Support
VIA EPIA EX mainboards have a very high degree of support under Linux.
Support and drivers are provided through various methods including:
• Drivers provided by VIA
– Using a driver built into a distribution package
– Visiting VIA Arena website at www.viaarena.com for latest updates on a monthly
basis
• Installing a third party driver (such as the ALSA driver from the Advanced Linux
Sound Architecture project for integrated audio)
For OEM clients and system integrators developing a product for long term production, other
code and resources may also be made available. You can submit a request either through
the Developers portal on VIA Arena, or through your VEPD support contact. Alternatively,
VIA can work further towards providing additional drivers to suite your specific needs.

EPIA EX-Series Operating Guide
January 16, 2007 - 15 - Version 1.01
Contact
For more information on the VIA EPIA EX-Series Mini ITX Mainboard contact your sales
representative or visit our website at www.viaembedded.com
USA
440 Mission Court, Suite 220
Fremont, CA 94539
Tel: [phone]
Fax: [phone]
Email: [email protected]
Germany
Mottmann Strasse 12
53842 Troisdorf-Oberlar
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Taiwan
1F, No. 531, Chung Cheng Road
Hsin Tien, Taipei 231
Tel: [phone]
Fax: [phone]
Email: [email protected]
China
6F, DAscom Tower
9 Shangdi East Road
Haidian District
Beijing, 100085
Tel: [phone]
Fax: [phone]
Email: [email protected].cn
