VIA Technologies EPIA-P820 User manual

Operating Guide
EPIA-P820 Mainboard

EPIA-P820 Operating Guide
January 15, 2010 - i - Version 1.0
Table of Contents
Table of Contents ..................................................................................................................i
VIA EPIA-P820 O er iew .......................................................................................................2
Layout Diagrams ..................................................................................................................3
EPIA-P820 (top and bottom iews) ......................................................................................3
VIA EPIA-P820 Specifications.................................................................................................4
VIA EPIA-P820 Processor SKU................................................................................................5
VIA EPIA-P820 Dimensions & Mounting Holes ..........................................................................6
VIA EPIA-P820 Height Distribution..........................................................................................7
Power Consumption..............................................................................................................8
Tested Configurations ........................................................................................................8
Configuration 1 ..............................................................................................................8
Configuration 2 ..............................................................................................................8
Configuration 3 ..............................................................................................................8
Configuration 4 ..............................................................................................................8
Boot to Idle (XP) ...............................................................................................................9
Samsung Stress Tool .........................................................................................................9
3DMark2003 .....................................................................................................................9
PowerDVD 6.0...................................................................................................................9
Power Specifications ........................................................................................................... 10
VIA EPIA-P820 Microsoft and Linux Dri er Support ................................................................. 11
Microsoft Dri er Support................................................................................................... 11
Linux Dri er Support........................................................................................................ 11
Contact ............................................................................................................................. 12

EPIA-P820 Operating Guide
January 15, 2010 - 2 - Version 1.0
VIA EPIA-P820 Overview
The VIA EPIA-P820 Pico-ITX mainboard is an ultra compact nati e x86 platform for a wide range of
embedded system applications. The mainboard is based on the VIA VX855 All-in-One System
Processor featuring the VIA Chrome9™ HCM DX9 IGP with ideo accelerators for rich digital media
performance.
The VIA EPIA-P820 onboard VIA Nano 1.2 GHz NanoBGA2 processor is a green, secure, and
efficient processor with its included VIA Padlock Security Engine, VIA CoolStream™ Architecture,
VIA StepAhead™ Technology Suite, and VIA TwinTurbo™ technology.
The VIA EPIA-P820 deli ers the performance le els with its included sizeable support of up to 2 GB
of 800 MHz DDR2 memory and nati e support for SATA 3Gb/s storage de ices.
The VIA EPIA-P820 is fully compatible with Microsoft
®
and Linux operating systems.

EPIA-P820 Operating Guide
January 15, 2010 - 3 - Version 1.0
ayout Diagrams
EPIA-P820 ( TOP AND BOTTOM VIEWS )

EPIA-P820 Operating Guide
January 15, 2010 - 4 - Version 1.0
VIA EPIA-P820 Specifications
1
Model Name EPIA-P820-12L
Processor VIA Nano 1.2 GHz NanoBGA2 processor
Chipset VIA VX855 All-in-One System Processor
System Memory - 1 x DDR2 800/667 SODIMM socket
- Up to 2 GB memory size
VGA - VIA Chrome9™ HCM DX9 Integrated Graphics with MPEG-2/4 accelerators
Onboard Storage - 1 x SATA 3Gb/s connector
- 1 x IDE 2.0 mm 44-pin connector
Onboard AN - 1 x VIA VT6122 Gigabit Ethernet Controller
Onboard Audio - VIA VT1708S High Definition Audio Codec
Onboard I/O
Connectors
- 1 x Gigabit LAN pin header
- 1 x Audio pin connector for Line-out, Line-in, and MIC-in
- 1 x Single-channel LVDS connector (5V/3V)
- 1 x Backlight control pin header
- 1 x Sys fan connector
- 1 x PS2 KBMS pin header
- 1 x USB pin header
- 1 x LPC pin connector
- 1 x SMBus pin connector
- 1 x DIO pin connector (4 GPI & 4 GPO)
- 2 x UART port/VCP pin headers
- 1 x Front panel pin header
- 1 x SATA power connector
- 1 x +12V DC-in power connector
I/O Ports - 1 x HDMI port
- 1 x VGA port
- 1 x GigaLAN port
- 2 x USB ports
BIOS - AMI BIOS
- 4 Mbit SPI flash memory
Operating System Windows XP/CE/XPe and Linux
System Monitoring &
Management
- Wake-on LAN and Keyboard-Power-on
- Timer-Power-on
- WatchDog Timer
- System power management, AC Power failure reco ery
Operating
Environment
Temperature: 0°C ~ 60°C
Humidity: 0% ~ 95% (relati e humidity; non-condensing)
Compliance CE/FCC/BSMI/RoHS
Form Factor - Pico-ITX
- 10 cm x 7.2 cm
1
Specifications subject to change without notice.

EPIA-P820 Operating Guide
January 15, 2010 - 5 - Version 1.0
VIA EPIA-P820 Processor SKU
The VIA EPIA-P820 Pico-ITX mainboard is a ailable in the following speed grades:
•1.2 GHz VIA Nano Processor

EPIA-P820 Operating Guide
January 15, 2010 - 6 - Version 1.0
VIA EPIA-P820 Dimensions & Mounting Holes

EPIA-P820 Operating Guide
January 15, 2010 - 7 - Version 1.0
VIA EPIA-P820 Height Distribution
EPIA-P820 board shown with P720-A module stacked on top

EPIA-P820 Operating Guide
January 15, 2010 - 8 - Version 1.0
Power Consumption
Power consumption tests were performed on four different configurations. The following tables
show the mainboard’s oltage, amp and wattage alues while running common applications in the
Windows XP en ironment.
T ESTED C ONFIGURATIONS
Configuration 1
•VIA Nano 1.2 GHz NanoBGA2 Processor with 800 MHz FSB
•2.5" Fujitsu 80 GB hard dri e
•1 GB Kingston DDR2 800 MHz
Configuration 2
•VIA Nano 1.2 GHz NanoBGA2 Processor with 800 MHz FSB
•2.5"Fujitsu 80 GB, hard dri e
•3.5" Seagate 80 GB hard dri e
•2 GB Hynix DDR2 800 MHz
Configuration 3
•VIA Nano 1.2 GHz NanoBGA2 Processor with 800 MHz FSB
•4 GB InnoDisk IDE DOM
•1 GB Kingston DDR2 800 MHz
Configuration 4
•VIA Nano 1.2 GHz NanoBGA2 Processor with 800 MHz FSB
•4 GB InnoDisk IDE DOM
•2 GB Hynix DDR2 800 MHz

EPIA-P820 Operating Guide
January 15, 2010 - 9 - Version 1.0
B OOT TO I D E (XP)
Measured Voltage (V) Measure Amp (I) Watts (W)
Configuration 1 11.997 1.07 12.84
Configuration 2 11.997 1.56 18.72
Configuration 3 11.997 0.90 10.80
Configuration 4 11.997 0.91 10.92
S AMSUNG S TRESS T OO
Measured Voltage (V) Measure Amp (I) Watts (W)
Configuration 1 11.997 1.36 16.32
Configuration 2 11.997 1.81 21.71
Configuration 3 11.997 1.14 13.68
Configuration 4 11.997 1.18 14.16
3DM ARK 2003
Measured Voltage (V) Measure Amp (I) Watts (W)
Configuration 1 11.997 1.29 15.48
Configuration 2 11.997 1.75 21.00
Configuration 3 11.997 1.19 14.28
Configuration 4 11.997 1.22 14.64
P OWER DVD 6.0
Measured Voltage (V) Measure Amp (I) Watts (W)
Configuration 1 11.997 1.05 12.60
Configuration 2 11.997 1.48 17.79
Configuration 3 11.997 0.86 10.32
Configuration 4 11.997 0.89 10.68

EPIA-P820 Operating Guide
January 15, 2010 - 10 - Version 1.0
Power Specifications
The VIA EPIA-P820 Pico-ITX mainboard utilizes a +12V DC-in power connector for pro iding power
to the mainboard. The dimensions of the DC-in port are show in the figure below.
Figure 1: DC-in dimensions

EPIA-P820 Operating Guide
January 15, 2010 - 11 - Version 1.0
VIA EPIA-P820 Microsoft and inux Driver Support
M ICROSOFT D RIVER S UPPORT
The VIA EPIA-P820 Pico-ITX mainboard is compatible with Microsoft operating systems. The latest
Windows XP dri ers can be downloaded from the VEPD website at www. iaembedded.com.
For embedded operating systems (Windows CE and Windows XP Embedded), the related dri ers
can be found in the VIA Embedded website at www. iaembedded.com.
INUX D RIVER S UPPORT
The VIA EPIA-P820 Pico-ITX mainboard is highly compatible with many Linux distributions.
Support and dri ers are pro ided through arious methods including:
•Dri ers pro ided by VIA
•Using a dri er built into a distribution package
•Visiting www. iaembedded.com for the latest updated dri ers
•Installing a third party dri er (such as the ALSA dri er from the Ad anced Linux Sound
Architecture project for integrated audio)
For OEM clients and system integrators de eloping a product for long term production, other code
and resources may also be made a ailable. You can submit a request to your VEPD support
contact.

EPIA-P820 Operating Guide
January 15, 2010 - 12 - Version 1.0
Contact
For more information on the VIA EPIA-P820 Pico-ITX mainboard contact your sales representati e
or isit our website at www. iaembedded.com.
