i
Version 1.2
December, 2003
VIA
User’s Manual
VIA EPIA-V
Mini-ITX Mainboard
P/N 99-51-012551-12

ii
Copyright
Copyright by VIA Technologies Inc. (“VIA”). No part of this manual
may be reproduced or transmitted in any form without express written
authorization from VIA.
Trademarks
All trademarks are the property of their respective holders.
Data protection
All data should be backed-up prior to the installation of any drive unit
or storage peripheral. VIA will not be responsible for any loss of data
resulting from the use, disuse or misuse of this or any other VIA
product.
No Warranty
VIA has made every effort to ensure the accuracy of the content of
this manual. However, it is possible that it may contain technical
inaccuracies or typographical or other errors. VIA will assume no
liability for any inaccuracy found in this publication, nor for
damages, direct, indirect, incidental, consequential or otherwise, that
may result from such an inaccuracy, including without limitation loss
of data or profits.
VIA provides this manual “as is”, and does not issue a warranty of
any kind, express or implied, including without limitation implied
warranties of merchantability or fitness for a particular purpose.
The information provided in this manual is subject to change without
notice. VIA reserves the right to alter product designs, layouts or
drivers without notification.

iii
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for
a class B digital device, pursuant to part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party re-
sponsible for compliance could void the user’s authority to operate the
equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in
order to comply with the emission limits.
VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU
RESEAU.
VIA EPIA-M Mini-ITX Mainboard
Tested to comply
with FCC Standard
For Home or Office Use

iv
Copyright Notice
We take every care in the preparation of this document, but no guaran-
tee is given as to the correctness of its contents. Our products are
under continual improvement and we reserve the right to make changes
without notice.
Trademarks
All trademarks used in this manual are the property of their respective
owners.
PS/2 and OS/2 are registered trademarks of IBM Corporation.
Windows 95/98/98SE/ME/2000/NT and Windows XP are registered
trademarks of Microsoft.
Netware is a registered trademark of Novell.
Award is a registered trademark of Award Software Inc.

v
NOTE
1. Always read the safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Keep this equipment away from humidity.
4. Lay this equipment on a reliable flat surface before setting it up.
5. The openings on the enclosure are for air convection hence pro-
tects the equipment from overheating. DO NOT COVER THE OPEN-
INGS.
6. Make sure the voltage of the power source and adjust properly 110/
220V before connecting the equipment to the power inlet.
7. Place the power cord in such a way that people cannot step on it.
Do not place anything over the power cord.
8. Always unplug the power cord before inserting any add-on card or
module.
9. All cautions and warnings on the equipment should be noted.
10. Never pour any liquid into the opening. Liquid can cause damage
or electrical shock.
11. If any of the following situations arises, get the equipment checked
by a service personnel:
•The power cord or plug is damaged
•Liquid has penetrated into the equipment
•The equipment has been exposed to moisture
•The equipment has not work well or you can not get it work
according to User’s Manual.
•The equipment has dropped and damaged
•If the equipment has obvious sign of breakage
12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT UNCON-
DITIONED, STORAGE TEMPERATURE ABOVE 600 C (1400F), IT
MAY DAMAGE THE EQUIPMENT.
Safety Instructions
CAUTION: Explosion or serious damage may occur if the
battery is incorrectly replaced. Replace only with the same
or equivalent type recommended by the manufacturer.

vi
This VIA EPIA-V Mini-ITX Mainboard package should contain the follow-
ing items:
• 1 x VIA EPIA-V Mini-ITX Mainboard
• 1 x User’s manual
• 1 x ATA-33/66/100 Hard drive ribbon cable
• 1 x Floppy ribbon cable
• 1 x I/O Bracket
• 1 x Driver Utilities CD
Box Contents

vi
Contents
Specifications ......................................................... 1-1
Mainboard Specifications................................................ 1-2
Mainboard Layout............................................................ 1-4
Connectors Guide ............................................................ 1-5
Installation ............................................................. 2-1
CPU ................................................................................. 2-2
The VIA C3™ E-Series Processor ................................... 2-2
The VIA Eden Processor .................................................. 2-3
Memory Installation ......................................................... 2-4
SDRAM Module Installation Procedures .......................... 2-4
Available SDRAM Configurations ..................................... 2-5
Power Supply .................................................................. 2-6
ATX 20-Pin Power Connector: ATXPWR ....................... 2-6
Back Panel ....................................................................... 2-7
Mouse Connector: JMS1 .................................................. 2-7
Keyboard Connector: JKB1 .............................................. 2-7
USB Port Connectors ....................................................... 2-8
RJ-45 NIC Port ................................................................. 2-8
Parallel Port Connector: LPT1 ......................................... 2-8
Serial Port Connector: COM 1 .......................................... 2-9
S-Video Port ..................................................................... 2-9
Audio Port Connectors ..................................................... 2-9
RCA Video or S/PDIF Port .............................................. 2-9
VGA Out ........................................................................... 2-9
Connectors ..................................................................... 2-10
Hard Disk Connectors: IDE1 .......................................... 2-10
Front Panel Connector (J3) ............................................. 2-11
CD-ROM Line In Connector (J7) ................................... 2-11
FIR Module Connector (J5) ............................................ 2-12
PS2 Connector (J6) ........................................................ 2-12
Wake On Modem Connector (J8) ................................... 2-13
USB Port 2&3 Connector (F_USB) ............................... 2-13

vii
Video In Connector (J12) ................................................ 2-14
Floppy Disk Drive Connector: FDD ............................... 2-14
Jumpers.......................................................................... 2-15
Clear CMOS Jumper: CLEAR_CMOS ........................... 2-15
Host Frequency Select (J13) ........................................... 2-16
Auto Reboot Function Setting (J2) .................................. 2-17
RCA Video or S/PDIF Select (J11) ................................. 2-17
Slots............................................................................... 2-18
PCI Slots ......................................................................... 2-18
PCI Interrupt Request Routing ....................................... 2-19
BIOS Setup............................................................ 3-1
Entering Setup.................................................................. 3-2
Control Keys.................................................................... 3-2
Getting Help .................................................................... 3-3
The Main Menu................................................................ 3-4
Standard CMOS Features ................................................ 3-6
Advanced BIOS Features ................................................ 3-8
Advanced Chipset Features ........................................... 3-11
Integrated Peripherals .................................................... 3-13
Power Management Setup.............................................. 3-16
PNP/PCI Configurations ................................................ 3-21
PC Health Status ............................................................ 3-23
Frequency/Voltage Control ............................................ 3-24
Load Fail-Safe Defaults................................................. 3-25
Load Optimized Defaults ............................................... 3-26
Set Supervisor/User Password ...................................... 3-27
Save & Exit Setup.......................................................... 3-29
Exit Without Saving ....................................................... 3-30

viii
Software Setup...................................................... 4-1
Driver Utilities CD Content ............................................. 4-2
Getting Started ................................................................. 4-2
Running the Driver Utilities CD ..................................... 4-2
CD Content ...................................................................... 4-2

Specifications
1-1
The ultra-compact and highly intergrated VIA
EPIA-V Mini-ITX Mainboard is the smallest form factor
mainboard specification available today, developed by VIA
Technologies, Inc as part of the company’s open industry-
wide Total Connectivity initiative. The VIA EPIA-V Mini-
ITX mainboard enables the creation of an exciting new
generation of small, ergonomic, innovative and affordable
embedded systems. Through high level of integration,
mini-ITX only occupy 66% of the size of FlexATX
mainboard form factor. The mainboard comes with an
embedded VIA Processor, boasting ultra low power
consumption and cool, quiet operation.
This chapter includes the following sections:
Mainboard Specifications 1-2
Mainboard Layout 1-4
Components Guide 1-5
1
Specifications

Chapter 1
1-2
CPU
• Embeddeed VIA Processor
• Enhanced Ball Grid Array Package (EBGA)
• Internal L1 128KB and L2 64KB cache memory
Chipset
•VIA 8601A North Bridge
•VT8231 South Bridge
Graphics
•Integrated Trident Blade 3D graphics core
Audio
•VT1612A 2 channel AC’97Codec
•3 Audio jacks: Line-in, Line-out and Mic-in
Main Memory
•2 x PC100/133 DIMM slots.
PCI Bus IDE
•Ultra DMA 33/66/100
LAN
•VIA VT6103 10/100 Base-T Ethernet PHY
USB
•2 USB ports
•1 onboard USB pin header for up to 2 additional connections
•USB v1.1 and Intel Universal HCI v1.1 compatible
TV-Out (Optional)
•VIA VT1621 TV-Out Controller
Specifications

Specifications
1-3
Onboard I/O Connectors
•1 USB connector for 2 USB 1.1 ports
•CD Audio-in connector
•FIR connector
•PS2 connector
•Wake-on-Modem
•CPU/Sys FAN
Back Panel I/O
•1 PS2 mouse port
•1 PS2 keyboard port
•1 Parallel
•1 RJ45 LAN port
•1 Serial port
•2 USB 1.1 ports
•1 VGA port
•1 RCA port (S/PDIF or TV out)
•1 S-Video port
Power
•Supports ATX type power supply
Onboard Floppy
•1 FDD connector
BIOS
•Award BIOS
•2/4Mbit flash memory
Form Factor
•Mini-ITX (4 layers)
•17 cm x 17 cm

Chapter 1
1-4
VIA EPIA-V Mini-ITX Mainboard
Layout
Mic
In
Line
In
Line
Out
COM Port
USB 0
USB 1
LAN
RJ45
RCA
Video
or
S/PDIF
S-Video
LPT Connector
CRT Connector
PS / 2
Keyboard
Mouse
FAN 1
FAN 2
VT1621
VT1612A
VT6103
J7
CD-ROM Line-In
J11
RCA Video
S/PDIF
J12
Video In Connector
Processor
EBGA
LAN
TV Out
North Bridge
VT8601A
SouthBridge
VT8231
Clock
Generator
J13
Host Frequency Select
J5
FIR Module Connector
J2
Auto Reboot
Function Setting
J3
Front Panel Jumper
BIOS
ROM IDE 1
FDD ATX PowerConnector
DIMM 1
DIMM 2
Battery CR2032
J10
Clear CMOS
J8
Wake up On Modem
PS2 Connector
J6
Buzzer
F_USB

Specifications
1-5
Component Function Reference
Fan 1, Fan 2 Fan power connectors See p. 2-2
DIMM1, DIMM2 DIMM slot See p. 2-4
ATX Power Connector Connecting ATX power supply See p. 2-6
PS/2 Mouse Mouse connector See p. 2-7
PS/2 Keyboard Keyboard connector See p. 2-7
LPT Connector Parallel port connector See p. 2-8
RJ-45 Port Connecting to a LAN See p. 2-8
USB 0, USB 1 Connecting to USB devices See p. 2-8
COM Port COM port connector See p. 2-9
Line Out Connecting Headphones/Speakers See p. 2-9
Line In Connecting an audio device See p. 2-9
Mic In Connecting a Micorphone See p. 2-9
RCA Video or S/P DIF Connecting to RCA Video or SPDIF See p. 2-9
S-Video Connecting to S-Video See p. 2-9
VGA Out Connect to a VGA monitor See p. 2-9
IDE 1 Connecting an IDE device See p. 2-10
J3 Front panel connector See p. 2-11
J7 CD-ROM Line in connector See p. 2-11
J5 FIR module connector See p. 2-12
J6 PS2 connector See p. 2-12
J8 Wake on Modem See p. 2-13
F_USB USB Port 2 &3 Connector See p. 2-13
J12 Video in connector See p. 2-14
FDD Floppy disk drive connector See p. 2-14
J10 Clear CMOS jumper See p. 2-15
J13 Host Frequency Select See p. 2-16
J2 Auto Reboot Function Setting See p. 2-17
J11 RCA Video / S/P DIF See p. 2-17
PCI Slot Connecting to expansion cards See p. 2-18
PCIIRQ PCI Interrupt Request Routing See p. 2-19
Connectors Guide

Hardware Setup
2-1
This chapter provides you with the information
about hardware setup procedures. While installating,
please be careful in holding the components and follow
the installation procedures. Some components could be
damaged if they are installed incorrectly. If possible,
use a grounded wrist strap before handling computer
components. The components can be damaged by static
electricity.
This chapter contains the following topics:
Central Processing Unit (CPU) 2-2
Memory Installation 2-4
Power Supply 2-6
Back Panel 2-7
Connectors 2-10
Jumpers 2-15
Slots 2-18
PCI Interrupt Request Routing 2-19
2Installation

Chapter 2
2-2
The VIA EPIA-V Mini-ITX Mainboard includes an embedded VIA Eden Proc-
essor or VIA C3™ E-Series Processor. Two fan connectors (Fan 1 & Fan 2)
are provided on the mainboard, allowing for the connection of a CPU fan and
an additional system case fan.
CPU
CPU Fan Cable CPU Fan / Heatsink
CPU Fan Connector
The VIA C3™ E-Series Processor
With low power consumption and advanced thermal dissipation properties,
the embedded VIA C3™ E-Series requires only a small fan to guarantee
performance and reliability. Ensure that the CPU Fan Connector is correctly
installed, as displayed below.

Hardware Setup
2-3
CPU Heatsink
Overclocking
This motherboard is not designed to support
overclocking. Any attempt to operate beyond product
specifications is not recommended. We do not guar-
antee the damages or risks caused by operation be-
yondproductspecifications.
WARNING!
The VIA Eden Processor
Providing ultra-low power consumption and advanced thermal dissipation
properties, the VIA Eden Processor features a fanless design. The VIA Eden
Processor requires only a heatsink, as shown below.

Chapter 2
2-4
The VIA EPIA-V Mini-ITX Mainboard provides two 168-pin DIMM slots
for PC 100/133 SDRAM memory modules. To operate properly, at least one
module must be installed.
Memory Installation
DIMM 1 & DIMM 2
SDRAM Module Installation Procedures
1.) Push the white retaining latches at either end of the DIMM slot outwards.
2.) Align the SDRAM module with the corresponding notches on the DIMM
slot. The modules will only fit if placed in the correct position.
2.) With both hands, press the SDRAM module down into the DIMM slot so
that the white retaining latches rotate up and secure the module in place (see
picture below).

Hardware Setup
2-5
Socket Memory Module Total Memory
DIMM 1 32MB, 64MB, 128MB,
256MB, 512MB 32MB~512MB
DIMM 2 32MB, 64MB, 128MB,
256MB, 512MB 32MB~512MB
Maximum System Memory Supported 1GB
Available SDRAM Configurations
Refer to the table below for available SDRAM configurations on the VIA
EPIA-V Mini-ITX Mainboard.

Chapter 2
2-6
ATX 20-Pin Power Connector
To connect the ATX power supply, make sure the plugs of the power supply
are inserted in the proper orientation and the pins are correctly aligned. Then,
push down the power supply plug firmly into the connector.
The VIA EPIA-V Mini-ITX Mainboard requires an ATX power supply to be
connected. Before inserting the power supply connector, always make sure
that all components are installed correctly to ensure that no damage will be
caused.
Power Supply
PIN SIGNAL
11 3.3V
12 -12V
13 GND
14 PS_ON
15 GND
16 GND
17 GND
18 NC
19 5V
20 5V
PIN SIGNAL
1 3.3V
2 3.3V
3 GND
45V
5 GND
65V
7 GND
8 PW_OK
9 5V_SB
10 12V
ATXPWR Pin Definition
110
20
11
