VIADRUS OV 100 L
MANUAL FOR OPERATION
AND INSTALLATION

Table of contents: page
1. Use and advantages of heater.................................................................................................................3
2. VIADRUS OV 100 L technical data..........................................................................................................3
3. Description...............................................................................................................................................5
3.1 Heater construction..............................................................................................................................5
3.2 Safety and regulation elements............................................................................................................6
3.3 Electric wiring diagram .........................................................................................................................6
4. Installation regulations .............................................................................................................................6
4.1 Regulations and directives ...................................................................................................................6
4.2 Summary of hot service water consumption........................................................................................7
5. Order, delivery and assembly..................................................................................................................7
5.1 Order....................................................................................................................................................7
5.2 Delivery and accessories .....................................................................................................................7
5.3 Assembly procedure.............................................................................................................................8
5.4 Heaters filling with water procedure.....................................................................................................9
6. Heaters operation by users......................................................................................................................9
7. IMPORTANT WARNINGS.......................................................................................................................9
8. Maintenance ..........................................................................................................................................10
9. Instructions for product disposal after its service life expiration.............................................................10
10. Guarantee and liability for defects .........................................................................................................10

3
Dear customer,
we thank you that you have bought the VIADRUS OV100 L water heater thus having shown your
confidence in VIADRUS a.s..
For you to get used to a correct way of handling your new product from the beginning please read at
first this manual for its usage (first of all the chapter no. 6 – Heaters operation by users). Please
follow the undermentioned information especially the prescribed annual inspections carried out by
an authorized firm in order to guarantee a long-time and trouble-free heater operation to both your
and our satisfaction.
1. Use and advantages of heater
Indirectly heated accumulation water heater is intended for hot service water preparation in family houses,
cottages, premises, workshops, shops. In case of VIADRUS OV 100 L stationary heater the service water is
heated by heating water by means of a spiral heating wire. In case of an increased HWS (Hot Service
Water) consumption the reservoir heats the water continually and in works like a flow heater.
VIADRUS OV 100 L stationary water heater is preferentially intended for boiler VIADRUS GARDE G 42 and
VIADRUS GARDE G 42 ECO, possibly VIADRUS CLAUDIUS K 2. Its design corresponds to design of
boilers and the boiler electric connection enables a preferential HWS heating.
Accumulation water heater advantages:
1. Uniform heating.
2. Internal surface protected by double layer of enamel
3. Adjustable service water temperature.
4. Economical operation
5. Service water heated quickly.
6. Easy assembly and operation
7. Compared to the flow heaters they enable to draw off the service water simultaneously at several points.
2. VIADRUS OV 100 L technical data
Tab. no.1 VIADRUS OV 100 L hater thermal data
Heater volume l 100
Heater (spiral heating wire) heat output kW 23
Heat transfer surface of the heater m
2
0,9
Connections: - heating water Js 3/4“
- hot service water Js 1/2“
Heater dimensions: - height mm 886
- width mm 574
- depth mm 587
Weight kg 60
Nominal overpressure of heater MPa (bar) 0,4 (4)
Maximum working overpressure for HWS MPa (bar) 0,6 (6)
Setting range °C 0 – 90 ***)
HWS time of heating from 10 °C to 60 °C
Boiler output 26,5 kW and heating water temperature 85 °C) *)
Boiler output 16 kW
Boiler output 49,5 kW
min
14
21
14
HWS flow (boiler output 26,5 kW) **) l/h 610
HWS flow (boiler output 16 kW) **) l/h 368
HWS flow (boiler output 49,5 kW) **) l/h 1139
Connection voltage 1/N/PE 230 V AC 50 Hz TN–S
Electric coverage IP 40
Environment normal,
pursuant to ČSN 33 2000-3

4
*) For a boiler output
different from 26,5 kW
and under the same
conditions like those
shown in the table the o
time of heating will
change as follows:
0
5
10
15
20
25
30
35
40
0 10 20 30 40 50 60
výkon kotle (kW)
doba ohřevu (min)
**) The water flow is stated
at 85 °C heating water
temperature and 35 °C
service water
temperature gradient
(10 °C HWS input
temperature, 45 °C
HWS output
temperature). If a boiler
with output different
from 26,5 kW is used
for the heater, then the
water flow will change
as follows(while
observing the above
input conditions):
0
100
200
300
400
500
600
700
0 10 20 30 40 50 60
výkon kotle (kW)
průtok vody (l/hod)
The above times for water heating and its flow are valid in case that a Grundfos pump is connected to the
heating system and its revolutions switch is in position 3(which corresponds to ∼720 l/h.). If the pump works
with lower revolutions (smaller flow quantity) the time of heating the service water will be prolonged..
***)
IMPORTANT WARNINGS!
Set the thermostat of the heater to max. 60 °C temperature (note: The regulations in the Czech Republic do
not allow do distribute water of temperatures higher than 60°C).
Once a week set the thermostat of the heater to 65 °C temperature in order to avoid the formation of
legionella (bacillary bacteria originating in water. They die between 60 and 65 °C temperature within several
minutes and at 70 °C temperature they die within several seconds.).
Time for water
heated (min)
Heat output (kW)
Heat output (kW)
Water
flow rate
(l/hour)
OV 100 L
OV 100 L

5
3. Description
3.1 Heater construction
The heater is made of a steel vessel (100 l volume at VIADRUS OV 100 L heater) in which there is installed
the spiral heating wire. The vessel internal surface is enamelled and together with the anode rod it creates an
efficient protection against corrosion and guarantees a long-time service life.
The spiral heating wire is made of a metal pipe and is treated by an enamelled layer. The heater is equipped
with a cover; after unscrewing the cover the vessel can be checked and cleaned.
At VIADRUS OV 100 L heater the cover is screwed to the upper neck of the vessel. In the cover there are
installed the reservoirs for thermostat and thermometer probes and there is screwed the anode protective rod
plus the hot service water input and output. Heating water input and output are at the back of the heater.
The heat loss is reduced markedly by the foam polyurethane insulation.
Fig. no.1 VIADRUS OV 100 L heater assembly (dimensions in mm)
In case of the stationary VIADRUS OV 100 L heater in the lower part of the vessel there is positioned the
discharge hole for a discharge valve. In case that of a demand on the circulation piping it can be connected
through a T-joint connected to the discharge hole.
1 network module
2 thermostat
3 thermometer
4 reservoir of thermometer probes
5 heated water outlet
6 heated water inlet
7 anodic protection bar
8 side part of the shell
9 reservoir 100 l
10 base
11 frontal part of the shell
12 heating water outlet
13 rear part of the shell
14 heating water inlet
15 electric panel
16 upper part of shell

6
3.2 Safety and regulation elements
Both reservoirs have their control panels equipped with a thermometer and regulation thermostat on which
the service water required temperature can be set.
In case of a reservoir combined with boiler controlled by an equithermal Honeywell AQ 6000 regulation (or by
other superior automatics which at the same time controls the hot service water heating process), it is
necessary to disqualify the heater from operation and use a thermostat delivered together with automatics.
3.3 Electric wiring diagram
ϑ
OV 100 L elementary wiring diagram OV 100 L wiring diagram –
Fig. no. 2 Electric wiring diagram of VIADRUS OV 100 L heater
4. Installation regulations
4.1 Regulations and directives
The heater positioning must comply with the safety connection:
a) regarding the heating system
ČSN 06 0310 Heating systems in buildings – Designing and installation
ČSN 06 0830 Heating systems in buildings – protecting device
b) regarding the electric network
ČSN 33 2180 Electrical regulations. Connection of electrical devices and appliances.
c) regarding the HWS heating
ČSN 06 0320 Heating systems in buildings – Hot water preparation – Designing and planning
ČSN 06 0830 Heating systems in buildings – Safety devices.
ČSN 73 6660 House water plumbing
ČSN 07 7401 Water and steam for thermal energy equipments with working pressure up to 8 MPa
ČSN 06 1010 Stack water heaters with water and steam heating combined with electric heating
Technical requirements. Testing..
ČSN 75 7111 Waters quality. Drinking water.
ČSN 83 0616 Hot service water quality
ELECTRIC PANEL
REAR PART

7
4.2 Summary of hot service water consumption
The consumption of hot service water in households depends on number of persons, the houses or flats
installation equipment and the individual consumers habits. The following table provides with a recommended
summary of the average hot water consumption.
Hot water consumption in litres
37 °C 55 °C
Bath 150 - 180
Showering 30 - 50
Hand washing 3 - 6
Shampoo(butch) 6 - 12
Shampoo (long hair) 10 - 18
Bidet use 12 - 15
Dish-washing
2 persons per day 16
3 persons per day 20
4 persons per day 24
The temperature is considered for a given hot water temperature by mixing it with cold water of approx.
12 °C temperature.
5. Order, delivery and assembly
5.1 Order
In an order it is necessary to specify the data as follows:
•Type of heater
•Demands on the parts ordered optionally
5.2 Delivery and accessories
The heater is delivered while fixed on a pallet, wrapped in a cardboard package and protected by a foil.
Standard accessories
•safety valve 1 pc
•commercial & technical documentation
Optionally:
•Honeywell V 4044F three-way valve (to assure a preferential heating)
•Grundfos UPS 25-40 pump
Optional heater equipment isn’t included in basic price.

8
5.3 Assembly procedure
The heater user is obliged to entrust only a contractual service with assembly and the guarantee and after –
guarantee fault repairs, otherwise the guarantee does not apply to a proper heater function.
1. The heater must be positioned on a required standpoint. We recommend to transfer the heater to
the determined standpoint while it is on a pallet and possibly wrapped in a protective wrapping. If for any
reasons this is not possible please transport the stationary heater without the wrapping by using its lower
support. In this support there are prepared two circular openings intended for putting on the „removal
hooks“, by means of which the heater can be lifted and transferred to the desired place.
Fig. no. 3 Recommended heater connection in heating system with ensured HWS preferential
heating
2. Connect the heater to the heating and water piping system according to the recommended
connection (Fig. no. 3) or the elaborated project documentation. Water for filling the heater must be
pure, clear, colourless, free of impurities, oil and chemically aggressive substances pursuant to
ČSN 75 7111. HWS quality is defined by ČSN 83 0616. Water from heater is considered to be the
service water. Its hardness must correspond to ČSN 07 7401, otherwise it must be softened. Every
independently closable service water heater pursuant to ČSN 06 0830, Article 7.2, must be equipped
with a closure on the cold pressure water inlet, a test cock, a check valve or a clack valve, a safety valve
and a pressure gauge. It is allowed to use a combined fitting consisting of a safety and clack valves. The
safety valve must be connected in a way making sure, that he longitudinal axis of the valve is in the
horizontal position. The valve discharge pipe is to be taken out into the effluent conduit. If the pressure in
inlet piping exceeds 630 kPa (6,3 bar) (applicable also to a transitory condition) then a reduction valve
must be installed in front of the safety valve.
If the HWS preferential heating is carried out by means of three way Honeywell V 4044F valve then
during the assembly it is important to observe the direction of connection in accordance with the
indication on this valve.
B - heating water outlet into the heating system
A - heating water outlet into the heater
AB - heating water inlet from the boiler into the three way valve
3. To carry out the electric interconnection between the heater and the boiler in accordance with the wiring
diagram of the used type of boiler.
4. Insulate the hot water distribution (piping) in order to reduce the thermal losses.
5. All materials used for heater manufacture are recyclable. After the heater unpacking the plastic foil, strip,
wooden pallet and cardboard wrapping must be put into the waste disposal containers intended for this
kind of waste.
Legend:
1 boiler
2 water heater
3,14 stop valves
4 bleeder valve
5 three-way valve
6,13 clack valve
7 pump
8 expansion reservoir
9 safety valve
10 discharge valve
11 manometer
12 safety valve
15 testing cock
16 radiator, vale
Note: It is possible to use a combined fitting consisting of a safety valve and a clack -valve.
Hot service valve inlet
Cold service
water inlet
heating water
inlet
return
water inlet

9
5.4 Heaters filling with water procedure
1. Open the combination faucet
2. As soon as the water at the draw-off point starts run out of the hot water valve the filling process is
completed and the combination faucet must be closed.
3. Check the joints tightness.
Warning:
In case that Honeywell V 4044F three way valve is used it is necessary to reset the lever for manual
valve operation from AUTO position into OPEN position. This must be done before the heating
system filling process starts in order to bleed the heater. After the filling process has been completed
reset again manually this lever back from OPEN into AUTO position.
6. Heaters operation by users
1. Set the required hot service water temperature on the heater thermostat. In order to ensure a sufficiently
quick HWS heating we recommend to keep the 15 °C difference between the temperatures set on the
heater and boiler thermostats (like the heater thermostat on 55 °C level and boiler thermostat on 70 °C
level). In order to inhibit the propagation of legionella (bacteria coming up in backwaters at temperatures
below 60 °C) we recommend to set the HWS temperature above 65 °C at least once a week.
2. Keep checking the service water temperature on the thermometer.
heater thermostat network module thermometer
Fig. no. 4 VIADRUS OV 100 L heater control panel
7. IMPORTANT WARNINGS
1. The appliance only can be used for the purpose that it is destined for.
2. The appliance can only be operated by adult persons and children without being supervised by
adults must not be left nearby the appliance.
3. The appliance is not destined for the use by persons (incl. children) whose physical, sensual or
mental disability or lack of experience and knowledge prevent them from a safe use of the
appliance unless they are supervised or if they were not instructed on the use of appliance by a
person responsible for their safety.
4. Children should be supervised in order to ensure that they do not play with the appliance.
5. If the appliance is going to be put out of operation for a long time it must be disconnected from
the electricity- from the socket.
6. During assembly, installation and operation of the appliance it is necessary to comply with
standards that apply in the relevant country of destination.
7. The user is obliged to put a professional contractual service accredited by VIADRUS a.s., the
heater manufacturer in trust with commissioning, regular maintenance and defects elimination,
otherwise the heater proper function isn’t guaranteed. „Quality and completeness certificate for
VIADRUS OV 100 L heater“ after having been filled out by contractual service organization
serves as the „Guarantee certificate“.
8. Regular maintenance on the heater must be done once a year according to the following chapter.
If you don’t adhere to these terms you cannot claim for guarantee repairs.

10
8. Maintenance
The recommended maintenance must be done once a year:
1. Discharge water from the heater. When discharging water from the heater the hot water combination
faucet at the draw-off point must be kept open in order to protect the vessel from vacuum emerge; the
vacuum would disallow the heater emptying.
2. Check the condition of anode protective rod. If the anode protective rod is strongly damaged (metal
decrement), it must be replaced.
9. Instructions for product disposal after its service life expiration
VIADRUS a.s. is a contractual partner of the firm EKO–KOM a.s., its client number being F00120649.
Packages are in compliance to ČSN EN 13427.
Because the product is constructed of common materials its individual parts are recommended to be
disposed of as follows:
- exchanger – through a firm dealing with waste collection and disposal
- piping, jacketing – through a firm dealing with waste collection and disposal
- other metal parts – through a firm dealing with waste collection and disposal
- bleeder cap – through a firm dealing with waste collection and disposal,(like a non-ferrous metal)
The heater wrapping should be disposed of in following way:
- plastic foil, cardboard cover and the wooden pallet into the common waste
- metal strap for strapping – through a firm dealing with waste collection and disposal
- wooden base, is designated for a single usage and no longer can be used as a product. Its disposal is
subject to Act. 477/ 2001 Sb. a 185/2001 Coll.as amended.
In case that the product has lost its serviceability you can take advantage of product “take back
service” (if this is established); in case that the originator has declared that it is a scrap it must be
handled according to the valid legislation of relevant country.
10. Guarantee and liability for defects
VIADRUS a.s. provides the guarantee during 24 months after the date when product was sold the end
user.
The manufacturer for the validity of his guarantee requires:
–To inspect heaters regularly once a year. Only an authorized service organization is qualified to exercise
the inspections.
–To document all records on carried out guarantee and after-guarantee repairs and annual inspections in
an annex to this manual guarantee certificate.
Every fault must be notified immediately after having been discovered and always in writing.
In case of an infringement of above instructions the guarantees provided by the manufacturer will not
be recognized.
The guarantee does not apply to:
- faults caused by improper assembly and improper attendance of the product and faults caused
by improper maintenance see chap. 8
- product damage arisen from transport or other mechanical damage
- the faults caused by an unsuitable way of storing
- faults caused by failure to observe instructions stated in this manual
The manufacturer reserves the right of alterations made within the product innovation that needn’t be
included in this manual

11
Information for customer
Packaging edentification
PE Plastic sacks, folie, corrugaled board, iron and plastic fix
line
Assessment reference
Identification od principál materials used. Paper, Polyethylene, iron, wood
Part 1: Summary of assessment
Standard/Report Assessment requirement Claim Note
1.1 Prevention by source
reduction YES
1.2 Heavy metals and ensure below maximum permitted levels
for components
(CR 13695-1:2000) YES
1.3 Other
noxious/hazardous
substances
ensure in compliance with
(CR 13695-2:2002, EN 13428:2000) YES
2 Reuse ensure reusability in all terms of the
standard for the functional packaging
unit (EN 13429:2000) NO
3.1 Recovery by material
recycling ensure recyclability in all term sof the standard for the functional packaging
unit (EN 13430:2000) YES
3.2 Recovery in the form
of energy ensure that calorific gain is achievable for the functional packaging unit
(EN 13431:2000) YES Iron - NO
3.3 Recovery by
composting ensure compost ability in all terms of the standard for the functional packaging
unit (EN 13432:2000) NO
NOTE Conformity with EN 13427 requires affirmative responses to sections 1.1; 1.2; 1.3 and to at
least one of 3.1; 3.2; 3.3. In addition, where a claim of reuse is made section 2 should also
record affirmative responses.
Part 2: Statement of conformity
In the light of the assessment results recorded in part I above, this packaging is claimed to comply
with the requirements of EN 13427:2000.

12

13
Intended for user VIADRUS a.s.
Bezručova 300
735 81 Bohumín
Guarantee certificate and Quality and completeness certificate for
VIADRUS OV 100 L heater
Heater serial number .......................….. type of heater (heater volume) ...........................
User (surname, name) …………………………………………………………………………………
Address (street, town, postcode) …………………………………………………………………………………
Telephone/Fax …………………………………………………………………………………
Overpressure in water supply piping ……………………..bar
The heater complies with requirements:
ČSN 06 1010 Stack water heater with water and steam heating and combined with el.heating..
Technical requirements. Testing.
ČSN 06 0830 Heating systems in buildings – protecting device
VIADRUS a.s. provides the guarantee during 24 months after the date when product was sold the end
user
•The heater will be installed by a contractual service organization.
•The completeness according to „Manual for operation and installation“ is guaranteed by the
contractual service organization.
•The guarantee certificate is invalid without having been filled in.
The user confirms that he:
•has received the „Manual for operation and installation “
•familiarized himself with heater operation and maintenance
Manufacture date Manufacturer ´s stamp Checked by (signature)
…………………………………….. …………………………………….. ……………………………………..
Installation date Contracting service organization
(stamp, signature User ´s signature
…………………………………….. …………………………………….. ……………………………………..

14
Annex to the guarantee certificate for customer- the user
Record of accomplished guarantee and after-guarantee repairs and regular product checks
Record
date Carried out activity Contracting service
organization
(stamp, signature)
Customer ´s
signature

15
Intended for the service organization VIADRUS a.s.
Bezručova 300
735 81 Bohumín
Guarantee certificate and Quality and completeness certificate for
VIADRUS OV 100 L heater
Heater serial number .......................….. type of heater (heater volume) ...........................
User (surname, name) …………………………………………………………………………………
Address (street, town, postcode) …………………………………………………………………………………
Telephone/Fax …………………………………………………………………………………
Overpressure in water supply piping ……………………..bar
The heater complies with requirements:
ČSN 06 1010 Stack water heater with water and steam heating and combined with el.heating..
Technical requirements. Testing.
ČSN 06 0830 Heating systems in buildings – protecting device
VIADRUS a.s. provides the guarantee during 24 months after the date when product was sold the end
user
•The heater will be installed by a contractual service organization.
•The completeness according to „Manual for operation and installation“ is guaranteed by the
contractual service organization.
•The guarantee certificate is invalid without having been filled in.
The user confirms that he:
•has received the „Manual for operation and installation “
•familiarized himself with heater operation and maintenance
Manufacture date Manufacturer ´s stamp Checked by (signature)
…………………………………….. …………………………………….. ……………………………………..
Installation date Contracting service organization
(stamp, signature User ´s signature
…………………………………….. …………………………………….. ……………………………………..

16

17
Intended for manufacturer VIADRUS a.s.
Bezručova 300
735 81 Bohumín
Guarantee certificate and Quality and completeness certificate for
VIADRUS OV 100 L heater
Heater serial number .......................….. type of heater (heater volume) ...........................
User (surname, name) …………………………………………………………………………………
Address (street, town, postcode) …………………………………………………………………………………
Telephone/Fax …………………………………………………………………………………
Overpressure in water supply piping ……………………..bar
The heater complies with requirements:
ČSN 06 1010 Stack water heater with water and steam heating and combined with el.heating..
Technical requirements. Testing.
ČSN 06 0830 Heating systems in buildings – protecting device
VIADRUS a.s. provides the guarantee during 24 months after the date when product was sold the end
user
•The heater will be installed by a contractual service organization.
•The completeness according to „Manual for operation and installation“ is guaranteed by the
contractual service organization.
•The guarantee certificate is invalid without having been filled in.
The user confirms that he:
•has received the „Manual for operation and installation “
•familiarized himself with heater operation and maintenance
Manufacture date Manufacturer ´s stamp Checked by (signature)
…………………………………….. …………………………………….. ……………………………………..
Installation date Contracting service organization
(stamp, signature User ´s signature
…………………………………….. …………………………………….. ……………………………………..

18

19

20
Date of revision 46/2012 ND – GB
