T-BERD/MTS 5800 Portable Network Tester
T-BERD/MTS 5800 Portable Network Tester
QUICK CARD
Ethernet Y.1564 Layer 2 Multiple Stream Test
This quick card describes how to configure and run a Y.1564 Layer 2 Multiple Stream
Traffic Test for Metro Ethernet service activation.
Figure 1: Equipment Requirements
LAUNCH TEST
1. Press the Power button to turn on the
T-BERD.
2. Press the Test icon at the top of the
screen to display the Launch Screen.
3. Using the Select Test menu, Quick Launch
menu, or Job Manager, launch the Ethernet
Y.1564 SAMComplete Multiple Streams test on
Port 1 for the desired rate. For Example:
Ethernet ►1GigE Optical ►Y.1564 SAMComplete
►L2 Multiple Streams ►P1 Terminate.
4. Tap the button next to “Start a New
Configuration (reset to defaults)”
Figure 2: Launch Screen
Figure 3: Y.1564 SAMComplete test
•T-BERD 5800 equippedwith the following:
oBERT software release V30.1.0 or greater
oC5COS for multiple steam traffic generation
oC510M1GE test option for 10/100/1000 Megabit
and 1 Gigabit Ethernet
oC510GELAN test option for 10 Gigabit Ethernet
oC525GE test option for 25 Gigabit Ethernet
oC540GE test option for 40 Gigabit Ethernet
oC550GE test option for 50 Gigabit Ethernet
oC5100GE test option for 100 Gigabit Ethernet
•Optical Transceiver supportingthe speed to be tested (SFP or QSFP)
•Cables to match the optical transceiver and the line under test
•Fiber optic inspection microscope (P5000i or FiberChek Probe)
•Fiber optic cleaning supplies

VIAVI//Public
T-BERD/MTS 5800 Portable Network Tester
T-BERD/MTS 5800 Portable Network Tester
QUICK CARD
2
►The followingInformation is needed to
configure the test:
•Number of Streams to generate
•VLAN ID, if VLAN tagging is used
•Frame Size for each stream
•Committed Information Rate (CIR) for
each stream
•Pass/Fail Threshold for Frame Loss
Ratio, Delay and Delay Variation (Jitter)
1. Tap the button 3 times to display
the Network Services screen. Set Number
of Services to the number of streams you
wish to generate.
2. If you want different Frame Sizes,
Destination MAC Addresses, or Ethertype
for each stream, tap
DA MAC, Frame Size setting and Ethertype,
enter desired values, and tap .
3. Tap to display the Network
Tagging screen.
►If you are testing a single VLAN, set
Encapsulation to VLAN and enter the
VLAN ID.
►If you are testing multiple VLANs, tap
the Yes radio button and enter the
VLAN IDs and Priorities.
CONFIGURE TEST
Figure 4: Work Order
Figure 6: Network Tagging
Figure 5: Network Services

VIAVI//Public
T-BERD/MTS 5800 Portable Network Tester
T-BERD/MTS 5800 Portable Network Tester
QUICK CARD
3
4. Tap to display the SLA Throughput
screen.
►Enter the CIR allocated to each stream of
traffic or service.
►Under EIR, enter the additional bandwidth
available when only one stream of traffic is
being generated.
►If the streams are not Policed individually,
uncheck all Policing checkboxes.
5. Tap the button twice to display the
SLA Performance screen.
►Enter the Frame Loss Ratio, Frame Delay,
and Delay Variation pass/fail criteria for all
services.
6. Tap the button 5 times to display the
J-QuickCheck screen.
Figure 8: SLA Performance
Figure 9: J-QuickCheck
Figure 7: SLA Throughput

VIAVI//Public
T-BERD/MTS 5800 Portable Network Tester
T-BERD/MTS 5800 Portable Network Tester
QUICK CARD
4
►For Optical Interfaces:
1. Use the VIAVI P5000i or FiberChek Probe
microscope to inspect both sides of every
connection being used (SFP, attenuators,
patch cables, bulkheads)
oFocus the fiber on the screen.
oIf it appears dirty, clean the fiber end-face
and re-inspect.
oIf it appears clean, run the inspection test.
oIf it fails, clean the fiber and re-run
inspection test. Repeat until it passes.
2. Insert desired Optical Transceiver into the
Port 1 SFP or QSFP slot on the top of the
T-BERD.
3. If necessary, insert optical attenuators into
the SFP TX and/or RX ports.
4. Connect the SFP to the port under test
using a jumper cable compatible with the
line under test.
►For Copper 10/100/1000BASE-T interfaces:
Connect the 10/100/1000RJ-45 jack to
the port under test using CAT 5E or better
cable.
1. Verify that Local Port status UP and Full
Duplex (FD)
2. Tap the button.
3. Verify that the Remote Loop is recognized.
4. Tap the button to display the
Run Y.1564 Tests screen.
Figure 11: Local Port status
Figure 10: Inspect Before You Connect
CONNECT TO LINE UNDER TEST AND LOOP BACK DEVICE
Figure 12: Run J-QuickCheck

VIAVI//Public
T-BERD/MTS 5800 Portable Network Tester
T-BERD/MTS 5800 Portable Network Tester
QUICK CARD
© 2022 VIAVI Solutions, Inc,
Product specifications and descriptions in this
document are subject to change without notice.
Patented as described at viavisolutions.com/patents
Contact Us
To reach the VIAVI office nearest you,
visit viavisolutions.com/contact
+1 844 GO VIAVI
([phone])
1. Tap the button three times to
display the Report screen.
2. Tap .
3. Tap buttons three times to
close the report and exit the Y.1564 test.
RUN TEST
1. Tap the button.
2. Wait for the test to complete and verify that
all tests pass or complete as indicated by a
green checkmark.
CREATE REPORT
Figure 13: Run Y.1564 Tests
Figure 14: Create Report
Figure 15: Exit
