NetTek®YBT100 and YBT100DS3
Backhaul Tester
User Manual
www.tektronix.com
071-2070-00
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Copyright © Tektronix. All rights reserved. Licensed software products are
owned by Tektronix or its subsidiaries or suppliers, and are protected by national
copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending.
Information in this publication supersedes that in all previously published
material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
NetTek is a registered trademark of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Warranty 2
Tektronix warrants that this product will be free from defects in materials and
workmanship for a period of one (1) year from the date of shipment. If any such product
proves defective during this warranty period, Tektronix, at its option, either will repair
the defective product without charge for parts and labor, or will provide a replacement
in exchange for the defective product. Parts, modules and replacement products used by
Tektronix for warranty work may be new or reconditioned to like new performance. All
replaced parts, modules and products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the
defect before the expiration of the warranty period and make suitable arrangements for the
performance of service. Customer shall be responsible for packaging and shipping the
defective product to the service center designated by Tektronix, with shipping charges
prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to
a location within the country in which the Tektronix service center is located. Customer
shall be responsible for paying all shipping charges, duties, taxes, and any other charges
for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or
improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish
service under this warranty a) to repair damage resulting from attempts by personnel other
than Tektronix representatives to install, repair or service the product; b) to repair damage
resulting from improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a
product that has been modified or integrated with other products when the effect of such
modification or integration increases the time or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE
PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED.
TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’
RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE
SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR
BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents
General Safety Summary ............................................... iv
Environmental Considerations ......................................... vi
Preface................................................................... vii
Documentation .................................................... vii
Getting Started............................................................ 1
Key Features......................................................... 1
Standard Accessories ............................................... 2
Installation ........................................................... 3
Configuration ........................................................ 4
Functional Verification.............................................. 9
Operating Basics........................................................ 13
The YBT100 and YBT100DS3 Front and Rear Panels .... . ... 13
User Interface...................................................... 18
Applications............................................................. 21
Monitor a Single DS1 Signal at a DSX Panel................... 21
Monitor Two DS1 Signals at a DSX Panel...................... 23
DS1 Loop Testing ................................................. 24
Monitoring a DS3 Signal (YBT100DS3 Only) ................. 29
Monitoring (Dropping) a DS1 Channel from a DS3 Signal
(YBT100DS3 Only) ......................................... 30
DS3 Loop Testing (YBT100DS3 Only)......................... 30
Measurement Logs................................................ 32
Unattended Signal Event Monitoring and Logging ..... . .... . . 35
Appendix A: Specifications............................................ 39
Appendix B: Parameter Settings ...................................... 43
Test Mode Parameters............................................. 43
Framing Parameters............................................... 43
Network Timing Parameters...................................... 44
Zero Coding Parameters .......................................... 44
Alarms and Events ................................................ 44
BERT Patterns..................................................... 46
Loopback Settings................................................. 48
NetTek YBT100 and YBT100DS3 Backhaul Tester i
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents
Spkr Button ........................................................ 48
Index
ii NetTek YBT100 and YBT100DS3 Backhaul Tester
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

List of Tables
Table 1: YBT100 and YBT100DS3 connectors and indicators .... 13
Table 2: Loop test methods............................................ 25
Table 3: In-Band loop codes........................................... 27
Table 4: Electrical characteristics..................................... 39
Table 5: Environmental characteristics............................... 41
Table 6: Physical characteristics ...................................... 42
Table 7: Standards compliance........................................ 42
Table 8: Safety compliance............................................ 42
NetTek YBT100 and YBT100DS3 Backhaul Tester iii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

General Safety Summary
General Safety Summary
Review the following safety precautions to avoid injury and prevent
damage to this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of a larger
system. Read the safety sections of the other component manuals for
warnings and cautions related to operating the system.
To Avoid Fire or Personal Injury
Connect and Disconnect Properly. Do not connect or disconnect probes or
test leads while they are connected to a voltage source.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all
ratings and markings on the product. Consult the product manual for
further ratings information before making connections to the product.
The inputs are not rated for connection to mains or Category II, III, or
IV circuits.
Do not apply a potential to any terminal, including the common
terminal, that exceeds the maximum rating of that terminal.
Do Not Operate Without Covers. Do not operate this product with covers
or panels removed.
Do Not Operate With Suspected Failures. If you suspect that there is
damage to this product, have it inspected by qualified service personnel.
Avoid Exposed Circuitry. Do not touch exposed connections and
components when power is present.
Recharge Batteries Properly. Recharge batteries for the recommended
charge cycle only.
Use Proper AC Adapter.Use only the AC adapter specified for this
product.
iv NetTek YBT100 and YBT100DS3 Backhaul Tester
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

General Safety Summary
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Terms in this Manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could
result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could
result in damage to this product or other property.
Symbols and Terms on the Product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you
read the marking.
WARNING indicates an injury hazard not immediately accessible
as you read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
NetTek YBT100 and YBT100DS3 Backhaul Tester v
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Environmental Considerations
Environmental Considerations
This section provides information about the environmental impact of
the product.
Product End-of-Life Handling
Observe the following guidelines when recycling an instrument or
component:
Battery Recycling. This product contains a lithium ion (Li-ion)
rechargeable battery, which must be recycled or disposed of properly.
Please properly dispose of or recycle the battery according to local
government regulations.
Transporting Batteries
The lithium ion rechargeable battery pack in this product contains
less than 8 grams of equivalent lithium content, with individual cells
containing less than 1.5 grams of equivalent lithium, as measured by
International Civil Aviation Organization (ICAO) standards. Consult
your air carrier for applicability and determination of any special lithium
ion battery transportation requirements.
Restriction of Hazardous Substances
This product has been classified as Monitoring and Control equipment,
and is outside the scope of the 2002/95/EC RoHS Directive. This
product complies with the RoHS Directive requirements except for
the presence of hexavalent chromium in the surface coating of the
aluminum chassis parts, assembly hardware, and 63/37 tin/lead solder
used in the fabrication of the circuit boards.
vi NetTek YBT100 and YBT100DS3 Backhaul Tester
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Preface
Preface
Documentation
To read about Use these documents
Installation and
operation (overviews)
NetTek YBT100 and YBT100DS3 Backhaul Tester
User Manual. The user manual contains general
information about how to put your instrument into
service, guides to user interface controls, and
application examples.
Help using the
application
YBT100 and YBT100DS3 Online Help. The online
help is context sensitive to provide definitions for
some instrument settings, and alarm and event
definitions. A help button is also available on some
dialog boxes to display information about that
dialog box.
NetTek YBT100 and YBT100DS3 Backhaul Tester vii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Preface
viii NetTek YBT100 and YBT100DS3 Backhaul Tester
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started
Key Features
The NetTek YBT100 and NetTek YBT100DS3 Backhaul Testers are
state-of-the-art, comprehensive, test modules for testing DS1 and DS3
services. The functionality and user-friendly design allows you to
easily analyze and resolve problems that arise in a network. These
lightweight, battery powered instruments combine all the test interfaces
needed to test and troubleshoot copper services without the need for
plug-in modules. The YBT100 or YBT100DS3 can operate either
independently (to log measurements/events) or from a PC or NetTek
Y400 Analyzer Platform. Features include:
Part of the NetTek Toolbox, which provides a portable and
full-featured transmitter, antenna, and backhaul testing solution
Controlled using the NetTek Y400 Analyzer platform, a PC, or a
laptop, or can be left on-site to monitor signal events
Wireless 802.11 b/g connection lets you operate the YBT100 or
YBT100DS3 from a laptop without a direct connection, such as
from a vehicle in bad weather
Display elements show all test results on the main screen, with
color coding to make pass/fail testing viewable from across a room
Easy-to-use interface with key settings accessible from the main
application screen, or within one or two clicks
Two fully independent DS1 test interfaces (YBT100 and
YBT100DS3), and an optional DS3 test interface (YBT100DS3),
with monitoring, error insertion, and loop test capabilities
NetTek YBT100 and YBT100DS3 Backhaul Tester 1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started
Standard Accessories
Accessory
Tektronix part
number
NetTek YBT100 Backhaul Tester YBT100
NetTek YBT100DS3 Backhaul Tester YBT100DS3
NetTek YBT100 and YBT100DS3 Backhaul Tester
User Manual
071-2070-XX
NetTek YBT100 and YBT100DS3 Backhaul Tester
Software installation CD
063-3987-XX
Instrument Pouch 016-1992-XX
Accessory Pouch 016-1993-XX
115 VAC Power Adapter 119-7323-XX
802.11 b/g Antenna 119-7330-XX
RS232 Adapter Cable 012-1706-XX
T1 Bantam Test Cables, 2 (Gray) 012-1710-XX
DS3 75 Ohm BNC Cable (Red) (YBT100DS3
only)
012-1704-XX
DS3 75 Ohm BNC Cable (Blue) (YBT100DS3
only)
012-1705-XX
2 BNC to WECo 440 Adapters (YBT100DS3 only) 012-1707-XX
2 NetTek YBT100 and YBT100DS3 Backhaul Tester
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started
Installation
Software
Do the following to install the YBT100/YBT100DS3 software on either
a PC or NetTek Y400 Analyzer Platform:
1. Insert the NetTek YBT100 and YBT100DS3 Backhaul Tester
CD into a CD-compatible drive on your PC or laptop. The PC
displays the installation screen.
2. Select one of the following:
Install YBT100 Software on Y400 to install software on a
NetTek Y400 Analyzer Platform.
Install YBT100 Software on PC to install software on your
PC or laptop.
3. Follow the on-screen instructions.
NetTek YBT100 and YBT100DS3 Backhaul Tester 3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started
Configuration
NOTE. Throughout the rest of the manual, the term YBT100 refers to both
the NetTek YBT100 and the NetTek YBT100DS3 modules. When instructions
or information is specific to a particular model, the specific model is called
out in the text.
Power
Connecting the AC Adapter. Do the following to install the AC power
adapter and charge the batteries:
1. Insert the AC power adapter mini-jack into the instrument. See 1
in the next figure.
2. Connect the AC adapter module to an AC power source. The
yellow Charge LED on the instrument lights to indicate that the
instrument battery is charging. The LED turns off when the battery
is charged. See 2 and 3 in the next figure.
3. Charge the Lithium-Ion battery for eight hours before using the
instrument on battery power for the first time. A full charge from a
discharged battery requires approximately six to eight hours.
Powering On and Off the Instrument.
1. Move the Power On switch in the up direction to power on
the YBT100. The green power LED lights to indicate that the
instrument is powered on.
2. To power off the instrument, move the switch in the down direction.
4 NetTek YBT100 and YBT100DS3 Backhaul Tester
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started
Running on Battery Power. The following are guidelines for operating
the YBT100 from battery power:
The AC adapter charges the battery pack and supplies power to
the module.
The battery charge circuit is independent of the power state
(On/Off) of the instrument.
A full charge from a discharged battery requires approximately
sixtoeighthours.
How long the instrument can run on battery power depends on
the number of active test interfaces (DS1-A, DS1-B, and DS3)
that are running. The battery supports a single test interface for
approximately 8 hours of continuous operation. Multiple test
interface selections decreases the battery life by about 30% for
each active interface.
Setting Up Communications to a PC or NetTek Y400
You must connect the YBT100 module to a PC or NetTek Y400 to
configure the YBT100 to monitor or insert signals. You can connect the
YBT100 module to a PC using a wireless 802.11 b/g connection, or to a
PC or NetTek Y400 Analyzer Platform by using the supplied YBT100
to PC RS-232 adapter cable (Tektronix part number 012-1706-XX).
Setting Up the Wireless 802.11 b/g Connection.
NOTE. Each PC 802.11 b/g implementation is different (built-in, PCMCIA
card wireless adapter, USB-port wireless adapter, PCI card). Use the
instructions that come with your PC or WiFi adapter to set up and enable
your 802.11 unit. The following instructions use the Microsoft Windows XP
Wireless Network Connection utility to configure your PC to use 802.11 b/g
to communicate with the YBT100.
1. Enable the 802.11 communications device on your PC. Consult
your PC manual or WiFi adapter manual for instructions.
2. Connect the 802.11 antenna to the YBT100 module antenna
connector.
3. Power on the YBT100 module.
NetTek YBT100 and YBT100DS3 Backhaul Tester 5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started
NOTE. Do not start the YBT100 application on the PC at this time. You
must set the PC or laptop wireless communications parameters before
running the YBT100 application.
4. On the PC, click Start > Settings > Network Connections >
Wireless Network Connection.
5. Click View Wireless Networks. The Windows XP operating
system scans for wireless connections and displays a list of all
detected wireless networks. The list should include LTRX_IBSS. If
LTRX_IBSS is not listed, make sure that the YBT100 is powered
on and that the LOW BAT indicator LED is not lit.
6. Double-click on LT RX _IBSS.ClickConnect Anyway if the
warning message dialog box is displayed. The list should update
after a moment to show that the LTRX_IBSS is connected.
7. Select LTRX_IBSS in the list and click Advanced Settings to
open the Wireless Network Connection Properties dialog box.
8. In the General tab, scroll down the list and select Internet
Protocol (TCP/IP).
9. Click Properties.
10. Click the Use the following IP address check box and enter the
following IP address inthefield:
192.168.10.01
11. Click inside the Subnet Mask field to automatically fill in the field
(255.255.255.0).
12. Click OK, then click Close.
13. Double-click the YBT100 icon on the PC.
14. Click Port in the menu bar and select the appropriate 802.11 port
for your YBT100 instrument. The YBT100 application should link
to your PC after a few moments.
6 NetTek YBT100 and YBT100DS3 Backhaul Tester
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Getting Started
Disabling the YBT100 Wireless Connection. UseyourlaptoporPC
wireless connectivity tools to disconnect or close the 802.11 b/g wireless
connection.
Setting Up the Serial Cable Connection.
CAUTION. Use only the supplied YBT100-to-RS-232 cable. Do not use a
standard USB cable to connect from the YBT100 RS-232 port to a USB port
on a PC or other device. The signal on the RS-232 port of the YBT100 is
not a USB signal. The YBT100 RS-232 connector pinouts, signal types, and
voltage types are not compatible with standard USB connectors and could
damage one or both pieces of equipment. If your PC does not have an
RS-232 connector, obtain an RS-232 to USB adapter to connect the RS-232
end of the cable to the PC USB port.
1. Connect the USB-style connector of the supplied YBT100
USB-connector-to-RS-232 cable into the YBT100 RS232 port on
the module rear panel.
2. Connect the DB9 RS-232 connector to the PC or Y400 COM1
RS-232 port.
3. Start the YBT100 application on the PC. The YBT100 application
displays No Comm Link to the right of the speaker on/off button.
4. Power on the YBT100 module. The YBT100 application
automatically recognizes and establishes communications with the
YBT100 instrument over the RS-232 cable, and replaces the No
Comm Link message (adjacent to the Spkr on/off button) with
ET: n:n:n, indicating the time period of the current test run.
You can also verify that the YBT100 application is communicating
with the YBT100 module by looking at the instrument rear panel
status LEDs. The Link Fault LED will be off, and the Rx and Tx
LEDs will be blinking.
NetTek YBT100 and YBT100DS3 Backhaul Tester 7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
