Vicon V4400QS-1 User manual

Vicon part number 8009-8029-01-01 Rev 403 Section 5
XX029-01-01
MODEL V4400QS-1 AND V4400QS-1P
DIGITAL COLOR QUAD SPLITTERS
Copyright © 2003 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: [phone] WEB: www.vicon-cctv.com

FCC Notice
Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart
B for a Class A digital device.
WARNING
This equipment generates and uses radio frequency energy and if not installed and used properly,
that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio
and television reception. It has been type tested and found to comply with the limits for a Class A
computing device in accordance with the specification in subpart B of part 15 of the FCC rules,
which are designed to provide reasonable protection against such interference in a commercial
installation. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio and television reception, which can
be determined by turning equipment off and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
•Reorient the receiving antenna.
•Relocate the equipment with respect to the receiver.
•Relocate the equipment away from the receiver.
•Plug the equipment into a different electrical outlet so that the equipment
and receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for
additional suggestions.
The user may find the following booklet prepared by the Federal Communications Commission
helpful:
“Interference Handbook, Bulletin CIB-2”
This booklet is available from the U.S. Government Printing Office, Superintendent of Documents,
Mailstop SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1.
Warning: Power must be removed from this unit before removing circuit modules or ribbon
cables.
Caution: This unit contains circuit cards with integrated circuit devices that can be damaged
by static discharge. Take all necessary precautions to prevent static discharge

Important
Safeguards
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the unit.
1. Read Instructions -All the safety and operating
instructions should be read before the video product is
operated.
2. Retain Instructions -All the safety and operating
instructions should be retained for future reference.
3. Heed Warnings -All warnings on the video product and in
the operating instructions should be adhered to.
4. Follow Instructions -All operating and use instructions
should be followed.
5. Cleaning -Step aapplies to equipment that can be
disconnected from the CCTV system without seriously
jeopardizing security. Step b applies to equipment that must
operate continuously such as video switching equipment at
military installations.
a. Disconnect this video product from its power source
before cleaning. Do not use caustic, abrasive, or
aerosol cleaners. Use a damp cloth for cleaning.
b. Use a damp cloth to clean the equipment. Do not
allow moisture or liquids to enter any vents. Do not
use caustic, abrasive, or aerosol cleaners.
6. Attachments -Do not use attachments not recommended
by Vicon as they may cause hazards.
7. Water and Moisture-Do not use this video product in
any location where it may be exposed to water or moisture.
This does not apply to outdoor camera housings, outdoor pan-
and-tilt drives, and other equipment designed for direct
exposure to outdoor environments.
8. Accessories -Do not place this video product on any
unstable surface or table. The video product may fall, causing
serious injury to a person and serious damage to the video
product. Use only withamountingaccessory recommended by
Vicon, or sold with the video product. Any mounting of the
video product should follow Vicon’s instructions, and a
mounting accessory recommended by Vicon should be used.
9. Ventilation -Slots and openings in the cabinet are
provided for ventilation and to ensure reliable operation of the
video product and to protect it from overheating, and these
openings must not be blocked or covered. The openings
should never be blocked by placing the video product on a rug
or other similar surface. This video product should never be
placed near or over a radiator or heat register. This video
product should not be placed in a built-in installation such as
a bookcase or rack unless proper ventilation is provided or
Vicon’s instructions have been adhered to.
10. Power Sources-This video product should be operated
only from the type of power source indicated on the marking
label. If you are not sure of the type of power supplied to your
installation site, consult your Vicon dealer or local power
company. For video products intended to operate from battery
power, or other sources, refer to the operating instructions.

11. Grounding -This applies to video products equipped
with a 3-wire grounding-type plug, a plug having a third
(grounding) pin. This plug only fits into a grounding-type
power outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose
of the grounding-type plug.
12.Power-Cord Protection -Power supply cords should be
routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and the
point where they exit from the video product.
13. Outdoor Cable Grounding-If an outside cable system
is connected to the video product, be sure the cable system is
grounded so as to provide some protection against voltage
surges and built-up static charges. Section 810 of the National
Electrical Code, ANSI/NFPA 70-1984, provides information
with respect to proper grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
14. Lightning -For added protection for this video product
when it is not used for long periods of time, disconnect it
from its power source and from the cable system. This
prevents damage to the video product due to lightning and
power-line surges.
15. Power Lines-An outside cable system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside cable
system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be
fatal.
16. Overloading-Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17. Object and Liquid Entry -Never push objects of any
kind into this video product through openings as they may
touch dangerous voltage points or short out parts that could
result in a fire or electric shock. Never spill liquid of any kind
on the video product.
18. Servicing-Do not attempt to service this video product
yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
19. Damage Requiring Service-Disconnect this video
product from its power source and refer servicing to qualified
service personnel under the following conditions. Note that
step cdoes not apply to outdoor camera housings, outdoor
pan-and-tilt drives and other equipment specifically designed
for direct exposure to outdoor environments.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into
the video product.
c. If the video product has been exposed to rain or
water.
d. If the video product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as an improper adjustment of other
controls may result in damage and will often require
extensive work by a qualified technician to restore
the video product to its normal operation.
e. If the video product has been dropped or the cabinet
has been damaged.
f. When the video product exhibits a distinct change in
performance -this indicates a needfor service.
20. Replacement Parts-When replacement parts are
required, be sure the service technician has used replacement
parts specified by Vicon or that have the same characteristics
as the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.
21. Safety Check-Upon completion of any service or repairs
to this video product, ask the service technician to perform
safety checks to determine that the video product is in proper
operating condition.

CONTENTS
1. UNPACKING ……………………………………………………………….… 1
2. SERVICE ……………………………………………………………………… 1
3. DESCRIPTION ………………………………………………………………… 1
3.1 V4400QS-1 …………………………………………………………………….. 1
4. INSTALLATION ……………………………………………………………….. 2
4.1 V4400QS-1 Connections ……………………………………………………. 2
5. PROGRAMMING ………………………………………………………………. 2
5.1 Key Functions ………………………………………………………………… 3
5.2 Camera Setup ………………………………………………………………… 3
5.2.1 Camera Titles ………………………………………………………………… 4
5.3 Time and Date ……………………………………………………………….. 4
5.3.1 Time/Date Set ………………………………………………………………… 4
5.3.2 Date Format…………………………………………………………………… 5
5.3.3 Hour Format ………………………………………………………………….. 5
5.4 Alarm …………………………………………………………………………… 5
5.5 Display …………………………………………………………………………. 5
5.5.1 PIP Mode Setup ………………………………………………………………. 6
5.5.2 Color Setup ……………………………………………………………………. 6
5.5.3 VCR Output …………………………………………………………………… 7
5.5.4 Title Display ………………………………………………………………….. 7
5.5.5 Time/Date Display …………………………………………………………… 7
5.5.6 Display Position ……………………………………………………………… 7
5.6 Password ……………………………………………………………………… 7
5.6.1 New Password ……………………………………………………………….. 8
5.6.2 Password State ………………………………………………………………. 8
6 OPERATION……………………………………………………………………. 8
6.1 V4400QS-1 Operation ………………………………………………………. 8
6.1.1 Basic Operation ……………………………………………………………… 8
6.1.2 VCR …………………………………………………………………………….. 9
6.1.3 Sequence Switching ……………………………………………………….. 9
6.1.4 Manual Switching ……………………………………………………………. 9
6.1.5 Quad Display ……………………………………………………………….. 9
6.1.6 Video Loss Alarm …………………………………………………………… 10
6.1.7 Freeze Frame Function …………………………………………………... 10
6.1.8 Computer Remote Control ………………………………………………… 10
6.1.9 Factory Default Settings …………………………………………………… 10
7. MAINTENANCE ……………………………………………………………… 11

1. UNPACKING
Unpack carefully. This is electronic equipment and should be handled carefully.
Check to ensure that the following items are included with applicable modules ordered.
•V4400QS-1 Digital Color Quad
•Accessory Pack (including brackets for rack installation)/Power Cord
•Installation Instructions
2. SERVICE
If the unit ever needs repair or service, follow the Shipping Instructions at the end of this manual.
3. DESCRIPTION
3.1 V4400QS-1
The V4400QS-1 Digital Color Quad Splitter provides on-screen display of four camera inputs combined with
numerous additional functions. Each quadrant may be sequenced full screen or be displayed in a quad split.
The image display is updated at the field rate of 60 field/sec, providing genuine real-time video. In addition to
the quad screen display, the unit offers “digital zoom” VCR playback function, to allow full screen viewing
during tape playback.
Notes:
1. This manual applies to both the V4400QS-1(120VAC) and V4400QS-1P(230VAC) units. The
V4400QS-1 is used to refer to both models unless specified differently.
2. Read these instructions through completely before attempting installation and operation.
3. The V4400QS-1 provides a Color Adjustment menu to assist initial monitor adjustment.
4. If the video is to be looped out to other equipment, make sure that the final item of video equipment
on each line is terminated with 75 ohms.
5. The VCR can be connected to the unit to allow response to alarms.
6. Do not apply any voltage to any alarm input; this will damage the unit.
7. Set the host computer to the half-duplex mode. The V4400QS-1 does not echo received characters.
1

4. INSTALLATION
4.1 V4400QS-1 Connections
Alarm In Quad
Pin No. Signal
1 Alarm 1 In
2 Alarm 2 In
3 Alarm 3 In
4 Alarm 4 In
COM Common
Alarm Out
Pin No. Signal
1(NC) Normally Closed
2(Com) Relay Com
3(NO) Normally Open
4(G) GND
5. PROGRAMMING
Alarm Connect
Looping (Automatic Termination)
camera 4
2
AC-IN
Power
Adaptor
Monitor 2Monitor 1
Time Lapse VCR
Monitor output
camera 3
camera 2
camera 1
Output Input
Looping(Automatic Termination)
Power DC12V adaptor

5.1 Key Functions
Table 1
Key Functions
Key label Operating Function Programming Function
VCR Selects VCR input for display on monitor. NONE
PIP Selects the Picture-in-Picture switching function. Enters the programming mode with SEQ/ALM.
SEQ/ALM Selects the sequential switching function and alarm
reset function. Enters the programming mode with PIP.
1/Selects camera 1 for full-screen display on monitor Scrolls upward through program selections; selects
entries.
2/Selects camera 2 for full-screen display on monitor. Scrolls downward through program selections;
selects entries.
3/Selects camera 3 for full-screen display on monitor. Shifts cursor to the left in menus; selects entries.
4/Selects camera 4 for full-screen display on monitor. Shifts cursor to the right in menus; selects entries.
QUAD/ENTER Selects quad display on monitor. Enters or sets function.
!Programming the V4400QS-1 includes writing titles for the video inputs, assigning dwell times for each input
and the quad display for sequential (SEQ) operation, enabling or disabling the video loss alarm, and enabling
or disabling the password. Each of these functions comes preprogrammed with a factory default setting.
!All programming is done with the front panel keys. There are eight keys on the front panel. The keys
named PIP + SEQ/ALM (MENU), 1/

, 2/

, 3/

, 4/

, and QUAD/ENTER are used for
programming units. Refer to Table 1 for key functions.
!Press and hold the PIP key and then press the SEQ/ALM key to display the programming screen. The
following is displayed.
5.2 Camera Setup
This menu allows you to adjust the dwell times of the 4 camera video displays and the quad screens.
!Select CAMERA SETUP and press the QUAD/ENTER key. The following menu is displayed.
MAIN MENU
CAMERASETUP
TIME/DATE SETUP
ALARM SETUP
DISPLAY SETUP
PASSWORD SETUP
EXIT
CAMERA SET UP
TITLE SET
CH1 DWELL : 5 SEC
CH2 DWELL : 5 SEC
CH3 DWELL : 5 SEC
CH4 DWELL : 5 SEC
QUAD DWELL : 5 SEC
EXIT
3

!Press the 1/and 2/keys to move the cursor to the required channel.
!Press the
QUAD/ENTER key to increase the dwell time. Dwell times may be programmed from SKIP to
99 seconds. (When you reach 99 seconds, pressing the QUAD/ENTER key will toggle you through the
sequence again. A setting of “SKIP” removes the channel from the sequence.)
!Select
EXIT and press the QUAD/ENTER key to exit the menu.
5.2.1 Camera Titles
!Select TITLE SET on CAMERA SETUP screen and press the QUAD/ENTER key. The following menu is
displayed.
!Press the 3/and 4/keys to move the cursor to the required channel.
!Select the camera title, using the 1/and 2/keys, up to maximum of 8 characters. Choose from the
following for each of the characters:
Alphabet (26 letters), Numbers (0-9), Special Characters ([,], [.], [:], [!], [*], [#], [(],[)], [-], [+], [/], [ ]).
!Select
EXIT and press the QUAD/ENTER key to exit the menu
5.3 Time and Date
!Select TIME/DATE on MAIN MENU screen and press the QUAD/ENETR key. The following menu is
displayed.
5.3.1 Time/Date Set
!Select the TIME/DATE SET on TIME/DATE SETUP screen and press the QUAD/ENTER key. The
following menu is displayed.
TITLE SETUP
CH1 : CH1
CH2 : CH2
CH3 : CH3
CH4 : CH4
EXIT
TIME/DATE SET
MM/DD/YYYY HH/MM/SS
09/14/1999 XX : XX : XX
TO EXIT PRESS ENTER KEY
TIME/DATE SET UP
TIME/DATE SET
DATE FORMAT : MM/DD/YY
HOUR FORMAT : 12 HOURS
EXIT
4

!To set the time and date properties, shift the cursor into position by pressing the 3/(or 4/) keys and
select the required time and date values using the1/and 2/keys.
5.3.2 Date Format
!Select the DATE FORMAT on TIME/DATE SETUP screen. Press the QUAD/ENTER key to toggle
choices and select date format.
MM/DD/YYYY
DD/MM/YYYY
YYYY/MM/DD
5.3.3 Hour Format
!Select the HOUR FORMAT on TIME/DATE SETUP screen. Press the QUAD/ENTER key to toggle
choices and select required hour format.
12 HOURS
24 HOURS
!Select
EXIT and press the QUAD/ENTER key to exit the menu.
5.4 Alarm
The ALARM menu allows you to set the alarm options for each of the video inputs. The alarms can be set on
or off, dwell time, polarity and video loss.
!Select ALARM on the MAIN MENU and press the QUAD/ENTER key. The following menu is displayed.
!Press 3/and 4/keys to move the cursor to the required channel.
!Press the
QUAD/ENTER key to toggle the selections.
ALARM OFF/ON
VD LOSS OFF/ON
POLARITY NC/NO
V/L DISPLAY ON/OFF
RESET TIME: Press the QUAD/ENTER key to select 1-99 seconds or manual.
!VD LOSS function enables you to define if an alarm is generated when any of the video inputs is
lost/defective.
!Polarity selects if the alarm is normally closed (NC) or normally open (NO).
!V/L DISPLAY function enables you to define what happens if video is lost. V/L ON displays a BLUE
COLOR and the words “VD LOSS” on the screen if video is lost. When OFF, a BLACK COLOR screen
is displayed.
!Select
EXIT and press the QUAD/ENTER key to exit the menu.
5.5 Display
!Select DISPLAY on MAIN MENU. The following menu is displayed.
ALARM
CH1 CH2 CH3 CH4
ALARM OFF OFF OFF OFF
VD LOSS OFF OFF OFF OFF
POLARITY NC NC NC NC
V/L DISPLAY : ON
RESET TIME 03 SEC
EXIT
5

5.5.1 PIP Mode Setup
!Select PIP MODE SETUP on DISPLAY SETUP screen. The following menu is displayed.
!Use the1/and 2/keys to select function.
!To use the PIP MODE function, select ENABLE or DISABLE by using QUAD/ENTER key.
!Select PIP FORM on PIP MODE SETUP screen. The following menu is displayed.
!Select PIP SIZE SET. The screen will display PIP image.
!Control the size of PIP display by pressing QUAD/ENTER key to toggle size selections.
!Select PIP POSITION SET.
!Control the position of PIP display by pressing QUAD/ENTER key to toggle position selections.
!Select
EXIT and press the QUAD/ENTER key to exit the menu.
5.5.2 Color Setup
!Select COLOR SETUP on DISPLAY SETUP screen. The following menu is displayed.
DISPLAY SETUP
PIP MODE SETUP
COLOR SETUP
VCR OUT :QUAD ONLY
TITLE DISPLAY : ON
TIME/DATE DISPLAY: ON
DISPLAY POSITION : BOTTOM
EXIT
PIP MODE SETUP
PIP MODE : ENABLE
PIP FORM : SETUP
EXIT
IF PIP MODE IS SELECTED
VCR_OUT_MODE IS FORCED TO
SAME_AS_MONITOR
PIP FORM SETUP
PIP SIZE SET
PIP POSITION SET
EXIT
6

!Select camera using the 1/key.
!Select Brightness or Contrast using the 2/key.
!Control brightness/contrast of camera by the 3/(darkens/decreases contrast)
and 4/(lightens/increases contrast) keys.
!Press the
QUAD/ENTER key to exit COLOR SETUP menu.
5.5.3 VCR Output
!Select VCR OUT on DISPLAY SETUP screen and press the QUAD/ENTER key to toggle selections.
Select required function.
QUAD ONLY
SAME AS MONITOR
5.5.4 Title Display
!Select TITLE DISPLAY on DISPLAY SETUP screen and press the QUAD/ENTER key to toggle
selections. Select required function.
ON
OFF
5.5.5 Time/Date Display
!Select TIME/DATE DISPLAY on DISPLAY SETUP screen and press the QUAD/ENTER key to toggle
selections. Select required functions.
ON
OFF
5.5.6 Display Position
!Select DISPLAY POSITION on DISPLAY SETUP screen and press the QUAD/ENTER key to toggle
selections. Select required positions.
TOP
BOTTOM
!Select
EXIT and press the QUAD/ENTER key to exit the menu.
5.6 Password
The unit incorporates a password function for entry to the menu operation. This ensures that only authorized
persons can change the unit’s settings.
!Select PASSWORD on the MAIN MENU. The following menu is displayed.
CAMERA BRIGHTNESS
!!!!!!!!!!!!!!!!!
PASSWORD SET
NEW PASSWORD
PASSWORD DISABLE
EXIT
7

!Confirm 4 digit password.
!When a correct password is entered, the main menu is displayed. Otherwise, “Wrong Password” is
displayed for 3 seconds.
!The password function can be disabled.
5.6.1 New Password
!Select NEW PASSWORD on PASSWORD SET screen. The following menu is displayed.
!Enter a 4 digit password by using 1/and 2/keys. The following menu is displayed.
!Confirm the same password again.
!PASSWORD SET is displayed if entered password is correct.
5.6.2 Password State
!Select PASSWORD.
!Press the
QUAD/ENTER key to toggle selections. Select desired function.
ENABLE
DISABLE
6 OPERATION
6.1 V4400QS-1 Operation
Normal operating selections are made using the eight front panel keys, and functions are selected with a
single key press. The V4400QS may be controlled by a host computer using a simple RS-232 command set.
6.1.1 Basic Operation
The basic operation includes selecting the sequence, follow, VCR, or quad modes and selecting individual
camera channels for hold viewing. When the unit is in the operational mode (that is, not in the programming
mode), six keys (SEQ/ALM,1,2,3,4,QUAD/ENTER) perform the functions. The four keys labeled 1, 2, 3, and
4 select video channels 1 through 4, respectively, and the QUAD/ENTER key selects the quad display.
ENTER PASSWORD
????
CONFIRM PASSWORD
????
8

6.1.2 VCR
!The VCR key selects the input from the VCR to be displayed on the system monitor.
!You can view the recorded VCR images in a quad format or any quad can be zoomed to full-screen.
To View Recorded VCR Images
1. Insert a recorded tape in the VCR and press the PLAY key.
2. Press the VCR button to display the playback video from the VCR. The LED above the VCR key remains
illuminated as long as this function is selected.
3. The VCR images can be viewed as recorded in a quad format or any quad be zoomed to full screen.
1 Press the “1” key: The upper left hand quad is zoomed to full screen.
2 Press the “2” key: The upper right hand quad is zoomed to full screen.
3 Press the “3” key: The lower left hand quad is zoomed to full screen.
4 Press the “4” key: The lower right hand quad is zoomed to full screen.
5 Press “QUAD” key: Display VCR video as recorded.
If the monitor screen does not display a picture when the VCR key is pressed, check to make sure that the
VCR is plugged in and turned on, that a recorded tape is inserted, and that the VCR is in the PLAY mode.
6.1.3 Sequential Switching
The SEQ/ALM key selects the sequential switching function. The sequencing list and dwell times can be
customized (refer to the Programming section).
!Press the
SEQ/ALM key to start video sequencing. The cameras are displayed in the order 1-2-3-4-
QUAD-1-2-etc. The quad screen is displayed after camera 4. Each camera remains on screen for
programmed dwell period, unless its dwell was set at “SKIP”. In this case, it is deleted from sequencing
stack.
If the unit is running in the VCR mode, pressing the VCR key again switches the unit to the sequential
switching mode. If the unit is running in the programming mode, selecting EXIT switches the unit to the
sequential switching mode.
6.1.4 Manual Switching
!Press the 1, 2, 3, or 4 key to select manual switching. The selected quadrants will be displayed in full
screen mode.
The camera title of the selected quadrant is displayed in the programmed position.
If the unit is operating in the VCR or programming mode, you cannot use manual switch mode.
6.1.5 Quad Display
!Press the
QUAD/ENTER key to display all four camera inputs on the system monitor screen. Each
quadrant displays the video from its respective camera. The four quadrants are separated by a black
border.
1. The title of camera 1 is displayed in the bottom right corner of the screen.
2. The title of camera 2 is displayed in the bottom left corner of the screen.
3. The title of camera 3 is displayed in the upper right corner of the screen.
4. The title of camera 4 is displayed in the upper left corner of the screen.
9

6.1.6 Video Loss Alarm
When an alarm input is generated, the relevant camera image appears as a full screen image.
For a generated alarm, the sequence of operation is:
1. MON output and VCR output are changed to display the full screen image of alarmed channel.
2. VCR output is changed to the same as MON output.
The VD LOSS remains in the alarm mode for the duration of the alarm.
6.1.7 Freeze Frame Function
This function enables you to freeze one channel of the 4 video channels on a full-screen mode by pressing
the numeric key of the selected channel on front panel.
To return to the previous mode, press the same numeric key.
6.1.8 Computer Remote Control
V4400QS-1 uses a very simple command set, each command consisting of three characters. The first
character in all cases is the slash or virgule (/). The unit looks only for a three-character command, with an
initial slash. It ignores all other characters. If a mistake is made in entering a command, just type in another
slash character followed by the appropriate character for the desired command. The commands are listed in
the Table 3, RS-232 Commands.
Signal Format is as follows:
1. Data Format: 1,200 Baud/8 Data Bit/No Parity/One Stop Bit.
2. Mode: Half Duplex Mode (Not Echo Received Character).
Table 3
RS-232 Commands
COMMAND RS-232 CODE RS-232 Pin-out
VCRinput /VR Pin1 NotUsed
Enter the programming mode /ME Pin 2 RS-232 In
Sequence/Reset /SR Pin 3-4 Not Used
Camera1/Up /1U Pin5 GND
Camera2/Down /2D Pin6-9 NotUsed
Camera 3/Left /3L
Camera 4/Right /4R
Quad display/Enter /QE
PIP /PI
6.1.9 Factory Default Settings
You can restore the unit to its factory default settings as follows:
!Press and hold the QUAD/ENTER key and plug in the power cord (turn on power). This restores the
unit to its initial values.
The initial Factory Default values are as follows:
!CAMERA TITLES - Display as “CH1”, “CH2”, “CH3”, “CH4”.
10

!VCR OUT MODE - Set up as “Quad Only” mode.
!ALARM SETUP - Alarm channels are all ON and Video Loss Channels are all OFF. Dwell Time
issetupat5sec.
!SEQ SETUP - Each 2 seconds (1-4 and Quad).
!TIME/DATE - Time and Date are not changed; format is set up as MM/DD/YYYY.
!PASSWORD SET - Password is disabled.
7. MAINTENANCE
The V4400QS-1 requires no routine maintenance and is designed for long, trouble-free use under normal
operating conditions. Repair should only be attempted by qualified personnel.
11

Shipping Instructions
Use the following procedure when returning a unit to the factory:
1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below.
Record the name of the Vicon employee who issued the R.A.
Vicon Industries Inc.
89 Arkay Drive
Hauppauge, NY 11788
Phone: 631-952-CCTV (2288); Toll-Free: 1-800-645-9116; Fax: 631-951-CCTV (2288)
For service or returns from countries in Europe, contact:
Vicon Industries Ltd
Brunel Way
Fareham, PO15 5TX
United Kingdom
Phone: [phone]; Fax: [phone]
2. Attach a sheet of paper to the unit with the following information:
a. Name and address of the company returning the unit
b. Name of the Vicon employee who issued the R.A.
c. R. A. number
d. Brief description of the installation
e. Complete description of the problem and circumstances under which it occurs
f. Unit’s original date of purchase, if still under warranty
3. Pack the unit carefully. Use the original shipping carton or its equivalent for maximum
protection.
4. Mark the R.A. number on the outside of the carton on the shipping label.

Vicon Industries Inc.
Corporate Headquarters
89 Arkay Drive
Hauppauge, New York 11788
631-952-CCTV (2288) 800-645-9116
Fax: 631-951-CCTV (2288)
!Infofax: 800-287-1207
Vicon Europe
Headquarters
Brunel Way
Fareham, PO15 5TX
United Kingdom
[phone]
Fax: [phone]
Brussels Office
Planet II - Unit E
Leuvensesteenweg 542
B-1930 Zaventem
Belgium
[phone]
Fax: [phone]
Far East Office
Unit 5, 17/F, Metropole Square
2 On Yiu Street, Shatin
New Territories,
Hong Kong
(852) 2145-7118
Fax: [phone]
Internet Address: www.vicon-cctv.com
