Vicon V1305R-DC User manual

Vicon part number 8006-8992-02-02 Rev 202 Section 9 & 12
X992
MODEL V1305R-DC
VARIABLE-SPEED RECEIVERS
Copyright © 2002 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com

FCC Notice
Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class
A digital device.
WARNING
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in
strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception. It
has been type tested and found to comply with the limits for a Class A computing device in accordance with the
specification in subpart B of part 15 of the FCC rules, which are designed to provide reasonable protection
against such interference in a commercial installation. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause interference to radio and television reception,
which can be determined by turning equipment off and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
•Reorient the receiving antenna.
•Relocate the equipment with respect to the receiver.
•Relocate the equipment away from the receiver.
•Plug the equipment into a different electrical outlet so that the equipment and receiver are
on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional
suggestions.
The user may find the following booklet prepared by the Federal Communications Commission helpful:
“Interference Handbook, Bulletin CIB-2”
This booklet is available from the U.S. Government Printing Office, Superintendent of Documents, Mailstop
SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1.
Warning: Power must be removed from this unit before removing circuit modules or ribbon cables.
Caution: This unit contains circuit cards with integrated circuit devices that can be damaged by static
discharge. Take all necessary precautions to prevent static discharge.

Coaxial Cable Recommendations
Coaxial cables used to route video signals to and from the unit must meet the video recommendations in this section.
Caution: Careful selection of the proper cable is essential to obtain the best performance from this
equipment. Vicon assumes no responsibility for poor performance when cables other than those
recommended are installed. In all cases, coaxial cable impedance should be 75 ohms.
Materials
Use only cable with a pure copper center conductor. Do not use cable with either a copper-plated steel or an aluminum
center conductor because these do not transfer signals effectively in the frequency range used in CCTV networks. A
center conductor with low DC resistance is required for effective CCTV operation. Solid-core bare copper conductor is
best suited to video applications, except where flexing occurs. If the coaxial cable will be subjected to flexing during
normal use, select a cable with a stranded center conductor. The preferred dielectric material is cellular (foam)
polyethylene. It has better electrical characteristics than solid polyethylene, but is more vulnerable to moisture.
Therefore, use only solid polyethylene dielectric cable with a heavy exterior insulation in applications subject to
moisture. The shield must be copper braid providing 95% or better coverage.
Cable Types
The most commonly used cable types are RG-59/U and RG-11/U. Each is actually a family of cables with widely varying
electrical characteristics, some of which are not suitable for CCTV applications. Choose a cable type by referring to the
characteristics and maximum distances listed below. The maximum distance for best picture refers to the distance
between the camera and the unit. The characteristics of the cables in this table should be used as a guideline when
cables other than Belden are used. Materials and construction must follow the guidelines above. Note that “BC” refers
to bare copper and “TC” refers to tinned copper.
Recommended Coaxial Cable Types
Cable
Type
Belden
Type No.
Alpha
Type No.
West Penn
Type No.
Type
Center
Conductor
Type Shield and
% Coverage
DC
Resistance
ohms per
1000 feet
(km)
RG-11/U 8213 9847 811,4811 14 Solid BC BC braid (95%) 2.6 (8.5)
RG-6/U 9248 9804C 806,4806 18 Solid BC Foil + 61% TC
braid (100%) 7.5 (24.6)
RG-59/U 8281 9803 815 20 Solid BC 2 TC braids (96%) 9.9 (32.5)
RG-59/U 9259 ---- 816 22 Stranded
BC BC braid (95%) 15.0 (49)
RG-59/U 9659 ---- ---- 22 Stranded
BC BC braid (95%) 15.0 (49)
Picture Quality vs Cable Length
Picture Quality Maximum Cable Run*
ft (m)
RG-59/U RG-6/U RG-11/U
Dim, faint picture.
Cable amplification required. Up to 1100 (350) Up to 1500 (450) Up to 2400 (750)
Usable picture 1100 (350) 1500 (450) 2400 (750)
Clean picture 820 (250) 1000 (300) 1600 (500)
Best picture 400 (120) 530 (160) 820 (250)
* For longer cable runs, refer to the Product Specifications for Video Amplifiers.

X992 Rev 202 V1305R-DC Contents •• i
Contents
Introduction.......................................................................................................................................1
Installation..........................................................................................................................................3
Unpacking and Inspection ...................................................................................................................3
Inspection For Visible Damage.............................................................................................................3
Inspection For Concealed Damage.......................................................................................................3
Physical Installation.............................................................................................................................3
Cover Removal....................................................................................................................................3
Auxiliary Functions..............................................................................................................................4
Installing the Auxiliary Option Board.....................................................................................................4
Heater Installation ...............................................................................................................................4
Wiring the Unit.....................................................................................................................................5
Power Cable.......................................................................................................................................6
Camera Station Cable.........................................................................................................................6
Control Signal Cabling.........................................................................................................................7
NOVA Control System.....................................................................................................................7
Simplex Operation........................................................................................................................8
Duplex Operation .........................................................................................................................8
Vicoax II Control System (with V1422)...............................................................................................9
Video Cabling.....................................................................................................................................9
Main PCB Connections........................................................................................................................9
Receiver Power Connections..............................................................................................................10
Pan-and-Tilt, Lens and Auxiliary Connections......................................................................................11
Alarm Input/Tamper Connections........................................................................................................14
NOVA Control Connections................................................................................................................14
Star Configuration.............................................................................................................................14
Daisy-Chain Configuration..................................................................................................................15
End-of-Line Termination..................................................................................................................16
Preset Connections ..........................................................................................................................16
Video In Connections ........................................................................................................................17
Vicoax II Control Connections...........................................................................................................17
Preset Connections ..........................................................................................................................17
Video Input and Control from Transmitter Connections..........................................................................18
Video In and Video Out Connections.................................................................................................18
Control Settings.................................................................................................................................18
Option 1 Setting ...............................................................................................................................20
Option 2 Setting ...............................................................................................................................20

ii •• Contents X992 Rev 202 V1305R-DC
Electronic Limit Stops Setting............................................................................................................21
Test Mode Setting ............................................................................................................................21
Clear All Presets...........................................................................................................................22
Autoiris Setting.................................................................................................................................22
Finishing Installation .........................................................................................................................22
Operation..........................................................................................................................................23
Maintenance....................................................................................................................................23
Fuse Replacement.............................................................................................................................23
Shipping Instructions....................................................................................................................24
Technical Information...................................................................................................................25

X992 Rev 202 V1305R-DC Important Safeguards •• iii
Important
Safeguards
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the unit.
1. Read Instructions -All the safety and operating
instructions should be read before the video product is
operated.
2. Retain Instructions -All the safety and operating
instructions should be retained for future reference.
3. Heed Warnings -All warnings on the video product
and in the operating instructions should be adhered to.
4. Follow Instructions -All operating and use
instructions should be followed.
5. Cleaning -Step aapplies to equipment that can be
disconnected from the CCTV system without seriously
jeopardizing security. Step b applies to equipment that
must operate continuously such as video switching
equipment at military installations.
a. Disconnect this video product from its power
source before cleaning. Do not use caustic,
abrasive, or aerosol cleaners. Use a damp cloth
for cleaning.
b. Use a damp cloth to clean the equipment. Do not
allow moisture or liquids to enter any vents. Do not
use caustic, abrasive, or aerosol cleaners.
6. Attachments -Do not use attachments not
recommended by Vicon as they may cause hazards.
7. Water and Moisture -Do not use this video product
in any location where it may be exposed to water or
moisture. This does not apply to outdoor camera
housings, outdoor pan-and-tilt drives, and other
equipment designed for direct exposure to outdoor
environments.
8. Accessories -Do not place this video product on
any unstable surface or table. The video product may
fall, causing serious injury to a person and serious
damage to the video product. Use only with a mounting
accessoryrecommended by Vicon, or sold with the video
product. Any mounting of the video product should
follow Vicon’s instructions, and a mounting accessory
recommended by Vicon should be used.
9. Ventilation -Slots and openings in the cabinet are
provided for ventilation and to ensure reliable operation
of the video product and to protect it from overheating,
and these openings must not be blocked or covered.
The openings should never be blocked by placing the
video product on a rug or other similar surface. This
video product should never be placed near or over a
radiator or heat register. This video product should not
be placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided or Vicon’s
instructions have been adhered to.
10. Power Sources -This video product should be
operated only from the type of power source indicated
on the marking label. If you are not sure of the type of
power supplied to your installation site, consult your
Vicon dealer or local power company. For video
products intended to operate from battery power, or
other sources, refer to the operating instructions.

iv •• Important Safeguards X992 Rev 202 V1305R-DC
11. Grounding -This applies to video products
equipped with a 3-wire grounding-type plug, a plug
having a third (grounding) pin. This plug only fits into a
grounding-type power outlet. This is a safety feature. If
you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
12. Power-Cord Protection -Power supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit
from the video product.
13. Outdoor Cable Grounding -If an outside cable
system is connected to the video product, be sure the
cable system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Section 810 of the National Electrical Code,
ANSI/NFPA 70-1984, provides information with respect
to proper grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding
electrode.
14. Lightning -For added protection for this video
product when it is not used for long periods of time,
disconnect it from its power source and from the cable
system. This prevents damage to the video product
due to lightning and power-line surges.
15. Power Lines -An outside cable system should not
be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside cable system, extreme care should be taken to
keep from touching such power lines or circuits as
contact with them might be fatal.
16. Overloading -Do not overload wall outlets and
extension cords as this can result in a risk of fire or
electric shock.
17. Object and Liquid Entry -Never push objects of
any kind into this video product through openings as
they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never
spill liquid of any kind on the video product.
18. Servicing -Do not attempt to service this video
product yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
19. Damage Requiring Service -Disconnect this video
product from its power source and refer servicing to
qualified service personnel under the following
conditions. Note that step cdoes not apply to outdoor
camera housings, outdoor pan-and-tilt drives and
other equipment specifically designed for direct
exposure to outdoor environments.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into
the video product.
c. If the video product has been exposed to rain or
water.
d. If the video product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician to
restore the video product to its normal operation.
e. If the video product has been dropped or the
cabinet has been damaged.
f. When the video product exhibits a distinct change
in performance-this indicates a need for service.
20. Replacement Parts -When replacement parts are
required, be sure the service technician has used
replacement parts specified by Vicon or that have the
same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
21. Safety Check -Upon completion of any service or
repairs to this video product, ask the service technician
to perform safety checks to determine that the video
product is in proper operating condition.

X992 Rev 202 V1305R-DC Introduction •• 1
Introduction
The information in this manual covers the installation, operation, and maintenance for the V1305R-DC Variable-
Speed Receiver. This equipment should only be installed by a qualified technician using approved materials in
accordance with national, state, and local electrical codes. Read these instructions through completely before
attempting installation.
The V1305R-DC receiver is designed to provide variable-speed control of Vicon’s ViStar25 series of pan-and-tilts
and Vicon motorized zoom lenses; the receiver is factory set to operate these units and no further option
settings are required. The receiver controls pan, tilt, zoom and focus as well as providing an autoiris drive. The
receiver may be used with any NOVA™ (RS-422) control system or a Vicoax II (V1422) control system. Refer to
Table 1 for model/system compatibility. The term V1305R-DC is used to refer to all versions of the receiver
unless specifically stated otherwise.
The receiver is designed to work in two modes, velocity mode and preset position mode. In velocity mode, pan
and tilt can operate together at any required combination of velocities. The maximum velocity is determined by
the pan-and-tilt drive. The velocity mode allows smooth motion at very low velocity. Using this mode, a complete
scan in the pan axis can be programmed to take up to 5 minutes. Focus and zoom can be operated
concurrently with pan and/or tilt. Two-speed operation of zoom and focus is provided.
The V1305R-DC can store up to 79 preset positions. Positions are stored in nonvolatile memory. A preset
position defines zoom and focus as well as pan and tilt. In preset position mode, software insures smooth
acceleration and deceleration, preventing the premature wearing out of the pan-and-tilt when using successive
preset position recalls to implement camera tours or using this mode on a long-term basis.
Two relays are provided in the receiver; two additional relays can be added with an optional board, Model
V1305R-R, which is mounted on the inside of the receiver cover. The relays operate remotely. Each relay output
may be configured separately to operate in either momentary or latching mode. In momentary mode, the relay
remains on only as long as the stimulus continues. In latching mode, the relay must be reset to remove the
condition.
The V1305R-DC is encased in a metal weatherproof enclosure. A 25 W heater option is available as an option,
Model V1305R-H. Seven compression fittings are provided for routing cable.
The V1305R-DC complies with FCC requirements for a Class A device and with European Community EMC
Directive 89/336 EEC and amendments 92/31/EEC. The product was subjected to the testing outlined in
European Normalization Standard (Emissions) EN55022, A1: 1995 and A2: 1997 Class B, (Harmonic
Emissions) EN61000-3-2: 1995, A1: 1998 and A2: 1998, (Flicker) EN61000-3-3: 1995 and (Immunity) EN50130-
4: 1995 and A1: 1998. Table 1
Model Numbers and Descriptions
Model Number Product Code Description
V1305R-DC1 5144 120 VAC input/24 VDC variable output, NOVA RS-422
V1305R-DC1-230 5144-01 230 VAC input/24 VDC variable output, NOVA RS-422
V1305R-DC2 5078 120 VAC input/24 VDC variable output, Vicoax II
V1305R-DC2-230 5078-01 230 VAC input/24 VDC variable output, Vicoax II

2•• Introduction X992 Rev 202 V1305R-DC
Notes

X992 Rev 202 V1305R-DC Installation •• 3
Installation
Unpacking and Inspection
All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver
the equipment in the same condition as it left the factory.
Inspection For Visible Damage
Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the carrier’s
freight bill.
Make sure the carrier’s agent (the person making the delivery) signs the note on all copies of the bill. If the agent
does not have claim forms, contact the carrier’s office.
Inspection For Concealed Damage
As soon as possible after delivery, unpack the unit and inspect it for concealed damage. Do not discard the
carton or packing materials. If the unit is damaged, contact the carrier immediately and request forms for filing a
damage claim. Make arrangements for a representative of the carrier to inspect the damaged equipment. If the
equipment must be returned for repair, follow the Shipping Instructions at the end of this manual.
Physical Installation
The receiver must be installed at a location near the corresponding camera station to be controlled. The
maximum distance between the receiver and the camera station is determined by the maximum operating
distance of the motorized lens or the pan-and-tilt. In most cases, the pan-and-tilt is the determining factor in
calculating the maximum distance between the receiver and camera station. Refer to the instruction manuals for
those units. The V1305R-DC is designed to be mounted on a vertical surface with four M6 bolts (or equivalent).
The upper two holes have keyhole slots for ease of mounting.
Note: Be sure the power is disconnected from the unit while performing installation procedures. Do not apply
power until instructed to do so.
Caution: When installed outdoors, the receiver must be positioned with the cable entry fittings and the
connectors pointing downward. If it is necessary to mount the receiver in a different position, protect
the cable entry fittings and connectors from exposure to moisture. Be sure to seal any unused
fittings. Make sure the unit is properly grounded via the earth ground of the power cable.
Cover Removal
To open the cover of the V1305R-DC, remove the four (4) screws from the top of the unit. When the cover is
removed, it remains attached to the enclosure by a cord.

4•• Installation X992 Rev 202 V1305R-DC
Auxiliary Functions
Four relay drives are available which operate remotely. Each relay output may be configured separately to
operate in a momentary or latching mode. The default setting for the auxiliary relays is momentary. The receiver
has two (2) installed relays that are rated 240 VAC or 30 VDC 5 A. These are normally open (NO) contacts. The
two (2) other relay drive outputs are rated at 50 mA and can be used to drive 2 relays on an option board or other
external relays as required.
Installing the Auxiliary Option Board
If additional relay driver outputs are needed, an option auxiliary relay board, Model V1305R-R, is available. This
option board is installed onto the receiver enclosure cover. Refer to Figure 1.
1. Snap the option board onto the four (4) standoffs on the inside front cover of the receiver.
2. Remove the connector provided on TB2 on the main board of the receiver.
3. Insert the connector from the V1305R-R into TB2 on the main board.
Note: The connector is keyed so it can only be inserted correctly.
4. Slip the sealing nut over the power cable with the threads facing toward the end of the cable. Position the
sealing nut approximately 10 inches (250 mm) from the end of the cable. Insert the end of the power cable
through the cable entry fitting and thread nut onto the fitting. Tighten the sealing nut firmly and secure the
power cable.
5. Strip off the outer cable covering of the three (3) conductors (HOT (LINE), NEUTRAL, and GROUND).
Remove approximately 0.25 inches (6 mm) of insulation from the end of each conductor.
6. Make power connections to TB1 on the option board according to the table below. Refer to Figure 1. Make
connections from TB4 to the relay device according to the table below. Tighten the screws on the terminal
block to secure the wires.
V1305R-R Screw Terminal Connections
TB1 Function
NNeutral
LLine (Hot)
Ground Symbol Ground
TB4
AUX3 Load
AUX4 Load
COM Return
Heater Installation
A 25 W heater option, Model V1305R-H, is available. The heater increases the receiver’s operating temperature
range to -40° to 140° F (-40° to 60° C). The option works with 120 or 230 VAC input. When the temperature goes
below 32° F (0° C), the thermostat closes the heater circuitry to generate heat. When the temperature reaches
86° F (30° C), the thermostat opens the circuit to turn off the heater.
The heater option is installed onto the four standoffs located on the side of the receiver with the compression
fittings. Refer to Figure 1. The heater assembly snaps onto the standoffs by the four holes in the aluminum panel
of the assembly. When mounting the heater assembly, be sure to orient it so that the end with the brown and
red wires is closest to the power terminal block mounted in the receiver adjacent to the main PCB. The heater is
wired to the power terminal block.

X992 Rev 202 V1305R-DC Installation •• 5
Connect the brown wire to the same screw terminal that the other brown wire is connected to (L or HOT);
connect the red wire to the screw terminal that the blue wire is connected to (N or RETURN).
Figure 1
Installing the V1305R-R and V1305R-H
Wiring the Unit
The receiver has pluggable terminal blocks that may be inserted vertically or horizontally into the mating halves
on the PCB. To avoid confusion, use the vertical orientation at all times.
Caution: Be sure that the detachable part of the terminal block is properly inserted into the dovetails in the
permanent part of the terminal block; otherwise the connector is not properly mated.
Seven cable entry fittings are provided for routing of cables. All cables should be routed through cable entry
fittings and terminated at the appropriate terminal block. Use the closest entry fittings to the terminal block so
that congestion is minimized inside the unit. Refer to Figure 2.

6•• Installation X992 Rev 202 V1305R-DC
Figure 2
Receiver Connector Panel
Power Cable
The total power requirement for the camera station is needed in order to determine the proper cable gauge for
input power. To determine the total power requirement of the camera station, add up the requirements of all
individual components, including pan-and-tilt drive, housing accessories, receiver and other related equipment.
The V1305R-DC requires a maximum of 50 W. Choose the appropriate cable gauge for the total power
requirement. Vicon strongly recommends the use of line conditioners, voltage regulators, and uninterruptible
power supply (UPS) systems.
Camera Station Cable
Vicon recommends that separate cables be used for pan-and-tilt, lens, alarm and auxiliary functions. Refer to
Table 2. Refer to Table 3 to choose the appropriate cable type per the maximum operating distance between the
receiver and the next component(s) in the line. All cable types except Belden 9182 are dual cable. Dual cables
have two twisted pairs of cables that are shielded to prevent communications between the two sets. Each pair is
enclosed by a shield. The shield includes a stranded conductor, the “drain,” that allows the shield to be
connected to a ground. Therefore, a dual cable has six conductors: two conductors plus a ground in each of two
sets of conductors plus a ground in each of two sets of conductors. Belden 9182 is not dual cable -it contains
two conductors and a shield for a total of three conductors. Be sure to ground all cables connecting the receiver
to the pan-and-tilt on both ends. The V1305R-DC provides several grounding tabs (Figure 1). Refer to the
instruction manual for the pan-and-tilt (X940 for ViStar) for grounding that device.
Table 2
Receiver Cables
Function Number of Conductors
Required
Pan and Tilt 4
Pan and Tilt Preset
Positions (normal feedback) 4
Pan and Tilt Preset
Positions (cosine feedback) 5
Pan/Tilt Brake4
Motorized Lens 4
Lens Preset Positions 4
Auxiliary Relays 4
Optional Auxiliary Relay
Drivers 3
Alarm/Tamper 2

X992 Rev 202 V1305R-DC Installation •• 7
Control Signal Cabling
The cable used to route control signals between the control system and the receiver depends upon the type of
control system used, NOVA (RS-422) or Vicoax II.
NOVA Control System
If the receiver is being used with a NOVA control system, model V1305R-DC1 or V1305R-DC1-230 is used.
Some system choices must be made to determine the number of cables required to use the V1305R-DC1 with a
NOVA control system.
NOVA communications permit the connection of the receiver in either a star or daisy-chain configuration, as
shown in Figure 3. The star configuration requires the use of a Distribution Line Control (DL). Refer to the
instruction manual for the DL as necessary. The relative location of the receiver in the configuration is one of the
factors which determines the required number of cables. Decide which receiver configuration will be used.
NOVA control systems offer both simplex and duplex operation. Command signals, which send control
information from the control system to the receiver, are always required. Response signals are used to transmit
information such as the activation of alarms and communication failures to the NOVA control system. Simplex
operation requires the use of only command signals; duplex operation requires the use of both command and
response lines. Choose either simplex or duplex operation.
Refer to Table 3 to choose the appropriate cable type per the maximum operating distance between the receiver
and the next component(s) in the communications line.
All cable types except Belden 9182 are dual cable. Dual cables have two twisted pairs of cables that are
shielded to prevent communications between the two sets. Each pair is enclosed by a shield. The shield
includes a stranded conductor, the “drain,” that allows the shield to be connected to a ground. Therefore, a dual
cable has six conductors: two conductors plus a ground in each of two sets of conductors. Belden 9182 is not
dual cable -it contains two conductors and a shield for a total of three conductors.
Table 3
Individually-Shielded Twisted-Pair Cable
Maximum Operating Distance
Cable Type Maximum Distance
Belden 9406* 5000 (1500)
Belden 9402* 5000 (1500)
Belden 8723* 8000 (2400)
Belden 8162* 15,000 (4600)
Belden 9729* 15,000 (4600)
Belden 9182 25,000 (7600)
*Dual cable

8•• Installation X992 Rev 202 V1305R-DC
Simplex Operation
Determine the number of cables to be connected for simplex operation based on the receiver configuration (star
or daisy-chain) using Table 4.
Table 4
Simplex Operation
Number of Cables to be Connected
Cable Type Star Daisy-Chain
Belden 9182 12
Duplex Operation
Both command and response connections are required for duplex operation. Using Table 5, determine the
number of cables to be connected for duplex operation based on the receiver configuration (star or daisy-chain)
and the cable type chosen.
Table 5
Duplex Operation
Number of Cables to be Connected
Cable Type Star Daisy-Chain
Belden 9406 12
Belden 9402 12
Belden 8723 12
Belden 8162 12
Belden 9729 12
Belden 9182 24
Figure 3
Daisy-Chain and Star Configurations
