Victor Tools G352 User manual

Power Washer Spray Set
G352 v01: 10/06/20
Please read and retain these instructions for future reference
Technical Data
Battery charger
Input: 100-240Va.c; 50-60Hz, 0.4A
Output Volt: 16.8V, 0.6A, 10.0W
Battery: Li-ion 2000mAh
Input voltage: 16.8V DC.
Output Speed: 4700(r/min)
Max Water Flow: 3-5L/min
Max Water Pressure: 1.0Mpa
30min runtime on full charge
3 hours charging time
Only use with the battery and charger
provided.
Product Safety
General safety warning
Warning! Please read all warnings and
instructions. Failure to comply with the
following warnings and instructions can result in
electric shock, fire and serious injury.
Keep all instructions
Accessories:
5m PVC Hose
Battery Charger
Spray gun
Watering can
Brush
Safety Warning
1. Do not spray water to device containing electrical
components.
2. Only use accessories supplied or approved by the
manufacturer.
3. Disconnect the battery pack after use or before
maintenance or cleaning.
4. Keep the machine away from children.
5. Stop using the machine when it accidentally falls to
the ground and causes visible damage or leakage.
6. The machine should not be left unattended when
connecting the battery pack
Brush
Advisory: We recommend this is
used by persons over 18 years.

Power Washer Spray Set G352 Instructions for Use
Please read and retain these instructions for future reference v001:10/06/20
Symbols
Warnings.
Read the instructions.
Do not throw into water.
Do not throw into fire.

Power Washer Spray Set G352 Instructions for Use
Please read and retain these instructions for future reference v001:10/06/20
Safety Warning
Battery Pack Instruction
1. Do not disassemble, open or shred battery pack
2. Do not expose battery pack to heat, flame, or sunshine.
3. Do not short-circuit.
4. Do not take battery cell out of battery pack.
5. No mechanical impact to battery pack.
6. If the battery leaks, do not expose the leaked liquid directly to the eyes or skin. If a leak occurs, rinse
with plenty of water and seek medical help.
7. Do not use non-device-specific charger.
8. Mind the POSTIVE(+) and NEGATIVE(-) signs.
9. Do not use non-device-specific battery pack.
10. Keep battery pack away from children.
11. Medical help should be obtained if battery pack is swallowed.
12. Choose the right battery pack for the product.
13. Keep battery clean and dry.
14. If there is dust on the interface of the battery pack, wipe it with a clean, dry cloth.
15. Charge before use; Use correct charger
16. Do not charge the battery pack if washer is not to be used for a long time.
17. After long-term storage, the battery pack should be subjected to multiple charge and discharge cycles
to achieve optimal performance.
18. Use within temperature range of between 20-25 °C for optimum performance.
19. Keep the manual for future reference.
20. The battery pack is for intended use only.
21. Remove the battery when not in use.
22. Correctly handle battery pack.
23. Do not expose battery to water or rain.
24. After using the product, unplug it and then clean it. If the product is used to clean a swimming pool
please ensure there is no water in the pool.

Power Washer Spray Set G352 Instructions for Use
Please read and retain these instructions for future reference v001:10/06/20
User Instructions
Preparation
Install the battery pack (see Image 1).
Installation
Install long lance (see image 4)
Tip: After the long lance is installed, shake it left and right to check if it is firmly fixed.
Connect PVC hose
Tip: After connecting PVC hose, gently pull the hose to check if it is firmly connected to the machine. If the
hose does not fall off, the installation is in place.
Connect your own hose
1. Remove the hose connector
2. Connect the machine to the hose with right connector
Operation
Select water pressure
Start up
Note: When using for the first time, the air in the water pipe must be drained. Put the washer at about
waist height (<1.5 m) and then select high voltage mode. Water enters the water pipe and sprays from the
washing machine then starts cleaning. The entire process takes about 20 seconds.
Choose water spray effect
Note: The water effect should be selected according to the working condition. Rotating nozzle, 0-40° for
cleaning and watering.
Warning: Do not rotate nozzle after turning on the machine
Cleaning
Warning: Do not use turbid, muddy or corrosive water sources (including window cleaning fluid, plant
nutrients, fertilizer etc.) Note: Please rinse with water after using the sea water.
Optional accessory use
This product comes with some accessories. Do not use the machine when there is no accessory attached.
1.Watering can
To provide deep cleaning cleaner; connect to the machine
2. Brush Attachment
To wash irregularities of a car's outline.
Maintenance and Repair
Please remove the battery pack from the machine before maintenance and repair.
Maintenance of water pipe filter maintenance and repair.
First take the filter cover down, then remove dirt on it, rinse all parts with clean water and finally put the

Power Washer Spray Set G352 Instructions for Use
Please read and retain these instructions for future reference v001:10/06/20
cover back.
Cleaning and Preservation
Please wipe the machine with a soft brush or a clean cloth. Do not use water, solvent or polish. Keep the
machine in a safe and dry place, away from children. Do not place other items on machine.
Troubleshooting
Problem
Cause
Solution
When the machine starts working
but cannot absorb water or there
is not enough pressure.
The machine is too high from the
water surface.
Please lower the machine within
1.5m from the water surface.
The water pipe filter is blocked.
Please remove the water hose
filter and clean the debris with
water.
The hose connector of the
machine is loose.
Please tighten the hose connector
with a wrench.
Pumps, water hose or other spare
parts are frozen.
Please use after thawing.
The water pipe is bent.
Please straighten the pipe.
After the machine is turned off,
there is water flowing out.
After the machine is turned off,
there is still water in the pump.
Please drain the water completely
before storing it.
The watering can cannot spray
the cleaner.
The watering can is blocked.
Wash it with water.
The machine cannot be started.
1. The battery is not correctly
installed.
2. The battery is exhausted.
3. The battery is broken.
1. Install the battery again.
2. Replace or charge the battery.
3. Replace the battery.
The pressure is not stable.
1. There is air inside the machine.
2. The machine is in low pressure
mode.
1. Check the machine and water
pipe whether they are connected
or not.
The machine stops automatically.
1. The battery is exhausted.
2. The nozzle of the long lance is
blocked.
1. Replace the battery.
2. Check the long lance.
DISPOSAL
•Coopers of Stortford use recyclable or recycled packaging where possible.
•Please dispose of all packaging, paper, cartons, packaging in accordance with your local
recycling regulations.

Power Washer Spray Set G352 Instructions for Use
Please read and retain these instructions for future reference v001:10/06/20
•Plastics, polybags –Contains the following recyclable plastic.
Code & Symbol
Type of Plastic
Polypropylene
Polystyrene
ABS, TPE, PA6
Commonly used
for
Microwaveable food
containers, yoghurt pots,
butter tubs, disposable
plates and cups
Insulation boxes, water cups,
protective packaging inserts,
take away containers
CD’s, crisp packets,
various flexible packaging,
baby bottles, sunglass
lenses
Notes
Commonly recycled and
collected from household
recycling bins (packaging
tape itself not recyclable but
does not interfere with
cardboard)
Not commonly recycled but
waste management
centres will recycle it.
Not often or widely
recycled
•At the end of the product’s lifespan please check with your local council authorised household waste
recycling centre for disposal.
