VictoriaPlum BSQ1003 User manual

8mm HINGED SQUARE BATH SCREEN
V05/05/2014
For Left And Right Hand Installation
(Left Hand Illustrated)
BSQ1003 BSQ1004
ASSEMBLY INSTRUCTIONS

BEFORE YOU START, HERE IS SOME IMPORTANT INFORMATION
1) General Information
2) Additional Notes
Please inspect this product upon delivery. any missing parts or manufacturing
defects must be reported immediately to the supplier. Damage of defects reported
later will not be accepted. TAKE CARE WHEN HANDLING GLASS PARTS-AVOID
HEAVY CONTACT BETWEEN THE GLASS EDGES AND ANY HARD SURFACE.
Glass breakage claims will not be accepted after the product has been unpacked.
Please note--alumimium is a soft metal, and undergoes a series of extrusion.
fabrication, polishing and anodising processes in order to create your finished
shower enclosure. Some light surface marks are normal, and is a result of the
manufacturing processes. Quality control has ensured that this item is of a good
standard, and is fit for purpose.
Please read these instructions carefully before starting installation.
Special care should be taken when drilling walls to avoid hidden pipes or electrical cables.
Note: this product is heavy and may require two people to install.
TOOLS REQUIRED
This product is heavy and may require two people to install.
Ø3mm Drill bit
Ø6mm Drill bit
Pencil
Spirit level
Tape measure
DESCRIPTION DESCRIPTIONPART IMAGE PART IMAGE
Drill
Flat-head
Screwdriver
Cross head
Screwdriver
Hammer
Silicone Sealant
1

ASSEMBLY INSTRUCTIONS-DRAWING
1
17
2
3
4
6
7
8
9
10
11
12
13
14
15
16
5
3xWall Plugs
3xScrew Clips
3xScrews 4x12
3xScrew Cover Caps
3xScrews 4x30
1xWall Profile
1xTowel Rail (Optional)
1xMoving Panel A
1xVertical Seal
2xHinges
1xBottom Seal A
1xDrip Strip
2xDrip Strip End Caps L/R
1xBottom Seal B
1xMoving Panel B
8xHinge Cover Caps
2xWall Profile Cover Caps (L/R)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
2

ASSEMBLY INSTRUCTIONS
If you require help, we advise you firstly contact a competent plumber
Installation Steps
IF YOUR SCREEN IS TO BE FITTED IN THE LEFT HAND POSITION - AS PER
THE FRONT COVER, THEN PLEASE PROCEED IMMEDIATELY TO STEP 2, DO
NOT FOLLOW STEP 1. IF YOUR SCREEN IS TO BE FITTED IN THE RIGHT
HAND POSITION THEN PLEASE FOLLOW THESE STEPS BELOW IN STEP 1
Step 1
3
1
10
3
5
8
9
2
6
Inside
4
7

Step 2
4
Flat Screw
M4x30
Step 3

INSIDE INSIDE
x3 x3 x3
Ø3.0mm Screw
M4x12
2 3
Step 4
Step 5
How to adjust the width of the hinged
square bath screen
Maximum adjustment
Wall
Minimum adjustment
Minimum 10mm
internal overlap required
Glass panel
Glass panel
Vertical profile
Vertical profile
Wall profile
Wall profile
Step 6
5

Step 7 Step 8
OUTSIDE
INTSIDE
Silicone (outside edge only) where the
vertical profile meets the wall.
Step 9
6

CARE AND MAINTENANCE
COMMITMENT TO QUALITY
1) AFTER CARE INSTRUCTIONS
2) MAINTENANCE
Regularly clean your shower product with warm soapy water
Clean the plastic parts with a cloth and mild detergent. Never
use any abrasive creams, dissolvents, acetone or detergents
and disinfectants that contain chlorine. The supplier accepts
no liability for any type of use of care other than those contained
in these instructions. The supplier reserves the right to introduce
technical changes without notice.
It is our intention that the quality and functions of this product
are of the highest standard. If you require help we advise you
firstly contact a competent plumber. However we understand that
this may not always be the case, so should you experience
any problems please contact out customer services quoting
the following:
Product name: 8mm Hinged Square Bath Screen
Product code: BSQ1003 BSQ1004
Customer help line number:0344 804 48 48
to prevent lime scale build up. Do not use abrasive cleaning
fluids or materials, or strong chemical cleaners as this will
damage the product surface.
7

8

The packaging you have received with your product is 100% recyclable.
It must be disposed of in a safe and environmentally friendly way.
We suggest you take it to the local landfill site and discard in the designated bins.
