V-Series Refrigerators
Cabinet:
Victory’s Value Packed V-Series refrigerators
are constructed of heavy gauge, polished
stainless steel and aluminum to maintain
an attractive appearance and maximum
durability for years to come.
Interiors feature coved corners that are easy
to clean and maintain. An average of over
21/2 inches of foamed-in-place polyurethane
insulation throughout the cabinet assures
the food storage compartment remains well
insulated promoting energy efficiency. The
bottom of the storage compartment is made
of heavy gauge metal with 31/2 inches of
polyurethane insulation for exceptional
strength. Interior lighting is recessed.
Doors:
The self-closing doors stay open at 110°
facilitating loading. Each door has a cylinder
lock.
Shelving:
Heavy-duty, epoxy coated steel shelves are
mounted on pilaster strips and are adjustable
on 1” increments. Wide door openings
accommodate two 12” x 20”, or one 18” x 26”,
or one 14” x 18” pans/trays per level.
Refrigeration:
All components of the self-contained refrigeration
system are mounted on top of the cabinet.
The air circulating fans and the forced
convection cooling coil are contained in an
insulated housing separate from the
product zone allowing for maximum food
storage capacity. All condensate water is
disposed of automatically by the energy
efficient nonelectric condensate evaporator,
no plumbing is required.
The R-134a refrigerant used is environmentally
friendly.
Standard Features
• Stainless Steel Fronts for Durability
• Polished Aluminum Sides
• Energy Efficient ABS Thermal Breakers
Around Door Jamb
• Heavy-Duty Swivel Casters with Brakes
• Recessed Interior Lighting
• Exterior Dial Thermometer
• Lifetime Self-Closing Camlift Hinges with
110° Stay-Open Feature
• Self-Adjusting Magnetic Door Gaskets
• Heavy-Duty Cylinder Locks
• Durable and Energy Efficient ABS Interior
Door Liners
• Field Reversible Door Swing
• Door Opening Accepts 20” Wide Pan(s)
• Epoxy Coated Shelves Adjustable on 1”
Centers
• Automatic Non-Electric Condensate Disposal
System
• Environmentally Friendly R-134a Refrigerant
• Anti-Corrosion Coated Evaporator Coil
• Cord Connected
Optional Features:
• Rod Type Pan Slides
• Stainless Steel Angle Type Pan Slides
• Adjustable 6” Legs
• Two Half Doors in Place of One Full Length
Door
• Change Door Swing
• Solar Digital Thermometer
VR-22
Victory Refrigeration, Inc. I 110 Woodcrest Road I Cherry Hill, NJ 08003 USA I Phone: [phone] I Fax: [phone] I E-mail: [e-mail]
Victory Refrigeration specification sheets
are available online at www.victory-refrig.com.
Approvals:
Project:
Location:
Item #:
Quantity:
VR-1
VR-2
VR-3
VR MODELS —
Stainless steel front.
Aluminum sides and interior.

Victory participates in the KCL CADalog, the most current source of CAD symbols for foodservice designers worldwide. Symbols include
standard equipment in plan, side, front and 3-D views, layered for FEDA/FCSI recommended guidelines.
Continuous product development may necessitate specification changes and design without notice.
Victory
Refrigeration, Inc. V-SSeries Refrigerators
CHARACTERISTICS ONE SECTION TWO SECTION THREE SECTION
Reach-In Reach-In Reach-In
Width, Overall 26 1/252 1/877 3/4
Depth, Overall (incl. handles) 33 1/433 1/434 1/2
Height, Overall (incl. adj. legs) 83 5/883 5/883 3/4
Depth, Open Door 90° 56 1/256 1/256 1/2
Clear Door Opening, Width 21 1/421 1/421 1/4
Clear Full Door Opening, Height 54 54 54
Clear Half Door Opening, Height 25 1/425 1/425 1/4
Capacity Net (cubic feet) 21.0 45.4 69.0
No. of Full Doors 1 2 3
No. of Half Doors 2 4 6
No. of Shelves 3 6 9
Shelf Area (square feet) 17.1 36.0 54.2
Cabinet Voltage 115/60/1 115/60/1 115/60/1
Feed Wires 2 2 2
Condensing Unit Voltage 115/60/1 115/60/1 115/60/1
Condensing Unit Size (HP) 1/31/31/2
Total Amperes 5.5 8.2 10.6
Plug, NEMA 5-15P 5-15P 5-15P
Crated dim. & wts. Ht. Width Depth Cu. Ft. Lbs.
One Section 83 34 43 82.2 305
Two Section 83 59 43 143.3 435
Three Section 83 86 43 204.4 585
Dimensional tolerance ± 1/4” Metric dimensions (MM)
Copyright January 2004
Printed in U.S.A. 010405
PART OF AGA FOODSERVICE GROUP
56.00
(1422)
33.25
(844)
31.00
(787)
2.25
(57)
13.88 (352)
6.00 (152)
VR-1, VR-2, VR-3 SIDE VIEW
26.50
(673)
83.62
(2124)
23.88 (606) TYP. DOOR
TYP. OPENING
VR-1 FRONT VIEW
26.00
(660)
22.50
(571)
33.25
(844)
VR-1 TOP VIEW
26.00
(660)
47.75 (1212)
33.25
(844)
52.12 (1323)
VR-2 TOP VIEW
33.25
(844)
77.75(1974)
73.25 (1860)
26.00
(660)
VR-3 TOP VIEW
52.12 (1323)
21.25
(539)
TYP. OPENING
23.88
(606)
TYP. DOOR
VR-2 FRONT VIEW
83.62
(2124)
77.75 (1974)
VR-3 FRONT VIEW
21.25
(539)
TYP. OPENING
23.88
(606)
TYP. DOOR
83.62
(2124)
21.25
(539)
NOTE: If cabinet is located directly against
wall and/or under low ceiling, a minimum
clearance of 2” is required.
We reserve the right to change
specifications and product design
without notice. Such revisions do not
entitle the buyer to corresponding
changes, improvements, additions or
replacements for previously purchased
equipment.
