Videocomm technologies Eat-002 (para-5829) User manual

5.8GHz Parabolic Antenna Manual Rev. A 2006

Model # EAT-002 (PARA-5829)

5.8GHz 29dB Parabolic Antenna

Manual Rev-A

OWNER’S MANUAL

It’s About Real-Time

5.8GHz Parabolic Antenna Manual Rev. A 2006

Antenna Assembly & Mounting

The longer the wireless video transmission range is, the more critical the alignment of BOTH the

transmitter and receiver antenna. If transmitting over one-mile in range, the vertical or horizontal

adjustment of the antennas can be measured in a few degrees. Consider using a portable Global

Positioning Satellite (GPS) receiver unit to determine the transmitter and receiver angles

accurately. Input the value for both the transmitter and for the receiver and then instruct the GPS

to give us the compass bearings between the two points with a GPS system a 10-mile unit can be

aligned faster than a 1-mile unit installed by “eye”.

Specifications:

Frequency Range 5.725 - 5.850 GHz

Antenna Gain 29 dBi

H-Plane Beamwidth 6 degrees

E-Plane Beamwidth 6 degrees

Antenna Connector N-Female

Mounting Brackets Maximum 3” Diameter Pole

STEP ONE

 Screw antenna element Rod into front dish.

5.8GHz Parabolic Antenna Manual Rev. A 2006

Antenna Assembly & Mounting

STEP TWO

 Mount the “L-Type” bracket to the

back of Parabolic antenna as shown

STEP THREE

 DO NOT TIGHTEN BOLTS

Mount Two “V-Type” brackets to the

mounting pole as shown

 See Step THREE before tightening

bolts for permanent installation.

5.8GHz Parabolic Antenna Manual Rev. A 2006

STEP FOUR

 DO NOT TIGHTEN BOLTS

Attach the “L-Type” bracket from

parabolic antenna - to the top TWO

bolts from the “V-Type” bracket

assembly on the pole as shown above.

 Make Horizontal adjustments to aim

the antennna LEFT-RIGHT as required

 Remove parabolic antenna and

permanently tighten four bolts on “V-

Type” bracket.

 Re-Attach parabolic antenna to the top

two bolts of “V-Type” bracket and

DO NOT TIGHTEN BOLTS –

hand tighten only for more adjustments

5.8GHz Parabolic Antenna Manual Rev. A 2006

STEP SIX

 The elevation of this antenna can be

adjusted to maximum 25-DEGREES UP or

DOWN as required – Shown Left

 The Vertical and Horizontal RF beam of

this antenna is 6-DEGREES. At this point

we strongly recommend a GPS device to

ensure proper targeting of the transmitter

device.

 Ensure proper antenna alignment and

strong RF signal before permanently

bolting the bracket assembly.

STEP FIVE

 Connect Low Loss Microwave cable

between parabolic antenna and video

receiver - As shown left & below

5.8GHz Parabolic Antenna Manual Rev. A 2006
