VideoHome ViewXpower User manual

ViewXpower
USB to HDMI 1080p adapter
USER’S MANUAL

I
FEDERAL COMMUNICATIONS COMMISSION
This device complies with Part 15 of the FCC Rules Operation is subject to the following
two conditions: this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiated radio frequency energy and, if not installed
and used in accordance with the instruction, may cause harmful interference to radio
communication. However, there is no grantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by tuning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Notice: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
CE DECLARATION
This device complies with CE . These limits are designed to provide reasonable protection
against harmful interface in a residential installation.
Printed in TAIWAN R.O.C No. 06282010
All contents are subject to change without notice.
All trademarks are the property of their respective owner.

Table of Contents
I I

Chapter 1. Overview
1
1.1 Introduction
ViewXpower- USB to HDMI adapter allows you connect an extra HDTV/monitor to
your desktop or notebook computer via USB port (include Video and Audio). Support
max resolution up to1920x1080 regardless your computer display card resolution.
The connected TV/monitor can be configured to either primary screen, mirror or
extend the Windows desktop which include the visibility of more applications at the
same time. ViewXpower is the best choice for your HD-display application.
1.2 Features
Delivers smooth high-resolution video & audio up to 1920 x 1080
Both Audio and Video via USB
Small size enough
Easily connect additional HDMI TV/monitor via USB 2.0 port.
Compatible with all Notebook/Desktop computers.
Plug & Play; Easy installation and operation.
Mirror, Extend and Primary a computer display workspace.
Support rotation (Normal/Left/Right/Upside-Down) function control.
Supports left, right, up and down extend display.
No external power supply needed.
Works seamlessly with Windows 7, Windows Vista and Windows XP operating
systems.
Support KVM switch and USB hub connection.
1.3 Specifications
USB 2.0 specification compliant.
HDMI 1.2 and HDCP 1.1 specifications compliant.
- Video : Supports pixel rates up to 165MHz, resolution up to 1080p.
-Audio : Supports 2 channels (Stereo) audio.
Dimension: 109 x 52 x 18.5 (mm)
Connectors:
- USB Mini-B female
-HDMI typeA

Chapter 1. Overview
0B1.4 System Requirements
Windows XP X86 / Windows Vista X86 & 64 / Win7 X86 & 64
Equipped USB2.0 Notebook/Desktop computer
CD-ROM drive (For software installation)
1.5 Package Contents
ViewXpower device x 1
USB A to mini B cable x 1
Driver / Manual CD x 1
Quick Installation Guide x 1
1.6 Application
Mirror mode (e.g. Presentation)
Extend mode (e.g. Play 1080p HD audio/video)
2

Chapter 2. Installation
2.1 Driver Installation
2.1.1Please insert "Multimedia Installation Kit" CD-ROM into your CD-ROM drive;
AutoRun will running. (if AutoRun didn’t run, please go to “My Computer”, click
CD-ROMdrive)
2.1.2 Select “ViewXpower” product.
2.1.3 Select “Device Driver”
2.1.4Setup wizard is running.
2.1.5LicenseAgreement, if you are agreeing to be bound by the terms of this
agreement, please click “I Accept”.
2.1.6Setup wizard will be completed automatically.
2.2 Hardware Installation
2
.2.1HDMI:Connect 2nd monitor with HDMI cable to ViewXpower HDMI port.
2.2.2USB:Connect USB to your computer’s USB port.
Note: We suggest plugging both USB plugs into the
computer USB ports, if the computer can not
supply enough current to one USB port.
2.2.3 System will now automatically detect new hardware.
2.2.4 Please check the Device Manager, ViewXpower
d
riveris installed successful in your computer.
2.2.5 After the driver is installed correctly, you should now
see
the following icon on your notification area.
3

Chapter 3. Operation (Win XP / Vista)
3.1 Starting
To access the menu, right click the icon on your notification area. This utility allows
you to quickly change the settings and resolution of your ViewXpower.
3.2 Screen Resolution
In Set as Main Monitor and Extended mode, you can change the display resolution
3.3 Color Quality
You can set display Color Quality, There are Medium (16-bit) and Highest (32-bit) can
select.
3.4 Screen Rotation
You can use the Rotation function
to change the display degree.
4

Chapter 3. Operation (Win XP / Vista)
3.5 Extend To
In the Extend mode, you can extend screen to Right / Left / Above / Below.
3.6 Extend
This setting will extend your
desktop from your main display
onto the secondary.
3.6.1 Extended Function Application
A
:DoubleDisplay
B:ScreenWall
3.7 Set as Main Monitor
Your main display (monitor) will
automatically switch to being the
secondary display and show the
extended desktop.
5

Chapter 3. Operation (Win XP / Vista)
3.8 Notebook Monitor Off
Disable main screen.
3.9 Mirror
This setting will mirror the image
from your main display onto the
secondary display. Your main
display and the extended display
will show the same image.
3.9.1 Mirror Function Application
e.g. Education
M
ultipleDisplay
Note: In the Mirror mode, Screen Resolution and Color Quality functions will
bedisabled.Thosetwofunctions depend on the primary screen display
settings,youcango to Advanced->Display to change.
6

Chapter 3. Operation (Win XP / Vista)
3.10 Off
Disable screen extend function.
3.11 Advanced…
Go to Windows operating system Display Properties
3.12 Optimize for Video (Only in Windows Vista)
Optimize for the video you are showing.
The function only can be used in Windows Vista.
7

Chapter 4. Operation (Win 7)
4.1 Starting
To access the menu, click the icon
on your notification area.
This utility allows you to quickly
change the settings of your
ViewXpower.
4.2 Check for Updates…
Check and download the latest driver automatically here.
4.3 Optimize for Video
Optimize for the video you are showing.
4.4 Advanced…
Change the appearance of your displays.
8

Chapter 4. Operation (Win 7)
1.Display:Display detected information.
2. Resolution: You can change the display resolution.
3.
Orientation: You can use this function to change the display Orientation you are
selected.
Select
a monitor Select the Orientation
Landscape
9

Chapter 4. Operation (Win 7)
Portrait
Landscape
(flipped)
P
ortrait(flipped)
10

Chapter 4. Operation (Win 7)
4. Multiple displays
Duplicate
these displays:
This setting will duplicate the image from your main display onto the secondary
display. Your main display and the extended display will show the same image.
Extend
these displays:
This setting will extend your desktop from your main display onto the secondary.
11

Chapter 4. Operation (Win 7)
Show desktop only on 1: Disable monitor 2
Show
desktop only on 2: Disable monitor 1
Note:
After the setting please remember to click “Apply” and “OK”
beforeyouquit.
12

Chapter 5. Troubleshooting
13
Q1: If the 2nd monitor’s image is out of screen (overscan):
A1: Please check the 2nd monitor’s display setting or change the ViewXpower screen
resolution (see 3.2).
Q2: I am unable to make the ViewXpower primary display!
A2: Some video cards ship their product with a utility that prevents other video cards from
being set as the primary card. Check the bottom right hand corner taskbar for this
utility and disable it before switching the ViewXpower to the primary display.
Q3: Why won’t my DVD player work when I move it over to the extended display?
A3: Some DVD playback software packages do not support playing on a second display
adapter of any kind.
Q4: How come my video will not play on Media Player if I move it over to the extended
desktop?
A4: Check that you have moved the Media Player window completely over to the second
screen.
Q5: Why does my mouse not move to the right side of the screen as it should on the
extended desktop?
A5: Check the display settings and make sure that your display number ‘2’ is on the right
side of display number ‘1’. You can rearrange how Windows treats each display in
relation to each other in the Display Properties Settings.
Q6: There are horizontal lines covering the displayed image
A6: This is due to a low refresh rate setting. You can change this in: Display Properties,
Settings, Advanced, Monitor. Make sure that you have selected the DisplayLink
device first, and do not exceed the refresh rate limitations of the monitor. Reset, or
resynchronize the monitor may also help. For further details on how to reset or
resynchronize your monitor, please refer to the documentation that was included with
your monitor purchase.
