Vidonn Q2 User manual

User Manual
Vidonn
Wireless Bone Conduction Headphones
Model: Q2
Bone conduction wireless headphones+MP3
User guide
Specifications
Power output---------------------------------750 mW
Headphones------------------------------------10.8mm driver
Frequency response---------------------------250Hz~20KHz
Rechargeable Lithium-ion battery----------3.7v, 175mA
Battery life----------------------------------------up to 3 hours
Charging time------------------------------------ approx. 1.5 hours
Weight---------------------------------------------approx. 31g
Size----------------------------------------------111mm(W)*120mm(L)*44mm(H)

Charge
1. Charge the headphones with the included Micro USB charging cable,
the USB output should be 5V, 0.5A or above, the headphones will be
fully charged in approximately 1.5 hours.
2. The LED indicator is red while charging, it will turn into blue when the
headphones are fully charged.
3. When the power is less than 30%, the LED indicator will flash red and
then turn off automatically when power runs out.
Wearing
Hang the speaker on ears as follow, make the speaker close to ear.
Wireless mode:
1. Pairing:
While F1 is power off, press the Power on/off button for 3
seconds, the LED flashes red and blue alternately and there is
voice prompt by the word “Pairing”, the LED flash blue after
paired.
Enter into pairing mode again:
Press and hold the Play/Pause button for 3 seconds while paired,

the LED flashes red and blue alternately, there is voice prompt by
“Pairing”, the LED flash blue after paired.
Note:
After paired, the headphones will pair with device automatically
if the device’s Bluetooth is on, if the headphones don’t pair
automatically, you may need to pair manually in device’s
“Settings-Bluetooth”, choose “Q2”.( This depends on the model
of devices)
2. MP3 mode:
Single click the Power on/off button while power is on, enter into
MP3 mode.
3. Instruction of buttons:
3.1 Press Volume + button to increase the volume.
3.2 Press Volume –button to decrease the volume.
3.3 Press Play/Pause button once to play or pause the audio.
3.4 Press and hold Volume + button for 3 seconds to move one track
backward.
3.5 Press and hold Volume - button for 3 seconds to move one track
forward.

Incoming calls
1. To answer an incoming call on your device, press the Play/Pause
button once.
2. To ignore an incoming call on your device, press and hold the
Play/Pause button for 3 seconds.
3. To end an active call on your device, press Play/Pause button once.
Note: The functions on controller box, includes Play/pause,
Answer/Reject calls and switch etc support iOS and most android mobile
devices.
Functions:
Button
Action
LED status
Voice prompt
Power on/off
Press and hold
Power on/off
button for 3
seconds(it enter
into pairing
mode
automatically
when turn on
first time)
LED flash red
and blue
alternately
power on/power off
Switch mode
Single click
Power on/off
button while
power is on
Wireless mode:
blue
MP3 mode:
green
Pairing/MP3
Paired
/
Solid blue
Your device is connected
Pairing
Press and hold
Play/Pause
button for 3
seconds
LED flash red
and blue
alternately
Pairing

Play/Pause
Single click
Play/Pause
button
Wireless mode:
Play: blue
breathing light
Pause: solid
blue
MP3 mode：
Play: green
breathing light
Pause: solid
green
/
Answer/End
call
Single click
Play/Pause
button
/
/
Reject call
Press and hold
the Play/Pause
button for 3
seconds
/
/
Increase
volume
Single click
Volume+ button
/
Decrease
volume
Single click
Volume- button
/
There is one beep if reach maximum
Next song
Press and
hold Volume +
button for 3
seconds
/
/
Previous song
Press and
hold volume –
button for 3
seconds
/
/
Prompt tone
language switch
Click volume +
and volume –
button once
simultaneously
while power is
on
/
/
Low power
alert
/
Prompt”Battery low, please charge”
Charging
/
Solid red
/

Charging
completed
/
LED off
/
Connect to
PC/laptop
connect the
controller with
PC/laptop by
USB data cable
while power off,
press and hold
the Power
on/off button
for 3 seconds,
and the PC
display
“removable
disk”
Solid blue and
green
/
Warning
To ensure the normal use of the product, please be sure to observe the
following safety precautions
1. Do not use the headphones while showering or bathing.
2. Do not place this product where it may fall into (or be drawn into) a
bathtub or a water basin.
3 Do not put this product into or immerse into water or other liquids.
4. When the headphones fall into the water, do not rush to remove them
by hand. Disconnect the headphones’power supply immediately.
5. Be careful not to get objects hit the headphones or Do not splash the
liquid into the earphone.
6 Use this unit only for its intended use as described in this manual.

7. Never drop or insert an object into any opening.
8. Protect the power cord from being walked on or pinched, particularly
at plug outlets, convenience receptacles and the point where is exits the
unit.
9. Do not allow cord to touch hot surfaces, wrap cord loosely around the
unit when storing.
10. The unit should be situated away from direct sunlight or heat sources
such as radiators, electric heaters, heat registers, stoves, or other
units(including amplifiers) that produce heat. Avoid placing on top of
stereo equipment that radiates heat.
11. Do not overload the electrical outlet. Use only the power source as
indicated.
12. Don not carry this unit by its cord or use the cord as a handle.
13. Never operate this unit if it has a damaged cord or plug, if it is not
working properly, or if it has been dropped or damaged, or dropped into
water. If the unit’s power supply cord or plug is damaged, do not attempt
to fix it yourself.
14. To avoid the risk of electric shock, do not disassemble or attempt to
repair the unit. Incorrect repair can cause risk of electric shock or injury
to persons when the unit is used.

Lithium-polymer battery warnings
This device contains a Lithium-Polymer battery. The battery must be
recycled or disposed of properly. Contact your local waste management
office for information on battery recycling or disposal.
Use only the supplied cable to recharge the battery. Improper charging
may damage the battery and the device.
Do not attempt to open the rechargeable battery or battery pack. There
are no serviceable parts inside.
Keep the battery out of reach of children. If swallowed, consult a
physician immediately.
Do not dispose of battery in a fire as it may explode. The battery may
also explode if damaged.
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.

NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without
restriction.
