Installation instructions
for contractors
Vitodens 200
Type WB2A, 8.8 to 26.0 kW
Wall mounted gas fired condensing boiler
Natural gas and LPG version
VITODENS 200
5862 559 GB 10/2006 Dispose after installation.

Please follow these safety instructions closely to prevent accidents and
material losses.
Safety instructions explained
Danger
This symbol warns against the
risk of injury.
!Please note
This symbol warns against the
risk of material losses and
environmental pollution.
Note
Details identified by the word "Note"
contain additional information.
Target group
These instructions are exclusively
designed for qualified personnel.
&Work on gas appliances must only
be carried out by a qualified gas fit-
ter.
&Work on electrical equipment must
only be carried out by a qualified
electrician.
Regulations
Observe the following when working
on this system
&all legal instructions regarding the
prevention of accidents,
&all legal instructions regarding
environmental protection,
&theCodeofPracticeofrelevant
trade associations,
&all current safety regulations as
defined by DIN, EN, DVGW, TRGI,
TRF, VDE and all locally applicable
standards.
Workingonthesystem
&Isolate the system from the power
supply and check that it is no longer
'live', e.g. by removing a separate
fuse or by means of a mains isola-
tor.
&Safeguard the system against
unauthorised reconnection.
&When using gas as fuel, also close
the main gas shut‐off valve and
safeguard against unauthorised
reopening.
Safety instructions
2
5862 559 GB

Preparing for installation
Product information .................................................................................... 4
Preparing for installation ............................................................................. 5
&Preparing the boiler installation ................................................................ 5
Installation sequence
Installing the boiler and making all connections ........................................... 7
Flue connection .......................................................................................... 8
Condensate connection .............................................................................. 8
Gas connection .......................................................................................... 9
Opening the control unit enclosure .............................................................. 10
Electrical connections................................................................................. 11
&Routing connecting cables ....................................................................... 13
Closing the control unit enclosure and inserting the programming unit ......... 14
Front panel installation................................................................................ 15
Commissioning and adjustment .................................................................. 15
Index
3
5862 559 GB

Vitodens 200, WB2A
Set up for operation with natural gas E.
For conversion to natural gas LL and LPG P (with conversion kit), see the instal-
lation instructions.
Conversion for other target countries
The Vitodens 200 should generally only be delivered to those countries speci-
fied on the type plate. For deliveries to alternative countries, an approved con-
tractor must arrange, on his own initiative, for an individual approval in
accordance with the law of the land.
Product information
4
5862 559 GB

Preparing the boiler installation
For on-site preparation of gas, water and electrical connections, see
installation instructions, installation aid or mounting frame.
AHeatingflowRp¾"
BDHW Rp ½" (gas fired combi boil-
er)
Cylinder flow G ¾" (gas fired boil-
er)
CGas connection
DCold water Rp ½" (gas fired combi
boiler)
Cylinder return G ¾" (gas fired
boiler)
EHeating return Rp ¾"
FFill & drain valve
Preparing for installation
5
5862 559 GB

GCable entry HDimension with DHW cylinder
below.
KCondensate drain
Note
This boiler (protection level: IP X4 D)
is approved for installation in wet
rooms inside protection area 1
according to DIN VDE 0100, providing
the occurrence of hosed water can be
excluded.
Observe the requirements of DIN VDE
0100.
1. Prepare the water connections.
Flush the heating system thor-
oughly.
2. Prepare the gas connection
accordingtoTRGIorTRForall
local regulations.
3. Prepare the electrical connections.
&Power supply cable: NYM-
J3x1.5mm
2
, fuse max. 16 A,
230 V~, 50 Hz.
&Accessory cables: NYM with the
required number of conductors
for the external connections.
&Allow all cables in area "G"to
protrude 1200 mm from the wall.
Preparing for installation (cont.)
6
5862 559 GB

Note
Quick-acting air vent valve and con-
nector for the expansion vessel
packed separately.
AHeating flow BDHW (gas fired combi boiler)
Cylinder flow (gas fired boiler)
Installing the boiler and making all connections
7
5862 559 GB

CGas connection
DCold water (gas fired combi boiler)
Cylinder return (gas fired boiler)
EHeating return
FFill & drain valve
Flue connection
Connect the balanced flue pipe. Flue gas system installation
instructions.
Condensate connection
Connect the condensate drain with a
slopeandapipeventtothepublic
sewer.
Installing the boiler and making all connections (cont.)
8
5862 559 GB

AGas connection
Notes regarding operation with
LPG.
We recommend the installation of an
external safety solenoid valve when
installing the boiler in rooms below
ground level.
1. Carry out a gas soundness test.
!Please note
Excessive test pressure
may damage the boiler and
the gas valve.
Max. test pressure 150mbar.
Where higher pressure is
required for leak tests, sepa-
rate the boiler and the gas
valves from the mains gas
supply pipe (undo the fit-
ting).
2. Vent the gas supply pipe.
Conversion to other gas
types:
Conversion kit installation
instructions
Gas connection
9
5862 559 GB

Opening the control unit enclosure
10
5862 559 GB

Information regarding the connection of accessories
For details of accessories, also observe their separate installation
instructions.
!Please note
Electronic modules can be damaged by electro-static discharges.
Touch earthed objects, such as heating or water pipes, to discharge sta-
tic loads.
ARadio clock receiver
Electrical connections
11
5862 559 GB

BVitotrol 100 UTD (only for con-
stant temperature control units)
Remove jumper when making this
connection.
CVitotrol 100 UTA (only for constant
temperature control units)
Remove jumper when making this
connection.
230 V~ plugs
fÖ Power supply
Danger
Incorrect core terminations
can cause severe injuries
and damage to the equip-
ment.
Take care not to inter-
change wires "L1" and "N".
&Install an isolator in the power
supply line which simulta-
neously separates all non-
earthed conductors from the
mains with at least 3 mm contact
separation.
&Max. fuse rating 16 A.
lH &Power supply accessories (230
V ~ 50 Hz). Where the boiler is
installed in a wet area, the con-
nection of accessories to the
power supply must not be car-
ried out at the control unit. The
power supply connection for
accessories can be made imme-
diately at the control unit, if the
boiler is installed outside wet
areas. This connection is
directly controlled with the sys-
tem ON/OFF switch (max. 3 A).
&Vitotrol 100 UTA
&Vitotrol 100 UTD
Low voltage plugs
!Outside temperature sensor
(only for weather-compensated
control units).
Installation:
&North or north-western wall,
2 to 2.5 m above ground level;
in multi-storey buildings, in the
upper half of the second floor
&Not above windows, doors or
ventilation outlets
&Not immediately below balco-
nies or gutters
&Never render over
&2-core cable, max. 35 m length
with a cross-section of
1.5 mm
2
?Flow temperature sensor for low
loss header (accessories)
%Cylinder temperature sensor
(part of the DHW cylinder con-
nection set).
aVG KM BUS user (accessories)
&Vitotrol 200 or 300 remote con-
trol
&Vitocom 100
&Extension kit for a heating cir-
cuit with mixer
&Vitosolic
&External extension H1 or H2
Electrical connections (cont.)
12
5862 559 GB

Routing connecting cables
!Please note
Connecting cables will be damaged if they contact hot parts.
When routing and securing connecting cables on site, ensure that the
maximum permissible temperatures for these cables are not exceeded.
ALow voltage connections
B230 V connections
CInternal extension
DMain PCB
ECommunications module
FCable grommet for power supply
cable
%Plugs for connecting the cylinder
temperature sensor to the cable
harness
Remove the existing cable grommet
when using larger cross-sections (up
to 714 mm). Secure the cable with
the cable grommet F(black) inte-
grated into the casing base.
Electrical connections (cont.)
13
5862 559 GB

Closing the control unit enclosure and inserting the programming unit
14
5862 559 GB

Commissioning and adjustment
For commissioning and adjust-
ment, see service instructions.
Front panel installation
15
5862 559 GB
