Viessmann KOB PYROMAT DYN 45 Assembly instructions

Instructions for Assembly and Installation
PYROMAT DYN 45 to DYN 85
5726 786 GB 10/2009 Version: 0.1 Please keep safe!

© by Köb Holzheizsysteme GmbH
Flotzbachstraße 33
A-6922 Wolfurt
All rights reserved, including photomechanical re-
production and storage in electronic media.
Viessmann Group

1General information 1
1.1 Technical standing 1
1.2 Information documented 1
2Important information 1
2.1 Safety information 1
2.2 Official permits 1
2.3 Standards and regulations 1
3The structural surroundings of the burner 2
3.1 Heating room requirements 2
3.2 The chimney connection 2
4Transport and installation 2
4.1 De-ashing, cleaning the heat exchanger and the exhaust blower 3
4.2 The light barriers 4
4.3 The casing 4
5The water installations 5
5.1 The safety equipment 5
5.2 Expansion 5
5.3 The burner circuit with burner control valve and storage unit valve 5
5.4 Container for extinguishing water (option) 5
6The electrical installations 6
6.1 The positioning of the control module and control system module (option) 6
6.2 Electrical connection 6
7Fire protection 6
7.1 Protection for the burner system against back-burn 6
7.1.1 Preventing overfilling of the combustion chamber 6
7.1.2 Preventing back-burn 6
7.1.3 The back-flash safeguard 6
7.1.4 Automatically Triggering Extinguishing System for the Burner Auger = ATEBA 7
7.2 Back-burn safeguard for the fuel supply system 7
7.2.1 Automatically Triggering System for the Material Supply System (ATSMS) 7
7.2.2 Slide valve, type MBA 7
7.2.3 Rotary valve, type MBS 7
7.2.4 Double rotary valve with pressure compensation 7
7.3 Fire protection for the fuel storage unit 7
8Initial Start-up 8
8.1 Filling the heating system 8
8.2 The fuel for the initial start-up 8
8.3 Inspecting the installation 8
8.4 Initial start-up and handover 8
9 Spec sheets
3950-1, 2 Wood-burning Pyromat-DYN, Installation, Closed System
3950-3, 4 Wood-burning Pyromat-DYN, Installation, Open System
4500-1 Water-bearing Components, Burner Safety Devices
4600-1, 2, 3 Water-bearing Components, Heat Distribution
3010-1, 2, 3, 4, 5 Burner System Loader System, PYROMAT-DYN
3110-1 Accessories for PYROMAT-DYN, Conducting Exhaust Gas / Cleaning
4000-1 ECOTRONIC Heating Control Unit, Equipping
4020-1, 2, 3 ECOTRONIC Heating Control Unit, Module Extension, Data Transmission Lines
4030-1, 2 ECOTRONIC Heating Control Unit, Additional Heat Generators
4040-1, 2 ECOTRONIC Heating Control Unit, Heat Consumer
4050-1, 2 ECOTRONIC Heating Control Unit, Solar Energy
4090-1 ECOTRONIC Heating Control Unit, Visualisation & Remote Maintenance
1120-1, 2 Installation Services
1010-1, 2 Wood Fuels, Minimum Requirements / Instructions
1000-1, 2 General Terms of Delivery
Supplement EC attestation of conformity

1
1 General information
Only specialists may set up and put into operation
Köb solid fuel burners. This will rule out any faulty
installation or initial start-up. These instructions
are therefore limited to important technical data,
references to ordinances, technical rules and other
regulations.
The PYROMAT DYN is a Burner Class 3 boiler for
heating systems with hot water with a protection
temperature of 110° C as per EN 303-5: 1999
(heating boilers for solid fuels, manual and auto-
matically loaded combustion systems).
1.1 Technical standing
The operating instructions comply with the PYRO-
MAT DYN at the time of its delivery. In the interest
of our customers, we reserve the right to make the
following alterations as a result of technical devel-
opments, without being under obligation to give no-
tification of such.
1.2 Information documented
The installation instructions contain the information
required according to the EC Directive "Machinery
98/37/EEC, Appendix 1, Number 1.7.4.
2 Important information
2.1 Safety information
The water-bearing and electrical installations as
well as the chimney connection must be carried
out by individuals authorised to do so, complying
with all relevant standards and safety regulations.
2.2 Official permits
The PYROMAT DYN has been inspected and ap-
proved in compliance with European Standard EN
303-5:1999. In addition, the PYROMAT DYN
meets all European national deviations relating to
tightened regulations relevant to emission limits
and efficiencies:
Austria:
Art. 15a of the B-VG
"Agreement on the Saving of Energy"
"Agreement on Protective Measures Concerning
Small Furnaces"
Federal Law Gazette
Ordinance 331
Furnace Ordinance
FAV dated 18 Nov 1997, Part II
Germany:
German Federal Emissions Control Act
"Small Furnaces Ordinance, 1st German Federal
Emissions Control Act" dated 1997-03-14
Switzerland:
The Clean Air Act (or "LRV") dated 16 Dec 1985,
incl. the amendment dated 20 Nov 1991
Netherlands:
NeR
Dutch guideline on the incineration of clean rem-
nant wood of June 1995
You can find out from your local building au-
thority whether the PYROMAT DYN requires an
official permit. This is why you should report
there your installation of the PYROMAT DYN.
2.3 Standards and regulations
- Hot-water heating systems: Safety equipment
DIN 4751, ÖNORM B 8130 [Austrian standard],
ÖNORM B 8131 [Austrian standard]
- Indoor chimneys: Requirements for planning
and design, DIN 18160
- Dimensioning of chimneys, DIN 4705, ÖNORM
M7515 [Austrian standard]
- Heating system water: preventing damage by
corrosion and scale formation in hot-water heat-
ing systems, VDI 2035
The regulations valid for the respective loca-
tion of installation must always be complied
with.
We will be glad to give you the sources on request
for the standards and regulations cited. If on
stock, we will be glad to send these to you at cost
price.

2
3 The structural surroundings of
the burner
Existing national building ordinances in this
connection must always be complied with.
3.1 Heating room requirements
A separate heating room must always be provided
for PYROMAT DYN wood heating systems. The
heating boiler may only be set up on a fire-
resistant floor. No temperature-sensitive pipes or
lines may be installed in the floor beneath the heat-
ing boiler.
The minimum distances to the walls and the ceiling
required according to the table of dimensions for
proper cleaning and maintenance of the boiler
have to be complied with. A sufficient supply of
fresh air has to be provided directly from outdoors
into the heating room. Induced ventilation is re-
quired for heating rooms that are small and/or in-
ternally situated.
The temperature in the heating room must not ex-
ceed +40° C while the system is in operation
(boiler surroundings approx. 1 m away from the
boiler).
The temperature in the heating room must not fall
below +10° C while the system is in operation (in-
terior side of the outside wall).
3.2 The chimney connection
The PYROMAT DYN is equipped with an exhaust
blower and so it is a fireplace not requiring a draft.
The design of the chimney should be carried out
as for a fireplace with an oil or gas blast burner not
requiring a draft (temperature of exhaust gas at
nominal load: 160°-200° C).
The PYROMAT DYN is output-controlled within a
range of 30%-100% of the nominal burner output.
This results in exhaust gas temperatures within a
range of min. 100° C and max. 250° C. An insu-
lated chimney should be provided to prevent the
danger of sooting.
The path from the exhaust blower to the chimney
should be as short as possible. 90° bends should
be avoided if possible. Exhaust gas lines with
lengths longer than 1 m should be insulated.
The connection to the chimney should be carried
out in a fashion rising at an angle of 30°-45°. The
exhaust gas line, incl. the lead-in into the chimney
should be designed so as to be gas-tight.
4 Transport and installation
The transport lug (1) is in the ash pan on delivery
and for transport purposes can be screwed in at
the top of the burner in place of the inspection win-
dow.
After moving it into the heating room, screw off the
transport feet (2) and position the burner such that
it is level.
The handle (incl. the safety lock for the refill ac-
cess cover) is in the ash pan on delivery.
1
2
2

3
The exhaust gas de-duster (option) is mounted on
the rear of the boiler.
4.1 De-ashing, cleaning the heat ex-
changer and the exhaust blower
Insert the motor with the rod assembly on the side
at the bottom of the boiler (opposite the feed au-
ger).
Insert the rod assembly into the drilled hole (1) on
the opposite side (feed side).
Screw the lid tight to the motor and rod assembly
and connect the electric line.
Run the squared shaft end from the de-ashing agi-
tator through the drilled hole in the grate (2) into
the receptacle for the shaped pipe.
Hang into position and screw tight the cover (3).
Mount the exhaust gas blower (4) to the rear of the
boiler.
Open the cleaning lid on top of the boiler and insert
the spirals (with the closing plate on the bottom)
into the heat exchanger tubes.
2
1
3
4

4
4.2 The light barriers 4.3 The casing
The casing can be removed if necessary for posi-
tioning.
Open the refill access lid (1), unscrew screws for
control system cover and open lid (2) to the front.
Unplug plugs and then unscrew both screws (3) on
the refill access lid flange.
Unplug plugs (6), remove servomotor burner con-
trol valve (4) and unscrew screws on the rear wall
(5).
Light barrier, ember monitoring system,
receiver (EO98VB3S770)
Abbreviated designation: B 1G.2
Transmitter (SO983S769)
Abbreviated designation: B2.1
and on the opposite side
Light barrier, metering container
Receiver (EO98VB3S770)
Abbreviated designation: B2.2
Light barrier, ember monitoring system
Transmitter (SO983S769)
Abbreviated designation: B 1G.1
3
2
5
6
4
1

5
Move out lambda sensor (B26) (1), unplug light
barrier (2), fold out casing on top, lift slightly and
remove.
5 The water installations
Here we refer to the standards and regulations
cited in this document.
5.1 The safety equipment
The safety equipping for the heating installation
should be carried out by the installing heating en-
gineer authorised to do so.
See Spec Sheets 3950-x for examples
5.2 Expansion
The water volume enlarged by the storage units
(option) requires a correspondingly large expan-
sion tank.
For closed expansion, the set pressure for the ex-
pansion tank should be equal to the max. facility
height plus 0.2 bar.
5.3 The burner circuit with burner con-
trol valve and storage unit valve
To reliably prevent burner corrosion through con-
densation of the exhaust gases, the burner tem-
perature must in no case be less than 70° C. For
this, a burner circuit pump should be provided with
a boiler control valve according to the diagram
(Spec Sheets 3950-x). The design of the burner
circuit should be carried out in such fashion that
the temperature difference between forward flow
and reverse flow is equal to or less than 15° C.
The triggering of the burner pump (230 V), burner
control valve and storage unit valve is integrated in
the control system that comes with the equipment.
5.4 Container for extinguishing water
(option)
Take note of the information on data sheet 4500.
As far as the installation is concerned, refer to the
installation instructions for the feed auger.
This functions by means of an extinguishing valve
and is not dependent on electric current. A float-
type level-control switch monitors the water level
and connects electrically. (See terminal connec-
tion diagram).
1
2

6
6 The electrical installations
6.1 The positioning of the control mod-
ule and control system module (option)
The installing electrical firm should mount the con-
trol module at a place easily accessible for opera-
tion. By positioning the control system module
(option) near the heating distributor, the lengths of
the lines can be minimised, thus reducing costs.
The position for the control system components
has to be selected such that any negative influ-
ences by heat radiation (rear side of burner with
exhaust gas collector and exhaust gas blower as
well as exhaust gas line) or interference caused by
dust during cleaning are as little as possible.
The ambient temperature (approx. 10 cm away) for
the control system components during operation of
the facility must not exceed 35° C. If there is any
doubt, place the control system components out-
side the heating room near the door to the heating
room.
6.2 Electrical connection
- Connect it according to the wiring plan, laying of
the CAN-BUS wire according to data sheet
4020.
- Around hot elements (exhaust gas blower, ex-
haust gas pipe), the lines should be installed so
as to be temperature-protected in steel pipes at
the distance necessary.
- The cable bushings to the motors and equip-
ment should be designed so as to be dustproof
and strain-relieved.
The regulations of the local electric supply
company must be complied with.
7 Fire protection
The fire protection regulations for wood heating
systems vary for each specific country.
The regulations valid for the respective place of
installation must be complied with.
7.1 Protection for the burner system
against back-burn
7.1.1 Preventing overfilling of the combustion
chamber
According to TRVB 118, a level monitor must be
installed to prevent any overfilling of the combus-
tion chamber. The PYROMAT DYN has a light
barrier as an ember monitoring system.
7.1.2 Preventing back-burn
With a sensor directly on the insertion pipe, any in-
cipient danger of back-burn will be detected and
counter-acted early on by an increase in the output
for a short period (increase in the advancing of ma-
terial). As a result, any protective equipment being
prescribed is prevented from going into force, and
normal operation is maintained for the purpose of
reliably providing the greatest possible supply of
heat.
7.1.3 The back-flash safeguard
According to TRVB 118, a back-flash safeguard is
prescribed for all systems over 150 kW.
TRD 414 prescribes a continuously present isolat-
ing layer if one foregoes having a spark alarm and
extinguishing system (TRD 414 relates primarily to
remnant wood from the processing of wood and
derived timber products). There is easing of re-
strictions in part in this connection for chip materi-
als from forestry and sawing activities. The PY-
ROMAT DYN is always equipped with an isolating
layer and is continuously operated with negative
pressure.
As a result, according to both TRVB 118 and TRD
414, the PYROMAT DYN is considered as
equipped with a back-flash safeguard.

7
7.1.4 Automatically Triggering Extinguishing
System for the Burner Auger = ATEBA
A water extinguishing system on the feed auger is
available as an option.
This device is used to reliably prevent any back
burn in case of a malfunction (such as a power
failure). For safety reasons and to prevent any
damage caused by overflowing, connecting this
extinguishing device directly to the water supply
network is not advised.
This extinguishing device is always equipped with
a 25-litre container for extinguishing water with a
float-type level-control switch and an adjustable
Danfos extinguishing valve.
According to TRVB 118, the container for the
automatically triggering extinguishing device must
be equipped with a level monitoring system.
If there is a shortage of water, the PYROMAT DYN
will switch off automatically. In case of excess
temperature, the feed auger will be flooded reliably
but to a limited degree.
The installing heating engineer should carry
out the pipework for the automatically trigger-
ing extinguishing system for the burner auger
in accordance with Spec Sheet 4550.
7.2 Back-burn safeguard for the fuel
supply system
The further "back-burn safeguard for material
transport" depends on the respective requirements
(position and size of the fuel storage unit, material,
pressure conditions and regulations), these being
separate items of the scope of delivery ordered
with Köb Holzheizsysteme GmbH according to the
following descriptions.
7.2.1 Automatically Triggering System for the
Material Supply System (ATSMS)
Approved in part as a variation to the slide valve in
non-pressurised fuel storage units (does not meet
TRVB).
The installation of the Automatically Triggering
System for the Material Supply System
(ATSMS) should be carried out by the installing
heating engineer according to Spec Sheet
4550.
7.2.2 Slide valve, type MBA
This is approved in non-pressurised fuel storage
units for all cases and according to TRVB 118 (test
certificate BV 2979/89) is considered as a suitable
back-burn safeguarding device.
7.2.3 Rotary valve, type MBS
If the remnant wood is put into the fuel storage
space with blowers, then due to the pressurisation,
at least one rotary valve is required between the
fuel storage unit and the burner to reduce the
pressure. A rotary valve is suited for reducing the
pressure and according to TRVB 118 (test certifi-
cate BV 2979/89) is also considered as a suitable
back-burn safeguarding device.
Max. permissible excess pressure in the fuel
storage unit: + 500 Pa
Max. permissible negative pressure in the fuel
storage unit: + 0 Pa
7.2.4 Double rotary valve with pressure com-
pensation
If, due to special circumstances, any mechanically
induced negative pressures or extraordinarily high
excess pressures are to be expected in the fuel
storage unit, then two rotary valves with a pressure
compensation line leading outdoors should be built
into the material transport route according to the
respective project plan.
Max. permissible excess pressure in the fuel
storage unit: + 3000 Pa
Max. permissible negative pressure in the fuel
storage unit: - 3000 Pa
You should have the maximum pressures to be
expected confirmed by the supplier of the chip
suctioning system.
The rotary valve beneath the silo extraction system
may become leaky due to wearing of the sealing
elements or due to large pieces of wood not able
to be conveyed. Any such leakiness may make it
possible for low-temperature gases to flow back
from the firing furnace into the silo.
A smoke gas alarm should be installed between
the revolving valve and the silo extraction system,
which when triggered will disconnect the system
causing the negative silo pressure.
7.3 Fire protection for the fuel storage
unit
The measures necessary for this are never a part
of the Köb Holzheizsysteme GmbH scope of deliv-
ery.
In this regard, the conditions set by the local
building authority must be met by the operating
organisation.

8
8 Initial Start-up
The first start-up of operation for a newly installed
facility may only be carried out by Köb Holz-
heizsysteme GmbH or another trained specialist.
Before the initial start-up, fill the facility with water,
provide fuel in the storage unit for the initial start-
up and inspect the installation.
8.1 Filling the heating system
The first filling is usually done with untreated water
without any chemical water treatment but definitely
filtered and thus free of any suspended matter.
Be sure to carefully bleed out any air when the fill-
ing is done. With difficult water conditions (high
degree of hardness, etc) and/or large water vol-
umes, follow VDI Guideline 2035 "Preventing
Damage by Corrosion and Scaling in Hot Water
Heating Systems" by taking necessary measures
to treat the water.
Note: The filling pressure of the cold water re-
serve should be approx. 0.1 bar times greater
than the set pressure of the closed expansion
container.
8.2 The fuel for the initial start-up
A sufficient quantity of dry fuel (max of w 20%)
should be stored.
- Approx. ten full hours of operation for auto-
matic operation.
- Approx. two burner fillings for manually loaded
operation.
8.3 Inspecting the installation
Before the initial start-up, the future operating or-
ganisation must inspect the installation with the in-
stalling firm (installing heating engineer, electri-
cian) for the following points:
1. Exhaust gas connection piece connected to
the exhaust gas line to the chimney.
2. Chimney completely installed with clear cross-
sectional area all the way through.
3. Safety valve mounted on burner and/or burner
inlet.
4. Thermal run-off safety valve connected to the
cold water mains.
5. The sensor for the thermal run-off safety valve
is in the dipping shell.
6. The container for extinguishing water (option)
on the feed auger is filled with water.
7. The sensor for the extinguishing valve (option)
is firmly mounted on the pipe for the feed au-
ger.
8. The expansion contained is connected.
9. The conveyor devices between the burner and
material storage unit are installed.
10. The facility has been filled with water.
11. Combustible fuel has been provided in the
storage unit for the trial operation.
12. The safety end switch has been installed on
the door to the material storage place (if there
is a door that can be walked through).
13. The control system is connected to the electric
mains.
14. The motors, switches and sensors are all con-
nected electrically.
Do not put the facility into operation too soon
without the presence of a specialist from Köb
Holzheizsysteme GmbH or another trained spe-
cialist.
In case of damage, you would lose your war-
ranty claims.
Inspected on . . . . . . . . . . . . . . . . . . . . . . . . . . . .
By . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.4 Initial start-up and handover
A competent contact person from the operating or-
ganisation's side has to be continuously present for
the initial start-up and handover.
The positively carried out inspection of the installa-
tion has to be confirmed by the installing heating
engineer by handing over these signed Installation
Instructions.
By following these Installation Instructions and
thereafter the Operating Instruction, you will be
provided with heat from wood in a safe, reliable
and convenient fashion.
Köb Holzheizsysteme GmbH thanks you for your
trust shown.
These Installation Instructions should be kept
at the facility on a permanent basis.

Spec Sheet
Wood-burning Pyromat-DYN
Installation, closed system
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
3950-1
2009-03-01_GB
Pyromat-DYN
Note:
To reliably prevent burner corrosion caused by condensation of exhaust gases, the burner outlet temperature must
not by any means be below 65°C. To do so, a burner circuit pump should be provided with a modulating valve as per
the diagram.
The burner circuit should be configured such that the temperature difference between the forward and return flow is
equal to or less than 15°C.
This is given in the design below, if no additional resistors are installed in the burner/accumulator circuit. Any
installation of slide valves or of a heat meter in the burner/accumulator circuit will require reconfiguration of the
burner pump and modulating valve by the heating technician
-For incorporation of heat consumers, refer to Spec Sheets 4000ff.
-The expansion tank has to be connected to the boiler above the boiler forward flow and without any shut-offs.

Spec Sheet
Wood-burning Pyromat-DYN
Installation, closed system
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
3950-2
2009-03-01_GB
a) Safety equipment provided by the installing heating engineer
SV... Safety valve, pressure set max. 3.0 bar, homologated component as per DIN 3440
Nominal width of the valve for the connecting line and the exhaust pipe as per DIN 4751, Part 2
TS... Thermal run-off safety valve R ¾", homologated component, opening temperature 95-100°C,
(safety heat exchanger built into the burner)
KW... Cold water inlet DN 15 R ½", metal, fixed pipework, min. 2.5 bar, max. 3.5 bar
TSL... Drain pipe, thermal run-off safety valve R ¾", (NW 20)
EL... Air separator (recommended: absorption-type degasser)
ExG... Expansion tank closed, homologated
(Recommendation: connect on cool return flow, connected to the boiler via the forward flow without any
blockage units)
DAZ... Pressure gauge (manometer)
TAZ... Temperature indicator (thermometer)
b) Burner circuit with hydraulically switched heat storage tank
Boiler
KPM-DYN Burner circuit pump M20 Make: Wilo model Modulating valve Y20 Make: Siemens Model Forward flow (VL)
Return flow
(RL)
Bypass (BP)
Safety valve
Model SV 68 M 1) Safety line SVL 2)
45 EAS 30/6-3-PR-180-12-I VXG48.32/SQS35.00 NW 40 R ¾ " NW 25
65 TOP-S 30/7 EM VXG48.32/SQS35.00 NW 40 R ¾ " NW 25
85 TOP-S 30/7 EM VXG48.40/SQS35.00 NW 50 R 1" NW 32
1) Connecting thread for inlet
2) Length of the exhaust pipe up to 4.0 m (for longer lines, see DIN 4751 Part 2)
c) Designation of the motors, sensors and safety switches
Motors: Electrical probes and sensors:
M1 Exhaust blower B1G.1 Transmitter light barrier for embers (opposite slide-in
module)
M2 Feed auger B1G.2 Receiver light barrier for embers (on slide-in module side)
M11 Drive for cleaning/de-ashing B1 Exhaust gas sensor PT-100
M12 Motor-operated air vent B02 Temperature sensor for feed auger PT-100
M13 Motor-operated air vent B2.1 Transmitter light barrier for feed auger
M16 Ignition device B2.2 Receiver light barrier for embers
M20 Burner circuit pump B20 Burner sensor KTY 10/6
Y20 Burner control valve B20.1 Return circuit sensor QAZ 21.5220
B26 Lambda sensor
Safety switches: Accumulator with storage management:
N21.1 Temperature-limiting safety switch Y28 Storage control valve (only with ECO-function)
S2 Safety limit switch
Maintenance lid for feed auger B28.1 B28.2 Heat storage sensor, top Heat storage sensor, centre
B28.3 Heat storage sensor, bottom
d) Recommended design for accumulator, VSP
The hydraulically switched heat storage tank has the following advantages:
-Gentle control in automatic operation (increased efficiency, minimal emissions in practical operation)
-Higher performance peaks are possible for the consumers
-Log operation is possible (see Operating Instructions)
Recommended volume, VSP:
PYROMAT-DYN Minimum VSP
[litres] Recommended VSP
[litres]
45 700 1000
65 900 1500
85 1100 2000

Spec Sheet
General Terms of Delivery
Installation, open system
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
3950-3
2009-03-01_GB
Pyromat-DYN
Note:
To reliably prevent burner corrosion caused by condensation of exhaust gases, the burner outlet temperature must
not by any means be below 65°C. To do so, a burner circuit pump should be provided with a modulating valve as
per the diagram.
The burner circuit should be configured such that the temperature difference between the forward and return flow is
equal to or less than 15°C.
This is given in the design below, if no additional resistors are installed in the burner/accumulator circuit. Any
installation of slide valves or of a heat meter in the burner/accumulator circuit will require reconfiguration of the
burner pump and burner control valve by the heating technician
For incorporation of heat consumers, refer to Spec Sheets 4000ff.

Spec Sheet
General Terms of Delivery
Installation, open system
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
3950-4
2009-03-01_GB
a) Safety equipment provided by the installing heating engineer
TS... Thermal run-off safety valve R ¾", homologated component, opening temperature 95-100°C,
(safety heat exchanger built into the burner)
This is not prescribed for open systems. However, we recommend installing one.
KW... Cold water inlet DN 15 R ½", metal, fixed pipework, min. 2.5 bar, max. 3.5 bar
TSL... Exhaust pipe, thermal run-off safety valve R ¾", (NW 20)
ExO... Expansion tank, open, at the topmost point of the facility, thermally insulated;
DAZ... Pressure gauge (manometer)
TAZ... Temperature indicator (thermometer)
b) Burner circuit with open expansion and storage circuit
Boiler
KPM-DYN Burner circuit pump M20 Make: Wilo model Modulating valve Y20 Make: Siemens Model Forward flow (VL)
Return flow
(RL)
Bypass (BP)
Safety valve
Model SV 68 M 1) Safety line SVL 2)
45 EAS 30/6-3-PR-180-12-I VXG48.32/SQS35.00 NW 40 R ¾ " NW 25
65 TOP-S 30/7 EM VXG48.32/SQS35.00 NW 40 R ¾ " NW 25
85 TOP-S 30/7 EM VXG48.40/SQS35.00 NW 50 R 1" NW 32
c) Designation of the motors, sensors and safety switches
Motors: Electrical probes and sensors:
M1 Exhaust blower B1G.1 Transmitter light barrier for embers (opposite slide-in
module)
M2 Feed auger B1G.2 Receiver light barrier for embers (on slide-in module side)
M12 Primary air vent, manual B1 Exhaust gas sensor PT-100
M12.2 Primary air vent, automatic B02 Temperature sensor for feed auger PT-100
M13 Secondary air vent B2.1 Transmitter light barrier for feed auger
M16 Ignition device B2.2 Receiver light barrier for embers
M20 Burner circuit pump B20 Burner sensor KTY 10/6
Y20 Modulating valve B20.1 Return circuit sensor QAZ 21.5220
B26 Lambda sensor
U26 Measuring transducer lambda sensor
Safety switches: Accumulator with storage management:
N21.1 Temperature-limiting safety switch Y28 Accumulator valve
S2 Safety limit switch
Maintenance lid for feed auger B28.1 B28.2 Heat storage sensor, top Heat storage sensor, centre
B28.3 Heat storage sensor, bottom
d) Recommended design for accumulator, VSP
The hydraulically switched heat storage tank has the following advantages:
-Gentle control in automatic operation (increased efficiency, minimal emissions in practical operation)
-Higher performance peaks are possible for the consumers
-Log operation is possible (see Operating Instructions)
Recommended volume, VSP:
PYROMAT-DYN Minimum VSP
[litres] Recommended VSP
[litres]
45 700 1000
65 900 1500
85 1100 2000

Spec Sheet
Fire-extinguishing Equipment
K-SLE; K-SLV Installation
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
4550-1
2009-03-01_GB
a) Fire-extinguishing System for Burner Slide-in Module, Art. No. K-SLE / 7387785
Note: Pyromat-DYN has an extra charge with Art. No. K-SLE (see Spec Sheet 4500)
With PYROT and PYRTEC this is included in the burner article.
Fig. 1: K-SLE on feed auger
b) Fire-extinguishing System for Material Feed Facility, Art. No. K-SLV / 7388521
For Köb scope of delivery, refer to Spec Sheet 4500
Fig. 2: K-SLV on conveyor auger Fig. 3: K-SLV on extractor system situated on top with downpipe
Note:
•The lines must be executed in metal (1/2") with fixed pipework (K-SLE and K-SLV).
•It must not be possible to shut off the cold water inlet without the aid of tools.
•Be especially sure to comply with Point 5 of the Installation Instructions (Fire Prevention).
Note:
K-SLV is an alternative or supplementary safety device. As standard, either a slide valve (Art. No. MBA-.; included in
Article ADF_.,. / ADE_3,0) is required for pressureless material storage sites or a rotary valve (Art. No. MBZ-.) for
material storage sites with over- or under-pressure (loading with fan, such as wood-processing businesses).
•Line from container to the
½" valve (short as possible)
•Valve adjustment
Danfoss AVTA 15 50-90°C
3, equivalent to approx. 80° C
KW: cold water inlet
DN 15 (½")
Min. 2.0, max. 3.0 bar
extinguisher water container 25
N25 level monitoring system
firing
material feed facility
CW
metering containermetering container
firing
with isolating layer with isolating layer
CW
firing

Spec Sheet
Water-bearing Components
Heat Distribution
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
4600-1
2009-03-01_GB
Motor-2-port valve,… [Art.-No. ZV-...]
These Siemens valves (models VVG and VXG) are characterised by precise control behaviour and leak-tight closing
without leakage losses. An important criterion for quality, especially for the PYROMAT burner series with accumulator
operation.
Motor-three way tap,… [Art.-No. ZH-3-..]
[Art. No.] Structural
design Model DN [mm] Kvs [m3/h] Adjusting drive
230 V
Incl. complete bolted
connection
ZV-2-20 / 7388232 2-port valve VVG 48.20 20 6.3 SSY 319 R ¾" – G 1¼"
ZV-2-25 / 7387483 2-port valve VVG 48.25 25 10 SSY 319 R 1" – G 1½"
ZV-2-32 / 7388259 2-port valve VVG 48.32 32 16 SQS 35.00 R 1¼“ – G 2“
ZV-2-40 / 7388166 2-port valve VVG 48.40 40 20 SQS 35.00 R 1½" – G 2¼"
ZV-3-20 / 7388152 3-port valve VXG 48.20 20 6.3 SSY 319 R ¾" – G 1¼"
ZV-3-25 / 7387484 3-port valve VXG 48.25 25 10 SSY 319 R 1" – G 1½"
ZV-3-32 / 7388049 3-port valve VXG 48.32 32 16 SQS 35.00 R 1¼“ – G 2“
ZV-3-40 / 7388204 3-port valve VXG 48.40 40 20 SQS 35.00 R 1½" – G 2¼"
ZH-3-50 / 7388100 3-way tap VBF 21.50 50 40 SQK 33 Counter-flange, seals
ZH-3-65 / 7388160 3-way tap VBF 21.65 65 63 SQL 33 Counter-flange, seals
ZH-3-80 / 7388260 3-way tap VBF 21.80 80 100 SQL 33 Counter-flange, seals
ZH-3-100 / 7388165 3-way tap VBF 21.100 100 160 SQL 33 Counter-flange, seals
ZH-3-125 / 7388053 3-way tap VBF 21.125 125 550 SQL 33 Counter-flange, seals
Pump … [Art.-No. ZP.-...]
[Art. No.] Pump model 1) DN
[mm] Volt- age
[V]
Capacity
[W] Capacity [m3/h/mWS] Incl. complete bolted
connection
RPM-
controlled
ZPS-255
7388095 RS 25/6 25 230 46-93 2.5/6.5 R 1" – G 1½" -
ZPE-256
7388057 Stratos ECO 25/1,5 25 230 5.8-59 2.5/5.0 R 1" – G 1½" X
ZPS-258
7388162 TOP-S 25/7 EM 25 230 95-195 7.5/7.0 R 1" – G 1½" -
ZPS-325
7388244 TOP-S 30/7 EM 32 230 85-195 7.5/7.0 R 1¼“ – G 2“ -
ZPE-258
7388075 TOP-S 25/7 DM 25 400 65-200 7.5/7.0 R 1¼“ – G 2“ -
ZPS-326
7388216 RS 30/6 32 230 46-93 2.5/6.5 R 1¼“ – G 2“ -
ZPS-406
7388114 TOP-S 40/7 EM 40 230 220-390 16.5/7.0 Counter-flange, seals -
ZPS-406-4
7388108 TOP-S 40/7 DM 40 400 130-370 16.5/7.0 Counter-flange, seals -
ZPS-506-4
7388271 TOP-S 50/7 DM 50 400 245-625 28.0/7.0 Counter-flange, seals -
ZPS-656-4
7388221 TOP-S 65/10 DM 65 400 400-960 42.0/9.0 Counter-flange, seals -
ZPS-806-4
7388224 TOP-S 80/7 DM 80 400 320-880 30/4.5 Counter-flange, seals -
ZPS-8012-4
7388131 TOP-S 80/10 DM 80 400 710-1500 30/6.0 Counter-flange, seals -
ZPS-1060-4
7388202 IL 100/145-1,1/4 100 400 1100 40/5.7 Counter-flange, seals -
1) Choice of the pump manufacturer and pump type remains a reservation of our purchasing department or the
engineering department, Viessmann.
Note: No individual deliveries of Z.. products! Z.. products are only delivered together with an entire system.

Spec Sheet
Water-bearing Components
Heat Distribution
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
4600-2
2009-03-01_GB
Wall-mounted Manifold 65-2 [Art.-No. LVW-65-2 / 7387823]
Wall-mounted Manifold 65-3 [Art.-No. LVW-65-3 / 7388040]
Wall-mounted heat distributor; forward- and return-flow distributor packed with intermediate insulation (chamber size 55
mm x 55 mm); distributor insulated all around and covered with powder coated steel plates.
Special design for Siemens motor-operated valves, models VXG 25/ SSY 319 (Art. No: ZV-3-25 / 7387484). Especially
suited for the Pyromat burner series with accumulator operation (burner output up to 65 kW).
Connections: Burner: Forward flow/return flow: 1½" IG on the left or right side
Accumulator: Forward flow/return flow: 1½" IG on the left or right side
Consumer: Forward flow/return flow: 1" AG at top with bypass, for two or three groups (last digit of the
Art. No.)
Incl. bolted connection for motor-operated valves, Siemens models VXG 25/ SSY 319 (Art.
No: ZV-3-25 / 7387484).
Heat Distributor Connection LVW-65 [Art. No. LVW-65-V / 7387862]
Connecting two model LVW-65- manifolds produces a manifold for four to six consumer groups. The connection is
assembled at the factory to assure an accurate fit.
Heat Distributor for Burner Design 65-2 [Art. No. LVK-65-2 / 7387815]
Heat Distributor for Burner Design 65-2 [Art. No. LVK-65-2 / 7387947]
Heat distributor for burner design; forward- and return-flow distributor packed with intermediate insulation (chamber size:
55 mm x 55 mm);
distributor insulated all around and covered with powder-coated steel plates.
Special design for Siemens motor-operated valves, models VXG 25/ SSY 319 (Art. No: ZV-3-25 / 7387484). Especially
suited for the PYROMAT burner series with accumulator operation (burner output up to 65 kW).
Connections: Boiler: Forward flow/return flow 1 1/2 " IG on the left side
Accumulator: Forward flow/return flow 1 1/2 " IG on the left side
Consumer: Forward flow/return flow: 1" AG at top with bypass, for two or three groups (last digit of the
Art. No.)
Incl. bolted connection for motor-operated valves, Siemens models VXG 25/ SSY 319 (Art.
No: ZV-3-25 / 7387484).
Note: This burner design is not possible with PYROMAT-DYN - standard version, hydraulically switched heat storage
tank
LVW-65-3 LVW-65-2
LVW-65-V
suspension
A:
PYROMAT
ditto dimensions
LVW-65-2
LVW-65-3
see M (2010-5)

Spec Sheet
Water-bearing Components
Heat Distribution
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
4600-3
2009-03-01_GB
Heating Group for Heat Distributor NW 25 [Art. No. LH-25 / 7387988]
A heating group for mounting on manifold models LVW and LVK, without pump, consisting of:
-Motor valve, Siemens VXG 48.25/SSY 319 for precise control behaviour and leak-free
closing without leakage losses
-One ball valve with screwed connection for mounting on motor valve VXG 48.25/SSY 319,
with pump connection on bottom
-One ball valve with thermometer socket and screwed connection with pump connection on
top
-One ball valve with thermometer socket, screwed connection and fastener for return flow
-Two immersion thermometers, installation in ball valve (forward- and return-flow)
Heating pump with L 180, 1" connection: provided by the customer or as per Spec Sheet 4600-
1
(Art.-No. ZPS–25. or ZPE-25.)
Note: If a heater group’s valve is to be used as quantity control (2-port valve for ECO-B1, -B2), the union on the bypass
must be sealed with a closed sealing disc.

Spec Sheet
Burner System Loader System
PYROMAT-DYN
1
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. [phone], Fax 65707, E-Mail: [email protected]
Subject to technical changes
3010-1
2009-03-01_GB
Description:
The PYROMAT-DYN is a boiler with patented double combustion chamber. Which means that the burner system enables
optimized operation with automatic loading (shavings, chippings from waste wood, wood chippings, max. W35; G50) and
may also be used with logs. A large loading shaft with loading lid and separate grid has been fitted in front of the main
combustion chamber to make loading wood easy. In automatic operation, the burner system is suitable for all dry to moist
wood fuels (max. W35). The control is integrated into the burner system with connector-ready cabling to the sensors and
motors. Which permits simple and rapid installation. The PYROMAT-DYN has been tested and approved in accordance
with the latest quality criteria in compliance with EN 303-5 heating boilers for solid fuels,
CE certification as per European Machinery Directive and continuous quality assurance by TÜV.
Max. flow temperature: 100°C
Max. operating pressure: 3.0 bar
Electric connection: 3 x 400V
Safety heat exchanger: Built into the boiler
Function:
- In manual operation, chopped wood and waste wood are degassed on the incineration grate situated before the
main combustion chamber. Simultaneous operation with automatic loading is not possible.
- In automatic operation the feed auger conveys the material to be burned into the main combustion chamber for
degasification.
The fasteners for the burn-back sensor and the thermally operated extinguisher valve are situated on the conveyor
pipe. Above the auger, there is a metering container with a light barrier to ascertain the level of the fuel isolating layer
required according to TRD 414.
- In automatic operation the material to be incinerated is ignited automatically by an electric hot air blower.
The combustion gases are entirely burned out in the afterburn chamber together with secondary airflow.
- The ash is mechanically removed from the main combustion chamber.
- In the upright pipe heat exchanger, the thermal energy from the combustion gases is transferred to
the boiler water. The vertical surfaces of the heat exchanger are regularly cleaned by motor-driven,
moving coil springs.
- The speed-controlled exhaust blower was specially designed for operation in wood heating systems and is very quiet.
- The negative pressure created by it produces a high degree of safety against burn-back in automatic operation and a
convenient feed function in manual operation.
- An integrated heat management system (accumulator-temperature-guided with return circuit valve) enables the best
possible controlled operation.
Scope of delivery:
-Boiler with double combustion chamber, ash pan, kindling and cleaning utensils, coil springs for the heat exchanger
cleaning system, mechanical drive with position sensor for removing the ash from the main combustion chamber.
- Exhaust blower, plug-and-play
- Integrated ECOTRONIC control system (decentralised microprocessor system via CAN-bus), consisting of:
Boiler control panel, control module for mounting preferably on a wall, bus cable for the drive motors wired to
output plug
- Feed auger with isolating layer, incl. Starttec drive via CAN-bus (including data transmission line) for gentle start-up,
automatic reversing and overload safeguard, light barriers for combustion chamber and metering container
-Automatic ignition system
- Burner group ready-installed on connecting flange, consisting of burner pump, two blockage units
Burner control valve, forward and return flow sensors incl. fittings.
-Three KTY heat accumulator sensors, incl. dipping shell (1/2" x 280 mm long) wired together to plug
-Four-pin master switch, uninstalled (for installation near the control module)
ACCESSORIES for PYROMAT-DYN (Article KPM-…) at extra charge:
Name Article Text Sizes Use
Reduction exhaust connection KPM-… 3110 3110 existing chimney 180 mm dia.
Exhaust blower-intake port 90° KPM-… 3110 3110 special exhaust gas conveyance
Exhaust gas deduster KPM-… 3110 3110 optional
De-ashing into the container 20 L KPM-DYN-AS 3200 3200 optional
ECO function for PYROMAT-DYN LSR-DYN 3200 - for use with logs; incl. storage
Error report 230 V ECO-ZA 3200 - optional
External requirements ECO-ANF 3200 - optional
Discharge systems ADE/ADF 3300 3300 material transport silo to boiler
Heater control, module extensions ECO-… 4000ff - optional
Data cable for operating module ECO-… 4020 - required
Boiler safety devices K-… 4500 - optional
Extinguishing equipment K-… 4550 4550 optional
