ViewSonic SD-T225 User manual

SD-T225
Client Monitor
User Guide
Model No. VS15741
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specic languages using the Regional selection
box in the upper right corner of our website. “Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual”

i
Compliance Information
NOTE: This section addresses all connected requirements and statements regarding
regulations. Confirmed corresponding applications shall refer to nameplate labels
and relevant markings on unit.
FCC Compliance Statement
This device complies with part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modifications not expressly approved
by the party responsible for compliance could void your authority to operate the
equipment.
Industry Canada Statement
CAN ICES-3(B)/NMB-3(B)
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE).The mark indicates
the requirement NOT to dispose the equipment as unsorted municipal
waste, but use the return and collection systems according to local law.

ii
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive
2011/65/EU of the European Parliament and the Council on restriction of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Directive) and is deemed to comply with the maximum concentration values issued
by the European Technical Adaptation Committee (TAC) as shown below:
Substance
Proposed Maximum
Concentration
Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex III
of the RoHS2 Directives as noted below:
Examples of exempted components are:
1. Mercury in cold cathode uorescent lamps and external electrode uorescent
lamps (CCFL and EEFL) for special purposes not exceeding (per lamp):
(1) Short length (≦500 mm): maximum 3.5 mg per lamp.
(2) Medium length (＞500 mm and ≦1,500 mm): maximum 5 mg per lamp.
(3) Long length (＞1,500 mm): maximum 13 mg per lamp.
2. Lead in glass of cathode ray tubes.
3. Lead in glass of uorescent tubes not exceeding 0.2% by weight.
4. Lead as an alloying element in aluminium containing up to 0.4% lead by weight.
5. Copper alloy containing up to 4% lead by weight.
6. Lead in high melting temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead).
7. Electrical and electronic components containing lead in a glass or ceramic other
than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.

iii
Cautions and Warnings
1. Read these instructions completely before using the equipment.
2. Keep these instructions in a safe place.
3. Heed all warnings and follow all instructions.
4. Sit at least 18” / 45cm from the Thin Client Monitor.
5. Always handle the Thin Client Monitor with care when moving it.
6. Never remove the rear cover. This Thin Client Monitor contains high-voltage
parts. You may be seriously injured if you touch them.
7. Do not use this equipment near water. Warning: To reduce the risk of fire or
electric shock, do not expose this apparatus to rain or moisture.
8. Avoid exposing the Thin Client Monitor to direct sunlight or another heat source.
Orient the Thin Client Monitor away from direct sunlight to reduce glare.
9. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the
Display” in this guide for further instructions.
10. Avoid touching the screen. Skin oils are difficult to remove.
11. Do not rub or apply pressure to the LCD panel, as it may permanently damage
the screen.
12. Do not block any ventilation openings. Install the equipment in accordance with
the manufacturer’s instructions.
13. Do not install near any heat sources such as radiators, heat registers, stoves, or
other devices (including amplifiers) that produce heat.
14. Place the Thin Client Monitor in a well ventilated area. Do not place anything on
the Thin Client Monitor that prevents heat dissipation.
15. Do not place heavy objects on the Thin Client Monitor, video cable, or power
cord.
16. If smoke, an abnormal noise, or a strange odor is present, immediately switch
the Thin Client Monitor off and call your dealer or ViewSonic. It is dangerous to
continue using the Thin Client Monitor.
17. Do not attempt to circumvent the safety provisions of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade
and the third prong are provided for your safety. If the plug does not fit into your
outlet, consult an electrician for replacement of the outlet.
18. Protect the power cord from being tread upon or pinched, particularly at the plug,
and the point where if emerges from the equipment. Be sure that the power outlet
is located near the equipment so that it is easily accessible.
19. Only use attachments/accessories specified by the manufacturer.
(Continued on next page)

iv
20. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the equipment. When a cart is used,
use caution when moving the cart/equipment combination to avoid
injury from tipping over.
21. Unplug this equipment when it will be unused for long periods of time.
22. Refer all servicing to qualified service personnel. Service is required when the
unit has been damaged in any way, such as: if the power-supply cord or plug is
damaged, if liquid is spilled onto or objects fall into the unit, if the unit is exposed
to rain or moisture, or if the unit does not operate normally or has been dropped.

v
Contents
Compliance Information
FCC Compliance Statement...................................................................................i
Industry Canada Statement....................................................................................i
Declaration of RoHS2 Compliance........................................................................ii
Cautions and Warnings ........................................................................................ iii
Copyright Information
Product Registration..............................................................................................2
For Your Records ..................................................................................................2
Getting Started
Package Contents .................................................................................................3
Quick Installation ...................................................................................................4
Additional Software Installation (Optional).............................................................4
Wall Mounting (Optional).......................................................................................5
Using the Thin Client Monitor
Setting the Timing Mode........................................................................................6
OSD and Power Lock Settings..............................................................................6
Adjusting the Screen Image ..................................................................................7
Main Menu Controls ..............................................................................................8
Main Menu Explanation.........................................................................................8
Landscape/Portrait Modes...................................................................................10
To Raise and Lower the display ..........................................................................10
Client System
Client Power Control............................................................................................11
Quick Connection ................................................................................................11
Desktop Mode .....................................................................................................16
Client Network IP Setting.....................................................................................24
Start Local Firmware Update...............................................................................25
Other Information
Specifications ......................................................................................................29
Cleaning the Thin Client Monitor .........................................................................31
Troubleshooting...................................................................................................32
Customer Support ...............................................................................................33
Limited Warranty ................................................................................................34

1
Copyright Information
Copyright © ViewSonic®Corporation, 2014. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered
trademarks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association.
ENERGY STAR®is a registered trademark of the U.S. Environmental Protection
Agency (EPA).
As an ENERGY STAR®partner, ViewSonic Corporation has determined that this
product meets the ENERGY STAR®guidelines for energy efficiency.
DPMS, DisplayPort, and DDC are trademarks of VESA.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors
or omissions contained herein; nor for incidental or consequential damages resulting
from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves
the right to change product specifications without notice. Information in this
document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means,
for any purpose without prior written permission from ViewSonic Corporation.

2
Product Registration
To fulfill possible future product needs, and to receive additional product information
as it becomes available, please visit your region section on ViewSonic’s website to
register your product online.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
SD-T225
ViewSonic Thin Client Monitor
VS15741
SD-T225_UG_ENG Rev. 1A 03-07-14
Product disposal at end of product life
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing.
Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

3
Getting Started
Important! Save the original box and all packing material for future shipping needs.
NOTE: The word “Windows” in this user guide refers to Microsoft Windows operating
system.
Package Contents
Your Thin Client Monitor package includes:
• Thin Client Monitor
• Power cord
• D-Sub cable
• Compliance Information Brochure
• Quick Start Guide
• ViewSonic Optical Disk
- User Guide
- INF/ICM files*
- Registration information
- Additional software (Optional)
NOTE: The INF file ensures compatibility with Windows operating systems, and
the ICM file (Image Color Matching) ensures accurate on-screen colors. ViewSonic
recommends that you install both the INF and ICM files.

4
Quick Installation
1. Connect video cable
2. Connect power cord (and AC/DC adapter if required)
3. Turn ON Thin Client Monitor
Note:
The Client power turned off as default. Please refer to the Client system chapter for
turning on.
Additional Software Installation (Optional)
1. Load the ViewSonic Optical Disk on your CD/DVD drive.
2. Double click on the "Software" folder and choose an application, if desired.
3. Double click on the Setup.exe file and follow the on-screen instructions to
complete the simple installation.

5
Wall Mounting (Optional)
NOTE: For use only with UL-listed Wall Mount Bracket.
To obtain a wall-mounting kit or height adjustment base, contact ViewSonic®or
your local dealer. Refer to the instructions that come with the base mounting kit. To
convert your Thin Client Monitor from a desk-mounted to a wall-mounted display, do
the following:
1. Verify that the power button is turned Off, then disconnect the power cord.
2. Lay the Thin Client Monitor face down on a towel or blanket.
3. Remove the base. (Removal of screws might be required.)
4. Identify one of the following VESA mount interfaces (a,b,c) located on the back of
your display (refer to “Specifications” page for your displays mounting interface).
Attach the mounting bracket from the VESA-compatible wall mounting kit using
screws of the appropriate length.
a. b. c.
75mm
75mm
100mm
100mm
100mm
100mm
200mm
5. Attach the Thin Client Monitor to the wall, following the instructions in the wall-
mounting kit.

6
Using the Thin Client Monitor
Setting the Timing Mode
Setting the timing mode is important for maximizing the quality of the screen image
and minimizing eye strain. The timing mode consists of the resolution (example
1024 x 768) and refresh rate (or vertical frequency; example 60 Hz). After setting
the timing mode, use the OSD (On-screen Display) controls to adjust the screen
image.
For optimal picture quality, please use the recommended timing mode specific to
your Thin Client Monitor listed on the “Specification” page.
To set the Timing Mode:
• Setting the resolution: Access "Appearance and Personalization" from Control
Panel via the Start Menu, and set the resolution.
• Setting the refresh rate: See your graphic card’s user guide for instructions.
IMPORTANT: Please make sure that your graphics card is set to 60Hz vertical
refresh rate as the recommended setting for most Thin Client Monitors. Choosing a
non-supported timing mode setting may result in no image being displayed, and a
message showing “Out of Range” will appear on screen.
OSD and Power Lock Settings
• OSD Lock: Press and hold [1] and the up arrow ▲ for 10 seconds. If any buttons
are pressed the message OSD Locked will display for 3 seconds.
• OSD Unlock: Press and hold [1] and the up arrow ▲ again for 10 seconds.
• Power Button Lock: Press and hold [1] and the down arrow ▼ for 10 seconds.
If the power button is pressed the message Power Button Locked will display
for 3 seconds. With or without this setting, after a power failure, your Thin Client
Monitor’s power will automatically turn ON when power is restored.
• Power Button Unlock: Press and hold [1] and the down arrow ▼ again for 10
seconds.

7
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD menu items
that appear on the screen.
Standby Power On/Off
[1] MENU/EXIT
Displays the Main Menu or exits the control screen and saves adjustments.
[2]
SOURCE/ENTER
Displays the highlighted OSD menu item.
Also a shortcut to toggle analog and Client.
▲/▼Scrolls through menu options and adjusts the displayed OSD menu item.
Blue light filter (▼) / ViewMode (▲)
Power indicator
Blue = ON
Orange = Power Saving
Client indicator
Green = Activates Client
Dark = Client OFF
Flash blue = The network cable is connected on RJ45 port.
Client
Turn on/off the Client power
* Press and hold the Client button. The Client power will be turned off and
LED will be dark.
Do the following to adjust the display setting:
1. To display the Main Menu, press button [1].
NOTE: All OSD menus and adjustment screens disappear automatically after
about 15 seconds. This is adjustable through the OSD timeout setting in the
setup menu.
2. To select a OSD menu item to adjust, press ▲ or ▼ to scroll up or down in the
Main Menu.
3. After the desired item is selected, press button [2].
4. To save the adjustments and exit the menu, press button [1] until OSD
disappear.
The following tips may help you optimize your display:
• Adjust the computer’s graphics card to support a recommended timing mode
(refer to “Specifications” page for recommended setting specific to your Thin
Client Monitor). To find instructions on “changing the refresh rate”, please refer to
the graphics card’s user guide.
• If necessary, make small adjustments using H. POSITION and V. POSITION
until the screen image is completely visible. (The black border around the edge
of the screen should barely touch the illuminated “active area” of the Thin Client
Monitor.)

8
Main Menu Controls
Adjust the menu items by using the up ▲ and down ▼ buttons.
NOTE: Check the Main Menu items on your LCD OSD and refer to Main Menu
Explanation below.
Main Menu Explanation
NOTE: The Main Menu items listed in this section indicate whole Main Menu items
of all models. For the actual Main Menu details corresponding to your product please
refer to your LCD OSD Main Menu items.
AAudio Adjust
Adjusts the volume, mutes the sound.
Auto Image Adjust
Automatically sizes, centers, and fine-tunes the video signal to eliminate
waviness and distortion. Press the [2] button to obtain a sharper image.
NOTE: Auto Image Adjust works with most common video cards. If this
function does not work on your Thin Client Monitor, then lower the video
refresh rate to 60 Hz and set the resolution to its pre-set value.
BBrightness
Adjusts background black level of the screen image.
CColor Adjust
Provides several color adjustment modes, including preset color
temperatures and a User Color mode which allows independent
adjustment of red (R), green (G), and blue (B). The factory setting for this
product is native.
Contrast
Adjusts the difference between the image background (black level) and
the foreground (white level).
IInformation
Displays the timing mode (video signal input) coming from the graphics
card in the computer, the LCD model number, the serial number, and
the ViewSonic®website URL. See your graphics card’s user guide
for instructions on changing the resolution and refresh rate (vertical
frequency).
NOTE: VESA 1024 x 768 @ 60Hz (example) means that the resolution is
1024 x 768 and the refresh rate is 60 Hertz.

9
Input Select
Toggles between inputs if you would like to switch D-sub and Client.
MManual Image Adjust
Displays the Manual Image Adjust menu. You can manually set a variety
of image quality adjustments.
Memory Recall
Returns the adjustments back to factory settings if the display is
operating in a factory Preset Timing Mode listed in the “Specications”
page.
Exception: This control does not affect changes made with the
Language Select or Power Lock setting.
SSetup Menu
Adjusts On-screen Display (OSD) settings.

10
Landscape/Portrait Modes
The LCD display can operate in either Landscape or Portrait mode.
Landscape Portrait
To Raise and Lower the display
You can easily raise and lower the display panel (the head) manually.

11
Client System
Client Power Control
The Client power of device is turned off as default. Please refer to below step to turn
on Client power.
1. AC power plugs in, press the “Power” button to turn on device and the screen will
be on VGA mode.
2. Press “Client” button once, the Client power will be turned on. Meanwhile, the
screen will be on Client mode. This action sets WOL function ready and the
Client LED will light up in green.
3. The Client screen will be seen around in 15 seconds.
The USB peripheral will not work when the Client power turned off.
Quick Connection
Simply login from the virtual desktop with the default connection setting.
Welcome
Log in to access your desktop.
Protocol:
Server IP:
Username:
Password:
Domain:
Citrix HDX
Login
Mon Feb 17 11:37 2014
The login information can be saved. Please click this icon.
*
*
*
12
3
No. Description
1Menu items
2Status row
3VDI login screen

12
VDI Login Screen
Welcome
Log in to access your desktop.
Protocol:
Server IP:
Username:
Password:
Domain:
Citrix HDX
Login
The login information can be saved. Please click this icon.
*
*
*
Label Description
Protocol Select the connection protocol type. Citrix HDX, Microsoft
RemoteFX, VMware PCoIP are provided in this option.
Server IP Input remote server IP address the user connects to. (Maximum
input length: 100 characters)
Username Input the user account name. (Maximum input length: 30 characters)
Password Input the user account password. (Maximum input length: 30
characters)
Domain Input the remote server domain name. (Maximum input length: 30
characters)
*Indicates this column is required in current protocol type.
Clicking on this button will save current account information and
protocol type as default values.
Login Pressing this button will pass the connection information to the
remote server and login VDI by different protocols:
• Citrix HDX: shows the Citrix VDI/App list.
• Microsoft RemoteFX: video output will be changed to single
output and 1280x1024 mode. If the NLA certication request
from the server IP is already accepted, it will continue to verify
the account information and then login VDI. Or it will show the
certicate conrmation window.
• VMware PCoIP: switches to VMware automatic login screen.
Note about display settings with VDI connection:
Changing the screen resolution or single/multiple monitor settings should be done on
the local Client. Dynamically modified display setting in VDI will not be applied. Users
can log out from the VDI first and then change display settings on the local side. The
next time the user logs into the VDI, the connection agent will adapt the VDI display
configuration from local-side settings.

13
Status Row
Icon/Text Description
This icon shows the network cable connection status
or wireless signal strength.
If the wireless USB dongle is plugged in, the displayed
icon will appear (see icon to the left). If the wireless
USB dongle is not connected, the displayed icon will
show a red “X”.
This column shows the local client system date and
time. User can update this date/time in the Time
setting window.
Menu Items
Menu Item Description
Open the Power menu. It includes Reboot, Power Off, Quick
Connection and Desktop mode options.
Use the Volume Control tool to set system audio output volume
from 0 to 100.
The ViewSonic Client Setup window provides Desktop, Display,
Keyboard, Mouse, Network, Quick Connection, Time setting
functions.
Open the Network Test tool to test if network connection is
working.
The System Information window will display network, hardware
and software information of client system.

14
• Power Menu
Power
Desktop mode
Power Off
Quick Connection
Reboot
Label Description
Reboot Restart the local client system.
Power Off Shutdown the local client system.
Quick
Connection
Close Power menu.
Desktop mode Switch to Desktop mode.
• Volume Control tool
Label Description
－
(Volume bar)
The level value can be set from 0 to 100.
• ViewSonic Client Setup window
CloseOverview
ViewSonic Client Setup
ViewSonic Client Setup
Customize your desktop
Desktop Keyboard
Display Mouse
Quick
Connection
Network Time
