N5230p
52" FULL 1080P LCD HDTV
WITH THREE HDMI 1.3 INPUTS
ViewSonic’s N5230p 52" LCD HDTV combines stunning images
with exquisite styling to offer unparalleled high-definition home
entertainment. Immerse yourself in the vivid colors and details of high-
def movies, sports and games. Connect your Blu-Ray™player, game
console, high-def cable or satellite box and all your digital home
entertainment components through the ELEVEN INPUTS INCLUDING
3 ADVANCED HDMI 1.3 INPUTS for ultimate enjoyment. Full high-
definition 1080p performance places you in the middle of the ac-
tion. High contrast ratio and brightness provide richer colors,
while ClearPicture™technology ensures extreme image clarity.
Dolby®Digital stereo sound and a convenient swivel base optimize
your viewing experience. Enjoy uncompromised HD entertainment
at home from the N5230p LCD HDTV.
A dramatic, home-theater
experience.
ELEGANT STYLE. EXCITING ENTERTAINMENT.
Experience widescreen HDTV
Enjoy a widescreen theater experience and high-definition picture
quality with this display’s widescreen aspect ratio, full 1080p HDTV
capability, and wide viewing angles.
ClearPicture™image processing delivers clearer, crisper,
sharper images
ClearPicture™image processing eliminates noise, increases
contrast and detail and optimizes color for rich, vibrant images.
High-definition images look amazing and even standard television
images are unbelievably smooth and sharp.
Vivid graphics, clear text, stunning TV
Ultra-high brightness of 500 nits (typ), dynamic contrast ratio of
6000:1, and 1920x1080 optimum resolution provide vibrant video
and lifelike images.
Expand your options with three HDMI 1.3 inputs
Enjoy the ultimate viewing experience with integrated HDTV and
analog TV tuners and plug-and-play, high-end connectivity of
three HDMI inputs for HD set-top boxes, standard and HD-DVDs,
game consoles, Blu-Ray™discs, camcorders and more.
Powerful high-fidelity audio
It’s all accompanied by high fidelity 30-watt
Dolby®Digital stereo sound that completes
the entertainment experience.
>
>
>
>
>

N5230p
52" FULL 1080P LCD HDTV WITH THREE HDMI 1.3 INPUTS
LCD Type 52" wide color TFT active Matrix LCD
Display Area 45.3" horizontal x 25.5" vertical; 52" diagonal
Optimum Resolution 1920x1080
Contrast Ratio 1500:1 static (typ), 6000:1 dynamic
Viewing Angles 176º horizontal, 176º vertical
Response Time 6.5ms (typ)
Light Source Long life, 50,000 hrs. (typ)
Brightness 500 cd/m2(typ)
Aspect Ratio 16:9
Glass Surface Anti-glare, anti-reflective coat
INPUT PC RGB analog (75 ohms, 0.7 Vp-p)
TV S-video, TV/cable x2, composite (RCA) x2,
component YPbPr/YCbCr x2
Audio 3.5mm mini stereo audio in/out and RCA x2 (left/right) audio in
RGB Frequency Fh: 30~64kHz, Fv: 60~75Hz
Sync H/V separated (TTL)
Digital HDMI 1.3 x3 (with HDCP and audio support)
Tuner ATSC/NTSC/QAM
RS-232 Control port
AUDIO OUTPUT Speakers 2x15-watt
COMPATIBILITY PC 640x480, 800x600,1024x768, 1280x720, 1280x768, 1280x1024,
1360x768, 1440x900, 1680x1050
INPUT SIGNAL TV/Video Comp. 480i, 480p, 720p, 1080i, 1080p
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital HDMI 1.3 x3
Power 3-pin plug
POWER Voltage AC 10–240V (universal), 50–60Hz
Consumption 300W (typ)
CONTROLS Basic Power, enter, channel +/– , volume +/– , menu
Picture Picture mode, brightness, contrast, color, tint, sharpness,
color temperature
TV/Audio Balance, bass, treble, surround, reverb, equalizer, SPDIF type,
auto volume control, tuner mode, auto scan, channel skip,
MTS, audio language
Set Up OSD language, aspect ratio, blue mute, time setup, closed
caption, memory recall, channel block, program block, input
block, change password, clear all
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 10–65% (non-condensing)
DIMENSIONS Physical with stand 49.3" x 33.9" x 12.2" (1251mm x 861mm x 310mm)
(W x H x D) Physical without stand 49.3" x 30.6" x 5.9" (1251mm x 778mm x 151mm)
WEIGHT Net with stand 86.6 lb. (40.0 kg)
Net without stand 77.7 lb. (35.2 kg)
Gross with stand 103 lb. (46.0 kg)
VESA®MOUNT 200mm x 400mm; 200mm x 600mm
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please dispose of in
accordance with local, state or federal laws.
REGULATIONS FCC, cUL (UL), RoHS, NOM, BETS-7, CB, HDMI
PACKAGE CONTENTS LCD HDTV display, power cable, remote control with batteries,
Quick Start Guide, User Guide
