ViewSonic VS10945-1G User manual

ViewSonic®
N4200w
LCD TV
Model No. : VS10945-1G
- User Guide
- 使用手册

ViewSonic N4200w
Contents
Important Safety Instructions ......................................................................... 1
Copyright Information..................................................................................... 2
Product Registration ...................................................................................... 2
Product disposal at end of product life........................................................... 2
Antenna Installation Instructions.................................................................... 3
Cleaning the LCD TV..................................................................................... 3
Disclaimer...................................................................................................... 3
Getting Started
Package Contents.......................................................................................... 4
Fixing ViewSonic LCD TV to the Wall............................................................ 5
Relocating the Satellite Speakers .................................................................. 6
Front Display and Controls ............................................................................ 7
Rear Panel and Connections......................................................................... 8
Side Panel Connections................................................................................. 9
Remote control............................................................................................. 10
Preparing Your LCD TV............................................................................... 12
Basic Operation ........................................................................................... 19
On Screen Display Menu System (OSD)
OSD Operation ............................................................................................ 20
OSD Configuration Screens......................................................................... 21
PC Mode...................................................................................................... 21
AV mode...................................................................................................... 25
TV mode...................................................................................................... 29
Additional Information
Specifications............................................................................................... 33
Troubleshooting........................................................................................... 34
Customer Support........................................................................................ 35
Limited Warranty.......................................................................................... 36

ViewSonic N4200w1
Important Safety Instructions
1. Read these instructions completely before using the equipment.
2. Keep these instructions in a safe place.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this equipment near water. Warning: To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or moisture.
6. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the Display” in
this guide for further instructions.
7. Do not block any ventilation openings. Install the equipment in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
devices (including amplifiers) that produce heat.
9. Do not attempt to circumvent the safety provisions of the polarized or grounded plug. A
polarized plug has two pins with one wider than the other. A grounded plug has two flat
parallel pins and a round, ground pin. The wider and ground pins are provided for your
safety. If the plug does not fit into your outlet, consult an electrician for replacement of the
outlet.
10. Protect the power cord from being stepped on or pinched, particularly at the plug, and the
point where it emerges from the equipment. Be sure that the power outlet is located near
the equipment so that it is easily accessible.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the equipment. When a cart is used, use caution
when moving the cart-equipment combination to avoid injury from tipping
over.
13. Unplug this equipment when it will be unused for long periods of time.
14. Refer all servicing to qualified service personnel. Service is required when the unit has
been damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid
is spilled onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if the
unit does not operate normally or has been dropped.
15. The device should not be spattered by water, and should not put things filled with liquid on
the device, such as vases.

ViewSonic N4200w2
Copyright Information
Copyright© ViewSonic®Corporation, 2006. All rights reserved.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered
trademarks of ViewSonic Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting from
furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specifications without notice. Information in this document may change
without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at www.viewsonic.com.
For Your Records
Product Name: N4200w
ViewSonic LCD TV
Model Number: VS10945-1G
Document Number: N4200w_UG_ENG Rev. 1A 03-14-06
Serial Number:
Purchase Date:
Product disposal at end of product life
ViewSonic is concerned about the preservation of our environment. Please dispose of this
product properly at the end of its useful life. Your local waste disposal company may provide
information about proper disposal.
The lamp in this product contains mercury. Please dispose of properly in accordance with
environmental laws of your location.

ViewSonic N4200w3
Antenna Installation Instructions
1. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the product be sure the antenna or cable system is
grounded to provide some protection against voltage surges and built-up static charge. Article 810 of the
National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
2. Lightning
For added protection for this product during a lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and power-line surges. Do not disconnect the antenna or the
power cord during a heavy storm, lightning may strike while you are holding the cable cord, causing serious
injury; turn off your LCD TV and wait for the weather to improve.
3. Power Lines
An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall onto such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact
with them might be fatal.
Cleaning the LCD TV
 Make sure the LCD TV is switched off.
 Never spray or pour any liquid directly onto the screen or case.
To clean the screen:
1 Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles.
2 If still not clean, apply a small amount of a non-ammonium, non-alcohol based glass cleaner onto a clean,
soft, lint-free cloth, and wipe the screen.
To clean the case:
1 Use a soft, dry cloth.
2 If still not clean, apply a small amount of a non-ammonium, non-alcohol based, mild non-abrasive detergent
onto a clean, soft, lint-free cloth, then wipe the surface.
Disclaimer
ViewSonic®does not recommend the use of any ammonia or alcohol-based cleaners on the LCD TV screen or case.
Some chemical cleaners have been reported to damage the screen and/or the case of the LCD TV.
ViewSonic will not be liable for damages resulting from use of any ammonia or alcohol-based cleaners.

ViewSonic N4200w4
Getting Started
You are now ready to install your LCD TV. Please make sure you have read the safety
instructions before proceeding.
Important! Save the original box and all packing material for future shipping needs.
Package Contents
Please check that your LCD TV package includes:
 LCD TV
 ViewSonic User’s Guide
 Quick Start Guide
 RF Cable
 AC Power Cable
 Universal Remote Control with
Batteries
 Warranty Card
 Service Sticker
Important! If there are any items missing from this list, please contact your distributor.

ViewSonic N4200w5
Fixing ViewSonic LCD TV to the Wall
The LCD TV can be wall-mounted or freestanding. Before installing the product to the wall,
please consider the following guidelines:
• Read the Important Safety Instructions, at the start of this manual.
• Do not install in a moist or wet environment. This equipment is intended for indoor use
only.
• Do not install near heat source, or strong magnetic fields.
• Use only approved wall brackets capable of supporting the weight of the LCD TV.
• Mount your LCD TV to a supporting wall.
• Ensure there is at least 3cm of space surrounding any air-vents of LCD TV.
To detach the wall-mounting bracket to LCD TV safely, please use the following guidelines:
1. Disconnect the power and any other cables that might hinder moving the LCD TV.
2. Set the LCD TV on a table or work surface, screen-down with a towel or woolen blanket
between the screen and the surface to protect the display.
3. There are 6 screws holes in the bracket that match the LCD TV (as shown), two-pairs are
at opposing ends of the base (perpendicular to the TV rear panel), and a single screw is
mounted on the underside of each supporting upright (parallel to the direction of the
supports). Loosen all six screws, and keep for future use.
Use only approved wall-mounting brackets advised by ViewSonic or your local distributor.
Notes:
• If your LCD TV is already set up for free-standing operation, you need to first remove the stand before
mounting the device to the wall.
• The wall-mount screw type: M6 x L10

ViewSonic N4200w6
Relocating the Satellite Speakers
To replace the speakers attached to LCD TV or extend the cable please contact ViewSonic or
your local distributor for advice.
To detach the satellite (side) speakers from the main LCD TV unit, please read the following
guidelines:
1. Disconnect the power to LCD TV.
2. Now remove the audio cable from
the LCD TV.
3. Set the LCD TV on a table or work
surface, screen-down with a towel or
woolen blanket between the screen
and the surface to protect the
display.
4. Remove the 6 screws holding the
speaker (3 screws on each side) to
the main unit.
5. Pull the speaker outwards, and away
from the main unit.
To connect the audio cable from a speaker to the LCD TV, ensure the polarity is correct. I.e.
match the red (+ve) wire to the red (+ve) terminal, and the black (-ve) wire to the black (-ve)
terminal connector on the LCD TV rear panel.

ViewSonic N4200w7
Introducing ViewSonic LCD TV
Front Display and Controls
A INPUT Select input sources.
B MENU Toggle the OSD menu .
C VOL- Decrease the volume during normal operation or adjust a
highlighted control whilst using the OSD menu.
D VOL+ Increase the volume during normal operation or adjust a
highlighted control whilst using the OSD menu.
E CH ﹀Channel down/ Scroll down.
F CH ＾Channel up/ Scroll up.
G Turn the power on/off.

ViewSonic N4200w8
Rear Panel and Connections
A POWER S/W Power (on/off) switch.
B AC IN Using the cable provided, plug the TV into the nearest outlet.
C HDMI (1) Have one HDMI cable terminals of your DVD player.
D HDMI (2) Have one HDMI cable terminals of your DVD player.
E VGA Connect the VGA cable output of PC to the VGA terminal input.
F PC STEREO Use a PC to Phono audio-cable to connect the audio output of your
PC to the audio input terminal.
G S-V Connect external video devices such as VCR, DVD, and video
game to this DIN socket.
H VIDEO Connect the video output from your DVD/VCR player or PC to this
terminal.
I Audio-L Connect this audio output to the left speaker.
J Audio-R Connect this audio output to the right speaker.
K SPDIF Connect to a SPDIF device.

ViewSonic N4200w9
Side Panel Connections
A Audio-R Connect audio output (right channel) from compatible devices to
this terminal.
B Audio-L Connect audio output (left channel) from compatible devices to
this terminal.
C VIDEO Connect external video devices such as VCR, DVD, and video
game to this jack.
D S-V Connect external video devices such as VCR, DVD, and video
games to this DIN socket.
E Audio-R Connect audio output (right channel) from compatible devices to
this terminal.
F Audio-L Connect audio output (left channel) from compatible devices to
this terminal.
G VIDEO Connect external video devices such as VCR, DVD, and video
game to this jack.
H S-V Connect external video devices such as VCR, DVD, and video
game to this DIN socket.
I Audio-R Connect audio output (right channel) from compatible devices to
this terminal.
J Audio-L Connect audio output (left channel) from compatible devices to
this terminal.
K Pr/Cr Connect an external video device to this input.
L Pb/Cb Connect an external video device to this input.
M Y Connect an external video device to this input.
N ANALOG ANT Connect to an external antenna or cable service.

ViewSonic N4200w10
Remote control
The following table describes the functions for the Universal Remote control.
A 信号源 (SOURCE) Select Input Source (e.g. Video, Antenna, PC).
B 0~100+ channel selectors Use these buttons to select a channel.
C 音量 (VOL+ / VOL-) Adjust Volume.
D UP/DOWN/LEFT/ RIGHT/ OK
buttons
UP/DOWN for OSD function select and LEFT/
RIGHT for function adjust. Press OK to confirm
your selection.
E 静音 (MUTE) Temporarily switch off audio output retaining
the current volume settings.
F 暂停 (FREEZE)
Press this button to hold the current display.
Press again to release the picture. Note this is
not the same as pause and the underlying
broadcast continues.
G 显示 (DISPLAY) Display the current input source and time.
H 画中画/画外画 (PIP/POP ) Activate PIP feature (Activate Guide).
I 画中画/信号源 (PIP/SOUR) Press to toggle the Sub picture between PIP.
J 画中画/位置 (PIP/POS) Change the display position of the Sub Picture
in PIP mode.

ViewSonic N4200w11
K 画中画/信号源互换(PIP/SWAP) Toggles between input sources for the Main and
Sub pictures.
L 观赏模式 (WIDE) Change Aspect Ratio.
M 休眠 (SLEEP) Set timer to turn off the Display.
N 菜单 (MENU) Display menu or exit OSD menu.
O 频道 (CH﹀/ CH＾) Sequentially scrolls between channels.
P 电源 Power ON/OFF.

ViewSonic N4200w12
Preparing Your LCD TV
1. Insert Remote Control Batteries
a) Remove the battery cover by pushing the catch in the middle of the remote control and then
lifting the cover.
b) Align the batteries according to the (+) and (-) markings on the battery and those in the
compartment.
c) Replace the battery cover and push down until it clicks into place.
CAUTION
 Only use the specified AAA batteries.
 Do not mix new and old batteries. This may result in cracking or leakage, which may
pose a risk of fire or lead to personal injury.
 Insert batteries according to (+) and (-) markings. Inserting the batteries incorrectly
may result in cracking or leakage, which may pose a risk of fire or lead to personal
injury.
 Dispose of the battery in accordance with local laws and regulations.
 Keep the batteries away from children and pets.
 When the remote control will not be used for extended periods, please remove the
batteries.

ViewSonic N4200w13
2. Connecting an External Antenna
Make sure the power is off before installing an external antenna to N4200w.
Connect the TV antenna to the LCD TV terminal or CATV box using only 75-ohm coaxial
cable.
3. Connecting to Audio Output
To connect an external amplifier, connect the L/R RCA cable from the TV AUDIO OUT port to
the appropriate AUDIO IN port on a compatible amplifier.
Audio in Cable
(Cable not supplied)
RF Cable or Ada
p
ter

ViewSonic N4200w14
4. Connecting to a SPDIF Device
To digitally transfer audio to an external amplifier, PC, or recorder, use a compatible SPDIF
stereo jack to connect to the LCD TV.
5. Connecting AV, S-Video, YCbCr, YPbPr, HDMI to Video Devices
The following figures show the available connections to the rear-panel of LCD TV, and how to
connect them to the corresponding device. In nearly all cases, the cables are color-coded to
match the terminals on the rear panel.
AV model:
Connect video cable to the output jack on the video source, and the composite input on the LCD
TV. Now connect the audio cables to the left and right audio-out terminals on the video source
to the audio-in terminals.
VCR/Cable Receiver
SPDIF Cable
(Cable not supplied)
RCA A/V Cable
(Cable not supplied)

ViewSonic N4200w15
S-Video model:
Connect video cable to the output jack on the video source, and the S-video input jack on the
LCD TV. Now connect the audio cables to the left and right audio-out terminals on the video
source to the audio-in terminals.
YCbCr / YPbPr model:
Connect video cables to the Y, Pb/Cb, Pr/Cr outputs on the video source, and the Y, Pb/Cb,
Pr/Cr inputs on the LCD TV. Now connect the audio cables to the left and right audio-out
terminals on the video source to the audio-in terminals.
S-Video Cable
(Cable not supplied)
A
udio in Cable
(Cable not supplied)
VCR
A
udio in Cable
(Cable not supplied)
DVD Player or VCR
YCbCr / YPbPr Cable
(Cable not supplied)

ViewSonic N4200w16
HDMI and HDTV:
LCD TV is compatible with HDTV and HDMI, uncompressed interference free digital
transmission standards. The former requires additional audio cable; in this case connect the
audio outputs on the DVD player to the PC stereo input. The latter, is an all-in-one interface
supporting audio and video in a single cable.
There are two possible HDMI cable connections to your DVD player. Please refer to the
connection that matches your equipment.
Note: To receive audio from a DVD player, locate the OSD Sound Menu and enable HDMI
audio. Ensure the input source is HDMI compatible.
6. Connecting a PC
VGA (15pin D-Sub):
Connect the VGA cable from the PC’s VGA-out to the VGA terminal input of N4200w.
Select PC screen resolution up to1360 x 768 (1280 x 1024 also supported) according to
preference.
DVD Player
PC
HDMI Cable (Cable not supplied)
VGA 15 Pin Cable
(Cable not supplied)
(Cable not supplied)

ViewSonic N4200w17
PC Audio in:
Connect an audio-cable from the audio output (green terminal) of your PC to the audio input
terminal (also green) of N4200w.
HDMI:
Connect the HDMI cable from DVI output of PC to the HDMI input of N4200w.
PC
PC
HDMI Cable (Cable not supplied)
PC Audio Cable
(Cable not supplied)

ViewSonic N4200w18
7. Connecting the power cable
Connect the power cable to the N4200w then to a properly grounded AC outlet. Turn on the AC
Switch on the back of N4200w.
8. Powering LCD TV
Press the Power button at the bottom of the LCD TV, or press the Power button on the Remote
Control. Now switch on the external video player.
AC wall socket
AC Switch
Switch to ON
