ViewSonic CD3225 User manual

CD3225
32" FULL HD 1080P
COMMERCIAL LCD DISPLAY
ViewSonic’s 32" CD3225 Commercial Display is designed for use in
educational, retail, public and commercial signage applications.
Full 1080p resolution and nearly 178º horizontal and vertical
viewing angles provide a clear view in any installation. Multiple
connectivity and resolutions provide many options for showing
a diverse set of digital signage content; from movies, to internet
pages, PowerPoint, Flash, and much more with ultimate HD
clarity. Display your vivid graphics and stunning video beautifully
with this bright and high contrast commercial display.
Grand Format for Large,
Crisp Digital Signage Images
1080p 8ms LCD panel for
vibrant video and crisp images
24V DC input for easy remote wiring
RS-232 daisy-chain capable
>
>
>
Screen saver/image sticking protection
Built-in 6Wx2 speaker
Installation options include stand (STND-015)
or VESA wall mount (WMK-013) 200x200m
>
>
>
VGA, DVI, HDMI and S-video
 inputs/outputsforexible
connectivity and control
Remote and front panel
control lock out
>
>

RESOLUTIONS 640 x 480 at 60 Hz, 72 Hz to 75 Hz
SUPPORTED 720 x 400 at 70 Hz
800 x 600 at 60 Hz to 75 Hz
1024 x 768 at 60 Hz, to 75 Hz
1280 x 768 at 60 Hz
1280 x 960 at 60 Hz
1280 x 1024 at 60 Hz
1360 x 768 at 60 Hz
1366 x 768 at 60 Hz
1600 x 1200 at 60 Hz
1920 x 1080 at 60Hz (recommended resolution)
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
Specicationsandavailabilityaresubjecttochangewithoutnotice.Selection,offersandprogramsmayvarybycountry;seeyour
ViewSonicrepresentative forcomplete details.HDMI, theHDMI logo,and theHigh-DenitionMultimedia Interface aretrademarks
or registered trademarks of HDMI Licensing LLC in the U.S. and other countries. Corporate names, trademarks stated herein are the
property of their respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved. [15175-00B-08/10] CD3225-1
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
CD3225
LCD Type 32" color TFT active matrix, wide LCD
Display Area 27.48" horizontal x 15.47" vertical; 31.5" diagonal
Optimum Resolution 1920x1080, 0.36375mm dot pitch
Contrast Ratio 5000:1 (typ)
Viewing Angles 178º horizontal, 178º vertical
Response Time 8ms
Light Source Long life, 50,000 hrs. (typ)
Brightness 450 cd/m2 (typ)
Aspect Ratio 16:9
Panel Surface Anti-glare
INPUT Video HDMI, DVI, VGA, S-Video, CVBS
 Audio 3.5mmjack
Control RS-232
OUTPUT Control RS-232
AUDIO Speakers 6Wx2
INPUT SIGNAL TV/Video Comp. 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital HDMI, DVI
Power 3-pin plug
POWER Voltage AC 100–240V (universal), 50–60Hz / DC 24V, 4.1A
Consumption 100W (typ)
CONTROLS Panel Input, Menu, Up, Down, Left, Right, Power
Picture Pictue Mode, Contrast, Brightness, Color, Tint, Sharpness,
Backlight, DCR, Color Temperature
Audio Volume, Mute
 OSDSetting AspectRatio,PIP,VideoSource,AutoAdjustment,Clock,
Frequency, Phase, H. Possition, V. Position, 3D Comb, Blue Screen
Special Language, Overscan, Power Save, Set Monitor ID, Image
  Rentaton,AutoAdjsutment,ResetAllSetting,Diagnostic
OPERATING Temperature (landscape) 32–104ºF (0–40ºC)
CONDITIONS Temperature (portrait) 41–95ºF (5–35ºC)
Humidity 20–80% (non-condensing)
DIMENSIONS Physical 29.2" x 18.6" x 5.1" (775.6mm x 472.6mm x 128mm)
(W x H x D) Packaging 33.6" x 26.5" x 13.9" (855mm x 675mm x 355mm)
WEIGHT Net 35.3 lb. (16 kg)
Gross 41.9 lb. (19 kg)
WALL MOUNT VESA 200mm x 200mm
REGULATIONS FCC-B, CE, ICES 003, CB, RoHS
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS LCD display, power cable, VGA cable, remote control with
batteries, power adapter holder, Quick Start Guide,
User Guide CD
WARRANTY Three-year limited warranty on parts, labor and backlight.
32" FULL HD 1080P COMMERCIAL LCD DISPLAY
1. Adapter Holder
Installation Holes
2. Kensington®Security Slot
3. Anti-Topple Rings
4. Video
5. S-Video
6. RS-232
7. VGA
8. DVI
9. HDMI
10. Audio In
11. DC Power
1 2
3
10
11
3
4
5
6
8
7
9
