ViewSonic CD4636 User manual

CD4636
46" ULTRA SLIM BEZEL
FULL HD 1080P
COMMERCIAL LCD DISPLAY
ViewSonic’s 46" CD4636 Commercial Display is designed for
use in educational, retail, public and commercial signage
applications. Super slim bezel is great for display wall
applications. High Denition resolutions provides a clear view
in any installation. Generous screen size and super slim bezel
make messages stand out in a big way. Multiple connectivity
and resolutions provide you with lots of options for showing a
diverse set of digital signage content; from video, to internet
pages, PowerPoint, Flash, and much more with ultimate HD
clarity. Display your vivid graphics and stunning video beautifully
with this large, bright and high contrast screen.
Versatile Video Wall Solution
1366 x 768 8ms panel for vibrant >
video and crisp images
2.5mm ultra slim bezel>
Built-in 5Wx2 speaker>
with 7Wx2 output
RS-232 daisy-chain capable>
VGA & DVI inputs/outputs for>
exible connectivity and control
5x5 ViewSonic Commercial Display Video Wall (Digital Signage)
PC/Server
Media
Media Player
Internet
Remote and panel control>
lock out
7 day on/off scheduling>
Screen saver/image >
sticking protection
Display wall capability up to 5x5>
Installation options include>
stand or VESA wall mount
Ultra Slim Bezel

RESOLUTIONS 640 x 480 at 60 Hz to 85 Hz
SUPPORTED 800 x 600 at 50 Hz, 60Hz to 85 Hz
1024 x 768 at 50 Hz, 60Hz to 85 Hz
1280 x 768 at 50 Hz, 60Hz to 85 Hz
1360 x 768 at 50 Hz, 60Hz to 85 Hz
NTSC, PAL, SECAM, 4.43 NTSC, PAL 60
Component: 480i,480p,720p,1080i,1080p
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
Specications and availability subject to change without notice. Selection, offers and programs may vary by country; see
your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved. [15215-01B-12/10] CD4636-1
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
CD4636
LCD Type 46" color TFT active matrix, wide LCD
Display Area 45.4" horizontal x 25.5" vertical; 46" diagonal
Optimum Resolution 1366x768, 600mm dot pitch
Contrast Ratio 3000:1 (typ)
Viewing Angles 178º horizontal, 178º vertical
Response Time 8ms
Light Source Long life, 50,000 hrs. (typ)
Brightness 450 cd/m2 (typ)
Aspect Ratio 16:9
Panel Surface Anti-glare, hard coating (3H)
INPUT Video Input HDMI, DVI, component, VGA, S-Video, composite
Video Output VGA, component, DVI
Control Input/Output RS-232
AUDIO OUTPUT Amplier 7-watt / 8 ohm
INPUT SIGNAL TV/Video Comp. 480i, 480p, 720p, 1080i, 1080p
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital HDMI, DVI
Power 3-pin plug
POWER Voltage AC 100–240V (universal), 50–60Hz
Consumption 232W (typ)
CONTROLS Panel Power, Exit, +, –, Menu/Enter
Picture Picture mode, contrast, brightness, color temperature,
temperature adjust, sharpness
VGA Setting Auto adjustment, clock, phase, sharpness,
H. position, V. position
OSD Setting Languages, OSD H. position, OSD V. position, OSD timer
Input VGA, DVI, HDMI, YPbPr
Audio Volume, mute, audio source
Special Aspect ratio, over scan, power save, image retention,
auto adjustment, monitor ID, reset
Diagnostic Thermal, back light, ambient, 5V detect, 12 detect
OPERATING Temperature (landscape) 41–104ºF (5–40ºC)
CONDITIONS Temperature (portrait) 41–95ºF (5–35ºC)
Humidity 20–80% (non-condensing)
DIMENSIONS Physical with stand (optional) 40.4" x 24.8" x 16" (1025.7mm x 650mm x 405mm)
(W x H x D) Physical without stand 40.4" x 22.8" x 4.8" (1025.7mm x 579.8mm x 120.8mm)
WEIGHT Net with stand (optional) 69.8 lb. (31.7 kg)
Net without stand 69.0 lb. (31.7 kg)
Gross without stand 76.5 lb. (34.7 kg)
WALL MOUNT VESA 100mm x 100mm, 12 holes
REGULATIONS FCC, ICES003, UL, cUL, CE, CB, ENERGY STAR®
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS LCD display, power cable, remote control with batteries,
User Guide CD
WARRANTY Three-year limited warranty on parts, labor and backlight
46" SLIM BEZEL FULL HD 1080P
COMMERCIAL LCD DISPLAY
1 2 3 4 5 6 7 8
1. Power Switch
2. AC IN
3. Speaker OUT
4. Audio OUT
5. PC Audio
6. HDMI
7. DVI
8. VGA IN
15
10
14
12
9. VGA OUT
10. RS-232 IN
11. RS-232 OUT
12. Video IN/OUT
13. Composite IN
14. S-Video
15. RGB IN
9
11
13
