ViewSonic’s complete line of Open Frame Commercial LCD Displays are ideal for use in kiosks,
simulators, instrumentation packs, and gaming/entertainment installations. Their six-point metal chassis
makes it easy to mount in any of these applications and eliminates the need for non-bezel displays.
Communicate targeted messages or play gaming/entertainment content on your schedule to your
chosen audience. The bright LCD panels deliver vibrant images for high-quality digital signage displays.
VGA inputs and outputs allow you to connect to PCs and high-def content sources. Wide viewing angles,
high brightness and contrast and excellent PC resolutions display crystal clear images in scrolling text or
video. ViewSonic’s Open Frame displays set a new standard for large format, open frame displays.
Flexible Installation Signage Display
High brightness and contrast ratios
Ready to mount, six-point metal chassis
Ideal for retail kiosks, simulators,
instrumentation packs or casino
games displays
VGA inputs and outputs
Complete digital signage solution
>
>
>
>
>
ViewSonic Corporation’s QMS & EMS have been
registered to ISO 9001 & ISO 14001, respectively,
by the British Standards Institution.
Open Frame
LCD Displays
17" – 47" SCREEN SIZES

For more product information, visit us on the web at www.ViewSonic.com
OP1700 OP1710 OP1900 OP1910
LCD Type 17" color TFT active 17" color TFT active 19" color TFT active 19" color TFT active
matrix, LCD matrix, wide LCD matrix, LCD matrix, wide LCD
Display Area 13.3" horizontal x 10.6" vertical; 14.6" horizontal x 8.2" vertical; 14.8" horizontal x 11.8" vertical; 16.2" horizontal x 10.1" vertical;
17" diagonal 17" diagonal 19" diagonal 19" diagonal
Optimum Resolution 1280x1024 1280x720 1280x1024 1440x900
Brightness (typ) 250 250 300 380
Contrast Ratio (typ) 700:1 500:1 1000:1 1000:1
Viewing Angles 160º horizontal / 160º vertical 140º horizontal / 130º vertical 170º horizontal / 160º vertical 170º horizontal / 160º vertical
Response Time 5ms 8ms 5ms 5ms
Light Source (typ) 40,000 hrs. 40,000 hrs. 40,000 hrs. 40,000 hrs.
INPUT Video Input VGA VGA VGA VGA
AUDIO Speakers 2x 1-watt 2x 1-watt 2x 1-watt 2x 1-watt
CONNECTOR Input 15-pin mini D-sub (VGA) 15-pin mini D-sub (VGA) 15-pin mini D-sub (VGA) 15-pin mini D-sub (VGA)
Power 3-pin plug 3-pin plug 3-pin plug 3-pin plug
POWER Voltage AC 100-240V (universal), AC 100-240V (universal), AC 100-240V (universal), AC 100-240V (universal),
50–60Hz 50–60Hz 50–60Hz 50–60Hz
Consumption < 45W < 45W < 45W < 45W
OPERATING Temperature
CONDITIONS (landscape) 32–104ºF (0–40ºC) 41–104ºF (5–40ºC) 41–104ºF (5–40ºC) 41–104ºF (5–40ºC)
Temperature
(portrait) 41–95ºF (5–35ºC) 41–95ºF (5–35ºC) 41–95ºF (5–35ºC) 41–95ºF (5–35ºC)
Humidity
(non-condensing) 20–80% 20–80% 20–80% 20–80%
DIMENSIONS W x H x D 14.8" x 12.7" x 2.0" 15.4" x 10.5" x 2.14" 15.9" x 13.1" x 2.5" 16.9" x 11.0" x 2.6"
(360 x 321 x 51 mm) (390 x 266 x 54 mm) (511 x 286 x 68 mm) (430 x 280 x 67 mm)
WEIGHT Net 15.9 lb. (7.2 kg) 15.6 lb. (7.1 kg) 15.3 lb. (6.9 kg) 15.3 lb. (6.9 kg)
VESA®MOUNT 100 x 100 mm N/A N/A N/A
REGULATIONS FCC, UL FCC, UL FCC, UL FCC, UL
WARRANTY 1 year 1 year 1 year 1 year
– Page 2 –
17"–19" Open Frame LCD Displays

For more product information, visit us on the web at www.ViewSonic.com
OP2210 OP2410 OP2610 OP3210
LCD Type 21.6" color TFT active 23.6" color TFT active 26" color TFT active 31.5" color TFT active
matrix, wide LCD matrix, wide LCD matrix, wide LCD matrix, wide LCD
Display Area 18.3" horizontal x 11.4" vertical; 20.5" horizontal x 11.5" vertical; 22.7" horizontal x 12.7" vertical; 27.5" horizontal x 15.4" vertical;
21.6" diagonal 23.6" diagonal 26" diagonal 31.5" diagonal
Optimum Resolution 1680x1050 1920x1080 1366x768 1366x768
Brightness (typ) 300 300 500 500
Contrast Ratio (typ) 1000:1 1000:1 800:1 1500:1
Viewing Angles 160º horizontal / 160º vertical 170º horizontal / 160º vertical 160º horizontal / 150º vertical 176º horizontal / 176º vertical
Response Time 5ms 5ms 8ms 6.5ms
Light Source (typ) 40,000 hrs. 50,000 hrs. 60,000 hrs. 50,000 hrs.
INPUT Video Input VGA HDMI, VGA, component, HDMI (x2), VGA, component (x2), HDMI (x2), VGA, component (x2),
S-video, composite S-video, composite S-video, composite
AUDIO Speakers 2x 1-watt 2x 3-watt 2x 10-watt 2x 10-watt
CONNECTOR Input 15-pin mini D-sub (VGA) 15-pin mini D-sub (VGA), RCA 15-pin mini D-sub (VGA), RCA 15-pin mini D-sub (VGA), RCA
(component, composite), 4-pin (component, composite), 4-pin (component, composite), 4-pin
Mini-DIN connector (S-video) Mini-DIN connector (S-video) Mini-DIN connector (S-video)
Power 3-pin plug 3-pin plug 3-pin plug 3-pin plug
POWER Voltage AC 100-240V (universal), AC 100-240V (universal), AC 100-240V (universal), AC 100-240V (universal),
50–60Hz 50–60Hz 50–60Hz 50–60Hz
Consumption < 50W < 65W < 130W < 200W
OPERATING Temperature
CONDITIONS (landscape) 41–104ºF (5–40ºC) 41–104ºF (5–40ºC) 41–104ºF (5–40ºC) 41–104ºF (5–40ºC)
Temperature
(portrait) 41–95ºF (5–35ºC) 41–95ºF (5–35ºC) 41–95ºF (5–35ºC) 41–95ºF (5–35ºC)
Humidity
(non-condensing) 20–80% 20–80% 20–80% 20–80%
DIMENSIONS W x H x D 20.1" x 11.3" x 2.7" 22.0" x 13.2" x 2.7" 25.3" x 15.6" x 3.7" 30.7" x 18.5" x 4.4"
(511 x 286 x 68 mm) (559 x 334 x 68 mm) (646 x 396 x 93 mm) (779 x 469 x 111 mm)
WEIGHT Net 17.7 lb. (8.0 kg) 17.7 lb. (8.0 kg) 20.9 lb. (9.5 kg) 25.3 lb. (11.5 kg)
VESA®MOUNT N/A N/A 200 x 100 mm 400 x 200 mm
REGULATIONS FCC, UL FCC, UL FCC, UL FCC, UL
WARRANTY 1 year 1 year 1 year 1 year
– Page 3 –
21.6"–31.5" Open Frame LCD Displays

37"–47" Open Frame LCD Displays
For more product information, visit us on the web at www.ViewSonic.com
OP3710 OP4210 OP4710
LCD Type 37" color TFT active 42" color TFT active 47" color TFT active
matrix, wide LCD matrix, wide LCD matrix, wide LCD
Display Area 32.3" horizontal x 18.9" vertical; 36.6" horizontal x 20.6" vertical; 40.9" horizontal x 23.0" vertical;
37" diagonal 42" diagonal 47" diagonal
Optimum Resolution 1366x768 1920x1080 1920x1080
Brightness (typ) 500 500 500
Contrast Ratio (typ) 2000:1 1500:1 1500:1
Viewing Angles 176º horizontal / 176º vertical 176º horizontal / 176º vertical 176º horizontal / 176º vertical
Response Time 8ms 6.5ms 6.5ms
Light Source (typ) 50,000 hrs. 60,000 hrs. (typ) 50,000 hrs. (typ)
INPUT Video Input HDMI (x2), VGA, component (x2), HDMI (x2), VGA, component (x2), HDMI (x2), VGA, component (x2),
S-video, composite S-video, composite S-video, composite
AUDIO Speakers 2x 10-watt 2x 10-watt 2x 10-watt
CONNECTOR Input 15-pin mini D-sub (VGA), RCA 15-pin mini D-sub (VGA), RCA 15-pin mini D-sub (VGA), RCA
(component, composite), 4-pin (component, composite), 4-pin (component, composite), 4-pin
Mini-DIN connector (S-video) Mini-DIN connector (S-video) Mini-DIN connector (S-video)
Power 3-pin plug 3-pin plug 3-pin plug
POWER Voltage AC 100-240V (universal), AC 100-240V (universal), AC 100-240V (universal),
50–60Hz 50–60Hz 50–60Hz
Consumption < 200W < 270W < 300W
OPERATING Temperature
CONDITIONS (landscape) 41–104ºF (5–40ºC) 41–104ºF (5–40ºC) 41–104ºF (5–40ºC)
Temperature
(portrait) 41–95ºF (5–35ºC) 41–95ºF (5–35ºC) 41–95ºF (5–35ºC)
Humidity
(non-condensing) 20–80% 20–80% 20–80%
DIMENSIONS W x H x D 35.8" x 21.4" x 4.8" 39.4" x 23.4" x 4.7" 44.3" x 26.3" x 4.5"
(910 x 542 x 123 mm) (1001 x 594 x 120 mm) (1124 x 668 x 115 mm)
WEIGHT Net 33.0 lb. (15.0 kg) 38.1 lb. (17.3 kg) 45.2 lb. (20.5 kg)
VESA®MOUNT 400 x 200 mm 400 x 200 mm 400 x 200 mm
REGULATIONS FCC, UL FCC, UL FCC, UL
WARRANTY 1 year 1 year 1 year
