ViewSonic’s 15" (13.8" viewable) Q51 and Q51B Optiquest®CRT
monitors deliver quality and RELIABILITY AT A PRICE THAT FITS
YOUR WALLET. View word processing documents, spreadsheets
and Internet content comfortably with high resolution up to
1024x768. A fine 0.24mm horizontal dot pitch produces clear, crisp
images with precise picture definition. The anti-reflection, anti-
glare screen reflects unwanted glare while maintaining HIGH
QUALITY IMAGES, SO IT’S EASY ON YOUR EYES. Adjust your
screen with the OnView®controls and secure them with the OSD
lock function to ensure optimum performance. The Q51 and Q51B
are ideal for home offices and student or Internet users.
ViewSonic
®
quality and reliability.
>0.24mm horizontal dot pitch
0.28mm diagonal dot pitch
This fine dot pitch produces clear, crisp images with precise
picture definition, even at the highest resolutions.
>1024x768 maximum resolution
Displays a maximum resolution of 1024x768; 800x600 at 85Hz
flicker-free refresh rate for easy-on-the-eyes viewing.
>OnView controls
Screen adjustments are made via an on-screen menu using
simple controls. This user-friendly control system easily adjusts
image quality, size, position and geometry for optimal viewing.
>OSD lock function
When activated, user-controlled OSD lock function prevents
changes to monitor settings, maintaining an optimized image.
>Reduced eyestrain
Anti-reflection, anti-glare screen treatment reduces reflection
and glare for exceptional viewing comfort.
>ViewSonic Wizard
This user-friendly Wizard software
automates the set-up process to deliver
optimized screen performance.
>MPR II qualified
>PC and Mac®compatible
>Three year limited warranty
24/7 free technical and customer
support*.
THE AFFORDABLE CHOICE
FOR WORK, HOME OR PLAY
Q51/Q51B
15" (13.8" VIEWABLE)
CRT MONITOR
WITH ONVIEW®CONTROLS

CRT Type 15" (13.8 viewable) 90° deflection
Dot Pitch 0.24mm (horizontal) x 0.14mm (vertical); 0.28 diagonal
Phosphor RGB medium-short persistence
Glass Surface Tint: TM~57%, anti-reflection, anti-glare screen coating
INPUT SIGNAL Video RGB analog (75 ohms, 0.7/1.0 Vp-p)
Sync H/V separated (TTL), composite sync
Frequency Hh: 30~54Hz, Fv: 50~120Hz
COMPATIBILITY PC VGA up to 1024x768 non-interlaced
Mac®** Power Mac™G3/G4 up to 1024x768
CONNECTOR Analog 15-pin mini D-sub
Power 3-pin plug (CEE22)
POWER Voltage AC 90–132/198–264 VAC (auto switch), 50/60 Hz (+/-3)
Consumption 70W (typ)
CONTROLS Basic Power, 1, down, up, 2
OnView®Contrast, brightness, degauss, H./V. size, H./V. position,
pincushion, trapezoid, pinbalance, parallelogram, tilt, moiré,
ViewMatch®color (9300K, 6500K), language, recall, ViewMeter®,
OSD position, zoom
VIDEO INPUT Bandwidth 75MHz (typ)
MISCONVERGENCE 0.25mm (max) at center; 0.35mm (max) at corner
DISPLAY AREA Factory Setting 270mm horizontal x 202mm vertical
Maximum Scan 280mm horizontal x 210mm vertical (dependent upon timing signal)
OPERATING Temperature 32–104°F (0–40°C)
CONDITIONS Humidity 10–90% (no condensing)
DIMENSIONS Physical (mm) 360mm x 362mm x 384mm
(W x H x D) Physical (in.) 14.2" x 14.3" x 15.1"
WEIGHT Net 24.6 lb. (11.2 kg)
Gross 28.6 lb. (13.0 kg)
REGULATIONS UL, cUL, DHHS, FCC-B, ICES-003, CB, NOM, TUV/S
(Argentina), BSMI, PSB, MPR II
POWER MANAGEMENT Meets MPR II standards
PACKAGE CONTENTS CRT monitor, video cable (attached), power cable,
Quick Start Guide, ViewSonic Wizard CD
WARRANTY Three-year limited warranty on CRT, parts and labor
Q51/Q51B
15" (13.8" VIEWABLE) CRT MONITOR WITH ONVIEW®CONTROLS
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Phone [phone] or [phone] • In Canada [phone]• Fax [phone]• [email protected] • ViewSonic.com
*Excludes major U.S. holidays. **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice.Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2005 ViewSonic Corporation. All rights reserved. [12259-01B-06/05] Q51-9/Q51B-9
For more product information, visit us on the web at ViewSonic.com
ViewSonic Corporation’s QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
Available colors:
Black (Q51B) and Beige (Q51)
