Q72b
17" LCD
WITH SUPER-FAST 5MS VIDEO RESPONSE
The Optiquest®Q72b 17" LCD delivers an impressive array of
features that will ENHANCE YOUR PRODUCTIVITY WHILE STAYING
WITHIN YOUR BUDGET. With an excellent 800:1 contrast ratio (typ)
and 300 nits brightness (typ), you’ll receive clear text and rich colors.
The full, flat 17 inches of viewable space and 1280x1024 resolution are
comparable to 19" CRT monitors for display productivity. The
super-fast 5ms video response time and anti-glare screen let you
work comfortably for hours with RAZOR-SHARP GRAPHICS AND
SMOOTH MOTION VIDEO. This LCD is the affordable upgrade with
performance features for your home or office.
Affordability without compromise.
HIGH IN FEATURES, LOW IN PRICE
Super-fast 5ms video response delivers superior picture clarity
High brightness and contrast ratio
300-nit brightness (typ) and 800:1 contrast ratio (typ) for rich,
detailed images.
1280x1024 optimum resolution
Incredible image detail for sharp text and graphics.
Stylish slim-bezel design
An ultra-thin bezel lets you see more without taking up
valuable desktop space.
OnView®controls for superior screen adjustability
Screen adjustments are precisely made via an
easy-to-use on-screen menu.
Full 17" viewable screen
Displays a full, flat 17" viewable area with crisp detail
and fully saturated color.
Integrated power supply
VESA®100mmx100mm wall-mount compliant
24/7 free technical support and customer support*
PC and Mac®compatible
>
>
>
>
>
>
>
>
>
>

17" LCD WITH SUPER-FAST 5MS VIDEO RESPONSE
LCD Type 17" color TFT active matrix LCD
Display Area 13.3" horizontal x 10.6" vertical; 17.0" diagonal
Optimum Resolution 1280x1024
Contrast Ratio 800:1 (typ)
Viewing Angles 160º horizontal, 160º vertical
Response Time 5ms (typ)
Light Source Long life, 50,000 hrs. (typ)
Brightness 300 cd/m2(typ)
Panel Surface Anti-glare
VIDEO INPUT Analog RGB analog (75 ohms, 0.7 Vp-p)
Frequency Fh: 30~81kHz, Fv: 56~75Hz
Sync H/V separated (TTL)
COMPATIBILITY PC VGA up to 1280x1024 non-interlaced
Mac®** G3/G4/G5 up to 1280x1024
CONNECTOR Analog 15-pin mini D-sub
Power 3-pin AC plug (CEE22)
POWER Voltage AC 100–240V (universal), 50–60Hz (auto switch)
Consumption 36W (typ)
CONTROLS Basic Power, menu, – , +
OnView®Auto setup, brightness, contrast, ViewMatch®color
adjust (cool, neutral warm, black level adjust (R, G, B),
user color), H. position, V. position, language, phase,
clock, recall, volume, OSD H. position, OSD V. postion
ERGONOMICS Tilt –5º/+20º
OPERATING Temperature 41–104ºF (5–40ºC)
CONDITIONS Humidity 20–85% (non-condensing)
DIMENSIONS Physical with stand 15.1" x 15.3" x 8.0" (383mm x 389mm x 203mm)
(W x H x D) Physical without stand 16.0" x 11.0" x 2.26" (383mm x 342mm x 58mm)
WEIGHT Net with stand 8.8 lb. (4.0 kg)
Net without stand 8.1 lb. (3.7 kg)
Gross with stand 12.1 lb. (5.5 kg)
REGULATIONS UL, cUL, FCC-B, NOM, , ENERGY STAR®, CE, CB, TUV-S,
CSA, RoHS, MPR II
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
POWER MANAGEMENT ENERGY STAR®standards
PACKAGE CONTENTS LCD display, power cable, video cable, User Guide
WARRANTY One-year limited warrranty on parts, labor and backlight
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [e-mail] • ViewSonic.com
*Excluding major U.S. holidays. **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2008 ViewSonic Corporation. All rights reserved. [13823-00B-12/07] Q72b-1
ViewSonic Corporation’s QMS & EMS have been
registered to ISO 9001 & ISO 14001, respectively,
by the British Standards Institution.
