ViewSonic ViewPanel VA720 User manual

Full 17" Diagonal Viewable Screen
VA720 ViewPanel®
User Guide
Guide de l’utilisateur
Bedienungsanleitung
Guía del usuario
Guida dell'utente
Guia do usuário
Användarhandbok
Käyttöopas
Jmdh\h^kl\hihevah\Zl_ey
,QVWUXNFMDREVáXJL

Contents
Product Registration ................................................... 2
For Your Records ....................................................... .2
Getting Started
Package Contents ....................................................... 3
Precautions ................................................................. 3
Quick Installation ........................................................ 4
Installation of Wall Mount (Optional) ........................ 5
Using the ViewPanel Display
Setting the Timing Mode ............................................ 6
OSD and Power Lock Settings ................................... 6
Adjusting the Screen Image ....................................... 7
Main Menu Controls .................................................... 9
Other Information
Specifications ............................................................. 12
Troubleshooting ......................................................... 13
Customer Support ...................................................... 14
Cleaning the ViewPanel Display ............................... 15
Limited Warranty ........................................................ 16
Appendix
Safety Guidelines ....................................................... 17
Compliance Information for U.S.A. ........................... 18
CE Conformity for Europe ......................................... 18
06/28/02 BViewSonic VA720 1

Copyright © ViewSonic Corporation, 2002. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of
Microsoft Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of
ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC
are trademarks of VESA.
ENERGY STAR®is a registered trademark of the U.S. Environmental Protection Agency (EPA).
As an ENERGY STAR®partner, ViewSonic Corporation has determined that this product meets the
ENERGY STAR®guidelines for energy efficiency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from furnishing this mate-
rial, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specifications without notice. Information in this document may change without
notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic®
Wizard CD-ROM also provides an opportunity for you to print the registration form, which you
may mail or fax to ViewSonic.
Product disposal at end of product life
ViewSonic is concerned about the preservation of our environment. Please dispose of this product
properly at the end of its useful life. Your local waste disposal company may provide information
about proper disposal.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
ViewSonic VA720
VLCDS23724-2W
A-CD-VA720-2
______________
______________
ViewSonic VA7202

ViewSonic VA720 3
Getting Started
Congratulations on your purchase of a ViewSonic®ViewPanel®display.
Important! Save the original box and all packing material for future shipping
needs.
NOTE: The word “Windows” in this user guide refers to the following
Microsoft operating systems: Windows ‘95, Windows NT, Windows ‘98,
Windows 2000, Windows Me (Millennium), and Windows XP.
Package Contents
Your ViewPanel package includes:
• ViewPanel display
•Powercord
• AC/DC power adapter
• Video cable
• ViewSonic Wizard CD-ROM
NOTE: The CD jacket contains the Quick Start Guide, and the CD includes the
User Guide PDF files and INF/ICM display optimization files. The INF file
ensures compatibility with Windows operating systems, and the ICM file (Image
Color Matching) ensures accurate on-screen colors. ViewSonic recommends
that you install both files.
Precautions
• Sit at least 18" from your ViewPanel display.
•Avoid touching the screen. Skin oils are
difficult to remove.
•Never remove the rear cover. Your
ViewPanel display contains high-voltage
parts. You may be seriously injured if you
touch them.
• Avoid exposing your ViewPanel display to
direct sunlight or another heat source. Orient
your ViewPanel display away from direct
sunlight to reduce glare.
• Always handle your ViewPanel display with
care when moving it.
• Place your ViewPanel display in a well-
ventilated area. Do not place anything on your
ViewPanel display that prevents heat
dissipation.
• Ensure the area around the ViewPanel display
is clean and free of moisture.
• Do not place heavy objects on the ViewPanel
display, video cable, or power cord.
• If smoke, abnormal noise, or strange odor is
present, immediately switch the ViewPanel
display off and call your dealer or ViewSonic.
It is dangerous to continue using the
ViewPanel display.

Quick Installation
Optional: For instructions on wall mounting,
see page 5 of this user guide.
1 Connect power cord and AC/DC
power adapter
2 Connect video cable
• Make sure both the ViewPanel®display
and computer are turned OFF
• Remove rear panel covers if necessary
• Connect the video cable from the View-
Panel to the computer
Macintosh users: Models older than G3
require a Macintosh adapter. Attach the
adapter to the computer and plug the video
cable into the adapter.
To order a ViewSonic®Macintosh adapter,
contact ViewSonic Customer Support.
3 Turn ON ViewPanel display and
computer
• Turn ON the ViewPanel display, then turn
ON the computer. This sequence (View-
Panel display before computer) is impor-
tant.
NOTE: Windows users may receive a
message asking them to install the INF file.
This is on the CD.
4 Insert the ViewSonic Wizard CD
into the computer’s CD drive.
• Follow the on-screen instructions
If your computer does not have a CD-ROM
drive, see “Customer Support."
(1) Wait for the CD-ROM to auto-start.
NOTE: If the CD-ROM does not auto-start:
double-click on the CD-ROM icon in the
Windows Explorer, then double-click on
viewsonic.exe.
(2) Follow the on-screen instructions.
5 Windows users: Set the timing
mode (resolution and refresh
rate)
Example: 1280 x 1024 @ 60 Hz.
For instructions on changing the resolution
and refresh rate, see the graphic card’s user
guide.
Installation is complete. Enjoy your new
ViewSonic, ViewPanel display.
To be best prepared for any future customer
service needs: print this user guide and write
the serial number in "For Your Records" on
page 2. (See back of ViewPanel display.)
You can register your product online at the
website for your region. See the Customer
Support table in this guide.
The ViewSonic Wizard CD-ROM also
provides an opportunity for you to print the
registration form which you may mail or fax
to ViewSonic.
AC/DC Power
Adapter
Video cable to computer
Power cord to adapter
Kensington
Lock
Power cord to computer
AC outlet (wall socket)
ViewSonic VA7204

Installation of Wall Mount (Optional)
To obtain a wall-mounting kit, contact ViewSonic or your local dealer. Refer to
the instructions that come with the base mounting kit. To convert your
ViewPanel from a desk-mounted to a wall-mounted display, do the following:
1Disconnect Power.
2Push the ViewPanel back and
down flat against the base as
shown.
3Lay the ViewPanel face down on
a towel or blanket. Notice the
four screw holes on the bottom of
the base.
4Attach the mounting bracket
from the VESA compatible wall-
mounting kit (100 mm x 100 mm
distance).
5Attach the ViewPanel to the wall,
following the instructions in the
wall-mounting kit.
Four
screw
holes
Mounted
on the wall
ViewSonic VA7205

Using the ViewPanel Display
Setting the Timing Mode
Setting the timing mode is important for maximizing the quality of the
screen image and minimizing eye strain. The timing mode consists of the
resolution (example 1280 x 1024) and refresh rate (or vertical frequency;
example 60 Hz). After setting the timing mode, use the OnView®controls
to adjust the screen image.
For the best picture quality set your ViewPanel®display timing mode to:
VESA 1280 x 1024@ 60 Hz.
To set the Timing Mode:
1Set the resolution: Right-click on the Windows desktop > Properties >
Settings > set the resolution.
2Set the refresh rate: See your graphic card's user guide for instructions.
WARNING: Do not set the graphics card in your computer to exceed the
maximum refresh rate of 75Hz; doing so may result in permanent damage to
your ViewPanel display.
OSD and Power Lock Settings
OSD Lock This mode locks all current control settings and prevents access to
the control menus until this mode is unlocked.
•OSD Lock: Press and hold [1] and the up arrow Ifor 10 seconds. If any
buttons are pressed the message OSD Lock will display for a few seconds.
•OSD Unlock: Press and hold [1] and the up arrow Iagain for 10 seconds.
Power Button Lock This mode locks the power of the ViewPanel in the ON
position.
•Power Button Lock: Press and hold [1] and the down arrow Jfor 10
seconds. If the power button is pressed the message Power Lock will display
for a few seconds. With or without this setting, after a power failure, your
ViewPanel’s power will automatically turn ON when power is restored.
•Power Button Unlock: Press and hold [1] and the down arrow Jagain for
10 seconds.
ViewSonic VA7206

Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OnView®
controls which display on the screen. The OnView controls are explained at the
top of the next page and are defined in “Other Information” on page 12.
Scroll through menu
options and adjust the
displayed control.
Displays, saves
changes to, and exits
the Main Menu.
Power On/Off
Selects a highlighted control. Also,
displays the control screen for the
selected control and toggles
between control pairs.
Power light
Front Control Panel
Main Menu
with OnView controls
ViewSonic VA7207

Do the following to adjust the screen image:
1To display the Main Menu, press button [1].
NOTE: All OnView menus and adjustment screens disappear automatically
after about 30 seconds. This time period is adjustable through the Setup
menu and the OSD timeout control described on page 11.
2To highlight a control you want to adjust, press Ior Jto scroll up or down
the Main Menu.
3To select the highlighted control, press button [2]. A control screen appears
like the example shown below.
4To adjust the control, press the up Ior down Jbuttons.
5To save the adjustments and exit the menu, press button [1] twice.
The following tips may help you optimize your display:
• Adjust your computer's graphic card so that it outputs a video signal 1280 x
1024 @ 60 Hz to the ViewPanel. (Look for instructions on "changing the
refresh rate" in your graphic card's user guide.)
• If necessary, make small adjustments using H POSITION and V POSITION
until the screen image is completely visible. (The black border around the
edge of the screen should barely touch the illuminated "active area" of the
ViewPanel®.)
The Jdown
arrow decreases,
Iup arrow
increases
The line at the
bottom of the screen
tells you what you
can do next - in this
example, either EXIT
or select the
BRIGHTNESS
control.
ViewSonic VA7208

Main Menu Controls
Adjust the menu items shown below by using the up Iand down Jbuttons.
Control Explanation
Auto Image Adjust automatically sizes, centers, and fine tunes
the video signal to eliminate waviness and distortion.
Press the [2] button to obtain a sharper image.
NOTE: Auto Image Adjust works with most common video
cards. If this function does not work on your ViewPanel®, then
lower the video refresh rate to 60 Hz and set the resolution to its
pre-set value.
Contrast adjusts the difference between the image background
(black level) and the foreground (white level).
Brightness adjusts background black level of the screen image.
Color Adjust provides several color options: preset color
temperatures and User which allows you to adjust red (R), green
(G), and blue (B). The factory setting for this product is 6500K
(6500 Kelvin).
9300K — Adds blue to the screen image for cooler white (used
in most office settings with fluorescent lighting).
6500K — Adds red to the screen image for warmer white and
richer red. Default setting.
5400K — Adds green to the screen image for a darker color.
User Color —Individual adjustments for red, green, and blue.
1To select color (R, G or B) press button [2].
2To adjust selected color, press Ior J.
3When you are finished making all color adjustments, press
button [1] twice.
ViewSonic VA7209
