ViewSonic
®
VG171/VG171b LCD Display
• technology
This multi-mode input technology supports
both digital (DVI) and analog (VGA) signals.
The digital interface delivers optimized
image quality with minimum adjustments.
•Full 17" viewable screen
Displays a native resolution of 1280 x 1024
for incredible detail and clarity. Lower
resolutions are scaled to full screen using
a third-generation processor with variable
sharpness control.
•OSD/Power Lock
When activated, user-controlled OSD/power
lock prevents changes to monitor settings,
maintaining an optimized image.
•OnView®controls
Screen adjustments are made via the
on-screen menu with user-friendly
four-button navigation.
•Anti-glare screen treatment
Cuts reflected light and delivers enhanced
contrast for improved legibility and superior
color saturation.
•Slim 2.5" profile (panel only)
•Weighs only 14.3 pounds
Feature-rich, yet cost effective 17-inch LCD.
Ideal for corporate customers, the ViewSonic VG171 and VG171b
LCD displays feature a DVI interface which simplifies installation and
guarantees the image quality is optimized without adjustments. The
built-in OptiSync™technology allows both models to display digital and
analog formats, utilizing today’s digital technology yet allowing for
backward compatibility. And, these 17-inch LCD displays come with
ViewSonic’s 24/7 toll-free technical support*. For today’s corporate user,
the ViewSonic VG171 and VG171b offer a complete benefits package.

VG171/VG171b LCD Display
LCD PANEL Type 17.0" Color TFT Active Matrix SXGA LCD
Display Area 13.3" (H) x 10.6" (V), 17.0" Diagonal
Pixel Pitch .264mm
Contrast Ratio 400:1 (typ)
Viewing Angle 150˚ horizontal, 140˚ vertical
Light Source Long Life, 50,000 hrs. (typ)
Response Time 30ms
Brightness 250 cd/m2(typ)
Panel Surface Anti-Glare
VIDEO INPUT Analog RGB Analog (75 ohms, 0.7/1.0 Vp-p)
Digital DVI-D (TMDS, 100 ohms)
Frequency Fh:30~82kHz, Fv:50~75Hz
Sync H/V separated (TTL), composite, sync on green
COMPATIBILITY PC VGA up to 1280x1024 non-interlaced
Mac®** 640x480, 800x600, 832x624, 1024x768, 1152x870,
1280x1024
CONNECTOR Signal 15-pin mini D-sub and 24-pin DVI-D, detachable cables
Power 12VDC adapter with 3-pin AC plug (CEE22)
POWER Voltage AC 100-240VAC Hz (auto switch) 50-60Hz (+/-3) Hz
Consumption 50W (typ)
CONTROLS Basic Power (soft), 1, down, up, 2
OSD Auto image adjust, contrast, brightness, input select,
color adjust [9300K, 6500K (default), R, G, B],
information [mode, model number, serial number],
manual image adjust [H. size, H. position, V. position,
fine tune, sharpness], setup menu [language, resolution
notice, OSD position, OSD timeout], memory, recall
OPERATING Temperature 32–104°F (0–40°C)
CONDITION Humidity 10–90% (non-condensing)
DIMENSIONS Physical 410mm (W) x 410mm (H) x 167mm (D)
16.1" (W) x 16.1" (H) x 6.6" (D)
WEIGHT Net 6.5 kgs. (14.3 lbs.)
REGULATIONS UL, CSA, DOC-B, CB Report, CE, FCC-B, TUV/Ergo,
ISO13406-2, TUV/GS, SEMKO, DEMKO, FIMKO, NEMKO,
BSMI, VCCI, PSB, PCBC, TUV-S, TCO’99 (VG171), TCO’95
(VG171b), Energy, NOM, C-TICK, GOST-R, PCT (BZ02)
POWER MANAGEMENT Meets TCO and Energy standards
WARRANTY Three-year limited warranty on parts, labor and backlight.
ViewSonic
®
VG171 / VG171b LCD Display
VG171 beige case version.
ViewSonic Corporation’s QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
*Excludes major U.S. holidays. **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete
details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2003, ViewSonic Corporation. All rights reserved. [10280-04B_03/03] VS-2248
•ViewSonic Wizard
This software provides user-friendly installa-
tion. The included CD-ROM automates the
set-up process to deliver optimized screen
performance.
•
•TCO and Energy certified
This monitor complies with the world’s
strictest standards for low radiation,
safety, ergonomics, recycling and
power management.
•Kensington®lock ready
Protect your assets with this attachment
point for an anti-theft cable.
•Three-year limited warranty
•Turn your LCD into
a high-resolution TV
Easily hook up favorite
extras like a DVD, VCR,
or digital camera with the
VB50HRTV TV tuner module.
