VigilLink VLSP-16H20 User manual

VLSP-16H20
1x16 HDMI 2.0 Splitter 18Gbps
VER 1.1

Thank you for purchasing this product
Please read these instructions carefully for optimum performance and safety
before connecting, operating, or adjusting this product. Please keep this
manual for future reference.
A surge protection device is recommended.
This product contains sensitive electrical components that electrical spikes
may damage, surges, electric shocks, lightning strikes, etc. The use of surge
protection systems is highly recommended to protect and extend the life of
your equipment.
Table of Contents
1. Introduction......................................................................................... 1
2. Features............................................................................................... 1
3. Package Contents.............................................................................. 1
4. Specifications. .................................................................................... 2
5. Operation Controls and Functions. ................................................... 3
6. EDID Mode. ......................................................................................... 4
7. Application Example.......................................................................... 5

-1-
1. Introduction
The 18Gbps 1x16 HDMI Splitter can distribute 1 HDMI source signal to 16
HDMI display devices synchronously. Supported video resolution is up to
4K2K@50/60Hz 4:4:4. The product supports advanced EDID management.
It also supports HDR, HDR10, HDR10+, HLG, and Dolby vision functions. This
product is widely used in multimedia conference halls, TV teaching, large-screen
display projects, and other places.
2. Features
☆ HDMI 2.0b, HDCP 2.2 / 1.x and DVI 1.0 compliant
☆ Support 18Gbps video bandwidth
☆ Support video resolution up to 4K2K@50/60Hz 4
: 4 : 4
☆ Support digital audio format: DTS-HD/Dolby-true-HD/LPCM 7.1/DTS/
Dolby-AC3/DSD
☆ Support HDR, HDR10, HDR10+, HLG, and Dolby vision
☆ Advanced EDID management
☆ Compact design for easy and flexible installation
3. Package Contents
① 1× 18Gbps 1×16 HDMI Splitter
② 1× 12V/2.5A DC Locking Power Adapter
③ 1× User Manual

-2-
4. Specifications
Technical
HDMI Compliance HDMI 2.0b
HDCP Compliance
HDCP 2.2/1.x
Video Bandwidth
594MHz/18Gbps
Video Resolution
Up to 4k2k@50/60Hz 4:4:4
Color Depth
8-bit,10-bit,12-bit(1080p@60Hz)
8-bit (4K2K@60Hz YUV4:4:4)
8-bit,10-bit,12-bit (4K2K@60Hz YCbCr 4:2:2/4:2:0)
Color Space
RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2/4:2:0
HDR
Support HDR, HDR10, HDR10+, HLG, Dolby vision
HDMI Audio Formats
PCM2.0/5.1/7.1CH, Dolby 5.1, DTS5.1, Dolby-
TrueHD, DTS-HD
ESD Protection
Human body model—±8kV (Air-gap discharge) &
±4kV (Contact discharge)
Connection
Input
1×HDMI Type A (19-pin female)
Output
16×HDMI Type A (19-pin female
）
Control
Mechanical
Housing
Metal Enclosure
Silkscreen Color
Black
Dimensions
300mm (W) × 100mm (D) × 28mm (H)
Weight
900g
Power Supply
Input: AC100 - 240V 50/60Hz, Output: DC 12V/2.5A
(US/EU standards, CE/FCC/UL certified)
Power Consumption
12W
Operation
Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90% RH (non-condensing)

-3-
1/
5. Operation Controls and Functions
No.
Name
Function Description
1
POWER switch
Press this switch to power on/off the device.
2POWER LED
When the device is powered on, the power LED
will be on.
3IN LED
The green LED will be on when tto he HDMI IN port
connects an active source device.
4OUT LED
(1~16)
When the HDMI OUT port connects to an
active display device, the corresponding
green OUT LED will be on.
5HDMI IN port
HDMI input ports connect to HDMI source devices
such as DVDs or set-top boxes with an HDMI
cable.
6
HDMI OUT
port (1~16)
HDMI output port, connect to the HDMI display
A device such as a TV or Monitor with an HDMI
cable.
7DC 12V
Plug the DC 12V power supply into the unit and
connect the adaptor to an AC outlet.
8EDID DIAL
switch
It is used to set EDID mode. Please refer to
Section “6. EDID Mode” for details.

-4-
9
SERVICE port
Firmware update port.

-5-
6. EDID Mode
The defined EDID setting list of the product is shown below:
EDID Mode
EDID Description
11111
1080P, Stereo Audio 2.0
11110
1080P, Dolby/DTS 5.1
11101
1080P, HD Audio 7.1
11100
1080I, Stereo Audio 2.0
11011
1080I, Dolby/DTS 5.1
11010
1080I, HD Audio 7.1
11001
1080P 3D, Stereo Audio 2.0
11000
1080P 3D, Dolby/DTS 5.1
10111
1080P 3D, HD Audio 7.1
10110
4K2K30Hz_444, Stereo Audio 2.0
10101
4K2K30Hz_444, Dolby/DTS 5.1
10100
4K2K30Hz_444, HD Audio 7.1
10011
4K2K60Hz_420, Stereo Audio 2.0
10010
4K2K60Hz_420, Dolby/DTS 5.1
10001
4K2K60Hz_420, HD Audio 7.1
10000
4K2K60Hz_444, Stereo Audio 2.0
01111
4K2K60Hz_444, Dolby/DTS 5.1
01110
4K2K60Hz_444, HD Audio 7.1
01101
4K2K60Hz_444, Stereo Audio 2.0 HDR
01100
4K2K60Hz_444, Dolby/DTS 5.1 HDR
01011
4K2K60Hz_444, HD Audio 7.1HDR
01010
copy output 1
01001
1080P, Stereo Audio 2.0
01000
1080P, Stereo Audio 2.0
00111
1080P, Stereo Audio 2.0
00110
1080P, Stereo Audio 2.0
00101
1080P, Stereo Audio 2.0
00100
1080P, Stereo Audio 2.0
00011
1080P, Stereo Audio 2.0
00010
1080P, Stereo Audio 2.0
00001
1080P, Stereo Audio 2.0
00000
PC control mode

-6-
7. Application Example
