VigilLink VLUC-USB22K User manual

VLUC-USB22K
1080p HDMI to USB2.0 Video Capture
Ver 1.02

Thank you for purchasing this product
Please read these instructions carefully for
optimum performance and safety before connecting,
operating, or adjusting this product. Please keep this
manual forfuture reference.
Surge protection device recommended
This product contains sensitive electrical components
that electrical spikes may damage, surges, electric
shock, lightning strikes, etc. The use of surge
protection systems is highly recommended to
protect and extend the life of your equipment.
Table of Contents
1. Introduction .................................................................. 1
2. Features ........................................................................ 1
3. Operation Controls and Functions ............................. 2
4. Specifications............................................................... 2
5. Package Contents....................................................... 4
6. Software instruction ..................................................... 4
7. Application Example................................................... 9

1/9
1. Introduction
This HDMI to USB2.0 video capture can collect
HDMI audio & video input signals. The captured
video resolution is up to 4K2K@30Hz, and the
output resolution is up to 1080P@60Hz. The product
has the advantages of high performance, high
compatibility, and manageable carrying and
installation. It is compatible with Windows, Linux,
Mac OS X operating system, USB2.0 port, plug and
play, and easy to use.
2. Features
☆HDMI 1.4 and HDCP 1.4 compliant
☆Supports 10.2Gbps video bandwidth
☆The captured video resolution is up to
4K2K@30Hz, and the output resolution is up
to 1080P@60Hz
☆Be compatible with Windows, Linux, Mac
OS X operating system, and USB2.0 port
☆Supports automatic recognition of input
video format

2/9
3. Operation Controls and Functions
①USB port: USB signal output port, connect to the USB
port of a PC directly.
②STATUS LED: Red LED is always on when the
capture is related to active HDMI IN signal source,
flashes slowly when not connected, about 1 second
once.
③HDMI IN port: HDMI signal input port, connect to
HDMI source device such as DVD with HDMI cable.
4. Specifications
Technical
HDMI Compliance
HDMI 1.4
HDCP Compliance
HDCP 1.4
Video Bandwidth
10.2 Gbps
Video Resolution
Input: Up to 4k2k@30Hz; Output:
Up to 1080P@60Hz
Color Depth
8/10/12-bit (1080P@60Hz); 8-bit
(4K2K@30Hz YUV4:4:4)
Color Space
RGB, YCbCr 4:4:4/4:2:2, YUV
4:2:0
HDMI Audio Formats
LPCM2.0
USB Version
USB 2.0
ESD Protection
Human body model —
±8kV (Air
-gap discharge) & ±4kV
(Contact discharge)

3/9
Connection
Input
1x HDMI [Type A 19-pin female]
Output
1x USB [Type A male]
Mechanical
Housing
Plastic Enclosure
Color
Black
Dimensions
51mm[W] x 31mm[D] x 13mm[H]
Weight
16g
Power Supply
PC USB 5V
Power Consumption
1.75W
Operating
Temperature 32 - 104°F / 0 - 40°C
Storage Temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no condensation)

4/9
5. Package Contents
①1×HDMI Capture
②1×User Manual
6. Software instruction
Take OBS (Open Broadcaster Software) software,
windows10 system as an example. The specific
operation is as below:
Step 1: Install the “OBS” application software on the
computer.
Step 2: Double-click the “OBS Studio” shortcut to
open the application.
Step 3: Click the “+,” you can see a drop-down menu
and select “Video Capture Device,” and then click the
“OK” button.
Step 4: Select “Mini FHD Capture” in the Device

5/9
option box, then check “Use a custom audio device”
under Audio Output Mode and select “USB Digital
Audio” for Audio Device. Then click the “OK” button.
Step 5: Click “Settings” to open the Settings page,
then select the “Output” option. On this page, you can
choose a recording path for video capture, set
recording quality, format, etc. Then click the “Apply”
button and the “OK” button.

6/9

7/9
Step 6: On the Settings page, you can select the
“Audio” option. On this page, you need to set “Sample
Rate” and select “USB Digital Audio” for the
“Mic/Auxiliary Audio.” Then click the “Apply” button and
the “OK” button.
Step 7: You can select the “Video” option on the
Settings page. You can select “Base Resolution” and
“Output Resolution” on this page. Then click the
“Apply” button and the “OK” button.

8/9
Step 8: Use the mouse to click the Setting icon, then
select the “Advanced Audio Properties” option. And
choose the “Monitor and Output” option on the
Advanced Audio Properties page. Then click the
“Close” button.
Step 9: When you have finished all settings, you can
click the “Start Recording” button to start video
capture. If it has finished, click this button again to stop
video capture.
Step 10: You can click the “Exit” button to close the
software when the video capture is finished.
Note: The software instruction is only about video
capture settings at the above content. You can
browse other related settings functions.

9/9
7. Application Example
HDMI and HDMI High-Definition Multimedia interface and the
HDMI Logo are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
