VIG610M
Motherboard
Manual

V1.0 VIG610M Motherboard Manual 1
Viglen, EMC and the ‘CE’ mark
CE Marking
European standards are being harmonised across borders. If products comply with the same standards in all
European countries, product exporting and importing is made simple - paving our way to a common market. If
you buy a product with a 'CE' mark on it (shown below), on the box, in the manual, or on the guarantee - it
complies with the currently enforced directive(s).
Introduction to EMC
EMC (Electromagnetic Compatibility) is the term used to describe certain issues with RF (Radio Frequency)
energy. Electrical items should be designed so they do not interfere with each other through RF emissions. E.g.
If you turn on your microwave, your television shouldn't display interference if both items are CE marked to the
EMC directive.
If emitted RF energy is not kept low, it can interfere with other electrical circuitry - E.g. Cars Automatic Braking
Systems have been known to activate by themselves while in a strong RF field. As this has obvious
repercussions ALL electrical products likely to cause RF related problems have to be 'CE' marked from 1st
January 1996 onwards.
If a product conforms to the EMC directive, not only should its RF emissions be very low, but its immunity to RF
energy (and other types) should be high. The apparatus has to resist many 'real world' phenomena such as
static shocks and mains voltage transients.
Viglen’s Environment laboratory
To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is
Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters.
We have made every effort to guarantee that each computer leaving our factory complies fully with the correct
standards. To ensure the computer system maintains compliance throughout its functional life, it is essential you
follow these guidelines.
Install the system according to Viglen’s instructions
If you open up your Viglen:
Keep internal cabling in place as supplied.
Ensure the lid is tightly secured afterwards
Do not remove drive bay shields unless installing a 'CE' marked peripheral in its place
The clips or ‘bumps' around the lips of the case increase conductivity - do not remove or damage.
Do not remove the ferrite ring from the L.E.D cables.
Only use your Viglen computer with 'CE' marked peripherals
This system has been tested in accordance with European standards for use in residential and light industrial
areas-this specifies a 10 meter testing radius for emissions and immunity. If you do experience any adverse
affects which you think might be related to your computer, try moving it at least 10 meters away from the affected
item. If you still experience problems, contact Viglen’s Technical Support department who will put you straight
through to an EMC engineer - s/he will do everything possible to help. If modifications are made to your Viglen
computer system, it might breach EMC regulations. Viglen take no responsibility (with regards to EMC
characteristics) of equipment which has been tampered with or modified.
This symbol on the product or on its packaging indicates that the product shall not be treated as
household waste. Instead it shall be handed over to the applicable collection point for recycling of
electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The recycling of materials will
help to conserve natural resources. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or Viglen Ltd.

V1.0 VIG610M Motherboard Manual 2
Copyrights and Trademarks
Please note
The material in this manual is subject to change without notice.
Trademarks
Microsoft, Windows, Windows NT, Windows 95,Windows 98, Windows ME,
Windows 2000 Pro, Windows XP Pro, Windows Vista and MS-DOS are registered
trademarks of Microsoft Corporation. IBM PC, XT, AT and PS/2 are trademarks of
International Business Machines Corporation. Pentium® and Pentium® Pro are
registered trademarks of Intel® Corporation. All other trademarks are acknowledged.
JAC-UP, Genie, Contender, Dossier, Vig, Viglen, and Envy are trademarks of Viglen
Limited.
Copyright and Patents
This manual and all accompanying software and documentation are copyrighted and
all rights reserved. This product, including software and documentation, may not, in
whole or in part, be copied, photocopied, translated or reduced to any electronic or
machine-readable form, without prior written consent except for copies retained by
the purchaser for backup.
© Copyright 2004 Viglen Limited
All Rights Reserved
VIG610M Manual Version 1.0
Printed in the United Kingdom
Liability
No warranty or representation, either expressed or implied, is made with respect to
this documentation, its quality, performance, merchantability or fitness for a particular
purpose. As a result the documentation is licensed as is, and you, the licensee, are
assuming the entire risk as to its quality and performance. The vendor reserves the
right to revise this operation manual and all accompanying software and
documentation and to make changes in the content without obligation to notify any
person or organisation of the revision or change.
In no event will the vendor be liable for direct, indirect, special, incidental or
consequential damages arising out of the use or inability to use this product or
documentation, even if advised of the possibility of such damages. In particular, the
vendor shall not have liability for any hardware, software or data stored or used with
the product, including the costs of repairing, replacing or recovering such hardware,
software or data.

V1.0 VIG610M Motherboard Manual 3
Contents
Chapter 1: Motherboard Overview 5
Introduction 5
Feature Summary 6
System Board Components 13
Overview of System Board Components 14
Back Panel Connectors 16
Chapter 2: System Board Options 18
Overview of Jumper Settings 20
System Board Jumper Settings 21
Motherboard Connectors 22
Front Panel Connectors 22
Upgrading the CPU 29
Installing & Removing Memory Modules 32
Expansion Slots (PCI & PCI Express) 34
Replacing the Clock/CMOS RAM Battery 35
Chapter 3: Solving Problems 36
Resetting the System 36
Troubleshooting Procedures 37
Problems Operating Add-in Boards 38
Problems & Suggestions 39
Chapter 4: System BIOS 41
What is the BIOS? 41
The Power-On Sequence 41
BIOS Upgrades 42
Using AWDFLASH to Update the BIOS 42
Configuring the Motherboard using BIOS Setup 44
Main BIOS Menu Screen 47
Standard CMOS features 49
IDE Primary/Secondary Master/Slave 50
Advanced BIOS features 51
Integrated Peripherals 54
Power Management Setup 56
H/W Monitor 58

V1.0 VIG610M Motherboard Manual 4
Cell Menu 59
Main Menu Additional Options 62
Chapter 5: Technical Information 63
Enhanced IDE 63
Operating Systems and Hard Drives 64
Power Supply Connector 65
Other Useful Connectors 65
Other Information 69
Reliability 69
Temperature 69
Chapter 6: Glossary 70
Notes 72
Chapter 7: Suggestions 73

V1.0 VIG610M Motherboard Manual 5
Chapter 1: Motherboard Overview
Introduction
This manual describes the Viglen Vig610m motherboard inside your computer. The
motherboard is the most important part of your computer. It contains all of the CPU,
memory and graphics circuitry that make the computer work.
The motherboard contains the very latest CPU design that supports the Intel® Core®
2 Quad and Core 2 Duo family. All of the supported CPU’s include Intel’s® MMX
Technology. MMX technology adds a total of 57 new instructions to the CPU, all of
which are designed to vastly improve both multimedia and communications on your
PC. The combination of the Intel® processor, MMX technology and Viglen expertise
make this a formidable computer.
This manual contains technical information about the Viglen Vig610m motherboard
and other hardware components inside your computer. If you are new to computers
we recommend that you read the user guide first. If you are an experienced
computer user this manual should provide all the information you will need to
perform simple upgrades and maintenance.
We hope that this manual is both readable and informative. If you have any
comments for suggestions about how we could improve the format then please fill
out the form at the back of the manual and send it to us.
Above all we hope that you enjoy using your Viglen computer.

V1.0 VIG610M Motherboard Manual 6
Feature Summary
The Vig610m is based on the Intel® G31 & ICH7/ICH7R chipsets for optimal system
efficiency. Designed to fit the advanced Intel® Core 2 Duo/Quad/Pentium/Celeron
LGA775 processor, the Vig610m delivers a high performance and professional
desktop platform solution.
The motherboard features:
Form factor:
Micro ATX Form Factor: 244mm by 218mm
Processor:
Intel® Core2 Quad/Core 2 Duo/Pentium Dual-Core E2XXX and Celeron 400
Socket 775 connector.
Supports 4 pin CPU fan pin-header with fan speed control
Supports Intel® Hyper-Threading Technology
Main memory:
Two 240 pin DDR2 DIMM sockets.
Supports memory speeds 667/800 MHz
Support for up to 4GB of DDR2 DIMM memory.
Chipset
Intel G31
Supports 800/1066/1333 MHz Front Side Bus (FSB)
Advanced System Power Management features
Integrated Super I/O Controller
Audio
Realtek ALC888 HD (High Definition) Audio compatible audio subsystem
Flexible 8-channel audio with jack sensing
LAN
Realtek RTL8111C 10/100/1000Mb/s Mbit/sec Platform LAN Connect (PLC)
device.
Compliance with PCI 2.2
Supports ACPI Power Management

V1.0 VIG610M Motherboard Manual 7
Rear Panel Port Support
1x PS/2 mouse port
1x PS/2 keyboard port
1x serial port (COM1)
1x VGA port
1x parallel port supporting SPP/EPP/ECP mode
4x USB 2.0 Ports
1x RJ-45 LAN Jack
3 flexible audio jacks
Internal Connectors
2x USB 2.0 pin headers
1x CD-in pin header
1x SPDIF-out pin header
1x Front panel audio pin header
1x serial port pin header
1x TPM module pin header
1x Chassis intrusion switch pin header
Expansion Capabilities
One PCI Express x16 slot
One PCI Express x1 slot
Two PCI bus add-in card connectors
Instantly Available PC
Suspend to RAM support
Wake on PS/2 keyboard, Mouse and USB ports

V1.0 VIG610M Motherboard Manual 8
Microprocessor
The motherboard supports the latest powerful and energy efficient processors from
Intel. These include Intel’s Core 2 Duo and Core 2 Quad processors in the LGA775
package. With the new Intel Core microarchitecture technology and 1333/1066/800
MHz FSB, users are able to step up to new levels o gaming experience and multi-
tasking performance.
Memory
Main Memory
The motherboard has two DDR2 DIMM sockets. Minimum memory size is 512MB;
maximum memory size is 4GB. The BIOS automatically detects memory type, size,
and speed.
The motherboard supports the following memory features:
240-pin DIMMs.
667/800 MHz
Supports memory bandwidths of up to 12.8 GB/s
Un-Buffered Non-ECC DIMM.
Chipset
The Intel® G31 chipset boosts your gaming and multimedia experience with
integrated graphic engine Intel Graphics Media Accelerator 3100. It supports
1066/800 MHz front side bus (FSB), and delivers breakthrough advances in 3D and
2D graphics, and video capabilities. This integrated chipset contains one 16-lane PCI
Express port intended for an external PCI Express graphics card and provides the
interface for the processor in the 775-land package, and the dual channel DDR2
memory at speeds up to 800MHz.
Realtek 8111C Platform LAN Connect Device
The Realtek 8111C component provides an interface to the back panel RJ-45
connector with integrated LEDs. This physical interface may alternately be provided
via the CNR connector.
The Realtek 8111C provides the following functions:
10/100/1000 Ethernet LAN Connectivity
Supports RJ-45 connector with status indicator LEDs
Full driver compatibility
ACPI Power Management
Programmable transit threshold
Configuration EEPROM that contains the MAC address

V1.0 VIG610M Motherboard Manual 9
RJ-45 LAN Connector LEDs
Two LEDs are built into the RJ-45 LAN connector. The following table describes the
LED states when the board is powered up and the LAN subsystem is operating.
Table 1: LAN LED Status
Universal Serial Bus (USB)
The motherboard has four USB ports and a further five can be added via internal
headers; one USB peripheral can be connected to each port. For more than nine
USB devices, an external hub can be connected to either port. The motherboard
fully supports the universal host controller interface (UHCI) and uses UHCI-
compatible software drivers.
USB features include:
Self-identifying peripherals that can be plugged in while the computer is
running.
Automatic mapping of function to driver and configuration.
Supports isochronous and asynchronous transfer types over the same set of
wires.
Supports up to 127 physical devices.
Guaranteed bandwidth and low latencies appropriate for telephony, audio,
and other applications.
Error-handling and fault-recovery mechanisms built into the protocol.
NOTE: Computer systems that have an unshielded cable attached to a USB port
may not meet FCC Class B requirements, even if no device or a low-speed (sub-
channel) USB device is attached to the cable. Use shielded cable that meets the
requirements for high-speed (fully rated) devices.
IDE Support
The motherboard has one independent bus-mastering PCI IDE interfaces. These
interfaces support PIO Mode 3, PIO Mode 4, ATAPI devices (e.g., CD-ROM), Ultra
DMA/66 & Ultra DMA/100 synchronous-DMA mode transfers. The BIOS supports
logical block addressing (LBA) and extended cylinder head sector (ECHS)
translation modes. The BIOS automatically detects the IDE device transfer rate and
translation mode.
Programmed I/O operations usually require a substantial amount of processor
bandwidth. However, in multitasking operating systems, the bandwidth freed by bus
mastering IDE can be devoted to other tasks while disk transfers are occurring.

V1.0 VIG610M Motherboard Manual 10
LS-120 Support
LS-120 MB Diskette technology enables you to store 120MB of data on a single, 3.5”
removable diskette. LS-120 technology is backward (both read and write) compatible
with 1.44MB and 720KB DOS-formatted diskette and is supported by Windows 95
and Windows NT operating system.
The Vig610m board allows connection of an LS-120 compatible drive and a standard
3½” floppy drive. The LS-120 drive can be configured as a boot device before a
floppy drive, if selected in the BIOS setup utility.
NOTE:If you connect an LS-120 drive to an IDE connector and configure it as the
“A” drive and configure a standard 3.5” floppy as “B” drive, the standard floppy must
be connected to the floppy drive cable’s “A” connector (the connector at the end of
the cable).
The BIOS setup utility can be configured to boot firstly from either the LS120 or
standard 3½” floppy drive.
Real-Time Clock, CMOS SRAM, and Battery
The real-time clock is compatible with DS1287 and MC146818 components. The
clock provides a time-of-day clock and a multi-century calendar with alarm features
and century rollover. The real-time clock supports 256 bytes of battery-backed
CMOS SRAM in two banks that are reserved for BIOS use.
The time, date, and CMOS values can be specified in the Setup program. The
CMOS values can be returned to their defaults by using the Setup program.
An external coin-cell (CR 2032) battery powers the real-time clock and CMOS
memory. When the computer is not plugged into a wall socket, the battery has an
estimated life of three years. When the computer is plugged in, the 3.3-V standby
current from the power supply extends the life of the battery. The clock is accurate
to 13 minutes/year at 25 ºC with 3.3 V applied.
I/O Interface Controller
The motherboard uses the I/O controller which features:
Serial ports:
oInternal send/receive 16-byte FIFO buffer.
oFour internal 8-bit DMA options for the UART with SIR support (USI).
Multimode bidirectional parallel port:
oStandard mode, IBM and Centronics compatible.
oEnhanced parallel port (EPP) mode with BIOS and driver support.
oHigh-speed extended capabilities port (ECP) mode.
Floppy disk controller:
oN82077 compatible.
oSingle diskette drive interface.
o16-byte FIFO.
oHigh-performance digital data separator (DDS).
oPC-AT and PS/2 drive-mode support.

V1.0 VIG610M Motherboard Manual 11
Keyboard and mouse controller:
oIndustry standard 8042A compatible.
oGeneral-purpose microcontroller.
o8-bit internal data bus.
ISA Plug-and-Play compatible register set.
PCI PME interface.
Intelligent auto power management:
oShadowed write-only registers for ACPI compliance.
oProgrammable wake up event interface.
By default, the I/O controller interfaces are automatically configured during boot up.
The I/O controller can also be manually configured in the Setup program.
Serial Ports
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.
Parallel Port
The connector for the multimode bidirectional parallel port is a 25-pin D-Sub
connector located on the back panel. In the Setup program, the parallel port can be
configured for the following:
Compatible (standard mode).
Bidirectional (PS/2 compatible).
Extended Parallel Port (EPP).
Enhanced Capabilities Port (ECP).
Floppy Controller
The I/O controller is software compatible with the N82077 floppy drive controllers
and supports both PC-AT and PS/2 modes. In the Setup program, the floppy
interface can be configured for the following floppy drive capacities and sizes:
360 KB, 5.25-inch
1.2 MB, 5.25-inch
720 KB, 3.5-inch
1.44MB, 3.5 inch
1.2 MB, 3.5-inch (driver required)
2.88 MB, 3.5-inch

V1.0 VIG610M Motherboard Manual 12
PS/2 Keyboard and Mouse Interface
PS/2 keyboard and mouse connectors are located on the back panel. The +5 V lines
to these connectors are protected with a PolySwitch circuit that, like a self-healing
fuse, re-establishes the connection after an over-current condition is removed.
The keyboard controller supports the hot-key sequence <Ctrl><Alt><Del> for a
software reset. This key sequence resets the computer’s software by jumping to the
beginning of the BIOS code and running the Power-On Self Test (POST).
Audio Subsystem
These audio connectors are used for audio devices. You can differentiate the colour
of the audio jacks for different audio sound effects.
Line-In / RS-Out (Blue) - Line In is used for external CD player, tape player or
other audio devices. Rear-Surround Out in 4/ 5.1 channel mode.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic / CS-Out (Pink) - Mic, is a connector for microphones. Center/
Subwoofer Out in 5.1 channel mode.
Management Extension Component
System BIOS
The system BIOS, from Phoenix Technology, provides ISA and PCI compatibility.
The BIOS is contained in a flash memory device on the system board. The BIOS
provides the power-on self test (POST), the system Set-up program, a PCI and IDE
auto-configuration utility, and BIOS recovery code.
PCI Auto Configuration
The PCI auto-configuration utility works in conjunction with the Set-up program to
support using PCI add-in boards in the system. When you turn on the system power
after installing a PCI board, the BIOS automatically configures interrupts, DMA
channels, I/O space, and so on. Since PCI add-in boards use the same interrupt
resources as ISA add-in boards, you must specify the interrupts used by ISA boards
in the set-up program. The PCI auto-configuration program complies with version 2.1
of the PCI BIOS specification.
IDE Auto Configuration
If you install an IDE drive in the system, the IDE auto-configuration utility
automatically detects and configures the drive for operation in the system. This
utility eliminates the need to enter the Set-up program after you install an IDE drive.
Expansion Slots
The system has two PCI bus add-in card connectors, One PCI Express x16
connector and one PCI Express x1 connector.

V1.0 VIG610M Motherboard Manual 13
System Board Components
Figure 1: Motherboard Layout & Components

V1.0 VIG610M Motherboard Manual 14
Table 2: Motherboard Connection
A: Rear System Fan M: Front Panel Connector 2 (Reset
Switch, HDDLED, Power LED, Power
Switch)
B: TPM Module connector N: USB headers
C: ATX 12V Power Connector O: Clear CMOS Jumper
D: LGA 775 CPU Socket P: Floppy Disk Drive Connector
E: S/PDIF-Out Connector Q: Serial Port Connector
F: CPU Fan Connector R: Front Panel Audio Connector
G: Memory DIMM Slots S: CD-In Connector
H: ATX 24-Pin Power Connector T: PCI Slot 32-bit
I: IDE Connector U: Chassis Intrusion Connector
J: Front System Fan Header V: PCI Express x1 and x16 Slot
K: Front Panel Connector 1 (Speaker,
Power LED) W: Rear I/O Connectors
L: Serial ATA Connectors
Overview of System Board Components
A – System Fan1
This is used to keep the Motherboard components and other components cool.
B – TPM Module Connector
This connector connects to a TPM (Trusted Platform Module) module.
C – ATX 12V Power Connector
This 12V power connector is used to provide power to the CPU
D – LGA775 pin CPU socket
CPU sits in the LGA775 pin socket.
E – S/PDIF-Out Connector
This connector is used to connect S/PDIF (Sony & Phillips digital Interconnect
Format) interface for digital transmission.
F – CPU Fan Header
Fan header dedicated purely for the Heatsink to cool the CPU.
G – 2 x DIMM Slots
Insert Memory modules 400/533/667 MHz.
H – ATX 24 pin Power Connector
This is the main power connector for the motherboard.
I – IDE Connector
This can be used to connect an IDE Hard Disk Drive or even a CD-ROM drive.
J – Front System Fan header
This is used to keep the Motherboard components and other components cool.
K – Front Panel Connector 1
Controls the Hard Disk Drive LED, Power Switch, Reset Switch and Power LED

V1.0 VIG610M Motherboard Manual 15
L – Serial ATA II Connectors
Can connect up to 4 SATA devices (Hard Disk Drive, CD-ROM)
M – Front Panel Connector 2
Controls the Speaker and Power LED
N – USB header
Allows up to 2 USB devices to be connected to each USB header
O – Clear CMOS jumper
This allows you to clear the CMOS of the Motherboard when moving the jumper from
pins 1-2 to 2-3.
P – Floppy Connector
This connector allows you to connect a floppy drive to the chassis.
Q – Serial Port Connector
This connector allows you to connect a serial device to the chassis
R – Front Panel Audio Connector
This header supports HD Audio which allows the Motherboard to support front panel
Audio.
S – CD-In Connector
This connector is provided for external audio input.
T– PCI Slot 32bit
The PCI slots support LAN cards, USB cards and other add-on cards that comply
with PCI specifications.
U – Chassis Intrusion
Notifies before entering OS that the Chassis panel may have been tampered with.
K and L – USB header
Allows up to 2 USB devices to be connected to each USB header
V – PCI Express x1 and x16 Slot
The PCI Express x1 supports up to 250 MB/s transfer rate. The PCI Express x16
supports up to 4.0 GB/s transfer rate.
V- Rear I/O Connector
Consists of multiple components to connect i.e. VGA, PS/2 Keyboard and Mouse.

V1.0 VIG610M Motherboard Manual 16
Back Panel Connectors
The motherboard external IO connectors are attached to a metallic I/O shield. This
shield serves several purposes:
It protects the sensitive motherboard from any external EMC interference.
It stops the computer from interfering with other electrical devices.
It allows the motherboard to be easily upgraded in the future without having to
resort to buying a whole new case. Simply change the I/O shield to match the
motherboard.
The I/O shield provides external access to PS/2 keyboard and mouse connectors as
well as one serial port, one parallel port, four USB ports, one LAN Port and the audio
connectors.
Figure 2: Back Panel Connectors
NOTE: Power to the computer should be turned off before a keyboard or mouse is
connected or disconnected.
The I/O shield provides external access to the following:
1. 1x PS/2 Keyboard
This port is for a PS/2 Keyboard
2. 1x PS/2 Mouse
This port is for a PS/2 Mouse
3. 1x Serial port
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.
4. 1x parallel port
A parallel port is a standard printer port that supports Enhanced Parallel Port (EPP)
and Extended Capabilities Parallel Port (ECP) mode.

V1.0 VIG610M Motherboard Manual 17
5. 4x USB ports
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard,
mouse, or other USB-compatible devices.
6. 1x LAN port
The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN).
You can connect a network cable to it.
Figure 3: LAN Port indicators locations
Table 4: LAN Port indicators meanings
7. 3x Audio connectors.
These audio connectors are used for audio devices. You can differentiate the colour
of the audio jacks for different audio sound effects.
Line-In (Blue) - Line In is used for external CD player, tape player or other
audio devices.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic (Pink) - Mic, is a connector for microphones.
This Mic (pink) jack connects a microphone. In 6-channel mode, the function of this
jack becomes Rear Speaker Out.
NOTE: The functions of the Line Out, Line In, and Microphone jacks change when
you select the 6-channel audio configuration.
Table 5: Audio 2, 4 or 6-channel configuration
Headphone/2
-
Speaker
4
-
Speaker
6
-
Speaker
Light Blue
Line In Rear Speaker Out Rear Speaker Out
Lime
Line Out Front Speaker Out Front Speaker Out
Pink
Mic In Mic In Bass/Center

V1.0 VIG610M Motherboard Manual 18
Chapter 2: System Board Options
The VIG610MM motherboard is capable of accepting Intel® Core2 Quad and Core 2
Duo CPU’s. RAM can be upgraded to a maximum of 4GB using DDR2 667 and
800MHz RAM DIMMs Non ECC Unbuffered memory.
WARNING!
Unplug the system before carrying out the procedures described in this
chapter. Failure to disconnect power before you open the system can result
in personal injury or equipment damage. Hazardous voltage, current, and
energy levels are present in this product. Power switch terminals can have
hazardous Voltages present even when the power switch is off.
The procedures assume familiarity with the general terminology associated
with personal computers and with the safety practices and regulatory
compliance required for using and modifying electronic equipment.
Do not operate the system with the cover removed. Always replace the cover
before turning on the system.
As the colours of the wires in the mains lead of this computer may not correspond with the
coloured markings identifying the terminals in your plug precede as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug
which is marked by the letter Eor by the safety Earth symbol Qor coloured green or
green-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with
the letter Nor coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with
the letter Lor coloured red.
CAUTION!
The Viglen VIG610MM
motherboard
and associated components are
sensitive electronic devices. A small
static shock from your body can
cause expensive damage to your
equipment.

V1.0 VIG610M Motherboard Manual 19
Make sure you are earthed and free of static charge before you open the computer
case. If you are unsure about upgrading your computer, return it to Viglen so a
qualified engineer can perform the upgrade.
STEPS TO TAKE TO PREVENT STATIC DISCHARGE:
1. The best way to prevent static discharge is to buy an anti-static strap from your
local electrical shop. While you are wearing the strap and it is earthed, static
charge will be harmlessly bled to ground.
2. Do not remove the component from its anti-static protective packaging until you
are about to install it.
3. Hold boards by the edges - try not to touch components / interface strips etc.
NOTE: We recommend that you return your computer to the service department for
upgrading. Any work carried out is fully guaranteed. Upgrades should only be carried
out by persons who are familiar with handling IC's, as incorrect installation will
invalidate the guarantee.
