Viking Electronics PA-IP User manual

PA-IP
SIP Multicast Paging
Adapter with Amplifier
August 28, 2018
1.0 Out-of-Box
1.1 Verify that you have received all of the parts listed
PA-IP Paging Adapter
Qty: 1
8-position terminal block
Qty: 1
QUICK START GUIDE
VIKING Electronics, Inc.
KSee Product Manual for complete installation and programming instructions.
1.3 Download and install the programming software
1. Go to www.vikingelectronics.com and enter PA-IP in the search box
2. Click PA-IP in the search results
3. Scroll down the page to Downloads, click IP Programming Software
4. Install the programming software by saving or opening the file and then clicking on
setup Viking IP Programming.exe
5. Follow the prompts on your screen to complete software installation
2.0 Power Source
• Make sure the port is not in trunk mode
• Make sure port is capable of 100mbps full duplex
• Disable Spanning Tree Protocol (STP) or enable Portfast
Select PoE Switch or PoE Injector that meets the following requirements:
1. IEEE 802.3af / 802.3at / 802.3bu compliant
2. Capable of providing at least 13 Watts (class 0 or class 3)
Note: CAT5e (or higher) cable recommended
3.0 Network Port Settings
1.2 Download the product manual
1. Go to www.vikingelectronics.com and
enter PA-IP in the search box
2. Click PA-IP in the search results
3. Click Product Manual to open and
download the PDF
- OR -
Scan the QR code to
open and download
the product manual

4.0 Features Overview
Due to the dynamic nature of the product design, the information contained in this document is subject to change without notice. Viking Electronics, and its affiliates and/or subsidiaries
assume no responsibility for errors and omissions contained in this information. Revisions of this document or new editions of it may be issued to incorporate such changes.
See the Product Manual for complete installation and programming instructions.
Questions? Call Viking Product Support: 715-386-8666
PA-IP Quick Start Guide ZF303995 REV A
Switch or Contact Input: To manually trigger Night Ring
Relay Output Contact (2A@30VDC / 250VAC max):
Connect to trigger input of amplifier, etc.
MAC Address Label:
The MAC address is a unique 12 digit
number used by network equipment to send
data packets to the correct IP address.
PoE LAN Port 10/100, PoE Class 3 (<13 Watts):
Connect to your LAN via RJ45 plug and CAT5 or
greater twisted pair wire.
Yellow Network Status LED: Lights steady to indicate
power and data link. Blinks to indicate network activity.
Green Unit Status LED
VIKING©
VIKING
ELECTRONICS
HUDSON, WI 54016
60 WATT 2 ZONE
POWER AMPLIFIER
PWR 60 W
+/ 24 VDC
MODEL PA-60
SPKRS
PWR
LED
SPKRS LINE LEVEL AUDIO INPUT
GAIN GAIN
70V OUT
SPKRS SPKRS LINE LEVEL AUDIO INPUT
70V OUT
CHANNEL 2CHANNEL 1
2315 7101112
46 89
Up to (15)
8 Ohm Speakers
(30AE shown,
not included)
Up to (15)
8 Ohm Speakers
(35AE shown,
not included)
Up to (15)
8 Ohm Speakers
(40AE shown,
not included)
Line Out
600 Ohm
Paging
Audio
Optional Paging Amplifier
Viking model PA-60 shown (DOD 493)
Bottom View
VIKING
Model: xxxxxx
Viking Electronics, Inc. [phone]
1531 Industrial St., Hudson, WI 54016
www.vikingelectronics.com DOD#
S/N: XXXXXXXX
P/N: DEV:
xxxxxxxx
MAC: 18E80FXXXXXX
asdesaxtff
Speaker Out
30AE 25AE
35AE
Up tp (6) Optional Viking Analog Speakers,
see DOD 497 and 498 (not Included)
+
_
300AE
40AE
Up to (15)
8 Ohm Speakers
(25AE shown,
not included)
40AE
Red Page / Status LED
