Viking D3 Series User manual

Surface Operation
Burner Control Knobs
Push in and turn the control
knob left to the desired setting.
The element will adjust the
power output to maintain the
desired heat setting. When finished turn all controls
to “OFF”.
Operating Single Elements
All burners have variable controls. Turn the knob
counter-clockwise one click left to achieve the lowest
setting. Continue turning clockwise through the Med
to Med-Hi Settings. The final setting once you have
turned the knob counter-clockwise to its max is the
Hi setting.
Operating Double Elements
All burners have variable controls. Turn the knob
counter-clockwise one click left to achieve the highest
setting for the center element. Continue turning
clockwise through the Med-Hi, Med, and down to
the Lo setting.
Continuing to turn counter-clockwise will bring you
into the Lo setting with both elements now activated.
From here, continue turning counter-clockwise to
activate the Lo-Med, Med, and Med-Hi settings of
both elements. The final setting once you have turned
the knob counter-clockwise to its max is the Hi setting
with both elements activated.
Operating Triple Elements
All burners have variable controls. Turn the knob
counter-clockwise one click left to achieve the highest
setting for the center single element.
Continue turning counter-clockwise through the Med-
Hi, Med, and down to the Lo setting. Continuing to
turn counter-clockwise will bring you into the Hi
setting for the two inner elements combined. From
here, continue turning counter-clockwise to go into
the Med-Hi, Med, Lo-Med, and into the Lo settings of
both elements.
Finally,continuing to turn counter-clockwise will bring
you into the Hi setting for all three elements
combined. Continue turning counterclockwise
to turn the elements down into the Med-Hi, Med, Lo-
Med and into the Lo setting.
Surface Heat Settings
Note: The above information is given as a guide only.
You may need to vary the heat settings to suit your
personal requirements.
Surface Indicator Lights
The surface indicator lights are located at the front
of the glass cooktop. The hot surface indicator light
will glow red when the corresponding element is
heated. The light will remain on after turning off the
control knob until the corresponding element has
cooled to a safe temperature.
Heat
Setting Use
Simmer
Melting small quantities
Steaming rice
Simmering sauces
Low
Melting large quantities
Med Low
Low-temperature frying (eggs, etc.)
Simmering large quantities
Heating milk, cream sauces, gravies,
and puddings
Med
Sautéing and browning, braising,
and pan-frying
Maintaining slow boil on large quantities
Med High
High-temperature frying
Pan broiling
Maintaining fast boil on large quantities
High
Boiling water quickly
Deep-fat frying in large cookware
8 9 10
7
6
5
1 2 3 4
7 8
6
5
4
1 2 3
78
6
5
4
1 2 3
CAUTION
Using cast iron cookware on the glass cooktop is
not recommended. Cast iron retains heat and
may res lt in cooktop damage.
Before Using Cooktop
Heating Elements and Glass Ceramic
Cooking Surfaces
•S urface areas on or adjacent to the unit may be hot
enough to cause burns.
•NEVER touch the glass surface areas directly on or
adjacent to the heating elements when the cooktop is
in use.
•Heating elements may be hot even though they are
dark in color. Areas near elements and interior
surfaces of an oven may become hot enough to cause
burns.
• During and after use, DO NOT touch or let clothing or
other flammable material contact surface of cooktop
or areas near heating elements until they have had
sufficient time to cool.
• DO NOT COOK ON BROKEN COOKING SURFACE
If cooking surface should break, cleaning solutions and
spillovers may penetrate the broken cooking surface
and create a risk of electric shock. Contact a qualified
technician immediately.
Ceramic Glass Cooktop
All products are wiped clean with solvents at the
factory to remove any visible signs of dirt, oil, and
grease which may have remained from the
manufacturing process. Clean your glass top before
the first time you use it. A thorough cleaning with a
glass top cleaner is recommended.
Cookware
•Each cook has his or her own preference for the
particular cooking vessels that are most
appropriate for the type of cooking being done.
Any and all cookware, including Viking cookware, is
suitable for use on the cooktop and it is not
necessary to replace your present cookware with
commercial cookware. This is a matter of personal
choice. As with any cookware, yours should be in
good condition and free from excessive dents on
the bottom to provide maximum performance and
convenience.
Cookware Safety
• Use pans with flat bottoms and handles that are
easily grasped and stay cool. Avoid using unstable,
warped, easily tipped or loose-handled pans. Pans
with heavy handles (especially small pans) could be
unstable and tip easily. Pans that are heavy to
move when filled with food may also be hazardous.
• Be sure cookware is large enough to properly
contain food and avoid boil overs. Pan size is
particularly important in deep fat frying. Pan should
accommodate the volume of food that is to be
added as well as the bubble action of fat.
• To minimize burns, ignition of flammable materials
and spillage due to unintentional contact with the
cookware, DO NOT extend handles over adjacent
burners. ALWAYS turn pan handles toward the side
or back of the appliance, not out into the room
where they are easily hit or reached by children.
•NEVER let a pan boil dry as this could damage the
cookware and the appliance.
• This appliance has been tested for safe
performance using conventional cookware.
DO NOT use any devices or accessories that are
not specifically recommended in this guide.
DO NOT use eyelid covers for the surface units.
The use of devices or accessories that are not
expressly recommended in this manual can create
serious safety hazards, result in performance
problems, and reduce the life of the components
of the appliance.
Cooktop Features
5”W. Cooktop
1. 6-1/2” 1,200 watt element
2. 1,100/1,000/1,100 watt element
3. 12”,1,000/1000/1,100 watt element
4. 8-1/2” 2,000 watt element
5. Left front element control knob
6. Left rear element control knob
7. Center left element control knob
8. Center right element control knob
9. Right rear element control knob
10. Right front element control knob
36”W. Cooktop
1. 6-1/2” 1,200 watt element
2. 12” 1,100/1,000/1,100 watt element
3. 8-1/2” 2,000/1,000 watt element
4. Left front element control knob
5. Left rear element control knob
6. Center element control knob
7. Right rear element control knob
8. Right front element control knob
30”W. Cooktop
1. 6-1/2” 1,200 watt element
2. 12” 1,100/1,000/1,100 watt element
3. 8-1/2” 2,000/1,000 watt element
4. Left front element control knob
5. Left rear element control knob
6. Center element control knob
7. Right rear element control knob
8. Right front element control knob

F20969 EN (060812)
VIKING RANGE CORPORATION
111 Front Street • Greenwood, Mississippi
38930 USA • [phone]
Built-In
Electric Cooktops
Warning and Important Safety Instructions appearing
in this guide are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution, and care must be exercised when
installing, maintaining, or operating the appliance.
ALWAYS contact the manufacturer about problems or
conditions you do not understand.
Recognize Safety Symbols, Words, Labels
Read and follow all instructions before using this
appliance to prevent the potential risk of fire, electric
shock, personal injury or damage to the appliance as
a result of improper usage of the appliance. Use
appliance only for its intended purpose as described
in this manual.
To ensure proper and safe operation: Appliance
must be properly installed and grounded by a
qualified technician. DO NOT attempt to adjust,
repair, service, or replace any part of your appliance
unless it is specifically recommended in this guide.
All other servicing should be referred to a qualified
servicer.
To Prevent Fire or Smoke Damage
•Be sure all packing materials are removed from the
appliance before operating it.
• Keep area around appliance clear and free from
combustible materials, gasoline, and other
flammable vapors and materials.
•If appliance is installed near a window, proper
precautions should be taken to prevent curtains
from blowing over burners.
•NEVER leave any items on the cooktop. The hot air
from the vent may ignite flammable items and may
increase pressure in closed containers which may
cause them to burst.
• Many aerosol-type spray cans are EXPLOSIVE
when exposed to heat and may be highly
flammable. Avoid their use or storage near an
appliance.
• Many plastics are vulnerable to heat. Keep plastics
away from parts of the appliance that may become
warm or hot. DO NOT leave plastic items on the
cooktop as they may melt or soften if left too close
to the vent or a surface element.
• Combustible items (paper, plastic, etc.) may ignite
and metallic items may become hot and cause
burns. DO NOT pour spirits over hot foods.
In Case of Fire
Turn off appliance and ventilating hood to avoid
spreading the flame. Extinguish flame, then turn on
hood to remove smoke and odor.
• Smother fire or flame in a pan with a lid or cookie
sheet.
•NEVER pick up or move a flaming pan.
•DO NOT use water on grease fires. Use baking
soda, a dry chemical or foam-type extinguisher to
smother fire or flame.
Important notice regarding pet birds:
NEVER keep pet birds in the kitchen or in rooms
where the fumes from the kitchen could reach. Birds
have a very sensitive respiratory system. Fumes
released due to overheated cooking oil, fat, margarine
and overheated non-stick cookware may be equally
harmful.
WARNING
To avoid risk of property damage,
personal inj ry or death; follow
information in this man al exactly to
prevent a fire or explosion. DO NOT
store or se gasoline or other flammable vapors
and liq ids in the vicinity of this or any appliance.
CAUTION
DO NOT store items of interest to children over
the nit. Children climbing to reach items co ld
be serio sly inj red.
DANGER
Hazards or unsafe practices which WILL result in
severe personal injury or death
WARNING
Hazards or unsafe practices which COULD result
in death severe personal injury or death
CAUTION
Hazards or unsafe ractices which COULD
result in minor ersonal injury.
All safety messages will identify the hazard, tell yo
how to red ce the chance of inj ry, and tell yo what
can happen if the instr ctions are not followed.
WARNING
BURN OR ELECTRICAL
SHOCK HAZARD
To avoid risk of inj ry or death, make
s re all controls are OFF and oven is
COOL before cleaning. Fail re to do so
can res lt in b rns or electrical shock.
C A U T I O N
BURN HAZARD
To avoid risk of inj ry, DO NOT to ch
the glass. The cooktop will get hot
d ring sage.
CAUTION
DO NOT heat empty cookware or let cookware boil
dry. The cookware can absorb an excessive
amo nt of heat very q ickly, res lting in possible
damage to the cookware and ceramic glass.
QuickReference
Warnings Warnings (cont.)
