Viking Oxeo Manual

Installation and Maintenance Manual
Oxeo Inert Gas Extinguishing System

IMPORTANT! Read this document before starting any work.
This document is a mandatory part of the installation and should always be stored in a easily
accessible location and retained for future use.
This document is a translation of the original German document with modifications specific
to the usage in North and South America.
The Viking Corporation
210 N. Industrial Park Dr.
Hastings, MI 49058
USA
Phone: [phone]
Fax: [phone]
www.vikinggroupinc.com
Document ID: F_101921
Revision: 02
Release date: October 2022

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en i
Table of Contents
1 General ................................................................................... 1
1.1 Information about this manual.............................................. 1
1.2 About this document ................................................................ 3
1.3 Copyright ....................................................................................... 3
2 Safety....................................................................................... 5
2.1 Safety and warning notices..................................................... 5
2.2 Warnings within instructions.................................................. 6
2.3 Intended use................................................................................. 6
2.4 Safe operation.............................................................................. 8
2.5 General dangers .......................................................................... 9
2.6 Qualification of personnel ....................................................... 14
2.7 Personal protective equipment............................................. 16
2.8 Obligations of the Authorized Distributor......................... 17
2.9 Safety and protective devices ................................................ 18
2.10 Signage ........................................................................................ 20
2.11 Environmental protection..................................................... 24
2.12 Behavior in the case of fire.................................................... 24
3 Transport, packaging and storage................................ 27
3.1 Transport inspection.................................................. 28
3.2 Transport........................................................................................ 29
3.3 Packaging ...................................................................................... 33
3.4 Storage............................................................................................ 34
4 Design and Function ........................................................ 37
4.1 Functional description .............................................................. 37
4.2 Oxeo unistrut racking arrangements................................... 40
4.3 Pipeline system............................................................................ 40
4.4 Manifold 200 bar and 300 bar, DN50................................... 41
4.5 Check valve KRV-2 ...................................................................... 42
4.6 Extinguishing cylinder with quick release valve QRV.... 42
4.7 Hose for extinguishing agent................................................. 48

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
ii
Table of Contents
4.8 Pilot hoses for activation of “slave” cylinder .................... 49
4.9 Monitored blocking................................................................... 49
4.10 Pressure reducer ...................................................................... 50
4.11 Manifold safety valve.............................................................. 52
4.12 Occupiable space protection kit ........................................ 53
4.13 Shuttle non-return valve....................................................... 61
4.14 Pilot pressure relief assemblies........................................... 62
4.15 Blocking device, pilot line..................................................... 64
4.16 Downstream pipework.......................................................... 64
4.17 Limit switch, pneumatically operated.............................. 65
4.18 VN Nozzle.................................................................................... 66
4.19 DCM Nozzle................................................................................ 67
4.20 Pilot line made of precision steel pipe............................. 67
5 Assembly and installation................................................ 69
5.1 Warnings for assembly and installation............................. 69
5.2 Requirements imposed on the pipeline system............. 71
5.3 Manifold Assembly .................................................................... 74
5.4 Extinguishing cylinder with quick release valve QRV ... 75
5.5 Installing the safety valve........................................................ 90
5.6 Mounting the pilot control cylinder.................................... 92
5.7 Assembling the shuttle non-return valve.......................... 98
5.8 Mounting flexible pilot hose.................................................. 101
5.9 Assembling the pilot pressure relief device ..................... 102
5.10 Mounting the blocking device............................................ 104
5.11 Mounting the pressure reducer.......................................... 107
5.12 Mounting the pneumatic time delay ............................... 108
5.13 Assembling the downstream pipework.......................... 111
5.14 Assembling the pneumatically operated limit switch 113
5.15 Mounting the VN Nozzle....................................................... 115
5.16 Mounting the pilot line made of precision steel pipe 117
5.17 Mounting makrofon MX-1.................................................... 125
6 Electrical Connections and Terminal Assignments 129

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en iii
Table of Contents
6.1 Electrical release device, QRV ................................................. 130
6.2 Monitor for the electrical release device ............................ 131
6.3 Contact pressure gauge ........................................................... 132
6.4 Blocking device............................................................................ 134
6.5 Pneumatically actuated limit switch.................................... 135
6.6 Light barrier (loss monitoring) ............................................... 135
6.7 Limit switch reed contact (loss monitoring) ..................... 137
6.8 Limit switch connections to monitored circuits per NFPA 139
7 Commissioning.................................................................... 143
7.1 Preparations.................................................................................. 144
7.2 Testing the function of QRV actuation................................ 145
7.3 Checking the functioning of the pneumatic time delay 145
7.4 Checking the functioning of the makrofon MX-1........... 148
7.5 Establishing operational readiness ...................................... 148
8 Inspection and Servicing.................................................. 151
8.1 Inspection and maintenance schedule............................... 156
8.2 Service report ............................................................................... 159
8.3 Activities before servicing........................................................ 159
8.4 Preparation activities................................................................. 160
8.5 Visual inspections ....................................................................... 160
8.6 Refilling........................................................................................... 162
9 Malfunctions......................................................................... 165
9.1 Extinguishing cylinder with quick release valve QRV.... 166
9.2 Safety valve ................................................................................... 166
9.3 Pneumatic control device........................................................ 167
9.4 Pneumatic time delay unit ...................................................... 168
9.5 Limit switch, pneumatically operated................................. 169
9.6 Makrofon........................................................................................ 169
10 Disassembly and Disposal............................................. 171
10.1 Disassembly................................................................................ 172

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
iv
Table of Contents
10.2 Disposal....................................................................................... 180
11 Technical Data ................................................................... 181
11.1 Operating Conditions............................................................. 181
11.2 Emissions .................................................................................... 182
12 Appendix A - Racking Assembly ................................. 183
12.1 Introduction............................................................................... 183
12.2 Racking System Configurations and Ordering Information184
12.3 Spare parts and component technical data................... 187
12.4 Assembling the Rack .............................................................. 191
13 Appendix B - Replacement components................. 201
14 Appendix C - Approval Checklists .............................. 213
15 Safety Data Sheet - IG-01 (Argon)............................... 215
16 Safety Data Sheet - IG-100 (Nitrogen)....................... 223

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en 1
1 General
1.1 Information about this manual
This manual describes the installation and maintenance of Oxeo inert gas extinguishing systems
Oxeo PR LCP with a pressure reducer (also referred to hereinafter as “system”). Information about
fire detection and electrical control is not part of this manual. Qualified knowledge of the extin-
guishing agent used and the technical details of Oxeo inert gas extinguishing systems Oxeo PR
LCP with a pressure reducer are prerequisites for working with this manual.
This installation and maintenance manual contains neither detailed information concerning proj-
ect planning of the system, nor detailed information concerning operation. For this, observe the
design manual and the operating manual. This manual can be obtained through authorized deal-
ers.
This manual is intended for the installer of the fire extinguishing system.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
2
Applicable documents
Operating manual “Oxeo inert gas extinguishing system with pressure reducer, Oxeo PR LCP”
(form no. F_101821).
Design manual “Oxeo inert gas extinguishing system with pressure reducer, Oxeo PR LCP”
(form no. F_102021).

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en 3
1.2 About this document
This document enables the intended use of the system described. Observing all specified instruc-
tions and safety instructions is the prerequisite for safe work. Furthermore, the local accident pre-
vention regulations and general safety conditions for the use of the system are also applicable.
If this document refers directly or indirectly to laws, regulations, or directives or quotes from them,
the manufacturer cannot be held responsible for the correctness, completeness or up-to-date
nature of the reference.
Observe the applicable guidelines, standards, and statutory legislation of the respective country
of deployment.
Illustrations in this document are intended to facilitate basic understanding, and may differ from
the actual design of the product.
1.3 Copyright
Any content in this document, particularly texts, photos, and graphics, are protected by copyright.
If not otherwise clearly indicated, copyright lies with the manufacturer.
The manufacturer can issue permission of usage for contents of this document. Anyone violating
copyright law, e.g. by copying the contents into their own documentation without the respective
permission, is liable to prosecution. Copyright violators shall also receive a written warning and be
liable to pay costs.
The manufacturer reserves the right to make modifications resulting from further develop-
ments while retaining the key features of the system described without making corrections to
this document.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
4

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en 5
2 Safety
This section provides an overview of all important aspects that are essential for the protection of
personnel as well as safe and trouble-free operation. Additional task-specific safety instructions
will be provided in the sections that refer to the individual stages of the installation process.
2.1 Safety and warning notices
Safety and warning notices are marked with symbols in this document. The introductory signal
words express the respective extent of the danger.
DANGER
The signal word describes a danger with a high risk level. If the danger is not avoided, it will
result in death or serious injury.
WARNING
The signal word describes a danger with a high risk level. If the danger is not avoided, it will
result in death or serious injury.
CAUTION
The signal word describes a danger with a low risk level. If the danger is not avoided, it
may result in minor or moderate injury.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
6
In instructions, this marking starts with the symbol shown above.
2.2 Warnings within instructions
Warnings in behavior guidelines
Warnings can refer to specific, individual behavior guidelines. Such warnings are embedded in
behavior guidelines so that they do not interrupt the reading flow when executing the action.
The signal words described above are used.
Example:
1. Unscrew screw.
2. Carefully close the cover.
3. Tighten screw.
2.3 Intended use
This system is designed exclusively for the intended use described here.
The Oxeo inert gas extinguishing system is intended only for extinguishing fires burning in
enclosed rooms using the following inert extinguishing gases:
•IG-100 (nitrogen)
•IG-01 (argon)
NOTICE
The signal word describes a danger with a low risk level. If the danger is not avoided, it
may result in property and environmental damage.
This marking emphasizes useful tips and recommendations as well as information for
efficient and trouble-free operation.
CAUTION
Clamping danger on the cover.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en 7
Typical fire hazards for which the system should be used include:
•Electrical or electronic equipment
•Telecommunications equipment
•Ignitable and combustible liquids
•Other goods of particularly high value
The system should only be used within the usage and ambient conditions for which it has been
designed.
Intended use also includes compliance with all instructions of this document.
Misuse
Any use that extends beyond the intended use, or any other use of the system is considered mis-
use.
Fire hazards
Do NOT use the system in conjunction with the following fire hazards:
•Chemicals that release oxygen.
•Mixtures containing oxidizing substances (e.g. sodium chlorate, sodium nitrate, explosives,
gunpowder).
•Chemicals capable of thermally decomposing autonomously (e.g. certain organic peroxides).
WARNING Danger due to misuse.
Misuse of the Oxeo inert gas extinguishing system can lead to personal injury and material
damage.
• Do not perform any structural modifications on the protection zone or the system.
• Do not use and operate the system if components are damaged or not functional.
• Do not use the protection zone for any purpose other than the one intended by the Authorized
Distributor.
• Do not hang objects from pipe lines.
• Do not block the extinguishing nozzles or the ventilation devices.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
8
•Reactive metals (e.g. sodium, potassium, magnesium, titanium or zirconium) and reactive
hybrids or metal amides.
2.4 Safe operation
If system components are used improperly or for other than their intended purpose, the sys-
tem in which they are used can pose hazards or be impaired. Only use undamaged and fully
functional products and machines. If safe operation damage can no longer be assured (for
example, if visible damage is present), put the system out of operation without delay and
secure against accidental commissioning.
Also observe the following:
•Use only original spare and wear parts.
•Replace parts that are not in perfect condition immediately.
•Do not carry out any changes, extensions or modifications without the express permission
of the manufacturer or distributor.
This also applies to welding work on load-bearing parts.
In certain circumstances, some of the mentioned fire types can be suppressed using
IG-01 (argon). Consult the manufacturer about this.
Any changes, extensions or modifications not approved by the manufacturer are the
sole responsibility and liability of the person making the modification and exclude any
responsibility of the manufacturer.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en 9
Also observe the following fundamental information:
•National safety regulations
•National accident prevention regulations
•National assembly and installation regulations
•Generally accepted technical principles
•Safety and warning notices as described in this document
•Demands on personnel as described in this document
2.5 General dangers
The following section describes residual risks that can arise from the system even with proper use.
In order to reduce risks of personal injury and property damage and avoid dangerous situations,
the safety instructions listed here and the safety instructions in the other sections of this docu-
ment must be followed.
2.5.1 General dangers associated with fire extinguishing systems

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
10
Electrical current
Oxygen deficiency
DANGER Risk of death due to electric shock
An imminent, risk of death due to electric shock exists if live components are touched.
Damage to the cable insulation of individual components involves the risk of fatal
injury. Moreover, incorrect connection can cause system malfunctions.
• Allow only qualified electricians to work on electrical components and the electrical connec-
tion.
• If there is damage to the cable insulation, shut off the power supply immediately and replace
defective cables with new cables.
• Prior to starting tasks on live components of electrical equipment and supplies, establish the
de-energized state and ensure this state for the duration of the tasks. In this process comply
with the 5 safety rules:
1. Power down.
2. Safeguard against restart.
3. Ensure de-energized state.
4. Ground and short circuit.
5. Cover or shield any adjacent live components.
• Never remove safety devices, change them, or render them inoperable. Only replace defec-
tive fuses with fuses of the same amperage.
• Keep moisture away from live components. This may lead to short circuits.
WARNING Risk of death due to oxygen deficiency
If the extinguishing agent concentration exceeds 52% by vol. (LOAEL), the extinguish-
ing agent can have a toxic effect due to the reduced oxygen concentration. A danger
of asphyxiation exists with extinguishing agent concentrations above 62% by vol.
• Ensure that the locally applicable directives for rooms used for the storage of extinguishing
agent containers are complied with.
• Comply with NOAEL (No Observed Adverse Effect Level) and LOAEL (Lowest Observed
Adverse Effect Level) and ensure that the limit values are not exceeded.
• Avoid inhaling vapors, aerosols, and atomized spray.
• Comply with the safety data sheet for the extinguishing agent.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en 11
Extinguishing agent cylinders under high pressure
2.5.2 Dangers when the system is activated
Cold extinguishing agent
Shock
WARNING Risk of death due to pressure in extinguishing agent cylinders.
If pressurized extinguishing agent cylinders are damaged and extinguishing agent
escapes uncontrollably, there is a risk of severe injuries.
• Do not transport or store extinguishing agent cylinders unless they are sealed with a protec-
tive valve cap and a lock nut.
• Ensure that the extinguishing agent cylinders are attached correctly.
• Replace damaged extinguishing agent cylinders immediately.
WARNING Risk of injury from cold extinguishing agent.
The extinguishing agent exiting at the discharge nozzles is very cold. Direct contact
may result in injury.
• Leave the extinguishing zone without delay and within the pre-discharge timer when an
alarm is given.
• Stay out of the direct flow area of a discharge nozzle.
WARNING Risk of injury from shock.
The activation of the system involves noises from the discharged agent which may
surprise persons to an extent that they suffer shock.
• Inform all persons staying inside or close to the protected enclosure about the existence of
an automatic fire suppression system and the possibility of the system's activation.
• Make persons familiar with the procedures required in the event of an alarm, a fire, or the
activation of the fire suppression system.
• If in doubt, deny persons direct access to the protected enclosure.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
12
Faulty activation
WARNING Risk of injury from faulty activation.
A faulty activation of the system may cause severe injuries and property damage.
• Activate the system only in the event of a fire.
• Protect the manual release devices in the protected enclosure from inadvertent activation.
• Refrain from smoking inside the protected enclosure.
• Before performing any work generating heat and smoke, observe the following:
1. Isolate the system.
2. Switch off the fire alarm system.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en 13
Falling and flying objects
Noise
Effects of cold
WARNING Risk of injury from falling and flying objects.
The discharge velocity of the extinguishing agent may cause objects to tip over or
become airborne or to be damaged. This can cause severe injuries and significant
material damage.
• Do not place any loose objects into the discharge zone of the discharge nozzles.
• Exit the extinguishing zone without delay and within the pre-discharge timer when an alarm
is given.
• Do not place any sensitive objects (e.g. hard drives) directly into the discharge zone of the
discharge nozzles.
WARNING Risk of injury from noise.
High sound pressure levels caused by discharged gas and acoustic alarm equipment
(e. g. signal horns) may cause hearing damage.
• Leave the extinguishing zone without delay and within the pre-discharge timer when an
alarm is given.
• Stay out from the immediate vicinity of acoustic alarm equipment and discharge nozzles.
NOTICE Property damage from cooling ambient air.
The discharged extinguishing agent extracts heat from the ambient air contained in the
extinguishing zone. This causes the air in the immediate discharge zone of the extinguish-
ing nozzles to cool to below -58 °F (-50 °C).
• Do not attach/store components that are sensitive to cold in the immediate vicinity of the dis-
charge nozzles.

Inst. and Maint. Manual | Oxeo PR LCP | F_101921 Rev 02 | 10-2022 | en
14
Excess pressure
2.6 Qualification of personnel
Before starting any work, the following persons must be designated who have the knowledge
required to operate the system:
•A person to be responsible for the system
•An operator/person authorized by the operator
For all tasks, only persons from whom it can be expected that they will carry out their tasks
reliably are authorized to perform such tasks. Persons whose reaction time is affected, for
instance by drugs, alcohol or medication, are not authorized.
Furthermore, all work must only be carried out by persons who meet the following prerequi-
sites:
•They have read and understood this document including the safety instructions and warn-
ing notices.
•They are familiar with basic regulations on occupational safety and accident prevention.
•They have been given instruction on handling the system.
The various tasks described in this document require that the persons responsible for them
have different qualifications. These qualifications are specified in the following section:
NOTICE Property damage from excess pressure.
Due to the emitted extinguishing agent, an overpressure arises in the extinguishing
zone which can lead to damages to walls and doors of the protected enclosure.
• Ensure that pressure relief devices are installed in the protected enclosure and included in the
design of the system.
• Make sure that the function of the pressure relief is checked regularly.
WARNING Inadequately qualified persons pose a hazard.
Inadequately qualified persons cannot assess the risks involved in handling the sys-
tem. They expose themselves and others to the risk of severe or fatal injuries.
• All work should be carried out only by persons qualified to do so.
