Viking Installation Guide
15”W. Undercounter/Freestanding
Ice Machine

32
TABLE OF CONTENTS
Warnings & Important Safety Instructions______________________________________________________________________3
Dimensions (Professional)____________________________________________________________________________________5
Dimensions (Designer) ______________________________________________________________________________________6
Dimensions (Custom Panel) __________________________________________________________________________________7
Specifications ______________________________________________________________________________________________8
Cutout Dimensions _________________________________________________________________________________________9
Drain/Electrical Locations___________________________________________________________________________________10
General Information _______________________________________________________________________________________11
Air Flow __________________________________________________________________________________________________11
Filters and Treatment ______________________________________________________________________________________11
Installation Overview_______________________________________________________________________________________12
Door Panel _______________________________________________________________________________________________12
Custom Panel _____________________________________________________________________________________________12
Door Panel Attachment ____________________________________________________________________________________14
Door Swing Change _______________________________________________________________________________________15
Water and Drain Installation ________________________________________________________________________________16
Electrical Connection ______________________________________________________________________________________18
Final Installation ___________________________________________________________________________________________18
Installation Checklist _______________________________________________________________________________________18
Service Information ________________________________________________________________________________________19
IMPORTANT – PLEASE READ AND FOLLOW
•• Before beginning, please read these instructions completely and carefully.
• DO NOT remove permanently affixed labels, warnings, or plates from the product. This may void the warranty.
• Please observe all local and national codes and ordinances.
• Please ensure that this product is properly grounded.
• The installer should leave these instructions with the consumer who should retain for local inspector’s use and for
future reference.
A GFI shall be used if required by NFPA-70 (National Electric Code , federal/state/local laws, or local ordinances.
• The required use of a GFI is normally related to the location of a receptacle with respect to any significant sources of
water or moisture.
• Viking Range Corporation will NOT warranty any problems resulting from GFI outlets which are not installed properly or
do not meet the requirements below.
If the use of a GFI is required, it should be
• Of the receptacle type (breaker type or portable type NOT recommended)
• Used with permanent wiring only (temporary or portable wiring NOT recommended)
• On a dedicated circuit (no other receptacles, switches or loads in the circuit)
• Connected to a standard breaker of appropriate size (GFI breaker of the same size NOT recommended)
• Rated for Class A (5 mA +/- 1 mA trip current) as per UL 943 standard)
• In good condition and free from any loose-fitting gaskets (if applicable in outdoor situations)
• Protected from moisture (water, steam, high humidity) as much as reasonably possible
It is your responsibility to be sure your ice machine is:
• located so the front is not blocked to restrict incoming or discharge air flow.
• properly leveled.
• located in a well ventilated area.
• connected to the proper kind of outlet, with the correct electric supply and grounding. A 115V, 60 Hz, 15 amp fused
electrical supply is required. Note: Time delay fuse or circuit breaker is recommended.
• not used by anyone unable to operate it properly.
• used only for its intended purpose.
• properly maintained.
•SAVE THESE INSTRUCTIONS•
WARNING
To reduce the risk o ire, electric shock, or injury when using your unit, ollow these basic
precautions:
• Read all instructions before using the unit.
• Never allow children to operate, play with, or crawl inside the unit.
• Never clean unit parts with flammable fluids. The fumes can create a fire hazard or explosion.
• Always turn the power on/off switch (located behind the air grille on top right side) to the OFF
position before attempting to change light bulbs, clean, or service the unit.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER APPLIANCE. THE FUMES CAN CREATE A FIRE HAZARD OR
EXPLOSION.

54
PROPER DISPOSAL (OF OLD REFRIGERATION UNIT)
DANGER
RISK OF CHILD ENTRAPMENT
Be ore You Throw Away Your Old Re rigeration Unit:
• Take off the doors.
• Leave the shelves in place so that children may not easily
climb inside.
IMPORTANT: Child entrapment and suffocation are not problems of the
past. Junked or abandoned refrigeration units are still dangerous... even if
they will sit for “just a few days.”
IMPORTANT:
Now that you have a new ice machine, it is extremely important that you
dispose of your old appliance in a way that minimizes the possibility that
children will find it. There have been many cases in years past of children
crawling inside junked and abandoned refrigeration units and becoming
trapped or suffocated.
Contact your municipal waste disposal authority to find out the best and
safest way to dispose of your old refrigeration unit.
DIMENSIONS (PROFESSIONAL)
14-3/4”
(37.5 cm)
3-7/8”
(9.8 cm)
Floor drain
access hole
90.0
115.0
37-3/4”
(95.9 cm)
2-1/2”
(6.4 cm)
22-3/4”
(57.8 cm)
20-3/8”
(51.6 cm)
Dimensions
FGIM/FPIM
w/ Professional
door panel
Door Swing
19-1/4”
(48.9cm)
22-3/4”
(57.8cm)
25-1/4”
(64.1cm)
33-7/8”
(86.0cm)
min.
to
34-7/8”
(88.6cm)
max.
14-7/8”
(37.8cm)
14-7/8”
(37.8 cm)
14-7/8”
(37.8cm)
30-5/16”
(77.0cm)

DIMENSIONS (DESIGNER)
19-1/4”
(48.9cm)
22-3/4”
(57.8cm)
25-1/4”
(64.1cm)
33-7/8”
(86.0cm)
min.
to
34-7/8”
(88.6cm)
max.
14-7/8”
(37.8cm)
14-7/8”
(37.8 cm)
14-7/8”
(37.8cm)
30-5/16”
(77.0cm)
14-3/4”
(37.5 cm)
3-7/8”
(9.8 cm)
Floor drain
access hole
90.0 37-3/4”
(95.9 cm)
2-1/2”
(6.4 cm)
22-3/4”
(57.8 cm)
20-3/8”
(51.6 cm)
115.0
Door Swing
Dimensions
FGIM/FPIM
w/ Designer
door panel
76
DIMENSIONS (CUSTOM PANEL)
19-1/4”
(48.9cm)
22-3/4”
(57.8cm)
33-7/8”
(86.0cm)
min.
to
34-7/8”
(88.6cm)
max.
14-7/8”
(37.8cm)
14-7/8”
(37.8 cm)
14-7/8”
(37.8cm)
30-5/16”
(77.0cm)
14-3/4”
(37.5 cm)
3-7/8”
(9.8 cm)
Floor drain
access hole
90.0 37-3/4”
(95.9 cm)
22-3/4”
(57.8 cm)
20-3/8”
(51.6 cm)
90.0
115.0
Door Swing
Dimensions
FGIM/FPIM
w/ Custom
door panel

9
8
15”W. Undercounter/Freestanding Ice Machine
Description
FGIM515 FPIM515
Overall width 14-7/8” (37.8 cm)
Overall height 33-7/8” (86.0 cm) min. to 34-7/8” (88.6 cm) max.
Overall depth from rear
(without door panel)
(with door panel)
(with door handle)
22” (55.9 cm)
22-3/4” (57.8 cm)
25-1/4” (64.1 cm)
Cutout width 15” (38.1 cm)
Cutout height 34-1/4” (86.4 cm) min. to 35-1/4” (89.5 cm) max.
Cutout depth 24” (61.0 cm)
Electrical requirements 115V/60 Hz, 15 amp dedicated circuit
6’ 3-wire cord attached to product
Maximum amp usage 5.0 amps
Inlet water requirement 1/4” OD copper tubing inlet waterline
20 psi min. to 80 psi max.
40°F (5°C) min. to 100°F (38°C) max.
Drain requirements 5/8” ID x 7/8” OD plastic tubing
required
3/8” ID x 10’ plastic tubing supplied
Temperature requirements 50°F (10°C) min. to 100° (38°C) max.
Maximum storage capacity 26 lbs.
Approximate
shipping weight 113 lbs. (51.25 kg) 118 lbs. (53.5 kg)
CUTOUT DIMENSIONS
15” (38.1 cm)
34-1/4” (86.4 cm) min.
to
35-1/4” (89.5 cm) max.
24”
(61.0cm)

1110
AIR FLOW
The machine takes in room temperature air at the lower right front
and forces warm air out the lower left front. Restricting the airflow
will adversely affect the ability of the ice machine to make ice.
Filters and Treatment
In general, it is always a good idea to filter the water. A water filter,
if it is of the proper type, can remove taste and odors as well as
particles. Some methods of water treatment for dissolved solids
include reverse osmosis, and polyphosphate feeders.
RO Water
This machine can be supplied with Reverse Osmosis water, but the water conductivity must be no less than 10
microSiemens/cm. A reverse osmosis system should include post treatment to satisfy the R.O. water’s potential
aggressiveness. Deionized water is not recommended.
Because water softeners exchange one mineral for another, softened water may not improve water conditions when
used with ice machines. Where water is very hard, softened water could result in white, mushy cubes that stick together.
If in doubt about the water, contact a local point of use water specialist for recommendations on water treatment.
Air
intake
Warm
air out
SPECIFICATIONS
DRAIN/ELECTRICAL LOCATION
GENERAL INFORMATION
Drain
Flexible tubing
3/8” ID pump model (included)
5/8” ID x 7/8” OD gravity model (not included)
Potable water inlet
1/4” compression fitting
3-1/4”
(8.3 cm)
2-1/2”
(6.4 cm)
1-1/2” (3.8 cm)
3-3/4”
(9.5 cm)
7-3/8”
(18.9 cm)
115V
power cord

1312
INSTALLATION OVERVIEW
The ice machine must
• Be connected to cold, potable water.
• Be connected to a drain.
• Be connected to the proper power supply.
• Be able circulate air through the vents at the front.
Note: DO NOT build in so that the door is recessed. Door is meant to be flush with surronding cabinetry, but
not recessed.
INSTALLATION PARTS
The following installation parts are supplied with the ice machine
2-Hinge covers 2-Door stop pins
2-Hinge side covers 10-#8 sheet metal screws
2-Hole plugs 2-8-32 Machine screws
2-Hinge opening covers -Leveling leg caps
1-Upper door bracket (LH) 2-Black kickplate screws
1-Lower door bracket (LH) 1-Access panel button cover
ACCESSORY DOOR PANEL
The ice machine is supplied without a finished door panel. Accessory door panels are offered or a custom panel may
be used.
Accessory Door Panel Attachment
Note: If door swing is to be changed, it must be done before
panel is attached.
To attach a door panel
The panel will be held on by 6 screws (supplied with door panel)
and 2 machine screws (supplied with ice machine).
1. Remove the gasket and retain for later use.
2. If the door panel is stainless steel, remove any plastic covering
the stainless steel panel.
3. Place the panel onto the outside of the door, and secure it to
the door using two machine screws, located at the left center
and right center ( behind door gasket).
4. Fasten the panel to the door using the 6 screws (supplied with
door panel). In the hinge area, use the outermost screw holes.
5. Place the covers over the hinge areas, and secure each cover to
the door using a screw (supplied with door panel).
6. Insert hole plug over screw installed in step 5 (supplied).
7. Return the gasket to its original position.
CUSTOM PANEL
A custom panel of wood or other material not exceeding 15 lb can be attached to the door. Attachment is from the ice
side of the door. Holes are provided in the door for this purpose.
To create and attach a custom panel
• Panel width 14-7/8” (37.9 cm)
• Panel height 30-5/16” (77.0 cm)
• Panel thickness 5/8” (14.5 cm) to 3/4” (1.9 cm)
1. Measure overall height of cabinet opening where ice machine will be (floor to botom of countertop edge).
2. Determine desired kickplate space (from bottom of door to floor). This could be equal to the adjacent cabinet’s
kickplate space or another space the user wants.
3. Subtract kickplate space from cabinet opening.
Hole
plug
Cover
Gasket
4. Subtract 1/8” or more for clearance space between top of door and bottom of countertop edge from cabinet
opening. This is the maximum door length.
5. Cut panel to width
6. Cut panel to length (cabinet space - kickplate space - top clearance = length).
7. Determine top of panel.
8. Mark hole locations using drawing on the back of these instructions. Drawing assumes top of panel will be flush
with top of door. Measure hole locations from the top of the panel.
9. Drill pilot holes for wood screws. Use drill stop to prevent drilling through the panel.
10. Mount panel to door using wood screws or supplied panel mounting screws.
Note: When installed, ice machine must be adjusted for height to position top of door to desired clearance.
13-9/16”
(34.4 cm)
8-1/4”
(20.9 cm)
6-25/32”
(17.7 cm)
4-1/8”
(10.5 cm)
13/16”
(2.4 cm)
13/32”
(1.3 cm)
13/32”
(1.3 cm)
14-7/8”
(37.9 cm)
30-5/16”
(77.0 cm)
14-11/16”
(37.3 cm)
ø 1/8”
TYP. (10)
13-31/64”
(34.3 cm)
CUSTOM PANEL DIMENSIONS

15
14
DOOR SWING CHANGE
The door can be attached to open with hinges on the left or right using new brackets shipped loose in
the ice bin. Retain all screws for re-use.
To change
1. Remove inner screw holding each hinge to cabinet, loosen the outer screw.
2. Slide hinges to the side and remove door from cabinet. Remove outer screws
loosened in step 1 from both hinge brackets.
3. Remove two screws securing top panel to back, pull top panel back and
remove from cabinet.
4. Remove two screws at the top of the upper door hinge bracket and lift out of
the cabinet. Replace with the left hinge upper door bracket. Fasten it to the
cabinet using the original screws.
5. Return the top panel to the cabinet and fasten it with the original screws.
6. Remove kickplate and front service panel.
7. Remove two front screws and two bottom screws holding the lower door
hinge bracket to the cabinet. Replace with the left hinge lower door bracket.
Secure it using the original screws.
8. Remove the upper hinge and move it to the door's opposite side, bottom
location. Secure using the original screws.
9. Remove the original lower hinge and move it to the door's opposite side,
upper location. Secure using the original screws. Note: If door panel is
attached, it must be removed to access hinge screws.
10. Install a screw removed in step 2 in outer hole of upper and lower door brackets.
11. Attach the door to the cabinet using the original screws.
12. Return kickplate and front service panel to their original positions and attach
to the cabinet using the original screws.
DOOR STOP
• In some situations the door can open too far and damage adjacent cabinets. To
prevent that, insert a stop into the provided hole in the top and bottom hinges
• Drive the pin into the hole until the head is against the hinge.
HINGE COVERS
After the hinge pins are installed (if used) and the door panel has been attached,
attach the hinge covers.
1. Slide the hinge cover over each hinge.
2. Attach the side cover over the hinge by peeling off the covering over the
adhesive and placing it over the side of the hinge.
Note: If the hinges are used to secure the unit to the cabinet, DO NOT use the side covers.
KICKPLATE
The kickplate is black with a stainless steel covering. To use the stainless steel, no changes are required. To use the black,
remove the stainless steel covering by removing the two stainless steel screws. Replace with supplied black screws.
DO NOT remove stainless steel covering if ice machine is used outdoors.
INSTALLATION NOTES
Built In Situations: If a finished floor is to be installed in the area after the ice machine has been built in, shims the expected
thickness of the floor should be installed under the unit to keep the machine level with the planned floor level.
Installations on a slab: Use a pump model and pump the water to the point of drainage. Pump models will pump 1 story
(10 feet) high.
Installations over a crawl space or basement: Either gravity drain or pump model units may be used, if there is not
enough room behind the machine for a drain/waste receptacle, the drain will have to be below the floor.
Note: When installed in a corner, the door swing may be limited due to handle contact with the wall or cabinet face.
Outer screw
Inner screw
Upper
door
bracket
Screw
Lower
door
bracket
Bottom
screw
Front
screw
DOOR PANEL ATTACHMENT
Gasket
Accessory
Door Panel
Cover
Machine
Screw
Use Upper
Holeatthe
Top
Use Lower
Holeatthe
Bottom
Hole Plug
Insert door
stop pin

1716
Gravity Drain Pump Model drain installation
1. Place the ice machine in front of the installation opening. Adjust leveling legs to the approximate height.
2. Remove the front service access panel and the upper back panel (if necessary).
Note: If you are connecting a gravity drain model and the drain opening has been located in the floor under the base
pan according to the pre install specifications, follow steps 3 through 5 to drain the unit through the base. If not,
proceed to step 6b.
3. Remove the clamp and barbed elbow and take off the plastic cover in the base pan below the drain hose.
4. Connect a straight 5/8” barbed connector to the drain hose, securing with the clamp removed in step 4.
5. Cut an 8” piece of 5/8” ID X 7/8” OD tygon (clear plastic) tubing. Slide one end of the tube onto the outlet of the
barbed connector and secure with a clamp. Leave the other end of the tube lying on the floor of the base pan until
the unit is positioned over the floor drain.
6. Route the drain tube. Either a) Insert the drain tube through the base pan into the floor drain or b) Route the drain
tube through the left hole in the lower back panel and connect to barbed elbow and secure with a clamp.
7. Reinstall the upper back panel (if removed in step 2).
8. Reinstall the service access panel. Level the unit.
Back View, Gravity Drain Model
Water Inlet
Tube (field
supplied)
Drain Hose
Barbed Elbow
Drain Hose,
Route to
building drain
CAUTION
Restrictions in the drain system to the machine will cause water to back up into the ice storage bin and melt the ice. Gravity drain tubing
must be vented, have no kinks and slope to the building drain. Air gaps are typically required by local code.
WATER & DRAIN INSTALLATION
The recommended water supply tubing is 1/4” OD copper. Stainless steel flex or reinforced PVC tube may also be
used. Install an easily accessible shut-off valve between the supply and the unit. This shut-off valve should not be
installed behind the unit.
Note: DO NOT use self-piercing type valves.
1. Remove the front service access panel by removing the screw.
2. Route the tubing through the right hole in the back to the inlet water
solenoid valve inlet.
3. Install a compression fitting on the tubing and connect to the inlet of the
solenoid (fitting is located in cloth bag behind access panel).
DRAINS
There are two types of ice machine models, one that drains by gravity and
one that has an internal drain pump.
Drain Pump Model drain installation
1. Locate the coil of 3/8” ID plastic drain tubing secured to the back of the unit.
2. Route the plastic drain tube from the back of the unit to the drain connection point.
IMPORTANT NOTE: Often an air gap is re uired by local codes between the ice maker drain tube and the drain
receptacle.
Screw
Service
Access
Panel
Back View, Drain Pump Model
Water Inlet
Tube (field
supplied)
Drain Tube,
Route to
building drain

1918
SERVICE INFORMATION
If service is required, call your dealer or authorized service agency. The name of the authorized service agency can be
obtained from the dealer or distributor in your area.
Have the following information readily available.
• Model number
• Serial number
• Date purchased
• Name of dealer from whom purchased
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency,
or if you continue to have service problems, contact Viking Range Corporation at 1-888-VIKING1 (845-4641), or write to
VIKING RANGE CORPORATION
PREFERRED SERVICE
1803 Hwy 82W
Greenwood, Mississippi 38930 USA
Record the information indicated below. You will need it if service is ever
required. The model and serial number for your ice machine are located upper
left interior compartment.
Model Number ____________________________________Serial Number ____________________________________________
Date of Purchase ____________________________________________________________________________________________
Date Installed _______________________________________________________________________________________________
Dealer’s Name ______________________________________________________________________________________________
Address ____________________________________________________________________________________________________
If service requires installation of parts, use only authorized parts to insure protection under the warranty.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
Model and
Serial number
ELECTRICAL CONNECTION
The ice machine is supplied with a power cord. DO NOT remove the
grounding pin from the cord’s plug. DO NOT use extension cords. Follow all
codes. Connect the machine to its own 115 volt, 15 amp circuit.
FINAL INSTALLATION
1. If the electrical outlet for the ice maker is behind the unit, plug in the unit.
2. Snap the black caps over the bottom of the leveling legs.
3. Position the unit in the installation opening.
4. Turn on the water supply. Make sure that the ice maker is plugged in and
the power is on.
5. Slide unit into installation opening, paying careful attention to water supply
and drain connections. DO NOT kink!
6. Pour a couple of quarts of water into the ice storage bin; on drain pump
equipped machines the drain pump should start and water should pump
out. Check for leaks.
7. Replace the service access panel and insert access panel button cover (supplied)..
8. Level the unit as needed by turning the leveling legs clockwise to raise the unit and counterclockwise to lower the
unit.
INSTALLATION CHECK LIST
1. Has the unit been connected to the proper water supply?
2. Has the water supply been checked for leaks?
3. Has the unit been connected to a drain?
4. Has the drain been tested for flow and leaks?
5. Has the unit been connected to the proper electrical supply?
6. Has the unit been leveled?
7. Have all packing materials been removed from the machine?
8. Has the door covering been installed?
Grounding type
wall receptacle
Power Supply
with 3-prong
grounding plug
WARNING
ELECTRICAL SHOCK HAZARD
Failure to follow these instructions could result in fire or electrical shock.
