COOKING
Pro essional Custom Series Freestanding Dual Fuel
Sel -Clean 30”/36”W. Sealed Burner Electronic Control Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
All models include
•Exclusive Custom esigne electronic
controller an isplay
•Exclusive VSH™ (Vari-Simmer to
High) Patente Seale Burner System
o Four 15,000 BTU burners
•Exclusive VariSimmer™ setting for all
burners
•Exclusive all burners equippe with
SureSpark™ Ignition System for
consistent an reliable ignition every
time
•Exclusive one piece toole an
porcelainize cooking surface for easy
clean up
•Exclusive patent-pen ing Vari-Spee
Dual Flow™ convection system has
the largest convection fan in the
in ustry; the 8 1/2" fan works bi-
irectionally for maximum airflow an
excellent cooking results
• Conceale 10-pass ual bake element
provi es precise temperature control
• Extra large Gourmet Glo™ glass
enclose infrare broiler provi es
superior broiling performance
• Rapi Rea y™ Preheat provi es one
of the fastest preheat times – so your
oven is rea y to begin cooking when
you are
• Oven has six porcelain coate rack
supports an comes stan ar with
one TruGli e™ full extension oven
rack an two stan ar oven racks
• Three strategically locate oven lights
provi e maximum visibility
• Heavy- uty broiler pan an tray with
rack provi e more roasting an
broiling options
• High performance cooking mo es
inclu e Bake, Convection Bake,
TruConvec™ convection cooking,
Convection Roast, Hi, Me ium, an
Low Broil, Convection Broil an Meat
Probe
• Shippe stan ar with stainless steel
islan trim
• All finishes have stainless steel
han le/chrome-plate brackets an
stainless steel rip tray pull, control
panel, an lan ing le ge.
o Has black porcelain grates, black
porcelain burner caps, black porcelain
grate supports, metal knobs with
stainless steel finish an black
switches.
• White (WH)
o Finish esignates oor front, lower
front panel, si e panels, porcelain
grate supports, porcelain center
worktop, an knobs/switches.
o Has black porcelain grates an black
porcelain burner caps.
FINISH DETAILS FOR ALL MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Gol en Mist (GM), Lemona e (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iri escent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Re (RR), Apple
Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
o Finish esignates oor front, lower
front panel, an si e panels.
Standard Features & Accessories
*Shown throughout with optional 8” H. backguard. S Installation Notes & Accessories for d tails.
ORDERING INSTRUCTIONS
First specify mo el number, an then color co e (VDSC530T-4BSS). If or ering optional LP conversion, specify co e at en (VDSC530T-
4BSSLP).
VDSC530T-4B*
30”W. Four-Burn r
Rang
VDSC536T-6B*
36”W. Six-Burn r
Rang
VDSC536T-4G*
36”W. Four-Burn r/
Griddl Rang
VDSC536T-4Q*
36”W. Four-Burn r/
Grill Rang
Model Options

COOKING
Pro essional Custom Series Freestanding Dual Fuel
Sel -Clean 30”/36”W. Sealed Burner Electronic Control Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
30”W. 4B models include
• Convection oven capacity:
o Overall capacity—4.7 cu. ft.
(25-5/16”W. x 16-1⁄2”H. x
19-1/2”D.)
o AHAM Stan ar oven capacity—
4.1 cu. ft. (25-5/16”W. x 16-1⁄2”H. x
16-13⁄16”D.)
o Four 15,000 BTU brass seale
burners with porcelain/cast iron caps
an automatic ignition/re-ignition
o Center grate allows movement of
cooking vessels across entire top
surface
• Shippe stan ar with heavy- uty
metal knobs with stainless steel finish
• Shippe with stainless steel islan
trim*
36”W. models include
• Convection oven capacity:
o Overall capacity—5.6 cu. ft.
(30-5/16”W. x 16-1⁄2”H. x 19-
1/2”D.)
o AHAM Stan ar capacity—
4.9 cu. ft. (30-5/16”W. x 16-1⁄2”H. x
16-13/16”D.)
36”W. 6B models include
•Exclusive one TruPower Plus™18,500
BTU burner (front right burner)
• Five 15,000 BTU brass seale burners
with porcelain/cast iron caps an
automatic ignition/re-ignition
36”W. 4G models include
• Four 15,000 BTU brass seale burners
with porcelain/cast iron caps an
automatic ignition/re-ignition
• 12”W. thermostatically controlle steel
gri le/simmer plate
• Cast aluminum removable grease
trough hol s 2-1/2 cups of liqui
36”W. 4Q models include
•Four 15,000 BTU brass seale burners
with porcelain/cast iron caps an
automatic ignition/re-ignition
• 12”W. grill with flavor generator
plates an automatic ignition/re-
ignition
•Exclusive two-piece removable
porcelainize rip pan hol s three
quarts of liqui
• All finishes have stainless steel
han le/chrome-plate brackets an
stainless steel rip tray pull, control
panel, an lan ing le ge.
o Has black porcelain grates, black
porcelain burner caps, black porcelain
grate supports/burner bowls, an
black knobs/switches.
• White (WH)
o Finish esignates oor front, lower
front panel, si e panels, porcelain
grate supports/burner bowls, porcelain
center worktop, an knobs/switches.
o Has black porcelain grates an black
porcelain burner caps.
FINISH DETAILS FOR ALL MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Gol en Mist (GM), Lemona e (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iri escent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Re (RR), Apple
Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
o Finish esignates oor front, lower
front panel, an si e panels.
Standard Features & Accessories
*Shown throughout with optional 8” H. backguard. S Installation Notes & Accessories for d tails.
ORDERING INSTRUCTIONS
First specify mo el number, an then color co e (VDSC530T-4BSS). If or ering optional LP conversion, specify co e at en (VDSC530T-
4BSSLP).
VDSC530T-4B*
30”W. Four-Burn r
Rang
VDSC536T-6B*
36”W. Six-Burn r
Rang
VDSC536T-4G*
36”W. Four-Burn r/
Griddl Rang
VDSC536T-4Q*
36”W. Four-Burn r/
Grill Rang
Model Options

COOKING
Pro essional Custom Series Freestanding Dual Fuel
Sel -Clean 30”/36”W. Sealed Burner Electronic Control Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E

Please see
Installation Not s &
Acc ssori s
for important
installation
information
inclu ing
backguar , high-
shelf, islan trim,
an curb base front.
Star-K Kosh r
C rtification for
us on th J wish
Sabbath or J wish
holidays
Dimensions & Speci ications
PRODUCT DIMENSIONS & DOOR SWING
ALL MODELS
30”W. Mod ls 36”W. Mod ls 30” & 36”W. Mod ls
VDSC530T-4B VDSC536T-6B VDSC536T-4G VDSC536T-4Q
Overall width 29 7/8” (75.9 cm) 35 7/8” (91.1 cm) 35 7/8” (91.1 cm) 35 7/8” (91.1 cm)
Overall height
Base height
To top of grate support 35-7/8” (91.1 cm) min. to 37” (94.0 cm) max.
Legs adjust (with “spindles” fully extended) 1-1/8” (2.9 cm)
Additions to base height
To top of island trim Add 1” (2.5 cm)
To top of 8” backguard Add 8” (20.3 cm)
To top of high shelf Add 23-1/2” (59.7 cm)
Overall depth (from rear)
To end of side panel 24-5/16” (61.8 cm)
To front of door 25-3/4” (65.4 cm)
To end of landing edge 28-1/16” (71.2 cm)
To end of door handle 28-11/16” (72.9 cm)
Oven
Interior width 25 5/16” (64.6 cm) 30 5/16” (79.5 cm) 30 5/16” (79.5 cm) 30 5/16” (79.5 cm)
Interior height 16-1/2” (41.9 cm)
Interior depth Overall - 19-1/2” (49.5 cm) AHAM - 16-13/16” (42.7 cm)
Overall interior size Overall 4.7 cu. ft. Overall 5.6 cu. ft. Overall 5.6 cu. ft. Overall 5.6 cu. ft.
AHAM 4.1 cu. ft. AHAM 4.9 cu. ft. AHAM 4.9 cu. ft. AHAM 4.9 cu. ft.
35-7/8”
(91.1cm)min.
to
37”
(94cm)max.
1”
(2.5 cm)
29-7/8”
(75.9 cm)
35-7/8”
(91.1 cm)
35-7/8”
(91.1cm)min.
to
37”
(94.0cm)max.
1”
(2.5cm)
25-3/4” (65.4 cm)
45-1/8” (114.6 cm)
19-3/8”
(49.2 cm)
8-1/8”
(20.6 cm)
26-7/16” (67.2 cm)
1-5/8”
(4.1 cm)
1”
(2.5 cm)
35-7/8”
(20.3 cm) min.
to
37”
(94 cm) max.
24-5/16” (61.8 cm)
28-1/16” (71.2 cm)
VDSC530T-4B
30”W. Four-Burn r
Rang
VDSC536T-6B
36”W. Six-Burn r
Rang
VDSC536T-4G
36”W. Four-Burn r/
Griddl Rang
VDSC536T-4Q
36”W. Four-Burn r/
Grill Rang

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
Pro essional Custom Series Freestanding Dual Fuel
Sel -Clean 30”/36”W. Sealed Burner Electronic Control Range
Minimum cl aranc s from adjac nt
combustibl construction
• Cooking surface an below, i.e.,
36” (91.4 cm) an below
o Si es—0”
o Rear—0” with backguar or high-
shelf; 0” with islan trim an
non-combustible rear wall; 6”
(15.2 cm) with islan trim an
combustible rear wall
o Top grate support—36” (91.4 cm)
• Above cooking surface, i.e., above
36” (91.4 cm)
o Si es—6” (15.2 cm)
o Within 6” (15.2 cm) si e clearance,
wall cabinets no eeper than 13”
(33.0 cm) must be minimum 18”
(45.7 cm) above cooking surface
o Wall cabinets irectly above pro uct
must be minimum 42” (106.7 cm) for
seale top burners above cooking
surface
• Use range only with factory supplie
legs
1.This range may be installe irectly
a jacent to existing 36” (91.4 cm) high
base cabinets. Important: The top
grate support must be 3/8” (0.95 cm)
above the a jacent base cabinet
countertop. This may be accomplishe
by raising the unit using the
a justment spin les on the legs.
2.The range cannot be installe irectly
a jacent to si ewalls, tall cabinets, tall
appliances, or other si e vertical
surfaces above 36” (91.4 cm) high.
There must be a minimum of
6” (15.2 cm) si e clearance from the
range to such combustible surfaces
above the 36” (91.4 cm) counter height.
3.Within the 6” (15.2 cm) si e clearance
to combustible vertical surfaces above
36” (91.4 cm), the maximum wall
cabinet epth must be 13” (33.0 cm)
an wall cabinets within this 6” (15.2
cm) si e clearance must be 18” (45.7
cm) above the 36” (91.4 cm) high
countertop.
4.Wall cabinets above the range must be
a minimum of 42” (106.7 cm) above
the range cooking surface for the full
wi th of the range. This minimum
height requirement oes not apply if a
rangehoo is installe over the
cooking surface.
Dimensions & Speci ications
42”min.
(106.7cm)
13”max.
(
33.0cm)
6”min.
(15.2cm)
18”min.
(45.7cm)
3/8”
(0.95cm)
36”
(91.4cm)
A
A
30”W. 29-7/8“ (75.9 cm)
36”W. 35-7/8“ (91.1 cm)

COOKING
Pro essional Custom Series Freestanding Dual Fuel
Sel -Clean 30”/36”W. Sealed Burner Electronic Control Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
2”
(5.1 cm)
Dia.
2-3/4”
(7.0 cm)
4-3/8”
(11.1 cm)
2-1/2”
(6.4 cm)
1-3/4”
(4.4 cm)
31-1/16”
(78.9 cm)
28-5/16”
(71.9 cm)
23-7/16”
(59.5 cm)
Gas or electrical
connection in
this area
Gas connection
in this area
Installation Requirements
ACCESS REQUIREMENTS
Note: Ground plug and electrical wire toward the direction of the electrical outlet.
VDSC530T-4B VDSC536T-6B VDSC536T-4G VDSC536T-4Q
Surface burner rating
Surface burners 15,000 BTU Nat. (4.4 kW)/ 15,000 BTU Nat. (4.4 kW)/ 15,000 BTU Nat. (4.4 kW)/ 15,000 BTU Nat. (4.4 kW)/
12,500 BTU LP (3.7 kW) 12,500 BTU LP (3.7 kW) 12,500 BTU LP (3.7 kW) 12,500 BTU LP (3.7 kW)
Surface burners 18,500 BTU Nat. (5.4 kW)/ 18,500 BTU Nat. (5.4 kW)/
(front right) 16,600 BTU LP (4.9 kW) 16,600 BTU LP (4.9 kW)
One griddle 15,000 BTU Nat. (4.4 kW)/
12,500 BTU LP (3.7 kW)
One grill 18,000 BTU Nat. (5.3 kW)/
16,000 BTU LP (4.7 kW)
UTILITY
REQUIREMENTS
GAS
• Shippe natural or LP/Propane gas;
fiel convertible with conversion kit
(purchase separately)
• Accepts stan ar resi ential 1/2”
(1.3 cm) ID gas service line
•Gas manifol pressure
oNatural gas 5.0” W.C.P.
o LP/Propane 10.0” W.C.P.
ELECTRICAL
• Electrical connection box on pro uct
for har wire irect; connect with
locally supplie 3-wire, flexible cor
rate or “pigtail” rate 40 amp 125-
250 VAC min.; must be agency-
approve for use with househol
electric ranges.
• Check your national an local co es
regar ing this unit.
•Maximum amp usage—
240 – 208 VAC/
60 Hz
o4B
• 240V—25.4 amps
• 208V—22.9 amps
o6B/4G/4Q
• 240V—28.5 amps
•208V—24.7 amps
PLUMBING
Not applicable

Island Trim
• Stainless Steel (SS)
•Coor inates with all finishes
• For islan /peninsula installation
• Can replace backguar if wall is non-combustible
• Inclu e an shippe automatically with 30”W. an 36”W. ranges.
8”H. Backguard
• Stainless Steel (SS)
• Coor inates with all finishes
High-shel
• Stainless Steel (SS)
• Coor inates with all finishes
• Shelf comes attache to a 24”H. backguar
Countertop Side Trim
• Stainless Steel (SS)
• Coor inates with all finishes
• One pair of trim
• Installs on si e of unit; overlaps countertop
Countertop Rear Trim
• Stainless Steel (SS)
• Coor inates with all finishes
COOKING
Pro essional Custom Series Freestanding Dual Fuel
Sel -Clean 30”/36”W. Sealed Burner Electronic Control Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Installation Notes & Accessories
A backguar , high-shelf, or islan trim must be use for all installations.
Model Description Approx. ship wt. lbs. (kg)
P30BG8 30”W. backguard 14 (6.3)
P36BG8 36”W. backguard 17 (7.7)
Model Description Approx. ship wt. lbs. (kg)
B30HS24 30”W. high shelf 45 (20.3)
B36HS24 36”W. high shelf 50 (22.5)
Model Description Approx. ship wt. lbs. (kg)
P24CST 24”D. side trim 2 (0.9)
Model Description Approx. ship wt. lbs. (kg)
P30TII 30”W. island trim 10 (4.5)
P36TII 36”W. island trim 11 (5.0)
Model Description Approx. ship wt. lbs. (kg)
P30CRT 30”W. countertop rear trim 2 (0.9)
P36CRT 36”W. countertop rear trim 2 (0.9)

COOKING
Pro essional Custom Series Freestanding Dual Fuel
Sel -Clean 30”/36”W. Sealed Burner Electronic Control Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Curb Base Front Custom Curb Base Front
• Stainless Steel (SS) • Remove stainless steel front an recycle
• Coor inates with all finishes •Conceals range legs
•Front only •Attach locally supplie trim
• Conceals range legs • Completely assemble
•Completely assemble • Easily clips onto range legs after range is installe
•Easily clips onto range legs after range is installe •Provi es rop-in range look
LP/Propane Conversion Kit
• Allows for fiel conversion of range from natural gas to LP
Compliance In ormation
WARRANTY INFORMATION*
• One-year full warranty—complete pro uct
• Ten-year limite warranty—porcelain oven an porcelain inner oor panel
• Five-year limite warranty—surface burners, gri le burners, grill burners, an oven burner
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items
* For complete warranty see Use & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
Model Description Approx. ship wt. lbs. (kg)
LPKPDR Natural to LP/propane conversion kit 2 (0.9)
Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
P30CBF4 30”W. curb base front 9 (4.1)
P36CBF4 36”W. curb base front 10 (4.5)
