Viking FDSB5421D Series User manual

FINISH DETAILS FOR VCSB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Apple Re (AR), Biscuit (BT),
Burgun y (BU), Chocolate (CH),
Cinnamon (CN), Cobalt Blue (CB),
Cotton White (CW), Dijon (DJ),
Graphite Gray (GG), Iri escent Blue
(IB), Kettle Black (KB), Lemona e (LE),
Mint Julep (MJ), Plum (PL), Racing Re
(RR), Sage (SA), Sea Glass (SE), Stone
Gray (SG), Taupe (TP), Viking Blue (VB),
Wasabi (WS).
• Finish co es esignate oor fronts.
Stainless steel upper grille, si e trim,
an han les (with chrome-plate
brackets); black lower kickplate.
• Brass Accent Option (BR)—nameplate
an han le en caps. Brass compo-
nents have a urable protective coat-
ing for maintenance-free normal use.
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Model Options
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
All models include
• Total capacity—23.9 cu. ft. (677 L)
oRefrigerator - 15.0 cu. ft.
oFreezer - 8.9 cu. ft.
o 84”H./24”D.
• ProChill™ Temperature Management
System
oVariable-spee DC Over rive™
Compressor is one of the quietest,
most technologically a vance com-
pressors available
oElectronic controls with igital tem-
perature rea outs
oMulti-channel airflow system an
O or Eliminator™ Evaporator
removes o ors an excess humi ity
•Exclusive Plasmacluster™* Ion Air
Purifier
oEliminates airborne bacteria an
mol spores
oRemoves o ors
oEnhances foo preservation
oNever nee s replacing
• Refrigerator Compartment
oFour a justable tempere glass
spillproof shelves
• A justable Col Zone™ rawer with
precision ball-bearing gli es
oSeparate temperature control can be
set for pro uce or fresh meat storage
oQuick chill option chills foo s an
beverages in minutes
• A justable Humi ity Zone™ rawers
with precision ball-bearing gli es
oHumi ity can be set high for leafy
greens or low for fruits an vegeta-
bles with skins
• Two in-the- oor seale airy
compartments with covers
• Four patente a justable aluminum
oor bins with tempere glass fronts
• Top-shelf provi es quick chill- own
area
• Freezer Compartment
oA aptive efrost
oThree wire shelves an two sli e-out
baskets
oThree patente a justable alu-
minum oor bins with tempere
glass fronts
• Ice/Water Dispenser
oThrough-the- oor ispenser
provi es cube ice, crushe ice an
water in easy on-han operation
oPremium water filter provi es clean-
er water an ice supply by filtering
ba tastes, o ors, se iment an
harmful contaminants.
• Super Clog-Resistant™ Con enser is
maintenance-free un er normal use
• Tru-Flush™ esign allows all mo els to
fit flush into 24” eep installation
cutout
• Open oor alarm soun s an glows to
warn that oor has been ajar for three
minutes
• A justable oor stops stan ar —90°,
110°, or 120° swing
• Sabbath Mo e
*Plasmacluster is a registere tra emark
of Sharp Corporation.
FINISH DETAILS FOR FDSB MODEL
• Han les not inclu e —opt for custom
han les, or purchase a Viking
Professional Series han le kit (see
Installation Notes & Accessories).
• See Custom Panels section for
more information an a itional
specifications.
Standard Features & Accessories
VCSB 421D
Professional
FDSB 421D
Custom Panel
ORDERING INSTRUCTIONS
First specify mo el number, an then color co e (VCSB5421DSS). If or ering optional brass accent, specify co e at en (VCSB5421DSSBR).

✪
Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel an
han le kits, an
water filters.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
22-3/16”
(56.4cm)
24”
(61.0cm)
75-15/16”
(192.9cm)
3-19/32”
(9.1cm)
42”
(106.7cm)
26-1/2”
(67.3cm)
41”
(104.1cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
23-3/8”
(59.4cm)
24”
(61.0cm)
75-15/16”
(192.9cm)
42”
(106.7cm)
41”
(104.1cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
26-1/2”
(67.3cm)
3-19/32”
(9.1cm)
VCSB5421D VCSB5421D/Flush Mount
Overall width 42” (106.7 cm)
Overall height (fro botto ) 2-3/4” (210.2 cm) min. to 4-1/16” (213.5 cm) max.
Overall depth (fro rear)
To front edge of side tri 22-3/16” (56.4 c ) 23-3/8” (59.4 c )
To front of top grille 24” (61.0 c ) 24” (61.0 c )
To front of handle 26-1/2” (67.3 c ) 26-1/2” (67.3 c )
Approx. ship weight 676 lbs. (304.2 kg)
VCSB 421D
Professional
Dimensions & Specifications
PRODUCT DIMENSIONS
PROFESSIONAL
WITH FLUSH
MOUNT TRIM
PROFESSIONAL

23-13/16”
(60.5cm)
24-3/4”
(62.9cm)
75-15/16”
(192.9cm)
42”
(106.7cm)
41”
(104.1cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
Varies
3-1/2”
(8.9cm)
CUSTOM PANEL
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
✪
Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel an
han le kits, an
water filters.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
FDSB5421D
Overall width 42” (106.7 cm)
Overall height (fro botto ) 2-3/4” (210.2 cm) min. to 4-1/16” (213.5 cm) max.
Overall depth (fro rear)
To front edge of side tri 23-13/16” (60.5 cm)
To front of top grille 24-3/4” (62.9 cm)
To front of handle Varies
Approx. ship weight 525 lbs. (236.2 kg)
FDSB 421D
Custom Panel
See Custom Panels section for
more information an a itional
specifications.
Dimensions & Specifications
PRODUCT DIMENSIONS

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
41-5/16”
(105.0 cm)
24”
(61.0 cm)
39-15/32”
(100.3 cm)
40-19/32”
(103.1 cm)
43-1/2”
(110.5 cm)
44-31/32”
(114.3 cm)
45-31/32”
(116.8 cm)
9-1/2”
(24.1 cm)
7-5/32”
(18.2 cm)
1-27/32”
(4.7 cm)
11-27/32”
(30.1 cm)
8-3/4”
(22.2 cm)
1-27/32”
(4.7 cm)
42”
(106.7 cm)
41”
(104.1 cm)
90° 90°
110° 110°
120° 120°
2-1/2” (6.4 cm)
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
Dimensions & Specifications
See Custom Panels section for
more information an a itional
specifications.
DOOR SWING
• A justable oor stops stan ar —90°, 110°, or 120° swing
VCSB 421D
Professional
FDSB 421D
Custom Panel
PROFESSIONAL

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
Door
Wall
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
3/4”
(1.9 cm)
full end panel
24”
(61.0 cm)
standard
cabinet
depth
1-3/4”
(4.4 cm) offset
5/16”
(0.8 cm)
1-13/16”
(4.6 cm)
space if 24”standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
1-3/4”
(4.4 cm) offset
Countertop
overhang
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
1-3/4”
(4.4 cm) offset
Partial overlay
cabinet door
TOP VIEW
TOP VIEW
TOP VIEW

REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Door
Wall
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
Door
24”
(61.0 cm)
standard
cabinet depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL WITH FLUSH MOUNT TRIM
Door
24”
(61.0cm)
standard
cabinet
depth
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
3/4”
(1.9 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Cabinet
door
TOP VIEW
TOP VIEW
TOP VIEW
Overlapping cabinet doors

REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cor
with groun e
three-prong plug
attache to
pro uct
• 115 VAC 60 Hz;
15 amp e icat-
e circuit
• Maximum amp
usage—9.9
• Estimate
energy usage—
694 kWh/year
PLUMBING
• Inlet waterline
requirements—
1/4”copper
tubing
• 35 psi min.;
120 psi max.
Installation Requirements
Anti-tipboard
6”
(15.2cm)
9”
(22.9cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/6”
(213.5cm)max.
anti-tipboard&
openingheight
24”*
(61.0cm)min.
6-3/4”
(17.1cm)
7-5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.5cm)
5/8”
(1.5cm)
10-1/2”
(26.7cm)
5/8”
(1.5cm)
10-3/4”
(27.3cm)
1”
(2.5cm)
3-5/8”
(9.2cm)
Optionalfloor
waterlineentry
9”
(22.9cm)
41-5/8”
(105.7cm)min.
to
41-3/4”
(106.0cm)min.
Professional
42”
(106.7cm)
FlushMountOnly
ACCESS REQUIREMENTS
VCSB5421D VCSB5421D/Flush Mount FDSB5421D
Cutout width 41-5/8” (105.7 c ) in. to 42” (106.7 c ) 42” (106.7 c )
41-3/4” (106.0 c ) ax.
Cutout height 2-7/ ” (210.5 cm) min. to 4-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
ELECTRIC OUTLET LOCATION
WATER LINE ENTRY AREA
*Custo panel odels fit flush in 25”-deep (63.5 c )
cabinet openings. They can be installed in standard
24”-deep openings. The door faces and top grille
will protrude 3/4” (1.9 c ) into the roo .
See Custom Panels section for
more information an a itional
specifications.
VCSB 421D
Professional
FDSB 421D
Custom Panel

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
Side Panel Kits
• Stainless Steel (SS)
• Panels provi e finishe , freestan ing look; unit must still be secure to the wall
•Kit inclu es one panel an installation har ware
Side Panel Hardware Kit
• For use with custom panel built-in refrigerator/freezers
• Har ware allows installation of custom si e panels
• Kit inclu es brackets, screws, an installation instructions to mount panels on left an right si e
Top Panel Kit
• Stainless Steel (SS)
• Panel provi es finishe , freestan ing look; unit must still be secure to the wall
• Kit inclu es one panel an installation har ware
Handle Kits
• For use with custom panel refrigerator/freezers
• For use on locally supplie custom panels
• Han les allow refrigerator/freezers with custom panels to coor inate with other Professional pro ucts
• Kit inclu es two han les an installation har ware
Replacement Water Filter
• Re uces se iment, taste, an o or
• Re uces cysts, particulates, turbi ity, lea , chlorine, atrazine, an lin ane
• NSF-certifie
• Rea y to install—no assembly require
• Replacement recommen e every nine months
Compliance Information
WARRANTY SUMMARY*
• Three-year full warranty—complete unit
• Six-year full warranty—seale refrigeration system
• Twelve-year limite warranty—seale refrigeration system (inclu es compressor, con enser,
ryer/strainer, evaporator, an connecting tubing)
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items
*For complete warranty see Use & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a. ]b]s.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
RWF-DISP Replace ent water filter 5 (2.3)
Model Description Approx. ship wt. lbs. (kg)
PHK-DFSB5-SS Professional handles (Stainless Steel) 10 (4.5)
Model Description Approx. ship wt. lbs. (kg)
PSSPL2 Professional side panel left - Standard Mount 45 (20.2)
PSSPR2 Professional side panel right - Standard Mount 45 (20.2)
DSSPL2 Designer side panel left - Flush Mount 45 (20.2)
DSSPR2 Designer side panel right - Flush Mount 45 (20.2)
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Model Description Approx. ship wt. lbs. (kg)
TOP-42 42”W. top panel 23 (10.4)
Model Description Approx. ship wt. lbs. (kg)
SPHKDS Side panel hardware 3 (1.4)
