MODERN SAUNA SCANDIT 5 Dear Customer!Congratulaons in the choice of SCANDIT 5 modern garden sauna.We wish you rest and relaxaon all year round!SCANDIT sauna is made by hand from top-quality components, in particular from wood of exceptional properties - ThermoWood® heat-treated Finnish pine. It is designed for outdoor use.VINGBERG TeamPlease keep this manual for future reference. Should you have any doubts regarding the use of sauna, we will be pleased to give you a necessary advice.Please note that it is very important to use sauna and care for it properly. To extend sauna lifespan considerably, just follow our recommendaons. Thus, you will enjoy unforgeable moments with family and friends for many years.vingberg.pl

MODERN SAUNA SCANDIT 5 1. Safety..............................................................................................................................................................................32. Sauna elements.......................................................................................................................................................4 3.2. Electrical connection..............................................................................................................................73. Installation3.1. Ground preparation and transport...............................................................................................64. Use of sauna .................................................................................................................................................................4.2. Settings menu .............................................................................................................................................94.3. Control with mobile app....................................................................................................................104.5. Bluetooth sound system....................................................................................................................123.3. Correct Stacking of stones...................................................................................................................8 4.4. Chromotherapy system ....................................................................................................................114.1. Control panel operation ......................................................................................................................95.2. Care for sauna interior.......................................................................................................................126.1. External dimensions .........................................................................................................................146.2. Specification and equipment.........................................................................................................155. Care and maintenance of sauna 5.1. ThermoWood® preservation.........................................................................................................136. Technical data7. Warranty terms ....................................................................................................................................................16 TABLE OF CONTENTS vingberg.pl

MODERN SAUNA SCANDIT 5 3 1. SAFETY vingberg.plFIn order to prevent dehydraon or other ailments caused by high temperature, it is recommended to drink water regularly.FDo not pour excess amount of water on stones. The steam being formed is at a boiling point! Either, never pour water on stones when there are any people around the heater because the heated steam can cause burns.FAlways check the sauna room and heater before it is turned on.FNever cover the heater - due to risk of fire.FBefore you become user of sauna, consult with a physician to make sure that you have no contraindicaons to use sauna.FUndiluted essenal oils, etc. can light up when poured directly on stones.FThe stones and outer surface of the heater may burn your skin. Keep children away from the heater. FNever leave heated sauna without supervision. If you have to leave sauna make sure that electric heater is turned off, and wood-burning heater is completely exnguished.FChildren, handicapped and ill people should not be le in sauna without supervision.FNever go to hot sauna if you have taken alcohol, strong medicines or drugs.To keep safety please respect the following instrucons!FStaying in the hot sauna for long periods of me makes the body temperature rise, which may be dangerous. FBe very careful when moving in the sauna, as the terrace and floor can be slippery.FNever sleep in hot sauna.FFor safety, always keep an exnguisher nearby the sauna.

MODERN SAUNA SCANDIT 5 4 2. SAUNA ELEMENTS vingberg.plSAUNA INTERIORREAR VIEW

MODERN SAUNA SCANDIT 5 Huum heater is fied with temperature sensor, provided in sauna room.Huum UKU Local control paneland current temperature, installed inside sauna. The heater also can be controlled via HUUM HeaterHuum (Hive or Drop) electric heater, factory-installed in sauna.Temperature sensor Control of heater is possible with use of electronic controller with display indicang setpoint Door sensorSensor installed in the door is used as an addional protecon from overheang the heater. Once external door is opened, the heater is turned off and turned on again once the door is UKU WiFi or GSM mobile app (addional opon). Descripon of funcons is given in the further part of this manual.and discharge. Once a session is over, make sure to vent sauna and let it dry completely, e.g.External switchboard IP66VentilationSauna is equipped with ventilation ducts and diffusers which allow adjustment of air intakeclosed.by opening the door for a short time.Descripton is given in the further part of this manual. 2. SAUNA ELEMENTS5vingberg.pl

6vingberg.plMODERN SAUNA SCANDIT 5 3. INSTALLATION The choice of the proper installation place is very important and has a serious impact on theuser's safety and sauna durability.Sauna should be placed on a stable and even surface, e.g. concrete slabs or paving stones, while ensuring venlaon from the boom and disabling the development of vegetaon underneath sauna. It is not recommended to situate the sauna directly on the ground or grass.Scandit sauna is delivered as pre-assembled. To enable access for forkli, lower skirng boards are removed for transport. Once sauna is set in the final locaon, make sure to screw the boards in indicated points using the supplied screws.3.1. GROUND PREPARATION AND TRANSPORTTransport and unloadingIf sauna is fied with external shower select such locaon so no problems with water drainage occur. In such case it is recommended to prepare an addional drainage of water to its final locaon.Drainage

do zmiany7vingberg.plMODERN SAUNA SCANDIT 5 3. INSTALLATION NOTE: Connecon to external electrical installaon must be carried out by authorised electrician only.A switchboard equipped with residual current device and separate circuit breakers for all auxiliary circuits (heang, internal lighng, external lighng, sound system, etc.) is installed on the rear wall.úChromotherapy system RGB Ruben DesignAccording to a selected configuraon SCANDIT sauna can be equipped with:úBluetooth Speakers3.2. ELECTRICAL CONNECTIONúHUUM UKU Local heater control system (standard) or WiFi and GSM control system (addional opons)The Huum electric heater has already been pre-installed in the sauna. In order to use the sauna, electricity must be connected to the sauna separately before stones will be placed in the heater. You can find more informaon in the user instrucons of Huum available on manufacturer`s website: www.huum.eu.P30430mAS303B16S301B10NPEACDCLNRGB 1RGB 2External switchboard IP66TemperaturesensorControlpanelUKUHUUMheater9kWLED lighting inside saunaBluetoothsound400V cable with adequate cross-secon (min. 5x2.5mm2 up to 20m), with adequate current protecon (S303 B16A)Controller DoorsensorController

MODERN SAUNA SCANDIT 5
3. INSTALLATION
Make sure that heang elements are not bent! (pic.2)3. Place the stones starng with lower part of basket (pic.1). Pick stone sizes alternately to fill voids.1. Before pung stones it is recommended to wash them with water to remove dust.2. Sorng of stones according to three sizes will make it easierto stack them properly in place.4. Stack the smallest stones between heang elements by pung them not too ghtly so there is sufficient aircirculaon around them. When stones are put too close to each other, heang elements can overheat and thus slow down sauna heang.5. The external surface of the stone container must be stacked full as ghtly as possible so the heang elements ATTENTION! A TOO SPARSELY FILLED STONE CONTAINER CAUSES FIRE HAZARD!Video instruconsCorrect placing of stones has a very significant impact on further use,lifespan of the sauna heater and safety!(pic.1)(pic.2)(pic.3)83.3. CORRECT STACKING OF STONESvingberg.plare not visible (pic.3).

MODERN SAUNA SCANDIT 5 4. USE OF SAUNA 9vingberg.pl§To turn on the control panel, start or end the heating, press the button once briefly.§During heating, the heating icon will appear above the temperature value.§The target temperature is displayed in the upper corner of the screen. Turn the knob to adjust the temperature.§To acvate the mer funcon press and hold the buon for 3 seconds. Aer selecng the desired me the mer can be turned off by short pressing the buon. The mer funcon will not be acvated without pressing the buon again!§Aer the heang ends or aer using the buon the control console will turn off.4.1. CONTROL PANEL OPEARATION§The current temperature is displayed in the centre of the screen. § The screen is always acve during heang. Heating time Reset to defaults WiFi settings 4.2. SETTINGS MENU§The child lock will automatically turn on when the screen of the control console turns offTemperature unit To get in the settings menu, press and hold the button for 10 seconds.Child lockSelect between C (Celsius) and F (Fahrenheit). You can select between smart and simple heating algorithms:Exit the Menu §When the child lock is on, hold down the button and turn it by quarter to the right, then back to the beginning, next turn by quarter to the left and back to the beginning to activate the screenWith a simple heating algorithm, all of the heating elements will be turned off as soon as the target temperature is reached. With a smart algorithm, the heating elements start turning off gradually one by one before the target temperature is reached.Depending on intended use of sauna you can select heating timeof 3, 6 hours for private saunas, 12 hours for semi-public saunas and 18 hours for public saunas. When you use the mobile app, it is possible to choose the heating period.§The child lock function can be turned on from the settings menu.Heating algo

MODERN SAUNA SCANDIT 5 4. USE OF SAUNA §Connect control panel idenfier (1XXXXX) to your user account. Idenficaon number and sauna code can be found on main module label.Opon with UKU GSM controller§Control panel is connected to network and ready-to-use if symbol is indicated in status bar.§Create user accountA special mobile app to be installed on smartphone is dedicated to operate a heater equipped with UKU Wi-Fi or GSM controller. Thus, the heater can be controlled from outsidethe sauna. Just download HUUM app from app site:4.3. CONTROL WITH MOBILE APP (OPTION)§Check whether all the funcons of the mobile app are working properly, and your commands actually reach the sauna. Commands should be executed within 60 seconds. If funcons of mobile app do not work, contact the manufacturer: [email protected]In case of selecng remote control through GSM network opon, the controller has a SIM card which will be acvated aer connecng sauna to user account in the app (on-line acvaon is effected within 30 minutes).§GSM control panel uses mobile data and is subject to annual fee. Tesng the funcon in thefirst year is free. Aerwards annual fee applies. Payments are made with credit card in mobile app. If connuaon to use mobile app is not acvated, sauna can only be controlled using the control panel.§Go to “Wi-Fi sengs” and select “SSID”IOS - App Store, Android - Google Play, app.huum.euOpon with UKU Wi-Fi controllerWi-Fi modem is 802.11 b/g/n compable. Control panel is compable with 2.4 Ghz networksonly. Connecon will fail if 5 GHz network has the same name as 2.4 Ghz network. Control panel does not support Wi-Fi names and passwords longer than 20 characters.§Using UKU control panel go to Sengs menu by pressing and holding the buon for 10 seconds.
Aer launching the app:
§Select desired Wi-Fi network and enter the password§Aer entering the password, select “Connect” and follow on-screen instrucons.10vingberg.pl

MODERN SAUNA SCANDIT 5 4. USE OF SAUNAWELLNESS PROGRAMME buon - select programme mode (readiness indicated by blue colour blinking) and press a programme-specific colour buon. Each programme lasts for 20 minutes and is repeated aer compleon of cycle. Automac acknowledgement aer 3 seconds indicated by blue colour blinking again. Descripon of programmes can be found on p. 12.DREAM LIGHT REMOTE CONTROLSCENE buon - if pressed with lights off, the last set colour configuraon isselected. When lights are off, this buon is used to toggle between upper and lower lighng secons.Mode buons (-), (+) - decrease, increase brightness and pulsaon duraon. ON/OFF buon - turn white light on/off.COLOURS buons – turn on/off the system with a selected single colour in all scenes or in a selected scene. Longer press - seng colour illuminaon pulsaon.WHITE buon – short press; turns on/off white colour (OPAL) illuminaon.colourseleconbuonsenable/ select:last scene, upper/lower light4.4. CHROMOTHERAPY SYSTEM (OPTION)MODE (-)MODE (+)turn on/ offwhite light; longerpress: 20min. operaon modeWellnessprogrammes/ customprogrammes11vingberg.pl

MODERN SAUNA SCANDIT 5 4. USE OF SAUNA Seng own colour sequences is possible in a fixed me of 20 minutes aer a long press of“P” buon (>3 seconds). Pressing a colour buon adds colour to a programme. A programme comprises max. 20 parts. The number of selected colours divides this me to even periods of illuminaon, e.g.: with 2 selected colours – each selected colour illuminates for 10 minutes each, and with 5 selected colours – each selected colour illuminates for 4 minutes each. + ADVENTURE + ORANGE COMPLEMENTATION - GREENA programme is acknowledged and started by pressing “P” buon or automacally aer 3 seconds, which is indicated by blinking green colour twice. When lights stop blinking aprogramme is started. RELAX - BLUE INSPIRATION - RED CIRCULATION - WHITE DEMO PROGRAMMEProgramming example: ENERGY - YELLOW MEDITATION - VIOLETWELLNESS PROGRAMMES (colour sequence and duraon in minutes) vingberg.pl12422,53242,5521,51,250,51,251,552233525522335511135451232142>3s.++++4.5. BLUETOOTH SOUND SYSTEM (OPTION)Note: The system is intended to operate with one device, and aempng to connect any other can disturb operaon of the system. If you aempt to reconnect and error message appears, reset the system by disconnecng power supply and connecng it again aer approx. 10 seconds.Sauna with Bluetooth sound system is equipped with two speakers under sauna benches. Thesystem appears on device list as PAM2P. Aer connecng to Bluetooth sound system, a beepis heard.A sequence of red 3x, yellow 1x indicates illuminaon of red colour for 15 minutes, then yellow colour for 5 minutes.

MODERN SAUNA SCANDIT 5 5. CARE AND MAINTENANCE13vingberg.pl5.1. CARE OF THERMOWOOD®ThermoWood boards are brown in cross-secon, therefore even if they were not protected with oil for a long me, it is possible to restore their original appearance. Please note that regular protecon of wood is much less labour-intensive compared to cleaning and renovaon of its coang aer a longer period. Regular cleaning of boards from dust and debris significantly extends the period when protecon is effecve.Before maintenance clean wood surface thoroughly with sponge or plasc coarse brush and dry.NOTE! Provide protecon to external surface of sauna only.Clean sauna aer each use. To keep the interior clean, use agents such as semi-liquid grey soap or products dedicated specifically for sauna care, e.g. Harvia Sauna Cleanser. Vingberg saunas are manufactured from the highest-quality Scandinavian pine, addionally subjected to thermal treatment in accordance with technology patented in Finland - ThermoWood®. Applicaon of ThermoWood® in construcon of saunas increases dimensional stability of wood.For maintenance and protecon from soiling (sauna chairs and floor) use, e.g. Harvia paraffin oil for sauna impregnaon. Note: the oil makes ThermoWood darker, therefore before use, please check effects in a less visible area.ThermoWood® also shows very high resistance to weather and is maintenance-free, if greying is allowed. To prevent wood from gaining grey nt, it can be coated with stained or pigmented wood oil, wax, stain, varnish or paint which all contain UV filter (once-twice a year), e.g. Bona Decking Oil or Tikkurila Vall Wood Oil.5.2. CARE OF SAUNA INTERIORIf necessary, remove stubborn stains and signs of discolouraon by slightly sanding them with fine sandpaper.In summer when sauna is not used it is advisable to put a bucket of water inside to reduce drying of wood.

2402452362302262202308MODERN SAUNA SCANDIT 5 14 6. TECHNICAL DATA 6.1. EXTERNAL DIMENSIONSvingberg.pl

6.2. SPECIFICATION AND EQUIPMENT6. TECHNICAL DATAMODERN SAUNA SCANDIT 5 standard equipment addional opon15vingberg.pl
External dimensions in cm (W/L/H)Sauna areaAREA AND DIMENSIONSNumber of usersTotal areaWeight
235 / 225 / 2455 m²4,1 m² 2-4ca. 1,5 t
Cerfied Scandinavian spruce C24Elevation protection with wood oilVercal ThermoWood® façadeCONSTRUCTIONDouble tempered glazing (tined glass)Complete outside insulaon with stone woolGlazing package Intima black
●●●●oo
Walls and floor made from ThermoWood®Ceiling and benches made from AspenINTERIORKarava panels - walls and ceiling
●●o
HUUM Drop electric heater 9kWHUUM Hive electric heater 9kWSauna accessories premiumSAUNA EQUIPMENTSauna accessories Tylö Brilliant Black
oooo
FUNCTIONALITYInternal LED lightening (white)Chromotherapy system RGB Ruben DesignExternal LED lighteningBluetooth Speakers
oooo

MODERN SAUNA SCANDIT 5 7. WARRANTY TERMS Our saunas are covered by 24-month Warranty against any defects in material and producon. The Warranty is effecve if the user is familiarized with instrucon manuals of sauna and heaters, and follows guidelines therein.NOTE! This Warranty is not applicable to products intended for commercial use. For commercial use, the Warranty is given for 6 months.źThe Warranty does not cover defects resulng from:źThe Warranty does not cover possible defects that are typical for natural wood materials, such as change of colour, discolouraon, sagging, change of humidity, cracking and other similar effects. -improper use or performing repairs by unauthorized personnel, incorrect installaon, maintenance, storage and transport of the product,źThe Warranty does not cover any damages caused by frostbite, as when following instrucon manual, such damages can be avoided.źThe Warranty does not cover addional costs related to assembly of sauna, such as construcon of plaorm or disassembly of the exisng infrastructure.-incorrect seng on uneven and unstable substrate,źIn the cases covered by the Warranty, immediately contact your vendor.-damages being result of random events, force majeure events (fire, flooding, lightning, etc.).-mechanical, chemical, thermal damages, and damages resulng from use of non-original materials or materials not in compliance with recommendaons of the manufacturer of materials, źThe Warranty does not cover wear and tear parts and consumables, such as heang elements, heaters, light bulbs.vingberg.pl16
