Vinservice LIFE 50 Installation guide

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
I
REV. 17/09/19
OPERATION AND MAINTENANCE BOOK
DOCUMENT CODE: 0150LIFEENG.000
VINSERVICE s.r.l. Via G. Falcone, 26/34 24050 ZANICA (BG) Italy Phone: [phone] Fax: [phone]
www.vinservice.it e-mail: [e-mail]
LIFE
50 - 65 - 100 - 115 - 130 -145 -175 -250
serial number:
R290

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
II
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
III
REV. 17/09/19
SYMBOLS AND SIGNS
Within this document, as well as directly on the casing or inside the appliance, graphics
symbols are use to draw the operator’s attention instantly. According to the situations,
such symbols may indicate the obligation to operate in the manner specied, any possible
occurrence of dangerous situations or the prohibition to carry out the actions specied.
OBLIGATION SIGNS
• This document must be consulted before operating the applian-
ce; therefore it must be kept integrally and stored in a safe place
in order to be consulted also in the future, any time it is necessary.
This document may not and must not be tampered with nor dama-
ged in any way.
• Operations which must be carried out by suitably qualied and
expressly authorized sta compulsorily.
• Obligation to wear suitable personal protection appliances (DPI)
which must be supplied by the employed before starting any ope-
rations specied.
• Obligation to turn o and disconnect the appliance from the
electricity grid before carrying out the operations specied; for in-
stance, installation, lling, maintenance and specic cleaning ope-
rations.
• Obligation to follow all legal obligations in force on the disposal
of electric and electronic waste.
PROHIBITION SIGNS
• Indicates that access to a specic area of the appliance is prohibi-
ted or that an action is expressly prohibited and not allowed.
DANGER SIGNS
• Operations or situations in which personnel must exert extreme
caution due to general hazard or dangerous voltage.
• Zones subject to low or high temperature
• Possible presence of condensate or leaks which can cause slip-
ping or injuries.
• Hazard from electromagnetic interference or exhalation of highly
inammable vapours. Possible risk of explosions.
SIGNS INDICATING THE NEED TO PROCEED WITH UTMOST CAUTION
• Fire danger
TABLE OF CONTENTS
CAUTION!
The working of this appliance is based on a closed-circuit compressor ope-
ration.
lled with R290 gas. This gas does not contain CFC and is respectful of the
ozone layer of the earth, but it is ammable. Therefore it is mandatory to
abide by the following instructions: Make sure that the vents openings on the
device casing or inside it are always kept free from any kind of obstructions.
• Do not use mechanical any appliances or other means to accelerate the
defrosting process inside the appliance, except for those expressly re-
commended by the manufacturer.
• Do not damage the coolant circuit in any way.
SYMBOLS AND SIGNS ................................................................................ II
SAFETY INSTRUCTIONS............................................................................. IV
PREVENTION OF ACCIDENTS AND RESIDUAL RISKS ............................ V
LIFTING AND HANDLING........................................................................... VII
PURPOSE OF DOCUMENT.......................................................................... V III
SUPPLY CONDITIONS................................................................................. IX
REFERENCE STANDARDS.................................................................... X
QUICK GUIDE .............................................................................................. 1
FIELD OF APPLICATION....................................................................... 1
INSTALLATION ...................................................................................... 1
MAINTENANCE ........................................................................................... 3
TROUBLESHOOTING ............................................................................ 4
MACHINE PARTS......................................................................................... 5
TECHNICAL SPECIFICATIONS ................................................................... 7
MACHINE PARTS......................................................................................... 8
LIFE 50-100-130 (VERTICAL) MACHINE PARTS ................................. 8
LIFE 65-115-145 (HORIZONTAL) MACHINE PARTS............................ 9
LIFE 250 (HORIZONTAL) MACHINE PARTS ........................................ 10
LIFE 175 (HORIZONTAL) MACHINE PARTS ........................................ 11
MAINTENANCE ..................................................................................... 12
TROUBLESHOOTING ............................................................................ 13
TECHNICAL DRAWINGS AND DIMENSIONS ............................................ 14
TECHNICAL DRAWINGS LIFE 50 ......................................................... 14
TECHNICAL DRAWINGS LIFE 65 ......................................................... 15
TECHNICAL DRAWINGS LIFE 100 ....................................................... 16
TECHNICAL DRAWINGS LIFE 115 ....................................................... 17
TECHNICAL DRAWINGS LIFE 130 ....................................................... 18
TECHNICAL DRAWINGS LIFE 145 ....................................................... 19
TECHNICAL DRAWINGS LIFE 175 ....................................................... 20
TECHNICAL DRAWINGS LIFE 250 ....................................................... 21
GENERAL WIRING DIAGRAM............................................................... 22
NOTES.......................................................................................................... 23
DECLARATION OF CONFORMITY ............................................................. 26

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
IV
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
V
REV. 17/09/19
PROFESSIONAL USE ONLY
This device may be operated by children at least 8 years of age and people
with diminished physical, sensory or mental abilities, or even lacking exper-
tise or the necessary operating ability, as long as they are closely watched
or have received instructions relating to the safe use of the device and the
understanding of any relevant dangers. Children must not play with the ap-
pliance. Unattended children must not be entrusted with the cleaning and
maintenance intended for the operator.
This appliance is suitable for residential use or similar uses, such as:
- Canteens for employees in shops, oces and other workplaces
- Rural lodges and hotel-motel customers or other residential contexts
- Bed & breakfast-type environments
- Catering and similar non-commercial applications
“SAFETY INSTRUCTIONS”
READ THOROUGHLY BEFORE INSTALLING OR USING THE APPLIANCE.
ALWAYS TURN THE APPLIANCE OFF AND DISCONNECT THE POWER CABLE FROM
THE ELECTRICITY OUTLET BEFORE OPENING THE INSPECTION PANEL OR ACCESSING
INSIDE THE CASING ANYWAY.
• The cable must be left disconnected until all openings and panels have been repositio-
ned in their original position and the screw-fastened parts re-tightened.
• This appliance MUST NOT be operated by unqualied people, or lacking experience in
the use of the same, or not using it in compliance with the instructions of this manual
or of the documents annexed.
• This appliance has been designed to cool beverages or food liquids anyway; its featu-
res are duly described in this manual.
PROHIBITED USES
It is expressly prohibited to use the appliance or parts of it in explosive environments. The
appliance must NOT be installed or used in environments saturated with gas or volatile
explosive substances. The appliance may NOT be use for purposes or applications other
than the cooling of beverages or food liquids. Beverages or food liquids to cool must NOT
be highly volatile or inammable, such as to cause a re.
Vinservice recommends cleaning the device thoroughly before putting it into service,
using a suitable cleaning product.
After removing the appliance from the packaging, make sure that:
1. The ground or place where the appliance is to be installed has a suitable bearing ca-
pacity or is absolutely even.
2. The appliance is installed far from heat sources, dripping or humidity.
3. The condenser and the ventilation grilles are completely free. We recommend to re-
spect a distance of minimum 30/40 cm around all vents and walls, in order to ensure
suitable air circulation
• The appliance must not be installed in an area where water jets or other liquids can be
used.
• The appliance must not be placed on a kitchen oor. The appliance must be installed
horizontally.
• The appliance must be installed in a place where operation and maintenance are restri-
cted to qualied sta only.
• The “overow” hole must be connected with a suitable water drain BEFORE lling the
tank, by means of a special properly-xed exible plastic draining pipe.
IMPORTANT
The electrical appliances must be handled by adopting special precautionary
measures in accordance with their electromagnetic compatibility (EMC).
Make sure to abide by the following direction during installation and opera-
tion of the system.
-maximum allowed impedance of the electric power line is 0.165Ohm
PREVENTION OF ACCIDENTS AND RESIDUAL RISKS
• Even if this appliance has been manufactured in full respect of the strictest safety
measures, for obvious reasons it is not possible to foresee all types of installation and
environments where it is installed. Therefore it shall be the customer’s responsibility to
advise the manufacturer about special installation conditions.
• The instructions provided by this manual do not substitute any safety instructions
and technical specications for installation and operation. They neither substitute any
common sense rules and safety regulations in force in the country of installation.
• The operators must be duly informed of the above. Therefore they must read and
follow all technical instructions provided by this manual and the documents annexed.
Store the technical documents supplied with the equipment carefully.
• VINSERVICE will not held responsible in case of failure to comply with the instructions
for installation.
• Do not use the machine in case of malfunctions.
• The machine has been designed based on the strictest energy saving regulations in
force in the country of manufacturing, therefore the customer shall avoid any useless
waste of energy.
• The machine must not be installed outdoor or in unfavourable environmental condi-
tions (exposure to sun, rain, snow, wind, heavy humidity, etc.) Make sure that there are
no electromagnetic interferences.
• The machine has not been designed to work in environments subject to danger of re
or explosion.
• It is absolutely forbidden to tamper with and/or deactivate or modify the safety devi-
ces.
• The movable panel can be removed only in case of installation, lling or maintenance
operations and the power cable must always be disconnected. On completion of such
operations tighten the screws down again.

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
VI
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
VII
REV. 17/09/19
• The sta in charge of maintenance must inform the owners of any failures or damage
due to wear or aging, so as to allow the immediate restoration of all safety measures.
• Do not carry out any improvised repair. For repair purposes only spare parts approved
of by the machine manufacturer must be used exclusively (and accordingly installed,
of course). The various parts must be reassembled in the original positions and condi-
tions.
In case the power cable is damaged, it must be replaced by the manufacturer or its tech-
nicians or by equally expert sta, in order to avoid any hazard of an electrical nature.
• The cleaning of the machine must be carried out by means of suitable equipment and
detergent products so as to avoid any damage to the machine. It is strictly prohibited
to use water for machine cleaning or washing. The food circuits must be washed and
cleaned by means of suitable non-toxic products.
- Installation, removal and/or reinstallation in another place and all extra-
ordinary maintenance operations must be carried out by specialized sta
exclusively and all instructions followed accurately.
- Even if VINSERVICE has eliminated, as far as possible, any sharp edges,
be advised to sue personal protection devices such as leather gloves, du-
ring operations involving sheet metal, condenser blades (H), self-tapping
screws, etc.
It is advisable to lighten the machine installation site suitably in order to ensure that all the
necessary operations be carried out in safe conditions.
• The noise emission level (Noise) of each machine working at full capacity and in cor-
rect maintenance conditions is lower than 70 dBA, therefore absolutely harmless for
the operator. Should the noise level be exceeded for diverse and unforeseeable instal-
lation reasons, apply for the interventions of a qualied technician.
• Handling and/or lifting of heavy objects (over 30 kg) must be carried out with the aid
of suitable lifting equipment.
• Cleaning and maintenance operations must be
carried out after turning o the machine and wai-
ting for 5 minutes at least since the power cable
was disconnected.
• The sta must NOT come close to the machine
bare-footed or wet-handed. - The sta must use
suitable personal protection devices. - Any beve-
rage leaks may cause slipping hazards.
LIFTING AND HANDLING
• The machine is usually delivered inside a cardboard box, with suitably protected cor-
ners. The packaging, if dry and intact, is self-supporting and sturdy enough to stand
lifting and handling.
• If the packaging is wet, be cautious while lifting it and make sure that special lifting
belts have been placed in a central position.
• The overlapping of machines is allowed only if the packaging is perfectly dry and in-
tact.
• The machines should be lifted one at a time.
• The lifting equipment (ropes, polyester belts, chains) must be designed to stand the
machine weight: the opening angle must be equal or lower than 50°-60° in order to
avoid any shocks or damage to the packaging and/or the sheet metal of the machine
body.
• Even if this appliance has been manufactured in full respect of the strictest safety
measures, for obvious reasons it is not possible to foresee all types of installation and
environments where it is installed. Therefore it shall be the customer’s responsibility to
advise the manufacturer about special installation conditions.
• The instructions provided by this manual do not substitute any safety instructions
and technical specications for installation and operation. They neither substitute any
common sense rules and safety regulations in force in the country of installation.
• During handling, check that the load weight is
distributed along the ropes correctly and avoid
sudden movements which may cause dangerous
oscillations.
• Keep in mind that all the packaging elements
(wood, nails, paper, cellophane, metal staples,
adhesive tape, belts, ropes, etc.) may cut and/
or cause injuries when handled carelessly. They
must be removed using special tools and kept out
of the reach of unaware people (e.g. children).
Such rules hold also for tools used to remove
the packaging (scissors, hammers, pliers, knives,
etc.) The packaging must be eliminated and di-
sposed of according to the regulations in force in
the country of installation.
• On packaging opening, check that the machine
does not show any damage signs and that no par-
ts or accessories are missing.
• In case you detect any damage or spoilage, im-
mediately stop the operations and contact the
carrier or the shipping agent and inform VINSER-
VICE at once.
The machine must be transported on rubber wheels by suitable
vehicles and in suitable manner, its parts being protected against
shocks, humidity, vibrations, etc.
• The machine must be transported vertically; refer to the signs
and the writings on the packaging.
• Some models are equipped with special supports (D); in this
case make sure not to leave the machine on an inclined plane,
in order to avoid any dangerous situations.
• The danger signs must always be legible and clean.
• When the machine is stationary or newly-turned o, some parts may be overheated,
for instance the motor of the stirrer (F) or the condenser air grille, therefore the ope-
rators must be cautious when touching the machine.
• In case of re, use carbon dioxide extinguishers and automatic suction devices to ght
the re in closed environments. Be cautious with inammable beverages.
Some models are equipped with special supports (D); in this case make sure not to leave
the machine on an inclined plane, in order to avoid any dangerous situation.

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
VIII
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
IX
REV. 17/09/19
PURPOSE OF DOCUMENT
This document (OPERATION AND MAINTENANCE MANUAL) is a useful guide to safe
working and provides instructions for all operations necessary to keep the machine in safe
running conditions.
• The instructions provided by this manual do not substitute any safety
instructions and technical specications for machine installation and ope-
ration. They neither substitute any common sense rules and safety regu-
lations in force in the country of installation.
• The sta in charge of the machine must read this manual carefully; the
operators must be advised about the risks resulting from its operation.
• This machine must be exclusively used by staff skilled in its working
and maintenance, accustomed to carrying out the duties described
and sufficiently trained in their execution. The staff must be able to
suitably carry out the operations described in this manual, as well as
ensure accurate checks and safe conditions.
• It is strictly prohibited to use unqualified staff for any installation
and maintenance operations.
• Since it is impossible to report all the machine working data, it is
essential for the machine operators to be well acquainted with the
basic knowledge of its working in order to carry out all functions
properly.
• The machine operators must use all the personal protection devices
provided for by the law: leather gloves when using sharp or pointed
objects or hot parts.
• VINSERVICE declines any responsibility for damages of any type that
may arise from non compliant or unwise usage of the machine. The ma-
chine MUST NOT be operated by unqualied sta or even by qualied
operators in an unconformable manner as to the instructions provided in
this manual and annexed documentation.
• The use of this equipment for purposes other than those intended is ab-
solutely forbidden.
The machine was designed to cool beverages and food liquids and provi-
ded with the possibilities and features described in this manual.
Usage limits:
- Environment temperature allowed: + 10/43 °C;
- Operating pressure allowed: max. 7 bar;
- Do not use liquids or beverages with high volatility or ammability de-
gree or that can cause re;
- Insulation thermal class 1.
Unintended use:
It is strictly prohibited:
• to use the machine or parts of it in ammable environments. The machi-
ne may NOT be operated or installed in environments in the presence of
gases or explosive volatile substances.
N.B. VINSERVICE declines any responsibility for any unsuitable and/or unhy-
gienic conditions in the workplace.
STAFF’S COMPETENCES
APPLICATION FIELD
• VINSERVICE declines any liability for damages of any type that may arise from non-con-
formable or careless usage.
• The distribution of beverages failing to clean and disinfect the machine is absolutely
forbidden.
• The use of this equipment or parts of it for purposes other than those intended for usa-
ge is absolutely forbidden. For instance: Do not dry or warm clothes on the condenser
grille (H). It is dangerous and it might jeopardize the proper working of the machine.
Do not introduce any foreign bodies (bottles or cans) in the tank (C) or in the ice bank.
IMPORTANT
This manual is to be held as an integral and necessary part of the appliance; it must also
be made accessible and available to the persons using it; this manual must accompany the
appliance along the whole useful life of the same; even in case the appliance is transferred
to a subject other than the rst user for any reasons. Any persons using the appliance
are bound to read this manual accurately and thoroughly and to follow all instructions
contained therein scrupulously. VINSERVICE will not be held responsible for any damage
occurred to persons and/or things, as well as to the appliance in hand, should one or more
provisions specied herein not be followed entirely.
The customer and the user of this appliance are bound to respect the intellectual proper-
ty rights of VINSERVICE: according to these, no documents supplied with the appliance,
including this manual, may be altered, edited or sold to third parties without the previous
written authorization from Vinservice.
SUPPLY CONDITIONS
Vinservice will not be held responsible for any installation-related facts or events that are
unconformable with the state-of-the-art or the regulations in force.
Vinservice will not be held responsible for any loss of prot, excepting in case of specic
agreement to the contrary mentioned in the purchase order expressly.
Vinservice will not be held responsible for any kind of damage deriving from unintended
or improper use of this appliance, alterations or tampering with, also resulting from tran-
sport or specic operating conditions, unsuitable or insucient maintenance, tampering
with, use of the product by unqualied sta and use of accessories not provided by Vin-
service as a standard.
Vinservice will not be held responsible for any damage deriving from careless or impro-
per use of this appliance, unconformably with the provisions of this manual and/or the
accessory documentation, both by qualied and unqualied sta. Since during the design
stage it is not reasonably possible to take all variables into account which might occur in
the actual installation conditions, it is the purchaser’s or the user’s specic responsibility
to check and ascertain:
This appliance can be used by children at least 8 years of age and persons
with diminished physical, sensory or mental abilities, or lacking experience or
the necessary knowledge, AS LONG AS they are watched over or the same
have received instructions on the safe use of the appliance or made aware of
any relevant dangers. Children must not play with the appliance. Unattended
children must not be entrusted with the cleaning and maintenance intended
for the operator.
- the environmental conditions of the installation site
- the beverage supply system, including the pressurization system
- the suitable capability of using or installing the appliance from the per-
sons who will use or install the appliance respectively.

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
X
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
1
REV. 17/09/19
It is expressly prohibited to use non-original parts or spare parts; the original parts and
spare parts must be installed in compliance with their intended use anyway.
N.B. Vinservice accepts responsibilities as regards the commercial parts. In case of doubt,
apply for the specic documentation.
VINSERVICE will not be held responsible for the disposal of the parts or materials that are
necessary for the machine operation: refrigerant gas, compressor or pressurized container,
condensers, etc. It is reminded that this is an electric appliance, therefore its parts must
be disposed of in compliance with the regulations in force in the country of installation.
List of attachments
Besides this operation and maintenance manual, the equipment will be supplied with the
following documentation:
- Declaration of Conformity
REFERENCE STANDARDS
This machine is manufactured in compliance with:
-EN 60335 -1;
-EN 60335 - 2 - 75;
-EN 60335 - 2 - 24;
-2014/35/EU
-2014/30/EU
-2006/42/EC
QUICK GUIDE
FIELD OF APPLICATION
VINSERVICE does not assume any responsibility for damage of any kind deriving from
improper use of the appliance or anyway unconformable with the manufacturer’s in-
structions. This appliance MUST NOT be operated by unqualied people, or lacking
experience in the use of the same, or not using it in compliance with the instructions of
this manual or of the documents annexed.
Prohibited uses:
It is expressly prohibited:
• To use the appliance or parts of it in environments subject to ammability dangers.
The appliance must NOT be installed or used in environments saturated with gas or
volatile explosive substances.
• VINSERVICE does not take any responsibilities in case of unsuitable conditions, also
from a food safety viewpoint, on the work environment. Vinservice declines all re-
sponsibilities for damage of any kind deriving from improper use of the appliance or
anyway unconformable with the manufacturer’s instructions.
• It is expressly prohibited to use this appliance or parts of it for purposes or applica-
tions other than those understood as “ proper use”.
INSTALLATION
CAUTION: VINSERVICE advises cleaning the equipment before start-up by means of a
suitable cleaning agent.
After removing the appliance from the packaging, make sure that:
a. The area where the appliance is to be installed has a suitable bearing capacity or is
absolutely even.
b. The appliance is installed far from heat sources, dripping or humidity.
c. The condenser and the ventilation grilles are completely free. We advise:
d. Respecting a distance of minimum 30/40 cm around all vents and the walls, in order
to ensure suitable air circulation.
The appliance is not suitable for installation in an area where water jets may be used. The
appliance must be installed horizontally. The appliance must be installed in a place where
operation and maintenance are restricted to qualied sta only.
Tank lling
After settling the cooler as indicated for the ordinary operations proceed with tank
lling. Remove the top cover of the equipment and then ll the tank with clean water
without adding any addictives, up to the special level indicator on the tank edge. Then
connect the “overow” drain outlet to a suitable water drain pipe by means of a special
properly-xed exible plastic draining pipe. Close and tighten the covers.
Thermostat adjustment
The standard conguration does not provide for a system automatically adjusting the ice
bank thickness.
There is no need to regulate any thermostat: ice bank production starts as soon as the
equipment is turned on.
QUICK GUIDE
• Using this equipment for purposes or applications other than those the
same has been designed for is absolutely prohibited
This appliance has been designed to cool beverages or food liquids anyway,
its features and performance being duly described in this manual.
Do not use highly volatile or inammable liquids or beverages, such as to
cause a re.

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
2
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
3
REV. 17/09/19
QUICK GUIDE QUICK GUIDE
The probe positioned inside the water tank reads the ice bank thickness and regulates
the compressor working in order to keep the ice bank constant during running.
OPTIONAL: mechanical thermostat (TM)
The mechanical thermostat can be adjusted by means of a at-head screwdriver. The ther-
mostat needs to be positioned, according to the operating conditions:
Hydraulic connections
The equipment is supplied with ready hydraulic connections. It contains steel cooling coils
ready to be connected to the inlet and outlet cooling beverage tubes.
Appliance start-up
The quick chiller operation is completely automatic and does not require any particular
operation by the operator. Anyway, rst of all make sure that there are no leaks present in
the system circuits, including the inlet and outlet beverage circuits, before start-up. This
check must be carried out periodically, as the appliance can be kept running permanently.
After making sure that all previously described conditions are present and necessary ope-
rations duly carried out (electrical connections, hydraulic circuit connection, tank lling,
etc...), power on the machine by turning the main bipolar switch (IG); check that the
built-in warning light goes on. • After powering on, the fan (M), the stirrer pump (F) and
the compressor (H) start working. After about 3-6 hours (according to the model and the
installation conditions), the compressor and the fan stop, as a suitably-thick ice bank has
formed. Anyway, the stirrer keeps on running and moving the tank and recirculation water
in the cooling coil, to facilitate the heat exchange (cooling of beverages in the cooling coil
and in the dispenser column).
The formation of the ice bank around the evaporator (O) takes place gradually and starts
immediately after the equipment is started up.
The tank-dipped probe (G) checks the formation of the ice bank and controls the cooling
system working by means of an electronic regulator (TE), in order to keep the ice bank
constant during the appliance operation.
On request a mechanical thermostat (TM) and a transformer (TR) for additional food com-
ponents can be installed.
• Winter operation: the notch visible on the adjusting pin is posi-
tioned on a value between 1 and 6 according to the temperature
of the installation environment. The lower position (1) is recom-
mended for very low temperatures of the installation site (3°
- 4°C). the following positions are to be selected according to
the increase in temperature of the installation environment: any
10°C of temperature increase require the selection of a higher
position.
• Summer operation: adjust the thermostat so as to bring the thi-
ckness of the ice bank desired (between 20 and 40 mm) around
the evaporator.
MAINTENANCE
Ordinary maintenance
CAUTION: ALWAYS TURN THE APPLIANCE OFF AND DISCONNECT THE POWER CABLE
FROM THE ELECTRICITY OUTLET BEFORE OPENING THE INSPECTION PANEL OR AC-
CESSING INSIDE THE CASING ANYWAY.
THE CABLE MUST BE LEFT DISCONNECTED UNTIL ALL OPENINGS AND PANELS HAVE
BEEN REPOSITIONED IN THEIR ORIGINAL POSITION AND THE SCREW-FASTENED PAR-
TS RE-TIGHTENED. THE APPLIANCE MUST NOT BE CLEANED WITH A WATER JET OR
OTHER LIQUID.
Ordinary maintenance can be carried out by common personnel in strict compliance with
the instructions given below.
• Daily: check for leaks in the various system circuits.
• Every six months: clean the condenser (L) blades with a brush and/or a soft brush
and/or a compressed air jet. CAUTION: Wear protective leather gloves: the condenser
blade edges are sharp and may cut your hands. Do not bend the blades.
• Every month, or as needed, sanitize or wash the cooling coils (A) through which the
beverages ow. Wash and rinse them with plenty of drinkable water. Only use deter-
gents suitable for food industry according to the supplier’s instructions.
• Every month: check that the “overow” discharge opening is not clogged by ice, dirt
or residues of any kind.
• Every month: clean the machine, remove any residues (including laments, paper frag-
ments or other materials) which may prevent the normal working of the system or of
the various motors, in order to avoid overheating.
Extraordinary Maintenance
Extraordinary maintenance must be performed by specialized personnel exclusively.
• Every year: change the tank water according to the procedure reported below.
Change of the tank water
This procedure is to be carried out any time there is a need to change the tank water.
1. Turn o and disconnect the machine power cable from the electric socket
2. Remove the upper covers
3. Wait until the ice bank has fully thawed
4. Empty the tank through the draining pipe located on the side of the machine (if any)
or drain it into a suitable discharge system
5. Fill the tank with clean water up to the level indicated on the tank edge
6. Remove the upper covers
7. Reconnect the power cable and restart the appliance
ICE
BANK
STOP
3
4
5
26
1
E
F
G
Q
O
A
TR
B
M
L
D
H
N
R
C

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
4
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
5
REV. 17/09/19
TROUBLESHOOTING
ANOMALY DETECTED POSSIBLE CAUSES CHECKS AND POSSIBLE
SOLUTIONS
• The appliance does not
work and the main switch
(IG) warning light does not
turn up
• Power failure
• A thermal protection has
been temporarily triggered
• Check that the power
cable is plugged into the
electric socket properly
• Check for disconnected
wires or cables; check the
electric system of the instal-
lation site
• The machine does not
cool, the fan (M), the stirrer
(F) and the compressor (H)
do not work)
• The coolant circuit is le-
aking or has an insucient
operating pressure
• Check the refrigerating
circuit pressure or any lea-
kage of coolant liquid; re-
store the correct operating
conditions
• The refrigerating unit is
working, but the stirrer (F)
is stationary
• Stirrer motor overheating
• Stirrer motor breakdown
or power drop
• Check the electric system
• Replace the stirrer
• The machine does not
cool (the fan (M), and the
compressor (H) are not
working but the stirrer (F) is
working
• System overheating
• Lack or insucient water
level in the tank
• Check the probe (E)
• Replace the probe
• Fill the tank
• The machine does not
cool (the compressor (H) is
not working but the fan (M)
and the stirrer (F) are wor-
king
• Power supply failure on
the compressor
• Compressor overheating
• Compressor breakdown
• Check the electric con-
nections and the electric sy-
stem of the appliance
• Replace the compressor
• The compressor runs con-
tinuously and does not stop,
causing the beverages to
freeze
• Thermostat failure
• Probe (G) failure
• Replace the faulty parts
• Contact Vinservice Custo-
mer Service.
• The machine does not
cool (the fan (M) is not wor-
king, but the compressor
(H) and the stirrer (F) are
working)
• Power supply failure on
the fan motor
• Fan motor failure
• Check the electric con-
nections and the electric sy-
stem of the appliance
• Replace the fan motor
• The stirrer (F) motor is
noisy
• Anomaly on bearings or
motor shaft supports
• Pump supports damaged
• Replace the stirrer motor
• Replace the pump
• The system is working re-
gularly but it is not possible
to tap beverages
• Beverage conduits are
dirty or clogged
• Clean or replace the parts
concerned
MACHINE PARTS
SIGNS
ACOOLING COILS MFAN
BPUMP NEXPANSION VALVE
CDISTRIBUTOR OEVAPORATOR
DWHEELS (OPTIONAL) PHANDLES
ETANK QOVERFLOW
FSTIRRER RREMOVABLE PANEL
GPROBE TE ELECTRONIC THERMOSTAT
HCOMPRESSOR TM MECHANICAL THERMOSTAT
IG MAIN SWICH TR TRANSFORMER (OPTIONAL)
LCONDENSER
E
F
G
Q
C
A
TEIG
M
L
D
H
N
TR
O
B
R

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
6
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
7
REV. 17/09/19
DESCRIPTION OF THE MACHINE
The machine is made up of a cooler installed inside a metal casing to protect the movable
parts.
• INTENDED USAGE:
The machine is intended to be used for both cooling and dispensing pre-mixed and post-
mixed beverages, beer, wine and soft drinks, through special plastic and stainless steel
food-specic tubes.
• UNINTENDED USAGE
The equipment is not intended for any uses other than those specied herein. Do not use
the machine for non-food liquids.
Since this equipment has not been designed to operate in excessively humid environmen-
ts, outdoors or in a explosive atmospheres, the installation and use in such conditions is
strictly prohibited
The main external body of the equipment is made of sheet stainless steel. The other parts
of the external body are:
- Openings from which the cooling coils (A) come out;
- Removable panel (R) for water lling and top-up;
- Main switch (IG), mechanical thermostat (TM)
- Support (B)
- Motor (O) of the stirrer (D)
- Overow (Q) tube connection point
TECHNICAL SPECIFICATIONS
Identication of machine and manufacturer.
Identication of machine and manufacturer. The EC plate is to axed in the
position shown by the following gure.
The plates bearing the manufacturer’s name are axed on the machine
side; they must be cleaned regularly and never be removed, damaged, stai-
ned, hidden, etc.
R290
LIFE
50
LIFE
65
LIFE
100
LIFE
115
LIFE
130
LIFE
145
LIFE
175
LIFE
250
Power 1/4 HP 1/4 HP 1/3 HP 1/2 HP 1/3 HP 1/2 HP 3/4 HP 3/4 HP
Type of refrige-
rant gas R290A R290A R290A R290A R290A R290A R290A R290A
Nominal power
(-10°C/+45°C) 539W 539W 697W 849W 895W 1033W 1710W 1742W
Number of coo-
ling coils 1-3 1-3 1-4 1-4 1-8 1-8 1-8 1-10
Tank capacity 18Lt 25Lt 36Lt 36Lt 50Lt 50Lt 70Lt 90Lt
Ice bank 8Kg 12Kg 15Kg 15Kg 23Kg 23Kg 32Kg 40Kg
Cooling capacity
(in +25°C/out-
4°C)
50Lt/
Hour
65Lt/
Hour
100Lt/
Hour
115Lt/
Hour
130Lt/
Hour
145Lt/
Hour
175Lt/
Hour
250Lt/
Hour
Beverage tempe-
rature IN/OUT
+24°C
+4°C
+24°C
+4°C
+24°C
+4°C
+24°C
+4°C
+24°C
+4°C
+24°C
+4°C
+24°C
+4°C
+24°C
+4°C
Supply voltage
/ standard fre-
quency
220/
240V -
50Hz
115V -
60Hz
220V -
60Hz
220/
240V -
50Hz
115V -
60Hz
220V -
60Hz
220/
240V -
50Hz
115V -
60Hz
220V -
60Hz
220/
240V -
50Hz
115V -
60Hz
220V -
60Hz
220/
240V -
50Hz
115V -
60Hz
220V -
60Hz
220/
240V -
50Hz
115V -
60Hz
220V -
60Hz
220/
240V -
50Hz
115V -
60Hz
220V -
60Hz
220/
240V -
50Hz
115V -
60Hz
220V -
60Hz
Rated current 3,1A 3,1A 4,1A 4,9A 5,2A 6A 7A 9,9A
Operating tem-
perature allowed
+10°C /
+43°C
+5°C /
+43°C
+5°C /
+43°C
+10°C /
+43°C
+10°C /
+43°C
+10°C /
+43°C
+10°C /
+43°C
+10°C /
+43°C
Max relative hu-
midity allowed 80% 80% 80% 80% 80% 80% 80% 80%
Weight (unladen
static load) 23Kg 34Kg 35Kg 40Kg 40Kg 40Kg 60Kg 65Kg

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
8
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
9
REV. 17/09/19
LIFE 50-100-130- (VERTICAL) MACHINE PARTS
Description Description
N DESCRIPTION QTY 17 PIPE OUTPUT FRAME 2 34 THERM. PROBE SUPPORT 1
1TANK HOLDER WITH INSERTS 1 18 PIPE OUTPUT MEMBRANE 2 35 PROBE HOLDER TUBE 1
2 TANK 1 19 BOTTOM DIS. PIPE COLLAR 2 36 DEHYDRATOR FILTER 1
3COMPRESSOR SIDE PANEL 1 20 OVERFLOW DRAIN 1 37 POWER SUP. CABLE W 1
4INSPECTION GRID 1 21 DRAIN SEAL 1 38 COPPER CAPILLARY PIPE 1
5CONTROL SUPPORT 1 22 OVERFLOW DRAIN NUT 1 39 SEND COPPER PIPE 1
6CILLER LIFE BASE 1 23 STEEL HANDLE 2 40 RETURN COPPER PIPE 1
7THERMOSTAT SUPPORT 1 24 HANDLE FIX STEEL PLATE 2 41 CHARGE COPPER PIPE 1
8CONDENSER 1 25 EVAPORATOR SPACER D.10 4 42 RETURN PIPE INSULATION 1
9COMPRESSOR 1 26 EVAPORATOR 1 43 OVERFLOW PIPE WASHER 1
10 COMPR. SHOCK ABOSERBER 4 27 FAN MOTOR 1 44 INSPECTION COVER 1
11 ADJUSTING FOOT 4 28 FAN GRID 1 45 PANEL CONSOLE SIDE 1
12 LIGHT BIPOLAR SWITCH 1 29 CONVEYOR 1 46 SERP. OUTPUT COVER 1
13 THERMOSTAT 1 30 LOKRING PLUG 1 47 TANK UPPER BRACKET 1
14 OUTLET 1 31 FAN COIL 1 1 48 SUPPORT BRACKET 1
15 PUMP CABLE CLIP 2 32 SERP. LOCKING SPACER F 4 49 SERPENTINE KIT 1
16 PYTHON PUMP 1 33 SERP. LOCKING SPACER M 4
LIFE 65-115-145 (HORIZONTAL) MACHINE PARTS
N DESCRIPTION QTY 17 POWER S CABLE WIRING 1 34 FAN GRID 1
1CONTROL SUPPORT 1 18 THERMOSTAT BRACKET 1 35 FAN MOTOR 1
2SERPENTINE OUTLET COVER 1 19 SERP. LOCKING F SPACER 4 36 PYTHON PUMP 1
3COMPRESSOR COVER 1 20 SERP. LOCKING M SPACER 4 37 THERMOSTAT 1
4INSPECTION COVER 1 21 PIPE OUTLET FRAME 2 38 FAN COIL 1
5INSPECTION GRID 1 22 BOTTOM DIS. PIPE COLLAR 1 39 EVAPO. SPACER D.10 4
6CONSOLE SIDE PANEL 1 23 THERMOSTAT PROBE SUP. 1 40 DEHYDRATOR FILTER 1
7COMPRESSOR SIDE PANEL 1 24 OVERFLOW DRAIN 1 41 EVAPORATOR 1
8CILLER BASE 1 25 DRAIN SEAL 1 42 SERPENTINE KIT 1
9COMPRESSOR SUPPORT 1 26 LOKRING PLUG 1 43 SEND COPPER PIPE 1
10 TANK 1 27 OVERFLOW DRAIN NUT 1 44 CHARGE COPPER PIPE 1
11 STEEL HANDLE 2 28 COMPR. SHOCK ABSORBER 1 45 COPPER CAPILLARY PIPE 1
12 ADJUSTING FOOT 4 29 HAND. FIXING STEEL PLATE 4 46 PROBE HOLDER TUBE 1
13 PUMP PIPE CLIP 2 30 OVERFLOW PIPE WASHER 2 47 RETURN COPPER PIPE 1
14 LIGHT BIPOLAR SWITCH 1 31 CONDENSER 1 48 FILTER COPPER PIPE 1
15 SOCKET 1 32 COMPRESSOR 1 49 RETURN PIPE INSULATION 1
16 PIPE OUTLET MEMBRANE 2 33 CONVEYOR 1
44
15
34
35
25
26 49
16 17 18
46
32 33 42
40
24 23 3
41 30 21 22 2
20
47
9
10
27
28
31
29
8
48
1
11
6
24
23
7
13
39
38
36
5
14
12
45
37
43
19
4
20 19 42
41 39
27 25
6
37
23
46
18
15
1
14
17
26
44
47
45
40 43
48
31 8
12
38
33
35
34 10
49
28
9
5
32
11
29
7
22
21
16
2
36
3
13
4
24
30

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
10
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
11
REV. 17/09/19
LIFE 250 (HORIZONTAL) MACHINE PARTS
N DESCRIPTION QTY 17 COMPRESSOR 1 34 LIGHT BIPOLAR SWITCH 1
1CILLER BASE 1 18 EVAPORATOR SPACER D.10 6 35 STEEL HANDLE 4
2CONSOLE SIDE PANEL 1 19 DEHYDRATOR FILTER 1 36 PIPE OUTLET MEMBRANE 6
3TANK SIDE PANEL 1 20 FAN GRID 2 37 HAN. FIXING STEEL PLATE 4
4INSPECTION GRID 1 21 FAN MOTOR 2 38 OVERFLOW PIPE WASHER 1
5COMPRESSOR GRID 1 22 REINFORCING PLATE 1 39 SOCKET 1
6SERPENTINE OUTLET COVER 1 23 EVAPORATOR 1 40 WHEEL 6
7COMPRESSOR COVER 1 24 FILTER COPPER PIPE 1 41 CONTROL SUPPORT 1
8INSPECTION COVER 1 25 RETURN COPPER PIPE 1 42 THERMOSTAT BRACKET 1
9DISCHARGE PIPE PROTECTION 1 26 SEND COPPER PIPE 1 43 THERMOSTAT 1
10 PYTHON PUMP 1 27 SERPENTINE KIT 1 44 THERMOSTAT PROBE SUP. 1
11 TANK 1 28 LOCKRING PLUG 1 45 OVERF. DISCHARGE PIPE 1
12 CONDENSER 1 29 COPPER CAPILLARY PIPE 1 46 OVERF. DISCHARGE NUT 1
13 POWER SUP.CABLE WIRING 1 30 TUBO CARICA 1 47 FAN COIL 1
14 PUMP CABLE CLIP 3 31 SERP. LOCKING FSPACER 8 48 FILTER COPPER PIPE 2
15 BOTTOM DIS. PIPE COLLAR 1 32 SERP. LOCKING M.SPACER 8 49 RETURN PIPE INSULATION 1
16 PIPE OUTLET FRAME 6 33 OVERFLOW DRAIN SEAL 1
LIFE 175 (VERTICAL) MACHINE PARTS
N DESCRIPTION QTY 17 PIPE OUTPUT FRAME 2 34 SERP. OUTPUT COVER 1
1TANK BRACKET 1 18 PIPE OUTPUT MEMBRANE 2 35 METAL WASHER 1
2 TANK 1 19 BOTTOM DIS. PIPE COLLAR 2
3COMPRESSOR SIDE PANEL 1 20 OVERFLOW DRAIN 1
4INSPECTION PANEL 1 21 DRAIN SEAL 1
5CONTROL SUPPORT 1 22 OVERFLOW DRAIN NUT 1
6CILLER LIFE BASE 1 23 STEEL HANDLE 2
7THERMOSTAT SUPPORT 1 24 HANDLE FIX STEEL PLATE 2
8CONDENSER 1 25 EVAPORATOR SPACER D.10 4
9COMPRESSOR 1 26 EVAPORATOR 1
10 COMPR. SHOCK ABOSERBER 4 27 FAN MOTOR 1
11 FAN MOTOR 2 28 SERPENTINE KIT 1
12 LIGHT BIPOLAR SWITCH 1 29 PROBE HOLDER TUBE 1
13 THERMOSTAT 1 30 POWER SUP. CABLE W 1
14 OUTLET 1 31 COPPER CAPILLARY PIPE 1
15 PUMP CABLE CLIP 2 32 SEND COPPER PIPE 4
16 PYTHON PUMP 1 33 SERPENTINE KIT SPACER 4
Description
Description
33 45
23
20
21 47
12
11
37
48
78610 16
36
14
30 28 25 29
17
18
44 32
31
27
35
3
15
46
9
38
40
1
22
19
5
43
41
39
13
2
34 42
24
26 4
1
23
5
4
4
6
7
8
9
10
11
12
13
14
18
17
15
16
19
20
23
24
25
26
28
29
30
31
32
33
34
35
22
21

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
12
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
13
REV. 17/09/19
MAINTENANCE
The appliance must not be cleaned by water jetting
Ordinary Maintenance
Ordinary maintenance can be carried out by unqualied sta provided that
the rules reported below are complied with.
• Every day check for any possible leakage.
• Every six months clean the condenser (L) blades by means of brushes and/or com-
pressed air jets. Be careful not to bend the blades. They are sharp, therefore always
wear leather gloves.
• Every month, or as needed, sanitize or wash the cooling coils (A) through which the
beverages ow. Wash and rinse them with plenty of water. Use special food-specic
detergents, according to the manufacturer’s instructions.
• Every month check that the overow tube (Q) is not clogged by ice or dirty or cra-
shed.
• Every month clean the vacuum device from any dust, laments, paper which may
overheat the motors or cause malfunctions.
EXTRAORDINARY MAINTENANCE
Extraordinary maintenance must be performed by specialized personnel exclusively.
• Clean the tank (E) every year.
To this end, drain the tank after the ice bank has totally thawed. DO NOT use sharp
objects which may pierce the tubes or the tank. Never use abrasive products. Correct
cleaning improves the chilling performance. After cleaning, ll the tank as previously de-
scribed with clean water, without any additives, up to 2 cm from the overow tube.
• If the power cable is damaged, have it replaced by the manufacturer, its customer
service or qualied sta in order to avoid any risks.
STORAGE DISASSEMBLY AND DISPOSAL
• If the machine remains unused for long periods, disconnect the power cable, the
electric system and the hydraulic system; drain the machine and clean it, disinfect
and wash the cooling coils. Let the cleaned parts dry out and set them in place; at
this point, store the machine in its original packaging, if available. Never leave the
machine without its original packaging.
• VINSERVICE will not be held responsible for the disposal of packaging materials or
machine parts or products used for its operation, such as refrigerant gas, compressor
or pressurized container, condensers, etc. Therefore the Customer will be held direct-
ly responsible for the disposal of such substances, that are potentially harmful for the
environment.
The appliance must not be cleaned by water jetting
Ordinary Maintenance
Ordinary maintenance can be carried out by unqualied sta provided that
the rules reported below are complied with.
CHANGE OF TANK WATER
When the tank water needs to be changed or disposed of, following this procedure:
1. Disconnect the machine form the power line.
2. Remove the upper cover
3. Wait for the ice bank to be thawed completely
4. Drain the tank through the drain pipe along the machine side
5. Fill the tank up to 2 cm from the overow pipe
6. After repositioning and reconnecting the cooling unit repeat passages 2 and 1 in the
contrary order.
TROUBLESHOOTING
ANOMALY DETECTED POSSIBLE CAUSES CHECKS AND POSSIBLE
SOLUTION
• The chiller does not work
and the main switch (IG)
warning light does not turn
up
• Power failure
• A thermal protection has
been temporary activated
• Check that the power
cable is plugged into the
socket
• Check for disconnected
wires or cables; check the
electric system of the instal-
lation site
• The machine does not
cool (the fan (M), the stirrer
(F) and the compressor (H)
do not work)
• The coolant circuit is le-
aking or has an insucient
operating pressure
• Check the refrigerating
circuit pressure or any lea-
kage of coolant liquid; re-
store the correct operating
conditions
• The refrigerating unit is
working, but the stirrer (F)
is not working
• Stirrer motor overheating
• Stirrer motor breakdown
or power drop
• Check the electric system.
• Replace the stirrer
• The machine does not
cool (the fan (M), and the
compressor (H) are not
working but the stirrer (F) is
working)
• System overheating
• Lacking or insucient
water level in the tank
• Check the probe (E)
• Replace the probe
• Fill the tank
• The machine does not
cool (the compressor (H) is
not working but the fan (M)
and the stirrer (F) are wor-
king)
• Power supply failure on
the compressor
• Compressor overheating
• Compressor failure
• Check the electric con-
nections and the electric sy-
stem of the appliance
• Replace the compressor
• The compressor is wor-
king continuously and does
not stop, causing the beve-
rages to freeze
• Thermostat failure
• Probe (G) failure
• Replace the faulty parts
• Contact Vinservice Custo-
mer Service.
• The machine does not
cool (the fan (M) is not wor-
king, but the compressor
(H) and the stirrer (F) are
working
• Power supply failure on
the fan motor
• Fan motor failure
• Check the electric con-
nections and the electric sy-
stem of the appliance
• Replace the fan motor
• The stirrer (F) motor is
noisy
• Anomaly on bearings or
motor shaft supports
• Pump supports damaged
• Replace the stirrer motor
• Replace the pump
• The chiller works correct-
ly, but no beverages are di-
spensed
• The taps or the pipes are
dirty or clogged
• Clean or replace the clog-
ged parts
N.B. All control and maintenance operations must be
carried out after stopping the machine and discon-
necting the power cable, that is with the plug out of
the socket. All operations, excluding those reported
below, must be carried out by specialized and autho-
rized sta.

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
14
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
15
REV. 17/09/19
TECHNICAL DRAWINGS LIFE 50 TECHNICAL DRAWINGS LIFE 65
387
348
555 96
325
326 356
355
503
585
584
231
96
504
610
410
375
374
306

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
16
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
17
REV. 17/09/19
TECHNICAL DRAWINGS LIFE 100 TECHNICAL DRAWINGS LIFE 115
96
755
630
10
406
250
96
420
439
405 406
406 270 406
612
231 381
144
149
30 365
539
Ø48
107 400
644
428
509
288
405
260
406
73
30

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
18
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
19
REV. 17/09/19
TECHNICAL DRAWINGS LIFE 130 TECHNICAL DRAWINGS LIFE 145
466 465
96
713
466 465
839
465
488
480
657
499
735
262
734 735
418
550
466
360
126

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
20
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
21
REV. 17/09/19
TECHNICAL DRAWINGS LIFE 175 TECHNICAL DRAWINGS LIFE 250
560
710
580
790
80 538 96
714
585
540
855
45

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
22
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
23
REV. 17/09/19
GENERAL WIRING DIAGRAM
LEGEND
1SHUKO PLUG
2LIGHTING SWICH
3MANUAL THERMOSTAT
4PROBE
5TANK
6AGITATOR
7AGITATOR - SOCKET
8AGITATOR - PLUG
9COMPRESSOR - CONNECTIONS
10 COMPRESSOR - PROTECTION
11 COMPRESSOR - RELAY
12 STARTING CAPACITOR
13 FAN MOTOR
14 FAN MOTOR - CONNECTIONS
NOTES
VERDE-GIALLO
GREEN-YELLOW
BLU
BLUE
MARRONE
BROWN
12
3
4
GRIGIO
GRAY
6
7
8
11
5
12
9
10
13
14
In Queensland a gas work licence (hydrocarbon refrigerant) is required
into a refrigeration system.
Caution
that uses fuel gas as a refrigerant such as charging, discharging or breaking
to undertake gas work on the gas system of a gas device in Queensland

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
24
REV. 17/09/19
This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
25
REV. 17/09/19
NOTES NOTES

This document is the property of VINSERVICE and must not be reproduced or transferred to third parties without permission.
26
REV. 17/09/19
GIULIO GUADALUPI MANAGING DIRECTOR
DECLARATION OF CONFORMITY
ACCORDING TO MACHINE DIRECTIVES:
- EN 60335 - 1;
-EN 60335 - 2 -24;
-EN 60335 - 2 - 75;
-2014/35/UE
-2014/30/UE
-2006/42/CE
VINSERVICE S.R.L. - VIA G.FALCONE 26/34. 24050 ZANICA (BG)
Declares under their own responsibility that:
HAVE BEEN DESIGNED AND MANUFACTURED IN CONFORMITY WITH THE SAFETY
REQUIREMENTS
PROVIDED FOR BY THE “EC” MARK REGULATIONS
Zanica, dated: 15/02/2016
LIFE
50 - 65 - 100 - 115 - 130 -145 -175 -250
R290
