lancer S8H Manual

www.lancerbeverage.com
S8H Hi-Carb Superchiller
230V / 50Hz
Installation, Operation &
Service Manual

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 2 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
This page is intentionally left blank

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 3 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
Table of contents
1Specifications and Features ................................................................................................4
1.1 Models...........................................................................................................................4
1.2 Specifications.................................................................................................................4
1.3 Product Features...........................................................................................................4
1.4 Options...........................................................................................................................4
2Superchiller Safety Information...........................................................................................4
2.1 Safety Instructions.........................................................................................................4
2.2 Recognise Safety Alert Symbols...................................................................................5
2.3 Operating.......................................................................................................................5
2.4 Service & Maintenance.................................................................................................5
2.5 Flammable Refrigerants (R290)....................................................................................6
2.6 Carbon Dioxide (CO2)...................................................................................................6
3Installation..............................................................................................................................6
3.1 Receiving.......................................................................................................................7
3.2 Unpacking......................................................................................................................7
3.3 Selecting a Location......................................................................................................7
3.4 Connecting Python........................................................................................................8
3.5 Connecting to water supply...........................................................................................9
3.6 Plumbing the drain and CO2 Exhaust. ...................................................................... 10
3.7 Connecting to CO2 supply......................................................................................... 10
3.8 Filling the waterbath ................................................................................................... 10
3.9 Electrical Connection.................................................................................................. 10
3.10 Commissioning........................................................................................................... 11
3.11 Purge System............................................................................................................. 11
3.12 LED Display Panel...................................................................................................... 11
4Scheduled Maintenance.................................................................................................... 12
4.1 Daily............................................................................................................................ 12
4.2 Quarterly..................................................................................................................... 12
4.3 Half Yearly.................................................................................................................. 12
4.4 Yearly.......................................................................................................................... 13
4.5 Sanitisation of Beverage System............................................................................... 13
5Postmix Circuit Diagram ................................................................................................... 14
5.1 Single Carbonator Superchiller (3 pumps)................................................................. 14
5.2 Twin Carbonator Superchiller (5 pumps)................................................................... 15
6Electrical Circuit Diagram ................................................................................................. 16
16
7Trouble Shooting................................................................................................................ 17
7.1 Refrigeration............................................................................................................... 17
7.2 Troubleshooting –Postmix......................................................................................... 18
8Icebank Probe Check......................................................................................................... 20
9Assembly Diagrams & Parts List ..................................................................................... 21
9.1 Postmix Spare Parts List............................................................................................ 21
9.2 Postmix Assembly Diagram....................................................................................... 21
9.3 Refrigeration Spare Parts List.................................................................................... 23
9.4 Refrigeration Assembly Diagram............................................................................... 23
10 Certificate of Warranty....................................................................................................... 27
11 Manufacturer’s Checklist .................................................................................................. 28

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 4 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
1Specifications and Features
1.1 Models
S8H23LAT Lancer S8H Superchiller with 3 pumps, single Carbonator.
S8H95LAT Lancer S8H Superchiller with 5 pumps, dual Carbonator.
1.2 Specifications
Power Supply 230 Volts / 50 Hz / 15 Amp
Max Current Draw S8H23LAT S8H95LAT
11.8 Amps 13.4 Amps
Standby Energy Consumption 8.9 kW-24h 10.7 kW-24h
Ambient Temperature 2 - 40°C
Refrigeration Capacity 2 x 1440 Watts @ -10C SST
Heat Rejection 3600 Watts Nominal, 4400 Watts Max
Dimensions Width Depth Height
1375 mm 737 mm 834 mm
934 mm w/Castors
Weight S8H23LAT S8H95LAT
Shipping 173 kg 185 kg
Empty 161 kg 173 kg
Operating 341 kg 353 kg
Refrigerant 145 grams R290 x 2
Ice bank Weight 75 kg
Water Bath Capacity 180 litres
Construction Stainless Steel
Compressor Secop x 2
Agitator Motor 12W, 208-230VAC 50/60HZ 1 Phase
Condenser Motor 20W, 208-230VAC 50/60HZ 1 Phase
Ice bank Control Electronic
Carbonation Level Control Electronic
Drink Capacity Continuous 473ml (16 oz) @ 40C/32C/40C
Ambient/Water/Syrup drinks below 4.4°C
4 x 16-oz (473ml) drinks/minute @ 3 oz/second
1.3 Product Features
Energy Optimised R290 Compressor
Variable Speed BLDC Circulation Pumps
Variable Speed EC Agitator Motor
Variable Speed EC Fan Motor
Continuous Low Speed Fan Operation
1.4 Options
• Adjustable Legs (79232218) –height with legs approx 1000mm.
2Superchiller Safety Information
2.1 Safety Instructions
For your personal safety, and that of others working around you please read, understand, and
follow thoroughly all safety instructions included in this manual and on the Superchiller.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 5 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
• Review all applicable WHS (Work Health & Safety) regulations.
• Review all applicable Beverage Dispensing Gas Standards
• Learn how to operate the Superchiller and use the controls properly.
• Do not allow untrained personnel to operate the machine.
• Ensure that the Superchiller is maintained according to service manual instructions.
• Do not allow any unauthorised modifications to the machine.
2.2 Recognise Safety Alert Symbols
The safety alert symbol precedes Warning and Caution notes throughout this manual. To
prevent personal injury or damage to the machine these alerts must be strictly adhered too.
Warning
Alerts to a potentially hazardous situation that if not avoided CANresult in
death, serious injury.
Caution
Alerts to a potentially hazardous situation that if not avoided MAY result in
injury or equipment damage.
Warning
Risk of fire.
2.3 Operating
Warning
Superchillers are intended for indoor operation only;do not operate outside
unless suitably protected by a weatherproof enclosure. This appliance is not
suitable for installation in an area where a water jet could be used.
Caution
This appliance is not intended for use by persons (including children)with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
Caution
This appliance is intended to be used in commercial applications such as
restaurants or similar.
2.4 Service & Maintenance
Caution
Installation of Superchiller and service work should only be performed by fully
trained & certified Electrical, Plumbing, & Refrigeration Technicians.
In Queensland a gas work licence (hydrocarbon refrigerant) is required to
undertake gas work on the gas system of a gas device in Queensland that
uses fuel gas as a refrigerant such as charging,discharging or breaking into a
refrigeration system.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 6 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
Warning
Carbonator contains CO2gas and water under pressure. De-pressurise before
performing any work on the system.
Warning
ALL WIRING AND PLUMBING MUST CONFORM TO LOCAL AND
NATIONAL CODES.
Warning
SUPERCHILLER MUST BE ISOLATED FROM ELECTRICAL SUPPLY
BEFORE COMMENCING ANY SERVICE OR MAINTENANCE WORK.
2.5 Flammable Refrigerants (R290)
This is a compression type appliance with R290 (Propane) refrigerant which is CFC-Free,
environmentally friendly, but it is flammable.
Warning
Keep ventilation openings, in the enclosure, or built-in structure, clear of
obstruction.
Warning
Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer
Warning
Do not damage the refrigeration circuit.
In Queensland a gas work licence (hydrocarbon refrigerant) is required to
undertake gas work on the gas system of a gas device in Queensland that
uses fuel gas as a refrigerant such as charging,discharging or breaking into a
refrigeration system.
Warning
Use only genuine Hoshizaki Lancer replacement components or parts certified
by Hoshizaki Lancer.
2.6 Carbon Dioxide (CO2)
Warning
The Superchiller uses a CO2 (Carbon Dioxide) supply. CO2is a heavier than
air, colourless, non-combustible gas with a faintly pungent odour.
Personnel exposed to high concentrations of CO2gas will experience tremors,
which are followed rapidly by loss of consciousness and suffocation.
If a CO2gas leak is suspected, immediately ventilate the contaminated area
before attempting to repair the leak.
3Installation
Warning
To avoid personal injury or damage, do not attempt to lift a Superchiller without
help. Use of a mechanical lift is recommended.
(NOTE: Empty S8H Superchiller weight: 175kg)

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 7 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
3.1 Receiving
Each unit is completely tested under operating conditions and thoroughly inspected before
shipment. At time of shipment, the carrier accepts the unit and any claim for damage(s) must
be made with the carrier. Upon receiving units from the delivering carrier, carefully inspect
shipping crate for visible indication(s) of damage. If damage exists, have carrier note damage
on bill of lading and file a claim with the carrier.
3.2 Unpacking
Caution
The use of gloves is recommended to protect hands from potential injury
from sharp edges. The Superchiller must always be handled in a horizontal
position.
Carefully unpack the Lancer S8H Superchiller from the shipping carton, remove the wooden
base.
To install the castors, lift the chiller with
appropriate help and screw the castors into the
mounting plates provided. DO NOT tilt the
chiller more than 45 degrees or lay chiller on
its side.
3.3 Selecting a Location
Warning
Superchillers are intended for indoor operation only; do not operate outside
unless suitably protected by a weatherproof enclosure.
This appliance is not suitable for installation in an area where a waterjet could
be used. Superchilllers are not to be installed in a kitchen.
Warning
When positioning the appliance, ensure the supply cord is not trapped or
damaged.
Do not locate multiple portable socket-outlets or portable power supplies at
the rear of the appliance.
Caution
The Superchiller is not suitable for use in subfreezing temperatures.
To prevent damage to the water supply line, turn off and drain unit when air
temperature is below zero.
Caution
The Superchiller is only to be installed in locations where its use and
maintenance is restricted to trained personnel.
Warning
The Superchiller must not be confined to an area less than 18m3and without
ventilation.
• The S8H Superchiller should be located in a well-ventilated, firm, level location close to
dispenser, water and electrical supplies, with easy access for servicing
• Ensure sufficient clearance around Superchiller to allow good fresh air circulation through
the condenser –allow at least 200mm at rear and sides.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 8 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
• Installation should only be performed by a qualified and competent technician.
Caution
Superchiller operational weight is 355kg; ensure that all supporting structures
are certified for this loading by a registered Mechanical Engineer. If using a
rack or frame mount then it must be securely fixed to floors or walls.
3.4 Connecting Python
Caution
NOTE: The S8H Superchiller is rated to operate with a maximum of 30m
of python connected at 40°C, 45m at 32°C –per carbonation circuit.
Exceeding manufacturer’s ratings may cause warm drink temperatures,
erratic dispensing valve behaviour and void machine warranty.
Connect the Python to Chiller and Dispenser.
Tube Markings Colour Stripe
Water Supply Beige
Water Return White
Soda Supply - A Maroon
Soda Return - A Black
Soda Supply –B Maroon (Solid)
Soda Return –B Black (Solid)
If Equipped With Syrup Coils:
1----1----1 Blue
2----2----2 Violet
3----3----3 Green
4----4----4 Yellow
5----5----5 Grey
6----6----6 Orange
7----7----7 Brown
8----8----8 Red
Ensure sufficient clearance for air flow.
Do not block or obstruct airflow into the
machine.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 9 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
Superchiller can be supplied with 5 pumps, dual carbonator, or 3 pumps single carbonator;
python should be connected to Chiller as follows:
5 Pump 3 Pump
SODA
RETURN A
WATER
RETURN
SODA
RETURN B
SODA
RETURN A
WATER
RETURN
SODA
SUPPLY A
WATER
SUPPLY
SODA
SUPPLY B
SODA
SUPPLY A
WATER
SUPPLY
Important: Ensure lines from python to Superchiller connections are insulated to prevent
condensation.
Note: For additional Soda reserve on short python lengths used in high volume accounts, it
may be necessary to extend the soda circuit by connecting the 2 spare lines in the python onto
the soda return line (i.e. double pass of soda circuit out and back from dispense point to soda
return).
3.5 Connecting to water supply
Warning
The connections to the mains water supply must be made in accordance
with the Plumbing Code of Australia and in accordance with AS / NZS
3500.1 and AS / NZS 3500.2. The dual check valve (backflow prevention)
supplied with this unit must be connected between the main supply
outlet and water inlet of appliance.
• Using appropriate tubing and fittings connect a minimum 10mm water supply line from
Superchiller carbonator pump inlet to a filtered, regulated water supply. (See Postmix circuit
diagram page 11-13). Installation in accordance with AS/NZS 3500.1 and AS/NZS 3500.2.
• Turn on water supply, check for leaks, adjust water regulator to 172-345kpa.
• Purge the carbonator of air by lifting the relief valve until water discharges from the CO2
exhaust port. For dual carbonators, repeat this operation for each carbonator.
Caution
Maximum water supply pressure to be 345 kpa.
Normal operating water temperature should be within 7°C to 32°C.
S
O
D
A
S
U
P
P
L
Y
S
O
D
A
R
E
T
U
R
N
1
0
m
m
'
U
'
B
E
N
D
P
Y
T
H
O
N

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 10 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
3.6 Plumbing the drain and CO2 Exhaust.
The waterbath drain / overflow tube should be plumbed to a suitable drain, installation in
accordance with the Plumbing Code of Australia and AS/NZS 3500.1 and AS/NZS 3500.2.
The 6mm tube labelled as CO2 EXHAUST should be plumbed to a well-ventilated safe outside
area.
3.7 Connecting to CO2 supply
Warning
As carbon dioxide (CO2) displaces oxygen; prevention of CO2leaks is
paramount. If a leak is suspected, immediately ventilate the
contaminated area, before attempting repairs.
• Connect CO2 supply line from regulator to each CO2 IN line on the chiller. There may be 2
lines to connect for 5 pump models.
• Adjust CO2 Regulator supplying Carbonator to 550 kpa.
• Turn on CO2 supply and check all connections for leaks. Repair any leaks before
continuing.
3.8 Filling the waterbath
Warning
Disconnect the power before opening the top cover for filling the water
bath.
When filling the water tank, care must be taken to not splash water onto
the electrical components
• Check that the Superchiller is unplugged from the mains electrical supply
• Remove the top panel.
• Fill the water tank with water up to the ‘FILL LEVEL’ marked on the inside of the tank.
• Refit the top panel
NOTE: Proper icebank control function depends on the conductivity of the water used. The
Electrical Conductivity should be between 100 and 300 uS/cm. Below 100 uS/cm the compressor
may not work properly, above 300 uS/cm the lines may freeze.
3.9 Electrical Connection
Warning
To prevent possible electrical shock or extensive damage to the unit, the
appliance must be connected with the flexible cord supplied with the
appliance to an appropriate electrical outlet socket installed in
accordance with local codes and regulations i.e. AS/NZS 3000.
Warning
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons with a replacement cord
available from Hoshizaki Parts/Service Centres.
• It is recommended that the Superchiller is connected to a separate 230VAC 50Hz 15 Amp
electrical supply, protected by an appropriate circuit breaker and Residual Current Device.
Check the nameplate on the Superchiller for the electrical supply requirements.
• The service of a licensed electrician may be required to ensure the installation is in
accordance with the local codes and regulations.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 11 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
3.10 Commissioning
• Ensure the Pump Switches are in the OFF position.
• Connect Superchiller power supply lead to an appropriate 3 pin socket outlet and switch the
main power on. The condenser fan and agitator motor should start immediately. There is a 3-
minute delay from initial power on before the compressor starts.
• The Power On and Waterbath > 5°C LED’s on the front panel should be illuminated.
• The Waterbath > 5°C LED should go out approximately after 60-90 minutes.
• When the ice bank is fully formed (approx. 4 -5 hours) the compressors will cycle off, but the
agitator and fan will run continuously.
• After the Superchiller has cycled off, place the Pump Switches to the ON position to activate
the carbonator and recirculation pumps.
3.11 Purge System
Progressively activate each dispensing valve or Bargun connected to the Superchiller systems
until an uninterrupted flow of soda, water (where applicable), and syrup pours from each
dispenser.
3.12 LED Display Panel
FUNCTION
DESCRIPTION
POWER
Indicates connection to mains utility. Is the only LED lit under normal
operating conditions.
LOW CO2
(OPTIONAL)
If equipped indicates CO2 pressure has dropped below 415 kPa (60 psi)
and in most cases indicates a depleted CO2 cylinder. Replace CO2
cylinder and check regulator set to 560 kPa (80 psi).
LOW H2O
(OPTIONAL)
If equipped indicates incoming water pressure has dropped below 140
kPa (20 psi) for longer than 3 minutes and switched the pumps off.
Check incoming water supply for closed cocks, pinched or blocked lines,
dirty / clogged water filter etc.
CARBONATOR
TIMEOUT
The carbonator has run past its timeout setting (default = 5 minutes).
This may indicate a blockage, a water supply problem, broken pipe
downstream or other related issue. Find and repair the problem. Cycle
power at the wall to reset.
WATERBATH > 5C
Should remain off during normal operations. If illuminated then either
there is an issue with the refrigeration, agitation or severe use over the
capacity of the chiller. Investigate and resolve the issue.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 12 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
HIGH
CONDENSING
TEMPERATURE
If yellow then unit is operating at the high end of its design capacity. If
red then is operating at its upper design limit. If flashing red then has
exceeded its design limit and shut down the refrigeration system.
Possible causes are a dirty/blocked condenser, failed condenser fan, or
ambient temperatures exceeding the design limits. Find and resolve the
issues. Cycle power at the wall / power on switch to reset.
CHANGE WATER
FILTER
There is an onboard timer that notifies the operator when approximately 1
year has elapsed since the last filter change. Check status of water
filters and correct as required. Reset is by momentarily pushing a hidden
button on the lower right side of the display panel.
FUNCTION LED
Possible freeze-up. Ice has grown over the temperature probe near the
icebank control. Cycle Power On switch to reset.
4Scheduled Maintenance
The following Superchiller routine maintenance should be performed at the intervals listed.
4.1 Daily
Cleaning/Sanitising
Maintain good food hygiene practises: Wipe up spills, throw away empty boxes and other
rubbish, ensure proper stock rotation, remove and wash all dispensing nozzles, ensure work
areas are clean and tidy.
The Superchiller supplies soda water to the dispensing valves/barguns. To ensure optimum
drink quality and system performance at all times please follow cleaning and sanitising
procedures for the dispensing valves/barguns recommended by the valve/bargun
manufacturer.
Checking CO2 Supply
Ensure that the contents gauge on the CO2 Regulator reads higher than 1400kpa on the dial. If
it does not, then the CO2 cylinder is empty and must be changed using safe working practices.
Warning
To avoid personal injury and/or property damage, always secure
the CO2cylinder with a safety chain to prevent it from falling over;
and use appropriate protective equipment (as defined in Clause
3.3.2 of AS 5034) to handle cylinders.
Should the valve become accidentally damaged or broken off, a
CO2cylinder can cause serious personnel injury.
4.2 Quarterly
The Superchiller should be connected to a filtered water supply. To ensure optimum drink
quality and system performance, supply water filters should be replaced every 3 months or as
recommended by the filter supplier.
4.3 Half Yearly
• Remove & Clean condenser filters on the Superchiller. When the environment is dirty and
dusty, the interval between cleaning the filters may need to be reduced. Clean condenser
with low pressure compressed air. When using compressed air always direct air from the
fan side through condenser. Remove all dust and foreign particles from refrigeration deck.
Caution
When using compressed air always wear safety glasses.
• Check that the water is level with the top of the overflow tube. Add water if necessary.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 13 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
• Open carbonator relief valve to purge CO2 and check leakage, close relief valve after
checking.
4.4 Yearly
Water bath and recirculation pump inspection.
• Isolate Superchiller from power supply by switching off at socket.
• Thaw the bank of ice formed in the tank. Empty the water from the tank with a suction pump
or drainage pipe.
• Inspect coils and agitator in water bath for algae or slime accumulation. Clean as necessary
using a soft brush, rinse with clean water.
• Check recirculation pump strainers for accumulation, replace if necessary.
• Fill tank with clean water to level indicated on the ‘FILL LEVEL’ plaque.
• Check for build-up on and correct placement of Icebank Probe. Clean as required.
• Commission and purge system as per Section 3 of this manual.
4.5 Sanitisation of Beverage System
To maintain optimum quality of dispensed product each Superchiller and its associated
beverage system components must be thoroughly cleaned and sanitised annually.
Prepare sanitising solution
Prepare sanitising solution in accordance with the manufacturer’s written recommendations
and safety guidelines.
Do not use preparations with greater than 200ppm chlorine for greater than 30 minutes. Rinse
thoroughly with clean potable water.
Sanitising BIB System
• Remove all disconnects from BIB containers.
• Immerse all disconnects in warm water and clean using a nylon bristle brush. Rinse with
clean water.
• Prepare sanitising solution according to manufacturer’s instructions.
• Attach sanitising fittings to BIB disconnects, if sanitising fittings are not available cut fittings
from empty BIB bags.
• Immerse all sanitising fittings with attached BIB disconnects in bucket of sanitising solution.
Operate all dispensing valves until the sanitising solution flows from the valve. Allow
sanitiser to remain in lines for fifteen (15) minutes.
• Immerse all sanitising fittings with attached BIB disconnects in bucket of clean water.
Operate all dispensing valves until all sanitiser has been flushed from the system.
• Remove sanitising fittings from BIB disconnects and re-connect disconnects to appropriate
BIB's. Operate dispensing valves until syrup flows freely.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 14 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
5Postmix Circuit Diagram
5.1 Single Carbonator Superchiller (3 pumps)

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 15 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
5.2 Twin Carbonator Superchiller (5 pumps)

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 16 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
6Electrical Circuit Diagram

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 17 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
7Trouble Shooting
7.1 Refrigeration
TROUBLE
CAUSE
REMEDY
Compressor will not
start.
Power Failure.
High condensing temperature (out on
liquid line temp sensor)
Ice bank control faulty contacts not
closing.
Check start mechanism components.
Thermal overload faulty, open circuit,
compressor seized.
Check forblown fuse, supply cord pulled
out or supply outlet turned off.
Clean condenser/filter; clear obstructed
airflow; check fan operation; ventilate room.
Cycle power to reset.
Check Ice bank control using Procedure in
Section 8. Replace if defective.
If faulty, replace e.g. capacitors, start
relays.
Replace compressor, check condenser,
check power supply, evacuate system and
if necessary fit burnout drier to industry
standards.
Compressor short
cycling on thermal
overload (frequent
starting and stopping
of the compressor
while ice bank control
contacts remain
closed).
Liquid Line temperature probe failure.
Dirty condenser.
Restricted air flow over unit.
Low supply voltage.
Defective thermal overload.
Check wiring connections.
Fan motor defective.
Check probe location and connection.
Replace if necessary.
Clean condenser of all lint and dirt.
Check for air restriction to condenser.
Check with voltmeter.
Replace compressor.
Tighten if loose.
Replace motor(s)
Product too warm
Ice bank control defective
(permanently open circuit).
Low refrigerant charge.
Check agitator motor, seized or fused.
Location too hot.
Incoming water temperature too hot.
Exceeds chiller capacity.
Check Icebank control using procedure in
Section 8. Replace control or probe if
defective.
Leak check, repair leak, charge with correct
amount of refrigerant.
Replace if not working.
Ventilate room or relocate chiller.
Find heat source and mitigate.
Consider upsizing or multiple chillers;
reduce python length.
Compressor runs too
long or doesn’t cycle.
Location too hot.
Exceeds chiller capacity.
Loss of refrigerant.
Condenser clogged.
Fan not operating.
Ventilate room or relocate chiller.
Consider upsizing or multiple chillers;
reduce python length.
Leak check and repair.
Clean off dust, lint, grease, etc.
Remove obstruction or replace motor.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 18 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
7.2 Troubleshooting –Postmix
TROUBLE
CAUSE
REMEDY
Rusty appearance
and/or metallic taste to
water.
Poor water supply - contaminated.
Variable causes. Check with potable water
filter specialist for remediation.
CO2gas or water
escapes from
pressure relief valve.
(Observed
from CO2exhaust)
CO2pressure too high.
Pump motor will not stop.
Inadequate water supply.
Lines too small or restricted.
Check CO2 pressure relief valve. Bleed gas
by opening and closing the relief valve - set
CO2 to 550 kpa.
Check carbonator control using procedure in
Section 8. Replace control or probe if
defective.
If strainer and filter are clear and line valves
are fully open, noisy pump operation
indicates insufficient water supply. Minimum
watersupply is 172 kpa flowing pressure.
Carb Pump Times out.
(LED on control panel
illuminated)
Insufficient water supply.
Higher than expected demand.
Tube burst / valve open
downstream.
Blocked vented backflowpreventer.
Coil freeze-up
Worn / defective pump.
Failed carbonator probe circuit.
Check filters, taps and supply tubing for
blockages and rectify. Minimum water
supply is 172 kPa flowing pressure.
Move timeout jumper to next higher time
interval. See electrical diagram.
Check and rectify.
Inspect, repair or replace as required.
Check prechill coil for ice accumulation.
Defrost, inspect icebank probe.
Replace pump.
Check carbonator control using procedure in
Section 8. Replace control or probe if
defective.
Poor carbonation
(low CO2volume).
Flooded carbonator.
Dirty water supply.
CO2 pressure too low.
Poor quality paper cups.
Dirty or greasy glasses.
Improperly drawn drink.
Check carbonator control using procedure in
Section 8. Replace control orprobe if
defective.
Check filters.
Check CO2 pressure at regulator. Should be
set between 550 kpa. CO2 inlet check valve
stuck, shut or blocked, repair or replace.
Purchase better quality cups.
Wash all glasses.
Open faucet all the way and draw against
side of glass or cup.
Pump leaks from shaft
seal.
Worn pump seals.
Replace pump.
Pump will not run.
Power failure or low voltage.
Out on Low Water Pressure LED.
Check fuses. Check power supply.
Check all incominglines, filters, taps and
regulators for blockages.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 19 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
Faulty low pressure switch (if fitted).
Defective motor.
Locked up pump. Motor has cut out
on overload.
Carbonator flooded –filled
completely with water.
Ensure of adequate water supply. Switch
should close above 140 kpa. Replace if
defective.
Replace motor.
Replace pump.
Excessive mains water pressure - must be at
least 175 - 345 kpa max.(Install water
pressure regulator if necessary)
Empty CO2 cylinder. Replace and check
reulator settings to 550 kPa
Faucet delivers CO2
gas continuously.
Low water supply.
Excessive CO2 Pressure.
See: Pump(s) Will Not Run
Check Carbonator CO2pressure regulator for
creeping. It should be set at 550 kpa.

S8H Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 20 of 28
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000036
Images are for illustration purposes only as product may vary. No. 111 –4 Apr 22
8Icebank / Carbonator Probe Checks
Warning
230VAC is present on PC Board.
Work should only be performed by fully trained & certified
Electrical, Plumbing, & Refrigeration Technicians.
1.
Remove the ice bank probe at the PC Board.
2.
Jumper the three terminals as shown. Use a spare male
connector with wiring if available. The compressor relay
should close and refrigeration system start.
(Simulates water covering all probes)
3.
With refrigeration system operating (compressor relay
energised) remove the jumper from the centre terminal.
Refrigeration system should continue to operate.
(Simulates ice growth over green probe. Water still
contacting red and black probes)
4.
Remove the remaining jumper. The compressor relay should
open and the refrigeration system should stop.
(Simulates ice growth over the probes)
8.1 Carbonator Probe Check
1.
Remove the carbonator probe connections from terminals J24, J25 &
J26. The carbonator pump relay should close.
(Simulates no water between ground (carbonator tank) and low level
probe)
2.
With carbonator pump operating connect alligator jumper from
terminal J25 to terminal J26. Carbonator pump should continue to
operate.
(Simulates water covering low level probe.)
3.
With carbonator pump operating, connect alligator lead to terminal
J24. Carbonator pump should stop.
(Simulates water over low & high level probes)
4.
Carbonator pump will not restart until alligator clips are removed from
J24 & J25.
(i.e. Water level drops below low level probe)
